329
3
Interior features
3-6. Using the storage features
List of storage features
CAUTION
■Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause
the following when cabin temperature becomes high:
●Glasses may be deformed by heat or cracked if they come into contact with
other stored items.
●Lighters or spray cans may explode. If they come into contact with other stored
items, the lighter may catch fire or the spray can may release gas, causing a fire
hazard.
Glove box
Console boxes
Cup holders
Bottle holders/door pockets
Overhead console
Auxiliary box (if equipped)
330
3-6. Using the storage features
Glove boxOpen (push button)
Lock with the mechanical key
Unlock with the mechanical key
Console boxesFront Pull up the knob to release the
lock.
Slide the armrest.
Pull up the knob to release the
lock.
Lift the armrest to open.
■Glove box light
The glove box light turns on when the “ENGINE START STOP” switch is in IGNI-
TION ON mode.
■Trunk opener main switch
The trunk opener main switch is located in the glove box. ( P. 5 2 )
CAUTION
■Caution while driving
Keep the glove box closed.
Injuries may result in the event of an accident or sudden braking.
Glove box and console boxes
430
4-3. Do-it-yourself maintenance
Air conditioning filter
The air conditioning filter must be cleaned or changed regularly to main-
tain air conditioning efficiency.
■ Removal method
Set the air conditio ning system to recirculated mode.
( P. 2 1 6 )
The air conditioning filter case cannot be removed with the system in
the outside air mode.
Turn the “ENGINE START STOP” switch OFF.
Open the glove box. Lift and
remove the partition.
Remove the filter cover.
Remove the filter case.
STEP1
STEP2
STEP3
STEP4
STEP5
447
4-3. Do-it-yourself maintenance
4
Maintenance and care
9ACC7. 5 A
Clock, air conditioning system, audio,
navigation system, outside rear view
mirrors, Lexus parking assist monitor,
glove box light, console box light, mul-
tiplex communication system, display,
smart access system with push-but-
ton start
10CIG15 ACigarette lighter
11PWR OUTLET15 APo w e r o u t l e t
12RR DOOR RH20 APo w e r w i n d o w s
13FR DOOR RH20 A
Power windows, outside rear view
mirrors, multiplex communication sys-
tem
14AM27. 5 AStarting system
15RH-IG7. 5 A
Seat belts, intuitive parking assist,
automatic transmission, seat heater
and ventilator, windshield wiper de-
icer
16FR S/HTR RH15 ASeat heaters and ventilators
17ECU-IG RH10 A
Power seats, smart access system with
push-button start, AWD system, out-
side rear view mirrors, VDIM, air con-
ditioning system, electric tilt and
telescopic steering, power windows,
navigation system, multiplex commu-
nication system
FuseAmpereCircuit
582
Alphabetical index
Front seatsAdjustment............................................... 56
Driving position memory.................. 58
Front turn signal lights Switch ........................................................154
Wattage..................................................536
Fuel Capacity ................................................. 523
Fuel gauge ............................................. 158
Fuel pump shut off system ............ 470
Gas station information.................. 592
Information............................................ 537
Refueling ................................................... 87
Fuel door ..................................................... 87
Fuel filler door ........................................... 87
Fuel pump shut off system ................. 470
Fuses ..........................................................435
Garage door opener ..........................360
Gas station information......................592
Gauges ...................................................... 158
Glove box ............................................... 330
Glove box light ..................................... 330 Hands-free system
for mobile phone* ............................. 294
Hazard lights Switch .......................................................462
Head restraints Adjusting .................................................. 62
Headlight aim ......................................... 450
Headlight cleaner.................................. 185
Headlights Discharge headlight precautions ....................................... 459
Replacing light bulbs ......................... 451
Switch .........................................................172
Wattage ................................................. 536
Heaters Seat heaters ............................. 345, 348
Side mirror............................................. 224
Hill-start assist control ..........................196
Hood .......................................................... 394
Hooks Cargo.......................................................357
Coat ......................................................... 355
Shopping bag ......................................357
Horn ............................................................. 157
