2012 Lexus IS220d stop start

157
2-1. Driving procedures
2
When driving
IS250/220d/200d_EE
Manual transmission
Check that the parking brake is set.
Check that the shift lever is set in N.
Firmly depress the clutch pedal.
The “ENGINE START STOP” switch indicator turns green.
Press the “ENGINE START
STOP” switch.
indicator turns on. The
engine begins starting after
the indicator light goes out.
The engine will crank until it
starts or for up to 30 seconds,
whichever is less.
Continue depressing the
clutch pedal until the engine
is completely started.
The engine can be started
from any “ENGINE START
STOP” switch mode.
STEP1
STEP2
STEP3
STEP4

158
2-1. Driving procedures
IS250/220d/200d_EE
Changing “ENGINE START STOP” switch mode
Modes can be changed by pressing the “ENGINE START
STOP” switch with the brake pedal (vehicles with an automatic
transmission) or clutch pedal (vehicles with a manual transmis-
sion) released. (The mode changes each time the switch is
pressed.)
OFF
*
The emergency flashers can
be used.
ACCESSORY mode
Some electrical components
such as the audio system can
be used.
The “ENGINE START
STOP” switch indicator turns
amber.
IGNITION ON mode
All electrical components can
be used.
The “ENGINE START
STOP” switch indicator turns
amber.
*: If the shift lever is in a posi-
tion other than P when turn-
ing off the engine, the
“ENGINE START STOP”

159
2-1. Driving procedures
2
When driving
IS250/220d/200d_EE
If the engine does not start
The engine immobilizer system may not have been deactivated. (P. 9 6 )
When the steering lock cannot be released
When the “ENGINE START STOP” switch indicator flashes in amber
The system may be malfunctioning. Have the vehicle inspected by any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional, immediately.
Auto power off function
If the vehicle is left in ACCESSORY mode for more than an hour with the
shift lever in P (vehicles with an automatic transmission), the “ENGINE
START STOP” switch will automatically turn OFF.
Electronic key battery depletion
P. 4 4
When the electronic key battery is discharged
P. 4 3 1
Conditions affecting operation
P. 4 2
Note for the entry function
P. 4 6
The “ENGINE START STOP” switch
indicator will flash in green and a mes-
sage will be shown on the multi-informa-
tion display. Press the “ENGINE START
STOP” switch again while turning the
steering wheel left and right.

160
2-1. Driving procedures
IS250/220d/200d_EE
CAUTION
When starting the engine
Always start the engine while sitting in the driver's seat. Do not press the
accelerator while starting the engine under any circumstances.
Doing so may cause an accident resulting in death or serious injury.
Stopping the engine in an emergency
If you want to stop the engine in an emergency while driving the vehicle,
push and hold the “ENGINE START STOP” switch for more than 3 sec-
onds.
However, do not touch the “ENGINE START STOP” switch while driving
except in an emergency. Turning the engine off while driving will not cause
loss of steering or braking control, but the power assist to these systems will
be lost. This will make it more difficult to steer and brake, so you should
pull over and stop the vehicle as soon as it is safe to do so.
NOTICE
To prevent battery discharge
Do not leave the “ENGINE START STOP” switch in ACCESSORY or
IGNITION ON mode for long periods without the engine running.
When starting the engine
Do not race a cold engine.
If the engine becomes difficult to start or stalls frequently, have the engine
checked immediately.

161
2-1. Driving procedures
2
When driving
IS250/220d/200d_EE
Automatic transmission
Select a shift position appropriate for the driving conditions.
Shifting the shift lever
While the “ENGINE START STOP” switch is in IGNI-
TION ON mode, depress the brake pedal and move the
shift lever.
Shift position uses
*: To improve fuel consumption and reduce noises, set the shift lever
Shift positionFunction
PParking the vehicle or starting the engine
RReversing
NNeutral
DNormal driving*
SS mode driving (P. 165)

: If equipped

166
2-1. Driving procedures
IS250/220d/200d_EE
When the “-” shift paddle switch is operated in the D position
When the “-” shift paddle switch is operated in the D position, a shift range
will be automatically selected. The highest gear of the first shift range will
be one gear lower than the gear in use during normal D position driving.
Automatic deactivation of shift range selection in the D position
Shift range selection in the D position will be deactivated in the following
situations:
When the vehicle comes to a stop
When range 6 is selected and the accelerator pedal is depressed
If the accelerator pedal is depressed for more than a certain period of
time
To protect automatic transmission
A function is adopted that automatically selects a higher shift range when
the fluid temperature is high.
Gear range display when driving
The current gear is displayed on the multi-information display. (P. 184)
Downshifting restrictions warning buzzer
To help ensure safety and driving performance, downshifting operation may
sometimes be restricted. In some circumstances, downshifting may not be
possible even when the shift lever or shift paddle switch is operated. (The
warning buzzer will sound twice.)
When driving with the cruise control system or dynamic radar cruise control
system
Engine braking will not occur during shift range selection in the D position
or S mode, even when downshifting to range 5 or 4. (P. 198, 202)
Snow mode automatic deactivation
Snow mode is automatically deactivated if the “ENGINE START STOP”
switch is turned off after driving in snow mode.
If the shift lever cannot be shifted from P
P. 5 1 4

170
2-1. Driving procedures
IS250/220d/200d_EE
Turn signal lever
Turn signals can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
If the indicators flash faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned
out.
Right turn
Left turn
Move and hold the lever
partway to signal a lane
change
The right hand signal will
flash until you release the
lever.
Move and hold the lever
partway to signal a lane
change
The left hand signal will flash
until you release the lever.

171
2
When driving
IS250/220d/200d_EE
2-2. Instrument cluster
Gauges and meters
The units used on the speedometer, tachometer and fuel gauge display
may differ depending on the model/type.
The following gauges, meters and display illuminate when the
“ENGINE START STOP” switch is in IGNITION ON mode.
Speedometer
Displays the vehicle speed.
Multi-information display
P. 181
Tachometer
Displays the engine speed in revolutions per minute.
Tacho indicator
When the set engine speed is reached, this ring-shaped indicator
comes on in yellow. The indicator comes on in red when the engine
speed reaches a dangerous range.
Engine coolant temperature gauge
Displays the engine coolant temperature.
