VISIBILITY
WIPER CONTROL STALK
System for the selection and control of
the various windscreen wiping modes
permitting the dispersal of rain and
cleaning.
The vehicle's windscreen wipers are
designed to gradually improve the driv-
er's visibility in relation to the weather
conditions.


Manual controls

The wiping commands are made directly
by the driver using stalk A
.
fast (heavy rain),
normal (moderate rain),
intermittent (in proportion to
the speed of the vehicle),
off,
single wipe (press downwards),
Model with intermittent wiping

Windscreen wipers


A.
wiping speed selection control:








Windscreen and headlamp
wash


)
Pull the windscreen wiper stalk to-
wards you. The screenwash then the
wipers operate for a fi xed period.
The headlamp wash is only activate if
the dipped headlamps are on
.
With daytime running lamps, to
activate the headlamp wash, posi-
tion the lighting stalk in the dipped
beam position.
On vehicles fi tted with digital air
conditioning, any action on the
windscreen wash control results in
temporary closing of the air intake
to avoid odours inside the passen-
ger compartment. Automatic wiping is not available
on the 207CC at present.

4
i
85
VISIBILITY


Special position of the windscreen
wipers
In the minute following switching off of
the ignition, any action on the stalk po-
sitions the wipers vertically on the wind-
screen.
This action enables you to position the
wiper blades for winter parking.
To park the wipers after this has been
done, switch on the ignition and operate
the stalk.
COURTESY LAMP



A.
Courtesy lamp


B.
Map reading lamps

In this position, the courtesy
lamp comes on gradually:

Map reading lamps



)
With the ignition on, press the cor-
responding switch.
With the "permanent lighting" mode,
the duration of lighting varies, de-
pending on the circumstances:


- with the ignition off, approxi-
mately ten minutes,

- in energy economy mode, ap-
proximately thirty seconds,

- with the engine running, unlimited.




- when the vehicle is unlocked,

- when the key is removed from the
ignition,

- when a door is opened,

- when the remote control locking but-
ton is activated, in order to locate
your vehicle.
It switches off gradually:


- when the vehicle is locked,

- when the ignition is switched on,

-
30 seconds after the last door is closed.

Permanently off.
Permanent lighting.


Courtesy lamp

9PRACTICAL INFORMATION
139

Engine compartment fuses

The fusebox is placed in the engine
compartment, near the battery (left-
hand side).

Access to the fuses


)
Unclip the cover.

)
Replace the fuse (refer to the cor-
responding paragraph).

)
When you have fi nished, close the
cover carefully to ensure correct
sealing of the fuse box.

Fuse table


Fuse N°



Rating



Functions



F1

20 A
Engine control unit and fan assembly control relay
supply, timing and canister electrovalves (1.6 l 16V
THP), air fl ow sensor (Diesel), injection pump
(Diesel), water in Diesel sensor (Diesel), EGR
electrovalves, air heating (Diesel).

F2

15 A
Horn.

F3

10 A
Front wash-wipe.

F4

20 A
Headlamp wash.

F5

15 A
Fuel pump (petrol), Turbo electrovalves
(1.6 l 16V THP).

F6

10 A
Vehicle speed sensor, automatic gearbox.

F7

10 A
Electric power steering, directional headlamps,
directional headlamps control relay, switching and
protection unit (Diesel).

F8

20 A
Starter motor control.

F9

10 A
ABS/ESP control unit, brake pedal switch.

F10

30 A
Engine control unit actuators (petrol: ignition coils,
electrovalves, oxygen sensors, injectors, heaters,
electronic thermostat) (Diesel: electrovalves,
heaters).

F11

40 A
Air conditioning blower.

F12

30 A
Windscreen wipers Low/High speed.

F13

40 A
Built-in systems interface supply (ignition positive).

9
!
i
PRACTICAL INFORMATION
143
A fl at battery prevents the engine
from starting (refer to the corre-
sponding paragraph). If a roof operation is in progress,
it will be completed, but no further
operation is possible.
ENERGY ECONOMY MODE

System which manages the duration of
use of certain functions to conserve a
suffi cient level of charge in the battery.
After the engine has stopped, you can
still use functions such as the audio
equipment, windscreen wipers, dipped
beam headlamps, courtesy lamp, etc.
for a maximum combined duration of
thirty minutes.
Exiting economy mode
These functions are reactivated auto-
matically next time the vehicle is driven.


)
In order to resume the use of these
functions immediately, start the
engine and let it run for a few minutes.
The time available to you will then be
double the duration for which the engine
is left running. However, this period will al-
ways be between fi ve and thirty minutes.
Switching to economy mode

Once the thirty minutes are over, a
message appears on the multifunction
screen indicating that the vehicle has
switched to economy mode and the ac-
tive functions are put on standby.
CHANGING A WIPER BLADE
Procedure for replacing a worn wiper
blade with a new one without the use
of tools.

Removing a front wiper blade



)
Raise the corresponding wiper arm.

)
Unclip the wiper blade and remove it.



Fitting a front wiper blade



)
Check the size of the wiper blade
as the shorter blade is fi tted on the
right-hand side of the vehicle.

)
Put the corresponding new wiper
blade in place and clip it.

)
Fold down the wiper arm carefully.

LOAD REDUCTION MODE

System which manages the use of cer-
tain functions according to the level of
charge remaining in the battery.
When the vehicle is being driven, the load
reduction function temporarily deactivates
certain functions, such as the air condi-
tioning, the heated rear screen...
The deactivated functions are reactivated
automatically as soon as conditions permit.

10
!
i
153
IDENTIFICATION MARKINGS
Various visible markings for the identifi cation of your vehicle.
Wheels which are fi tted with 205/45
R17 tyres cannot be fi tted with
snow chains. For more information,
contact a PEUGEOT dealer.
If the infl ation pressures are too low,
this increases fuel consumption. The infl ation pressures must be
checked when the tyres are cold,
at least once a month.

A. Vehicle identifi cation (VIN) number
under the bonnet.
This number is etched on the bodywork
near the passenger compartment fi lter.
B. Visible VIN on the dashboard.

This number is indicated on a self-
adhesive label which is visible through
the windscreen.
C. VIN on the chassis.

This number is indicated on a self-de-
stroying label affi xed to the centre pillar,
near the driver’s door striker.

D. Manufacturer’s label.

This label is affi xed to the edge of the
door on the driver’s side.
It bears the following information:


- the wheel rim and tyre sizes,

- the brands of tyre recommended by
the manufacturer,

- the associated infl ation pressures,

- the paint colour code.
