2012 TOYOTA PRIUS PLUG-IN check engine light

23
3. Basic operation
PLUG-IN QG_U (OM47747U)
How to operate the power (ignition) switch
■Starting the hybrid system
Check that the charging cable is disconnected.
Check that the parking brake is set.
Firmly depress the brake pedal.
Check that the “POWER” switch indicator turns green. If the indica-
tor does not turn green, the hybrid system cannot be started.
When the shift position is N, the hybrid system cannot start. Shift the
shift position to P when starting the hybrid system.
Press the “POWER” switch.
The hybrid system can be started
from any “POWER” switch mode.
Continue depressing the brake
pedal until the hybrid system is
completely started.
Check that the “READY” indicator is on.
If the “READY” indicator changes from a flashing light to a solid light
and the buzzer sounds, the hybrid system is starting normally.
The vehicle will not move when the “READY” indicator is off.
The vehicle can move when the “READY” indicator is on even if the
engine is stopped. (The gasoline engine starts or stops automatically
in accordance with the state of the vehicle.)
STEP1
STEP2
STEP3
STEP4
STEP5

239
2-1. Driving procedures
PRIUS PHV_OM_OM47818U_(U)
2
When driving
Check that the “READY” indicator is on.
If the “READY” indicator changes from a flashing light to a solid
light and the buzzer sounds, the hybrid system is starting nor-
mally.
The vehicle will not move when the “READY” indicator is off.
The vehicle can move when the “READY” indicator is on even if
the engine is stopped. (The gasoline engine starts or stops auto-
matically in accordance with the state of the vehicle.)
■Stopping the hybrid system
St op th e veh i cle co mp lete ly.
Set the parking brake. (→P. 2 5 5 )
Shift the shift position to P.
(→P. 2 4 8 )
Check that the shift position
indicator shows P. (→P. 2 4 5 )
Press the “POWER” switch.
The hybrid system will stop.
Slowly release the brake pedal and check that the indicator
on the “POWER” switch is off.
STEP 5
STEP 1
STEP 2
STEP 3
STEP 4
STEP 5

261
2-2. Instrument cluster
PRIUS PHV_OM_OM47818U_(U)
2
When driving
CAUTION
■To p r e v e n t a n a c c i d e n t
NOTICE
■To p r e v e n t d a m a g e t o t h e e n g i n e a n d i ts c o m p o n e n ts
The engine may be overheating if the high coolant temperature warning light
comes on or flashes. In this case, immediately stop the vehicle in a safe
place, and check the engine after it has cooled completely. (→P. 6 0 0 )
Do not place anything or attach a sticker
in front of the instrument cluster. The item
may obscure or obstruct the display, or
could reflect off the display, possibly
causing an accident.
Instrument cluster

269
2-2. Instrument cluster
PRIUS PHV_OM_OM47818U_(U)
2
When driving
■Reading Hybrid System Indicator
When EV Mode
Charge area
EV driving area
Power area
As shown below, the driving conditions of the vehicle can be con-
firmed by checking the status of the indicator bar.
*1: The images are examples only, and may vary slightly from actual condi-
tions.
*2: If the gasoline engine is operated (for example when driving at high
speeds or using the heater), the EV indicator may turn off even if the bar
is in the EV driving area. (→P. 4 0 )
Multi-information display*1
Charge area:
Shows that energy is being
recovered via the regenera-
tive braking system. (→P. 3 4 )
EV driving area:
Shows that the vehicle is
being powered only by elec-
tric motor
(traction motor).*2
Power area:
Shows that the gasoline
engine is used as auxiliary
power (during full power driv-
ing etc.).

270
2-2. Instrument cluster
PRIUS PHV_OM_OM47818U_(U)
When HV Mode
Charge area
Eco area
Power area
Hybrid Eco area
As shown below, the driving conditions of the vehicle can be con-
firmed by checking the status of the indicator bar.
*1: The images are examples only, and may vary slightly from actual condi-
tions.
*2: The gasoline engine will automatically stop and restart under various
conditions.
Hybrid System Indicator*1
Charge area:
Shows regenerative charging.
(→P. 3 9 )
Hybrid Eco area:
Shows that gasoline engine
power is not being used very
often.*2
Eco area:
Shows that the vehicle is
driven in Eco-friendly.
Power area:
Shows that the driving power
is more than the upper limit of
Eco driving (during full power
driving etc.).

672
Alphabetical index
PRIUS PHV_OM_OM47818U_(U)
Engine
Accessory mode....................240
Compartment ........................459
Hood......................................442
How to start the hybrid
system ................................238
Identification number .............611
If the hybrid system will not
start .....................................588
Ignition switch........................238
Overheating...........................600
“POWER” switch ...................238
Engine coolant
Capacity ................................617
Checking ............................... 464
Preparing and checking
before winter ....................... 349
Engine/power control
unit coolant
Capacity ................................617
Checking ............................... 464
Preparing and checking
before winter ....................... 349
Engine oil
Capacity ................................614
Checking ............................... 460
Preparing and checking
before winter ....................... 349
Enhanced VSC .........................328
EPS............................................328
EV driving ratio indicator ........271
EV driving range ................58, 268
Event data recorder ...................25
EV/HV mode selection
switch .......................................37
Floor mats ................................ 401
Fluid
Brake..................................... 619
Washer.................................. 469
Fog lights
Replacing light bulbs ............. 507
Switch ................................... 298
Wattage................................. 620
Foot lights ................................ 382
Front fog lights
Replacing light bulbs ............. 507
Switch ................................... 298
Wattage................................. 620
Front passenger occupant
classification system ............ 198
Front passenger’s seat belt
reminder light ........................ 537
Front seats
Adjustment ............................ 146
Front side marker light
Replacing light bulbs ............. 507
Wattage................................. 620
Front turn signal lights
Replacing light bulbs ............. 507
Switch ................................... 254
Wattage................................. 620
Fuel
Capacity ................................ 613
Fuel gauge ............................ 257
Information ............................ 621
Refueling ............................... 174
Type ...................................... 621
Fuel door .................................. 174
Fuel filler door .......................... 174
Fuses ........................................ 495
F
