2012 Lexus IS250 engine

530
6-1. Specifications
Clutch
Brakes
*1: Minimum pedal clearance when depressed with a force of 110 lbf (490 N, 50kgf) while the engine is running.
*2: Parking brake pedal travel when depressed with a force of 67.4 lbf (300 N,30.6 kgf).
*3: Parking brake lever travel when pulled up with a force of 45.0 lbf (200 N, 20.4kgf).
Clutch free play0.2  0.6 in. (5  15 mm)
Fluid typeSAE J1703 or FMVSS No.116 DOT 3
Pe d a l c l e a r a n c e *1
IS 350
IS 250
Manual transmission
Automatic transmission4.13 in. (105 mm) Min.
4.09 in. (104 mm) Min.
4.3 in. (108 mm) Min.
Pedal free play0.04  0.08 in. (1.0  2.0 mm)
Brake pad wear limit0.04 in. (1.0 mm)
Parking brake lining wear limit0.04 in. (1.0 mm)
Parking brake pedal travel *2/
lever travel
*3
Pedal type
Lever type7  9 clicks
5
 7 clicks
Fluid typeSAE J1703 or FMVSS No. 116 DOT 3

537
6-1. Specifications
6
Vehicle specifications
Fuel information
■Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your Lexus has a fuel tank opening that only
accommodates the special nozzle on unleaded fuel pumps.
■If your engine knocks
●Consult your Lexus dealer.
●You may occasionally notice light knocking for a short time while accelerating
or driving uphill. This is normal and there is no need for concern.
Your vehicle must use only unleaded gasoline.
IS250
Premium unleaded gasoline with an oc tane rating of 91 (Research Octane
Number 96) or higher required for optimum engine performance. If 91
octane cannot be obtained, you may us e unleaded gasoline with an octane
rating as low as 87 (Research Octane Number 91). Use of unleaded gaso-
line with an octane rating lower than 91 may result in engine knocking. Per-
sistent knocking can lead to engine damage and should be corrected by
refueling with higher octane unleaded gasoline.
IS350
Premium unleaded gasoline with an oc tane rating of 91 (Research Octane
Number 96) or higher required for optimum engine performance. If 91
octane cannot be obtained, you may us e unleaded gasoline with an octane
rating as low as 87 (Research Octane Number 91). Use of unleaded gaso-
line with an octane rating lower than 91 may result in engine knocking and
significantly reduced perf ormance. Persistent knocking can lead to engine
damage and should be corrected by refueling with higher octane unleaded
gasoline.
At minimum, the gasoline you us e should meet the specifications of
ASTM D4814 in the U.S.A. an d CGSB3.5-M93 in Canada.

538
6-1. Specifications
■Gasoline quality
In very few cases, driveability problems may be caused by the brand of gasoline you
are using. If driveability problems persist, try changing the brand of gasoline. If this
does not correct the problem, consult your Lexus dealer.
■Gasoline quality standards
●Automotive manufacturers in the US, Europe and Japan have developed a
specification for fuel quality called World-Wide Fuel Charter (WWFC) that is
expected to be applied worldwide.
●The WWFC consists of four categories that are based on required emission
levels. In the US, category 4 has been adopted.
●The WWFC improves air quality by lowering emissions in vehicle fleets, and
customer satisfaction th rough better performance.
■Lexus recommends the use of gasoline containing detergent additives
●Lexus recommends the use of gasoline that contains detergent additives to
avoid build-up of engine deposits.
●All gasoline sold in the US contains de tergent additives to clean and/or keep
clean intake systems.
■Lexus recommends the use of cleaner burning gasoline
Cleaner burning gasoline, including reform ulated gasoline that contains oxygen-
ates such as ethanol or MTBE (Methyl Tertiary Butyl Ether) is available in many
areas.
Lexus recommends the use of cleaner burning gasoline and appropriately blended
reformulated gasoline. These types of gasoline provide excellent vehicle perfor-
mance, reduce vehicle emissions and improve air quality.

540
6-1. Specifications
NOTICE
■Notice on fuel quality
●Do not use improper fuels. If improper fuels are used the engine will be damaged.
●Do not use leaded gasoline.
Leaded gasoline can cause damage to your vehicle’s three-way catalytic convert-
ers causing the emission control system to malfunction.
●Do not use gasohol other than that stated here.
Other gasohol may cause fuel system damage or vehicle performance problems.
●IS250: Use of unleaded gasoline with an octane rating lower than 91 may result
in engine knocking. Persistent knocking can lead to engine damage and should
be corrected by refueling with higher octane unleaded gasoline.
●IS350: Use of unleaded gasoline with an octane rating lower than 91 may result
in engine knocking and significantly re duced performance. Persistent knocking
can lead to engine damage and should be corrected by refueling with higher
octane unleaded gasoline.
■Fuel-related poor driveability
If after using a different type of fuel, poor driveability is encountered (poor hot start-
ing, vaporization, engine knoc king, etc.), discontinue the use of that type of fuel.
■When refueling with gasohol
Take care not to spill gasohol. It can damage your vehicle's paint.

546
6-1. Specifications
■Temperature A, B, C
The temperature grades are A (the highest), B, and C, representing
the tire's resistance to the generation of heat and its ability to dissipate
heat when tested under controlled conditions on a specified indoor
laboratory test wheel.
Sustained high temperature can cause the material of the tire to degenerate
and reduce tire life, and excessive temperature can lead to sudden tire fail-
ure.
The grade C corresponds to a level of performance which all passenger car
tires must meet under the Federal Mo tor Vehicle Safety Standard No. 109.
Grades B and A represent higher levels of performance on the laboratory
test wheel than the minimum required by law.
Warning: The temperature grades for this tire are established for a tire that
is properly inflated and not overloaded.
Excessive speed, underinflation, or excess ive loading, either separately or in
combination, can cause heat buildup and possible tire failure.
Glossary of tire terminology
Tire related termMeaning
Accessory weight
The combined weight (in excess of those standard
items which may be replaced) of automatic transmis-
sion, power steering, power brakes, power windows,
power seats, radio and heater, to the extent that these
items are available as factory-installed equipment
(whether installed or not)
Cold tire inflation pres-
sureTire pressure when the vehicle has been parked for
three hours or more, or has not been driven more
than 1 mile or 1.5 km under that condition
Curb weight
The weight of a motor vehicle with standard equip-
ment, including the maximum capacity of fuel, oil and
coolant, and if so equipp ed, air conditioning and
additional weight optional engine

557
6-2. Customization
6
Vehicle specifications
Windshield
wipers and
washer
(
P. 1 7 8 )
Switching operation when
the vehicle is stationaryOnOff
Drip prevention functionOnOff
Time elapsed before the
drip prevention function
operatesVa r i a b l e
depending on
the vehicle
speed
3 seconds
Intuitive park-
ing assist
(
P. 1 9 0 )
Back sensor operation
display and buzzerOnOff
Buzzer volumeLevel 3Level 1 to 5
Distance which a sensor
detects4.9 ft. (150 cm)2.0 ft. (60 cm)
Illumination
(
P. 3 2 5 )
Time elapsed before lights
turn off15 seconds7. 5 s e c o n d s
30 seconds
Operation when the
doors are unlockedOnOff
Operation after the
“ENGINE START STOP”
switch is turned OFF
OnOff
Front footwell lightsOnOff
Shift lever lightOnOff
Outer foot lightOnOff
Seat belt
reminder
(
P. 4 7 3 )
Vehicle speed linked seat
belt reminder buzzerOnOff
ItemFunctionDefault settingCustomizedsetting

580
Alphabetical index
Child-protectors ...................................... 49
Cigarette lighter....................................343
CleaningExterior ................................................... 378
Interior ..................................................... 382
Seat belts................................................383
Clock ........................................................ 338
Coat hooks ..............................................355
Compass ..................................................366
Condenser ..............................................406
Console box .......................................... 330
Cooling system Engine overheating ............................513
Cornering assist sensors .................... 190
Cruise control ......................................... 186
Cup holder ..............................................332
Curtain shield airbags............................98
Customizable features .......................553
Daytime running light system ............174
Defogger* Rear window ........................................ 224
Side mirror ............................................ 224
Dimension ................................................520
Dinghy towing ................................. 211, 212
Display Satellite switch mode ....................... 339
Trip information ................................... 168
Warning message.............................. 481 Do-it-yourself maintenance ...............391
Door courtesy lights
Door courtesy lights ........................ 325
Wattage ................................................. 536
Door pockets ......................................... 334
Doors Door lock ................................33, 45, 48
Door windows ....................................... 80
Side mirrors.............................................. 77
Driver's seat belt reminder light ..... 473
Driving Correct posture.....................................96
Procedures............................................. 130
Driving position memory...................... 58
Electric power steering........................196
Electronic key If the electronic key does not operate properly............................505
Emergency, in case of If a warning message is displayed .............................................. 481
If the electronic key does not
operate properly............................505
If the engine will not start .................501
If the shift lever cannot be shifted from P................................... 503
If the vehicle has a discharged battery ...................................................510
If the warning buzzer sounds........ 471
If the warning light turns on............ 471
D
E

581
Alphabetical index
If you have a flat tire ........................ 492
If you lose your keys ........................ 504
If you think something is wrong................................................... 469
If your vehicle becomes stuck ......516
If your vehicle has to be stopped in an emergency.............................. 518
If your vehicle needs to be towed ................................................... 463
If your vehicle overheats.................. 513
Emergency flashers Switch ...................................................... 462
Engine Compartment ..................................... 397
Engine switch .......................................... 141
Hood ....................................................... 394
How to start the engine...................... 141
Identification number......................... 521
If the engine will not start ................ 501
Ignition switch.......................................... 141
Overheating........................................... 513
Engine compartment cover............. 399
Engine coolant Capacity..................................................527
Checking ............................................... 404
Preparing and checking before winter .................................... 206 Engine coolant temperature
gauge....................................................... 158
Engine immobilizer system..................90
Engine oil Capacity .................................................524
Checking ................................................ 401
Preparing and checking before winter ................................... 206
EPS .............................................................. 196
Event data recorder .................................21
First-aid kit storage belt ..................... 357
Floor mat ..................................................356
Fluid Brake ....................................................... 406
Washer ...................................................... 411
Fog lights Switch.........................................................176
Wattage ................................................. 536
Footwell lights ........................................ 325
Front fog lights Switch.........................................................176
Wattage ................................................. 536
Front passenger occupant classification system .......................... 109
Front passenger's seat belt reminder light...................................... 473
F
*: For vehicles with a navigation system, refe r to the “Navigation System Owner’s Manual”.
