2012 Lexus IS220d key

88
1-4. Opening and closing the windows and moon roof
IS250/220d/200d_EE
Door lock linked window operation
The power windows can be opened and closed using the mechanical key.
(P. 516)
The power windows can be closed using the entry function. (P. 3 8 )
Customization that can be configured at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional
Settings (e.g. linked door lock operation) can be changed.
(Customizable features P. 556)
CAUTION
Closing the windows
Observe the following precautions.
Failing to do so may result in death or serious injury.
Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.
Do not allow children to operate the power windows.
Closing a power window on someone can cause serious injury, and in
some instances, even death.
Jam protection function
Never try jamming any part of your body to activate the jam protection
function intentionally.
The jam protection function may not work if something gets caught just
before the window fully closes.

90
1-4. Opening and closing the windows and moon roof
IS250/220d/200d_EE
The moon roof can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
Moon roof open warning buzzer
The buzzer sounds and a message is shown on the multi-information display
in the instrument panel when the “ENGINE START STOP” switch is turned
OFF and the driver's door is opened with the moon roof open.
Door lock linked moon roof operation
The moon roof can be opened and closed using the mechanical key. (P.
516)
The moon roof can be closed using the entry function. (P. 3 8 )
Operating the moon roof after turning the “ENGINE START STOP” switch
OFF
The moon roof can be operated for approximately 45 seconds even after the
“ENGINE START STOP” switch is switched to ACCESSORY mode or
turned OFF. It cannot, however, be operated once either front door is
opened.
Jam protection function
If an object is detected between the moon roof and the frame while closing
or tilting down, travel is stopped and the moon roof opens slightly.
To reduce moon roof wind noise
When the moon roof is opened automatically, it will stop slightly before the
fully open position. Driving with the moon roof in this position can help
reduce wind noise.
Sunshade
The sunshade can be opened and closed manually. However, the sunshade
will open automatically when the moon roof is opened.

96
IS250/220d/200d_EE
1-6. Theft deterrent system
Engine immobilizer system
System maintenance
The vehicle has a maintenance-free type engine immobilizer system.
Conditions that may cause the system to malfunction
If the key is in contact with a metallic object
If the key is in close proximity to or touching a key to the security sys-
tem (key with a built-in transponder chip) of another vehicle
The vehicle's keys have built-in transponder chips that prevent the
engine from starting if the key has not been previously registered in
the vehicle's on-board computer.
Never leave the keys inside the vehicle when you leave the vehicle.
The indicator light flashes
after the “ENGINE START
STOP” switch has been
turned OFF to indicate that
the system is operating.
The indicator light stops
flashing after the “ENGINE
START STOP” switch has
been turned to ACCESSORY
or IGNITION ON mode to
indicate that the system has
bld

104
1-6. Theft deterrent system
IS250/220d/200d_EE
Unexpected triggering of the alarm
In the following situations, perform an operation that will deactivate or stop
the alarm. (P. 102)
The battery is disconnected. (some models)
Alarm-operated door lock
When the alarm is operating, the doors are locked automatically to pre-
vent intruders.
Do not leave the key inside the vehicle when the alarm is operating, and
make sure the key is not inside the vehicle when recharging or replacing
the battery.
The doors or trunk are unlocked using
the mechanical key.
When someone without a key is left in
the vehicle and the doors are locked.
When a door, the trunk or hood is
opened from inside the vehicle, the
alarm may be triggered.
When the battery is recharged or
replaced, due to battery discharge and
so forth, after locking the doors.
(some models)
The alarm may be activated when the
hood is opened and the battery is recon-
nected after the mechanical key has
been used to unlock the doors.

105
1-6. Theft deterrent system
1
Before driving
IS250/220d/200d_EE
Canceling the intrusion sensor
The alarm will be set even when the intrusion sensor is canceled.
To re-enable the intrusion sensor, press the “ENGINE START STOP”
switch or unlock the doors using the wireless remote door lock function
while the intrusion sensor is canceled.
Automatic re-enabling of the intrusion sensor
When the alarm system is set again, the intrusion sensor will also be set.
Intrusion sensor
The sensor may trigger the alarm in the following situations. Before locking
the doors, turn off the intrusion sensor. (P. 103)
Persons or pets are in the vehicle.
Unstable items, such as dangling accessories or clothes hanging on the
coat hooks, are in the vehicle.
The windows or moon roof are open.
The vehicle is parked in a place where extreme vibration or noises occur,
such as in a parking garage.
The vehicle is inside an automatic or high-pressure car wash.
The vehicle experiences impacts, such as hail, lightning strikes, or other
kinds of repeated impacts or vibrations.
Ice or snow is removed from the vehicle, causing the vehicle to receive
repeated impacts or vibrations.
The wind or something similar causes an externally mounted reflectively
coated windshield cover to move.
When the battery is disconnected
Be sure to deactivate the alarm system.
If the battery is disconnected before deactivating the alarm system, the
alarm may be triggered when the battery is reconnected.
When using the mechanical key to unlock the doors or trunk
Deactivate the alarm.
If the doors or trunk are unlocked using the mechanical key with the alarm
operational, the alarm will be triggered.

125
1-7. Safety information
1
Before driving
IS250/220d/200d_EEKey of letters inserted in the above table:
U: Suitable for “universal” category child restraint system
approved for the use in this mass group.
L1: Suitable for “LEXUS BABY-SAFE (0 to 13 kg [0 to 28 lb.])”
approved for the use in this mass group.
L2: Suitable for “LEXUS DUO+ (without ISOFIX, 9 to 18 kg [20
to 39 lb.])” approved for the use in this mass group.
L3: Suitable for “LEXUS KID (15 to 36 kg [34 to 79 lb.])”
approved for the use in this mass group.
X: Not suitable seat position for children in this mass group.
The child restraint systems mentioned in the table may not be
available outside of the EU area.
Other child restraint systems different from the systems mentioned
in the table can be used, but the suitability of the systems must be
carefully checked with the child restraint system manufacturer and
retailer.

127
1-7. Safety information
1
Before driving
IS250/220d/200d_EE(1) For CRS which do not carry the ISO/XX size class identifica-
tion (A to G), for the applicable mass group, the car manufac-
turer shall indicate the vehicle specific ISOFIX child restraint
system(s) recommended for each position.
Key of letters inserted in the above table:
IUF:Suitable for ISOFIX forward child restraints systems of uni-
versal category approved for use in this mass group.
X: ISOFIX position not suitable for ISOFIX child restraint sys-
tems in this mass group and/or this size class.
The child restraint systems mentioned in the table may not be
available outside of the EU area.
Other child restraint systems different from the systems mentioned
in the table can be used, but the suitability of the systems must be
carefully checked with the child restraint system manufacturer and
retailer.

141
1-7. Safety information
1
Before driving
IS250/220d/200d_EEInsert the mechanical key into
the cylinder and rotate to the
“OFF” position.
The “OFF” indicator turns on.
(Only when the “ENGINE
START STOP” switch is in
IGNITION ON mode.)
“PASSENGER AIRBAG” indicator information
If any of the following problems occurs, it is possible that there is a mal-
function in the system. Have the vehicle inspected by any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional.
Neither “ON” nor “OFF” comes on.
The indicator does not change when the airbag manual on-off switch is
switched to “ON” or “OFF”.
CAUTION
When installing a child restraint system
For safety reasons, always install the child restraint system in a rear seat. In
the event that the rear seat cannot be used, the front seat can be used as long
as the airbag manual on-off system is set to off.
If the airbag manual on-off system is left on, the strong impact of the airbag
deployment (inflation) may cause serious injury or even death.
When a child restraint system is not installed on the front passenger seat
Ensure that the airbag manual on-off system is set to on.
If it is left off, the airbag may not deploy in the event of an accident, which
may result in serious injury or even death.
