2012 Seat Leon 5D sensor

187
Intelligent technology
If the warning lamp remains on and the driver indication appears, the power
steering could be faulty.
Do not continue driving. Seek specialist assistance.  (in yellow) Steering: System fault! You may continue driving.
If the warning lamp comes on, the steering could react with more difficultly
or more sensitivity than normal. In addition, when driving in a straight line
the steering wheel may be off-centre.
Drive slowly to a specialised workshop and have the fault repaired.  (in yellow) Steering lock: fault! Go to an Official Service
The electronic steering lock is malfunctioning.
Go to a specialised workshop as soon as possible and have the fault re-
paired.
WARNING
Take it immediately to a specialised workshop and have the fault re-
paired: risk of accident!
Note
If a  red or  yellow warning lamp come on briefly, you can continue driv-
ing. Power Management
This system helps to ensure reliable starting
The power management controls the distribution of electri-
cal energy and thus helps to ensure that there is always
enough power available to start the engine.
If a vehicle with a conventional electrical system is left parked for a long
time, the battery will gradually lose its charge because certain electrical
equipment (such as the electronic gearbox lock) continues to draw current
even when the ignition is off. In some cases there may not be enough power
available to start the engine.
Your vehicle is equipped with an intelligent power management system to
control the distribution of electrical energy. This significantly improves relia-
bility when starting the engine, and also prolongs the useful life of the bat-
tery.
The main functions incorporated in the power management system are bat-
tery diagnosis , residual current management and dynamic power manage-
ment.
Battery diagnosis
The battery diagnosis function constantly registers the condition of the bat-
tery. Sensors detect the battery voltage, battery current and battery temper-
ature. This enables the system to calculate the current power level and
charge condition of the battery.
Residual current management
The residual current management reduces power consumption while the ve-
hicle is parked. It controls the supply of power to the various electrical com-
ponents while the ignition is switched off. The system takes the battery di-
agnosis data into consideration. 
Safety FirstOperating instructionsPractical TipsTechnical specifications

198Care and cleaning
Care and cleaning
General information
Regular care helps to maintain the value of the vehicle.
Regular and careful care helps to maintain the value of the vehicle. This may
also be one of the requirements for upholding any warranty claims in the
event of corrosion or paint defects.
SEAT Official Services and specialist retailers carry stocks of suitable car
care materials. Please follow the instructions for use on the packaging.
WARNING
● Cleaning products and other materials used for car care can be dam-
aging to your health if misused.
● Always keep care products in a safe place, out of the reach of chil-
dren. Failure to comply could result in poisoning.
For the sake of the environment
● If possible, use environmentally friendly products.
● The remains of car care products should not be disposed of with ordina-
ry household waste. Care of vehicle exterior
Washing the vehicle
The longer substances such as insects, bird droppings, resinous tree sap,
road dirt, industrial deposits, tar, soot or road salt and other aggressive ma-
terials remain on the vehicle, the more damage they do to the paintwork.
High temperatures (for instance due to strong sunlight) further intensify the
corrosive effect.
After the period when salt is put on the roads it is important to have the un-
derside of the vehicle washed thoroughly.
Automatic car washes
Before going through a car wash, be sure to take the usual precautions such
as closing the windows and roof. If the vehicle has special accessories such
as spoilers or a roof carrier or two-way radio aerial, etc., it is advisable to
consult the car wash operator.
It is best to use a car wash without revolving bristles if possible.
Washing the vehicle with a high pressure cleaner
When washing the vehicle with a high-pressure cleaner, always follow the
operating instructions for the equipment. This applies particularly to the op-
erating pressure and the spraying distance. Do not hold the nozzle too
close to soft materials such as rubber hoses or seals. The same applies to
the parking aid sensors*, which are located in the rear bumper.
Do not use a nozzle that sprays the water out in a direct stream or one that
has a rotating jet for forcing off dirt. 

199
Care and cleaning
Washing the car by hand
When washing the car by hand, use plenty of water to soften the dirt first,
and rinse off as well as possible.
Then clean the vehicle with a soft sponge, glove or brush using only slight
pressure. You should start on the roof and work down. Special car shampoo
should only be used for very persistent dirt.
Rinse the sponge or glove thoroughly and often.
Wheels, sills and similar should be cleaned last. Use a second sponge for
this.
WARNING
● The vehicle should only be washed with the ignition switched off.
Failure to do so could result in an accident.
● Do not clean the underside of chassis, the inside of wheel arches or
wheel trims without protecting your hands and arms. You may cut your-
self on sharp-edged metal parts. Otherwise, there is a risk of sustaining
cuts.
● When washing the car during the winter season: water and ice in the
brake system can reduce braking effectiveness: risk of accident!
CAUTION
● Do not wash the vehicle in direct sunlight – otherwise the paint can be
damaged.
● Do not use sponges, abrasive household sponges or similar to clean in-
sect remains. This could damage the surface.
● Clean off stubborn dirt (insects, etc.) from the headlights at regular in-
tervals, for instance when filling the fuel tank. The headlights should only
be washed with water, do not wipe them with a dry cloth or sponge. It is
best to use soapy water. ●
Never wash tyres with a jet that sprays the water out in a direct stream.
This could damage the tyres even if the spray is kept at a distance and only
used for a very short time.
● Before washing the vehicle in an automatic car wash, please make sure
to retract the exterior mirrors to prevent them from being damaged. Electri-
cally retractable exterior mirrors must not be folded in or out by hand. Al-
ways use the electrical power control.
For the sake of the environment
The car should only be washed in special wash bays. This prevents oily wa-
ter from getting into the public drains. In some places, washing vehicles
anywhere else may be prohibited. 
Sensors and camera lenses
● Use a small brush to remove snow and a de-icer spray to remove ice.
● Clean the sensors with a solvent-free product and a soft, dry cloth.
● Moisten the camera lens using a standard alcohol-based glass cleaning
agent and clean the lens with a dry cloth. The area in front of the active
Lane Assist* lens area is normally cleaned with the windscreen washer.
CAUTION
● When you clean the vehicle with a pressure washer,
– stay a suitable distance from the sensors on the front and rear bump-
ers.
– Do not clean the camera lenses or surrounding area with the pressure
washer.
● Never use warm or hot water to remove snow and ice from the reverse
camera lens, as it could crack the lens.
● Never use abrasive cleaning agents on the lens. 
Safety FirstOperating instructionsPractical TipsTechnical specifications

251
Fuses and bulbs
No.Electrical consumerAmpsF29Vacant-F30Vacant-F31Left lights40F32Parking aid control unit7,5F33Airbag5
F34Reverse switch, clima sensor, electrochromic
mirror7,5
F35Diagnosis, headlight control unit, headlight ad-
juster10
F36Front camera10F37Vacant-F38Vacant-F39Right door30F4012V socket20F41Steering column20F42Central locking40F43Interior light30F44Vacant-F45Vacant-F47Rear window wiper15F49Starter motor; clutch sensor5F51Vacant-F53Heated rear window30
The electric windows and electric seats* are protected by circuit breakers.
These switch on again automatically after a few seconds when the overload
(caused for example by frozen windows) has been corrected.
Note
Please note that the above list, while correct at the time of printing, is sub-
ject to alterations. 
Fuses on left side of engine compartment
No.Electrical consumerAmpsF1Vacant-F2ESC control unit40F3Engine control unit (diesel/petrol)15/30F4Engine sensors5/10F5Engine sensors7,5/10F6Brake light sensor5F7Engine power supply5/10F8Lambda probe10F9Engine5/10/20F10Fuel pump control unit15/20F11PTC40F12PTC40F13Automatic gearbox control unit15/30F15Horn15F16Fuel pump control unit20F17Engine control unit7,5F18Terminal 30 (positive reference)5F19Front windscreen washer30F20Alarm horn10F22Engine control unit5F23Starter motor30 
Safety FirstOperating instructionsPractical TipsTechnical specifications

Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185Brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . 217
Brake servo . . . . . . . . . . . . . . . . . . . . . . . . . 185
New brake pads . . . . . . . . . . . . . . . . . . . . . 185
Braking Brake assist system . . . . . . . . . . . . . . . . . . 183
Moving off on a hill . . . . . . . . . . . . . . . . . . 148
C
Carbon components: Cleaning . . . . . . . . . . . . 200
Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
Care of vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 198
Care (paint care) . . . . . . . . . . . . . . . . . . . . . . . . 200
Catalytic converter . . . . . . . . . . . . . . . . . . . . . . 190
CD-ROM reader (navigation) . . . . . . . . . . . . . . 130
Central locking Anti-theft alarm . . . . . . . . . . . . . . . . . . . . . . 93
Central locking switch . . . . . . . . . . . . . . . . . 93
Electric windows . . . . . . . . . . . . . . . . . . . . . 101
Programming . . . . . . . . . . . . . . . . . . . . . . . . 92
Remote control key . . . . . . . . . . . . . . . . . . . . 91
Selective unlocking system . . . . . . . . . . . . . 91
Sliding/tilting sunroof . . . . . . . . . . . . . . . . 101
Central locking system . . . . . . . . . . . . . . . . . . . . 86 Manual locking in an emergency . . . . . . . . 97
Rear lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Cetane number (Diesel fuel) . . . . . . . . . . . . . . 207
Changing Windscreen and rear window wiper blades . .221
Changing a bulb . . . . . . . . . . . . . . . . . . . . . . . . 252 Bulb sizes . . . . . . . . . . . . . . . . . . . . . . . . . . 252 Changing gear
Engaging gears (manual gearbox) . . . . . . 152
Manual gearbox . . . . . . . . . . . . . . . . . . . . . 152
Changing main headlight main beam . . . . . . . . . . . . . . . . . . . . . . . . . 255
turn signal . . . . . . . . . . . . . . . . . . . . . . . . . . 255
Changing main headlight bulbs daylight bulb . . . . . . . . . . . . . . . . . . . . . . . 254
Dipped beam . . . . . . . . . . . . . . . . . . . . . . . 254
Changing the battery of the vehicle key . . . . . . . . . . . . . . . . . . . . . 90
Chassis number . . . . . . . . . . . . . . . . . . . . . . . . 264
Child-proof lock Electric windows . . . . . . . . . . . . . . . . . . . . . 100
Child safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Child seat Categorisation in groups . . . . . . . . . . . . . . . 49
Group 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Group 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Group 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Groups 0 and 0+ . . . . . . . . . . . . . . . . . . . . . . 49
Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . 47
Securing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Child seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 ISOFIX system . . . . . . . . . . . . . . . . . . . . . . . . 54
on the front passenger seat . . . . . . . . . . . . . 31
Top Tether system . . . . . . . . . . . . . . . . . 54, 55
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198 Alcantara . . . . . . . . . . . . . . . . . . . . . . . . . . . 204
Carbon components . . . . . . . . . . . . . . . . . . 200
Display/Easy Connect control panel . . . . . 202
Exhaust pipe . . . . . . . . . . . . . . . . . . . . . . . . 201 Leather . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
Plastic parts . . . . . . . . . . . . . . . . . . . . 200, 202
Radio display . . . . . . . . . . . . . . . . . . . . . . . 202
Rims . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . 205
Trim parts . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Trims . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
Washing the vehicle . . . . . . . . . . . . . . . . . . 198
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Windscreen and rear window wiper blades . .221
Cleaning/De-icing the windows . . . . . . . . . . . 201
Cleaning the rims . . . . . . . . . . . . . . . . . . . . . . . 201
Cleaning the upholstery Natural leather . . . . . . . . . . . . . . . . . . . . . . 203
Closing Bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210
Panoramic sliding sunroof . . . . . . . . . . . . . 103
Panoramic sunroof . . . . . . . . . . . . . . . . . . . 103
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Clutch (warning lamp) . . . . . . . . . . . . . . . . . . . 162
Coming Home . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Compartments . . . . . . . . . . . . . . . . . . . . . . . . . 129
Consumption (fuel) . . . . . . . . . . . . . . . . . . . . . 264
Control lamp Airbag system . . . . . . . . . . . . . . . . . . . . . . . . 33
Cruise control . . . . . . . . . . . . . . . . . . . . . . . 164
Tyre monitor indicator warning lamp . . . . 175
Tyre monitoring systems . . . . . . . . . . . . . . 175
Windscreen wiper fluid level . . . . . . . . . . . 117
Control lamps Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Control of function Rain sensor . . . . . . . . . . . . . . . . . . . . . . . . . 120
278 Index

Outside temperature . . . . . . . . . . . . . . . . . . . . . 64
Outside temperature display . . . . . . . . . . . . . . . 73
OverviewTurn signal and main beam lever . . . . . . . 107
Overview (controls and displays) . . . . . . . . . . . 59
P Paint code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264
Paint damage . . . . . . . . . . . . . . . . . . . . . . . . . . 200
Panoramic sliding sunroof . . . . . . . . . . . . . . . . 103 Closing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Convenience closing . . . . . . . . . . . . . . . . . 104
Convenience opening . . . . . . . . . . . . . . . . 104
Fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Roll-back function . . . . . . . . . . . . . . . . . . . 104
Parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Parking aid Adjusting the display/audible warnings . 181
Environment warning . . . . . . . . . . . . . . . . . 179
Fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
Plus parking aid . . . . . . . . . . . . . . . . . . . . . 179
Rear parking aid . . . . . . . . . . . . . . . . . . . . . 179
Sensors/Camera: cleaning . . . . . . . . . . . . 199
Towing bracket . . . . . . . . . . . . . . . . . . . . . . 182
Parking aid system see Parking aid . . . . . . . . . . . . . . . . . . . . . . 179
Parking light . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Parking (automatic gearbox) . . . . . . . . . . 156, 157
Particulate filter (Diesel) . . . . . . . . . . . . . . . . . 190 Passenger
see Correct sitting position . . . . . . . 11, 12, 13
Pedals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Physical principles of a frontal collision . . . . . . 21
Plastic parts: Cleaning . . . . . . . . . . . . . . . 200, 202
Polishing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
Power Management . . . . . . . . . . . . . . . . . . . . . 187
Power socket . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Preheating . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Pressure (tyres) . . . . . . . . . . . . . . . . . . . . . . . . . 223
R Racks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Radio display: cleaning . . . . . . . . . . . . . . . . . . 202
Radio transmitters . . . . . . . . . . . . . . . . . . . . . . 230
Rain sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120 Control of function . . . . . . . . . . . . . . . . . . . 120
Rear lid automatic locking . . . . . . . . . . . . . . . . . . . . . 99
Central locking system . . . . . . . . . . . . . . . . . 98
Manual release in an emergency . . . . . . . . 99
Rear lights Changing a bulb . . . . . . . . . . . . . . . . . . . . . 252
Rear vision mirror . . . . . . . . . . . . . . . . . . . . . . . 122
Rear vision mirrors Adjusting the exterior mirrors . . . . . . . . . . 122
see also Rear vision mirrors . . . . . . . . . . . . 123
Reflective vests . . . . . . . . . . . . . . . . . . . . . . . . . 232
Remote control See "Keys" . . . . . . . . . . . . . . . . . . . . . . . . . . 88 Remote control key
Unlocking/Locking . . . . . . . . . . . . . . . . . . . . 91
Remove the wheel cover . . . . . . . . . . . . . . . . . 236
Removing the head restraint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230 Airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Replacement parts . . . . . . . . . . . . . . . . . . . . . . 230
Reservoir capacity Windscreen washer water reservoir . . . . . 122
Reset button (trip recorder) . . . . . . . . . . . . . . . . 67
Reset the trip recorder to zero . . . . . . . . . . . . . . 67
Retrofitting a towing bracket . . . . . . . . . . . . . . 196
Rev counter . . . . . . . . . . . . . . . . . . . . . . . . . . 61, 66
Reverse gear (automatic gearbox) . . . . . . . . . 154
Rims Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
RME (fuel) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207
Roll-back function Panoramic sliding sunroof . . . . . . . . . . . . . 104
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Roof carrier (roof load) . . . . . . . . . . . . . . . . . . . 131
Running in New brake pads . . . . . . . . . . . . . . . . . . . . . 185
New engine . . . . . . . . . . . . . . . . . . . . . . . . . 190
New tyres . . . . . . . . . . . . . . . . . . . . . . . . . . 223
S Safe driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Safelock see Anti-theft security system . . . . . . . . . . . 86
283
Index

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8child safety . . . . . . . . . . . . . . . . . . . . . . . . . . 47
child seats . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Safety equipment . . . . . . . . . . . . . . . . . . . . . . . . . 7
Safety first . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Safety interlock for ignition key . . . . . . . . . . . . 144
Safety notes Airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Curtain airbags . . . . . . . . . . . . . . . . . . . . . . . 43
Front airbags . . . . . . . . . . . . . . . . . . . . . . . . 37
Seat belt tensioners . . . . . . . . . . . . . . . . . . . 29
Side airbags . . . . . . . . . . . . . . . . . . . . . . . . . 41
Using child seats . . . . . . . . . . . . . . . . . . . . . 47
Using seat belts . . . . . . . . . . . . . . . . . . . . . . 23
Saving fuel Conscientious driving . . . . . . . . . . . . . . . . 191
Inertia mode . . . . . . . . . . . . . . . . . . . . . . . . 161
Saving tips (efficiency programme) . . . . . . . . . 78
Seat adjustment . . . . . . . . . . . . . . . . . . . . . . . . . 125
Seat adjuster . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Seat belt control lamp . . . . . . . . . . . . . . . . . . . . 19
Seat belt position Pregnant women . . . . . . . . . . . . . . . . . . . . . 27
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Seat belt protection . . . . . . . . . . . . . . . . . . . . . . 23
Seat belt release . . . . . . . . . . . . . . . . . . . . . . . . 27
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . 205
control lamp . . . . . . . . . . . . . . . . . . . . . . . . . 19
Incorrectly fastened . . . . . . . . . . . . . . . . . . . 28 Not worn . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . 23
Seat belt tensioners . . . . . . . . . . . . . . . . . . . . . . 28
SEAT Drive Mode . . . . . . . . . . . . . . . . . . . . . . . 171
Selective unlocking system . . . . . . . . . . . . . . . . 91
Selector lever Automatic gearbox . . . . . . . . . . . . . . . . . . . 154
Function fault . . . . . . . . . . . . . . . . . . . . . . . 155
Selector lever (automatic gearbox) Manual release . . . . . . . . . . . . . . . . . . . . . . 163
Service interval display . . . . . . . . . . . . . . . . . . . 65
Service intervals . . . . . . . . . . . . . . . . . . . . . . . . 211
Service notification: read . . . . . . . . . . . . . . . . . . 66
Setting Headlight range . . . . . . . . . . . . . . . . . . . . . 114
Side airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Description . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . 41
side assist Cleaning the sensors . . . . . . . . . . . . . . . . . 199
Side light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Sitting position driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Sitting position for vehicle occupants . . . . . . . 10
Sliding/tilting sunroof Convenience opening/closing . . . . . . . . . 101
Snow chains . . . . . . . . . . . . . . . . . . . . . . . 229, 266
Spanner symbol . . . . . . . . . . . . . . . . . . . . . . . . . 65
Special features Windscreen wipers . . . . . . . . . . . . . . . . . . . 118
Speedometer . . . . . . . . . . . . . . . . . . . . . . . . . . . 73 Speed warning function . . . . . . . . . . . . . . . . . . 149
Start-Stop system . . . . . . . . . . . . . . . . . . . . . . . 149
Driver messages . . . . . . . . . . . . . . . . . . . . . 152
Stop/Start the engine . . . . . . . . . . . . . . . . 150
Switching on/off . . . . . . . . . . . . . . . . . . . . . 152
The engine does not switch off . . . . . . . . . 151
The engine starts by itself . . . . . . . . . . . . . 151
Warning lamps . . . . . . . . . . . . . . . . . . . . . . 150
Starting up (engine) . . . . . . . . . . . . . . . . . . . . . 144
Steering Electro-mechanical steering . . . . . . . . . . . 186
Engage the steering lock (ignitionkey) . . . . . . . . . . . . . . . . . . . . . . . . . . 144, 146
Steering wheel Gearshift paddles (automatic gearbox) . . 159
Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Storage compartment . . . . . . . . . . . . . . . . . . . 130
Storage compartments Glove compartment lighting . . . . . . . . . . . 115
Sun visor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Switch Hazard warning lights . . . . . . . . . . . . . . . . 110
Switching ignition on/off . . . . . . . . . . . . . . . . . 144
Switching off using inertia . . . . . . . . . . . . . . . . 191
Switching off (engine) With the key . . . . . . . . . . . . . . . . . . . . . . . . 146
Symbols See "Lamps" . . . . . . . . . . . . . . . . . . . . . . . . . 69
System Automatic dipped beam control . . . . . . . . 109
System Easy Connect . . . . . . . . . . . . . . . . . . . . . 79
284 Index

WWarning lamp Cruise control . . . . . . . . . . . . . . . . . . . . . . . 164
Washing Care of the vehicle exterior . . . . . . . . . . . . 198
Wearing suitable shoes . . . . . . . . . . . . . . . . . . . 16
Wheel changing . . . . . . . . . . . . . . . . . . . . . . . . . . . 225
Wheel bolts . . . . . . . . . . . . . . . . . . . . . . . . 227, 266 Anti-theft . . . . . . . . . . . . . . . . . . . . . . . . . . . 237
Loosening . . . . . . . . . . . . . . . . . . . . . . . . . . 237
Removing the cap . . . . . . . . . . . . . . . . . . . . 236
Wheel brace . . . . . . . . . . . . . . . . . . . . . . . . . . . 232
Wheel cover (wheel bolts): removing . . . . . . . 236
Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . 223, 266 Changing . . . . . . . . . . . . . . . . . . . . . . 235, 239
Why assume the correct sitting position? . . . . . 30
Why should head restraints be correctly adjus- ted? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Why wear seat belts? . . . . . . . . . . . . . . . 19, 21, 30
Windows Electric windows . . . . . . . . . . . . . . . . . . . . . 100
Windscreen washer . . . . . . . . . . . . . . . . . . . . . 116
Windscreen washer system . . . . . . . . . . . . . . . 220
Windscreen washer water Checking . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Topping up . . . . . . . . . . . . . . . . . . . . . . . . . 121
Windscreen wiper . . . . . . . . . . . . . . . . . . . . . . . 116 Window wiper lever . . . . . . . . . . . . . . . . . . 118
Windscreen wiper fluid Control lamp . . . . . . . . . . . . . . . . . . . . . . . . 117 Windscreen wipers
Functions . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Headlight washer system . . . . . . . . . . . . . 119
Heated windscreen washer jets . . . . . . . . 119
Lifting the wiper blades . . . . . . . . . . . . . . . 119
Rain sensor . . . . . . . . . . . . . . . . . . . . . . . . . 120
Replacing the wiper blades . . . . . . . . . . . . 119
Service position . . . . . . . . . . . . . . . . . . . . . 119
Special features . . . . . . . . . . . . . . . . . . . . . 118
Windscreen wipers service position . . . . . . . . 119
Winter conditions Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217
Care of vehicle . . . . . . . . . . . . . . . . . . . . . . 198
De-icing the glass . . . . . . . . . . . . . . . . . . . . 201
Diesel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207
Snow chains . . . . . . . . . . . . . . . . . . . . . . . . 229
Tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227
Windscreen washer system . . . . . . . . . . . . 220
Winter operation Headlight washers . . . . . . . . . . . . . . . . . . . 119
Heated windscreen washer jets . . . . . . . . 119
Salt on the roads . . . . . . . . . . . . . . . . . . . . 121
Winter tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227
286 Index
