2012 Peugeot 207 CC fog light

i
13
FAMILIARISATION
SEEING CLEARLY

Lighting
Wipers


Ring B



81

Front and rear foglamps.
Ring A

Stalk A: windscreen wipers

2.
Fast wipe.

1.
Normal wipe.

I.
Intermittent wipe.

0.
Park.

È
Single wipe.
Screenwash: pull the stalk towards
you.



84 Lighting off.
Automatic illumination of head-
lamps.
Sidelamps.
Dipped/main beam headlamps.



80

Automatic wiping is not currently
available on the 207CC.

4
80
VISIBILITY
LIGHTING CONTROL STALK
System for selection and control of the
various front and rear lamps providing
the vehicle's lighting.

Manual controls

The lighting commands are made di-
rectly by the driver by means of ring A

and stalk B
.

A.
main lighting mode selection ring,
with:
Model without AUTO lighting

Model with AUTO lighting
lighting off,
sidelamps only,
dipped or main beam
headlamps,

B.
stalk for inversion of the beam by
pulling:
dipped/main beam headlamps. automatic illumination of
headlamps.

Displays

The corresponding indicator lamp
comes on on the instrument panel to
confi rm the switching on of the lighting
selected.

Main lighting

The vehicle's various front and rear
lamps are designed to adapt the driv-
er's visibility gradually in relation to the
climatic conditions:


- sidelamps, to be seen,

- dipped beam headlamps to see
without dazzling other drivers,

- main beam headlamps for good
visibility when the road is clear.



Additional lighting

Other lamps are installed to respond to
particular driving conditions:


- rear foglamps to be seen from a dis-
tance,

- front foglamps for even better visibility,

- directional headlamps for improved
visibility around corners.



Programmes

Various automatic lighting control
modes are also available according to
the following options:


- "guide-me-home" lighting,

- automatic illumination of headlamps,

- static directional lighting. In the lighting off and sidelamps modes,
the driver can switch on the main beam
headlamps directly ("headlamp fl ash")
by pulling and holding the stalk.

4
!
i
81
VISIBILITY

Model with front and rear foglamps
front and rear foglamps
C.
foglamps selection ring.
These operate with the dipped and main
beam headlamps.


)
To switch on the foglamps, turn
ring C
forwards.

)
To switch off the rear foglamps, turn
ring C
rearwards twice in succes-
sion.
When the lighting is switched off auto-
matically (on AUTO model) or when the
dipped beam headlamps are switched
off manually, the foglamps and the side-
lamps will remain on.


)
Turn the ring rearwards to switch
off the foglamps, the sidelamps will
then switch off.
Do not forget to switch off the front
foglamps and the rear foglamps
when they are no longer neces-
sary. In normal light levels, the
power of their beams may dazzle
other drivers.
Lighting on reminder
The triggering of an audible signal
when a door is opened warns the
driver that they have forgotten to
switch off the vehicle's lighting, with
the ignition off.
In this case, switching off the light-
ing will stop the audible signal.
When the ignition is switched off,
if the dipped beam headlamps re-
main on, they will be switched off
automatically after thirty minutes to
prevent discharging of the battery.
This indicator lamp comes on
on the instrument panel.

* According to country.

Daytime running lamps *

On vehicles fi tted with daytime running
lamps, the dipped beam headlamps
come on when the vehicle is started.
The instruments and controls (multi-
function screen, air conditioning control
panel, ...) are not lit, unless the auto-
matic lighting mode is activated or the
lighting is switched on manually.

4
!
82
VISIBILITY
In fog or snow, the sunshine sensor
may detect suffi cient light. There-
fore, the lighting will not come on
automatically.
Do not cover the sunshine sensor,
coupled with the rain sensor and
located in the centre of the wind-
screen behind the rear view mirror;
the associated functions would no
longer be controlled.

Coupling with the "Guide-me-home"
lighting
Association with the automatic illumina-
tion of headlamps provides the "guide-
me-home" lighting with the following
additional options:


- selection of the lighting duration to
15, 30 or 60 seconds in the vehi-
cle parameters in the multifunction
screen confi guration menu,

- automatic activation of "guide-me-
home" lighting when automatic illumi-
nation of headlamps is in operation.











Automatic illumination of headlamps

The sidelamps and dipped beam head-
lamps are switched on automatically, with-
out any action on the part of the driver, when
a low level of external light is detected (sen-
sor behind the rear view mirror) or when the
windscreen wipers are switched on.
As soon as the brightness returns to a suf-
fi cient level or after the windscreen wipers
are switched off, the lighting is switched off
automatically.

"Guide-me-home" lighting

The dipped beam headlamps remain on
temporarily, after switching off the vehi-
cle's ignition, to make the driver's exit
easier in poor light.

Activation


)
With the ignition off, activate a
"headlamp fl ash" using stalk B
.

)
A second "headlamp fl ash" switches
the function off again.


Switching off
The "guide-me-home" lighting is
switched off automatically following the
door locking command, after a given
time.


Activation


)
Turn ring A
to the " AUTO
" position.
The automatic illumination of head-
lamps is accompanied by a mes-
sage in the multifunction screen.


Deactivation


)
Turn ring A
to a position other than
" AUTO
". Deactivation is accompa-
nied by a message in the multifunction
screen.

Operating fault
In the event of a malfunction of
the brightness sensor, the light-
ing comes on accompanied by
the service warning lamp, an
audible signal and a message on the
multifunction screen.
Have it checked by a PEUGEOT dealer
or a qualifi ed workshop.

9
i
!
i
PRACTICAL INFORMATION
147




ACCESSORIES

A wide range of accessories and genu-
ine parts is available from the PEUGEOT
dealer network.
These accessories and parts have been
tested and approved for reliability and
safety.
They are all adapted to your vehicle and
benefi t from PEUGEOT's recommenda-
tion and warranty.

Depending on the legislation in
force in the country, it may be com-
pulsory to have a high visibility
safety vest, warning triangle and
spare bulbs and fuses available in
the vehicle.
The fi tting of electrical equipment or
accessories which are not recom-
mended by PEUGEOT may result
in a failure of your vehicle's elec-
tronic system and excessive electri-
cal consumption.
Please note this precaution. You
are advised to contact a PEUGEOT
representative to be shown the range
of recommended equipment and
accessories.







"Comfort":
door defl ectors, side blinds and rear
blind, coat hanger fi xed to head re-
straint, front centre armrest, under shelf
storage, front and rear parking sen-
sors...
Installation of radio
communication transmitters
Before installing any after-market
radio communication transmitter,
you can contact a PEUGEOT deal-
er for the specifi cation of transmit-
ters which can be fi tted (frequency,
maximum power, aerial position,
specifi c installation requirements),
in line with the Vehicle Electro-
magnetic Compatibility Directive
(2004/104/EC).



"Transport solutions":
boot liner, luggage net, cigarette lighter,
roof bars, bicycle carrier on roof bars,
ski carrier, roof box...
Tow bar, which mst be fi tted by PEUGEOT
dealer or a qualifi ed workshop.

"Styling":
aluminium gear lever knob, spoiler, styling
strips, alloy wheels, trims, chromed mirror
shells, body kit...

*
To avoid any risk of jamming of the
pedals:


- ensure that the mat is positioned
and secured correctly,

- never fi t one mat on top of another.

"Security":
anti-theft alarm, window engraving,
wheel security bolts, child seats and
booster cushions, breathalyzer, fi rst aid
kit, warning triangle, high visibility jacket,
stolen vehicle tracking system, tempo-
rary puncture repair kit, snow chains,
non-slip covers, front foglamps kit...

"Protection":
mats * , seat covers compatible with lateral
airbags, aluminium or PVC door aperture
fi nishers...

"Multimedia":
audio systems, satellite navigation
systems, hands-free kit, CD changer,
speakers, DVD player, connection kit
for MP3 or CD player, USB Box...

You can also obtain products for cleaning
and maintenance (exterior and interior),
topping up (screenwash...),and refi lls
(cartridge for the temporary puncture re-
pair kit...) by visiting a PEUGEOT dealer.
