2012 Lexus LFA remove seats

33
1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
Seatback fold and returnTo enable easier loading and unloading of luggage, the seats can be
moved using the seatback fold and return switch. A buzzer will sound
once the seat starts moving. Fold
Press the switch to fold the seat-
back down and move the seat for-
ward.
Return
Press the switch to return the seat
to its former position.
Power easy access system*
When the driver enters and exits the vehicle, the driver's seat will auto-
matically perform the following operations: Exiting the vehicle: When the key
is removed from the ignition
switch, the driver’s seat will move
backward (auto away function).
Entering the vehicle: When the key
is inserted into the ignition switch,
the driver’s seat will move forward
(auto return function).
*: This setting must be customized at your Lexus dealer.

40
1-3. Adjustable components (seats, mirrors, steering wheel)
CAUTION
■Child restraint lock function belt precaution
Do not allow children to play with the child restraint lock function belt. If the belt
becomes twisted around a child’s neck, it will not be possible to pull the belt out
leading to choking or other serious in juries that could result in death.
If this occurs and the buckle cannot be un fastened, scissors should be used to cut
the belt behind the seat belt guide.
■Seat belt damage and wear
●Do not damage the seat belts by allowing the belt, plate, or buckle to be jammed
in the door.
If the seat belt is damaged, the built-in SRS seat belt airbag may not inflate in an
accident.
●Inspect the seat belt system periodically. Check for cuts, fraying, and loose parts.
Do not use a damaged seat belt until it is replaced. Damaged seat belts cannot
protect an occupant from death or serious injury.
●Ensure that the belt and tab are lo cked and the belt is not twisted.
If the seat belt does not function co rrectly, immediately contact your Lexus
dealer.
●If your vehicle has been involved in an accident, have the seat assembly including
the belts inspected at your Lexus dealer even if there is no obvious damage.
●Do not attempt to install, remove, modify, disassemble or dispose of the seat belts.
Have any necessary repairs carried out by your Lexus dealer. Inappropriate han-
dling of the pretensioner may prevent it from operating properly resulting in
death or serious injury.
■When using the seat belt guide
●Always make sure that the belt is not twisted, and runs freely through the guide.
●Always make sure the seat belt passes through the seat belt guide. If the seat belt
is not passing through the seat belt guide correctly and the SRS airbags are
inflated, the SRS seat belt airbag may no t inflate correctly, resulting in death or
serious injury.

45
1-3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
NOTICE
■If the mirrors become iced up
In order to retain the rain-clearing properties of the mirror, do not attempt to scrape
the ice off. Instead, remove it by turning on the mirror defoggers or by applying
warm water.

75
1-7. Safety information
1
Before driving
CAUTION
■Passenger occupant classification system precautions
Observe the following precautions regarding the passenger occupant classification
system.
Failure to do so may cause death or serious injury.
●Wear the seat belt properly.
●Make sure the passenger’s seat belt tab has not been left inserted into the buckle
before someone sits in the passenger seat.
●Do not apply a heavy load to the passenger seat or equipment.
●Do not put objects under the passenger seat.
●Keep the passenger seatback as upright as possible when the vehicle is moving.
Reclining the seatback excessively may le ssen the effectiveness of the seat belt
system.
●If an adult sits in the passenger seat, the “AIR BAG ON” indicator light should illu-
minated. If the “AIR BAG OFF” indicator is illuminated, ask the passenger to sit
up straight, well back in the seat, feet on the floor, and with the seat belt worn cor-
rectly. If the “AIR BAG OFF” indicator still remains illuminated, ask the passenger
to move the passenger seat fully rearward.
●If a child restraint system needs to be installed, install a forward facing child
restraint system on the passenge r seat in the proper manner. (P. 8 0 )
●Do not modify or remove the seats.
●Do not kick the passenger seat or subject it to severe impact. Otherwise, the SRS
warning light may come on to indicate a malfunction of the detection system. In
this case, contact your Lexus dealer immediately.
●Do not use a seat accessory, such as a cushion or seat cover, that covers the seat
cushion surface.
●Do not modify or replace the upholstery of the seat.

267
4-3. Do-it-yourself maintenance
4
Maintenance and care
■Removing the negative (-) battery terminalTurn the ignition switch to the “LOC K” position and check that the gear
indicator is not displayed. ( P. 2 6 9 )
Open the rear hatch and remove the cover.
●When reconnecting the terminal, make sure that the lever is lowered into the
lock position.
●Do not disconnect the term inal while the power seats, power windows or other
electrical devices are being operated.
●When the battery terminal is disconnect ed, the “Lap Timer” data and clock in
the meter will be reset.
STEP1
STEP2
Lift the lever.
Disconnect the terminal.STEP3
Lock position
STEP4

403
Alphabetical index
Back camera ............................................ 163
Back doorOpener.......................................................29
Back door light Replacing light bulbs ....................... 299
Wattage ................................................. 367
Back monitor ........................................... 163
Back-up lights Wattage ................................................. 367
Battery Checking ............................................... 265
Terminals ............................................... 265
If the vehicle has a discharged battery ........................ 348
Warning light......................................... 313
Warning message .............................327
Wireless remote control
battery ..................................................... 285
Bottle holder ..............................................211
Brake Braking sound........................................ 90
CCM brake disc ............................... 365
Fluid ...........................................................262
Parking brake ..........................................113
Warning light............................... 312, 314
Warning message .............................327
Brake assist ............................................... 166
Brightness control ................................. 147 Camera ...................................................... 163
Care
Exterior....................................................228
Interior .....................................................235
Seat belts ................................................236
Cargo capacity ........................................176
CCM brake disc ...................................365
Chains ..........................................................181
Child restraint system Booster seats, definition .................... 76
Booster seats, installation ................. 82
Convertible seats, definition ............ 76
Convertible seats, installation .......... 81
Installing CRS with seat belts ........... 81
Installing CRS with top straps.........83
Passenger occupant classification system ......................... 72
Child safety Active rear wing ................................... 172
Airbag precautions ..............................68
Battery precautions .............268, 350
Child restraint system ......................... 76
How your child should wear the seat belt ..........................................38
Installing child restraints.................... 80
Power window precautions ............48
Rear hatch precautions......................30
Removed wireless remote control battery precautions...... 286
Seat belt guide........................................ 37
Seat belt precautions .......................... 39
Seat heater precautions..................... 35B
*1: Refer to “Navigation System Owner’s Manual”.
C
