2012 Lexus GS350 CD player

5415-3. Using the audio system
5
Interior features
GS350/250_EE (OM30C36E)Press to select the DVD player.
Press “” or “” on to select a chapter.
MP3 disc or WMA disc
Press to select the DVD player.
Press “” or “” on to select a folder.
Press “” or “” on to select a file.
USB memory
Press to select the USB memory.
Press “” or “” on to select a folder.
Press “” or “” on to select a file.
Selecting a chapter (DVD video mode)
Selecting a file
1
2
1
2
3
1
2
3

5425-3. Using the audio system
GS350/250_EE (OM30C36E)
Fast forwarding or rewinding a chapter or file
Press and hold “” or “” on .
Button lock function
To prevent inadvertent operation, some buttons on the rear armrest can be
locked. (P. 429)
Rear control panel illumination off function
Control panel illumination on the rear armrest can be turned off. (P. 429)
When “ERROR”, “WAIT” or “NO MUSIC” is shown on the display
Refer to the following and take the appropriate measures. If the problem is
not rectified, take the vehicle inspected by any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional.
“ERROR”:This indicates a trouble either in the disc or inside the player. The
disc may be dirty, damaged, or inserted up-side down.
“WAIT”:Operation is stopped due to a high temperature inside the player.
Eject the disc and allow the player to cool down.
“NO MUSIC”:This indicates that an MP3/WMA file is not included in the
disc.

6015-4. Using the hands-free phone system (for cellular phone)
5
Interior features
GS350/250_EE (OM30C36E)
Setting the Bluetooth®
Registered devices
Connect telephone
Connect portable player
Detailed Bluetooth
® settings
Communication settings
To display the screen shown above, press the “MENU” button on
the Remote Touch, then select “Setup”, select “Bluetooth
*” on the
“Setup” screen.
*: Bluetooth is a registered trademark of Bluetooth SIG. Inc.
You can confirm and change the Bluetooth® settings.
1
2
3
4
15

6025-4. Using the hands-free phone system (for cellular phone)
GS350/250_EE (OM30C36E)
Registering a Bluetooth® devices
Bluetooth
® devices compatible with phones (HFP) and portable
players (AVP) can be registered simultaneously. Phones (HFP)
and portable players (AVP) (maximum of 5) can be registered.
Display the “Bluetooth
*” screen. (P. 601)
Select “Registered devices” on the “Bluetooth
*” screen.
Select “Add new” to regis-
ter a Bluetooth
® device to
the system.
When 5 Bluetooth® devices
have already been registered, a
registered device needs to be
deleted.
Select “Yes” to delete one or
more.
Select the device to be deleted,
then select “Remove”, and then
“Yes”.
*: Bluetooth is a registered trademark of Bluetooth SIG. Inc.
Registered devices
1
2
3

6055-4. Using the hands-free phone system (for cellular phone)
5
Interior features
GS350/250_EE (OM30C36E)Select the device to be
edited.
Select “Device name”.
Input the device name, and
select “OK”.
Confirm the device name and select “OK”.
Setting portable player connection method
Display the “Bluetooth
*” screen. (P. 601)
Select “Registered devices” on the “Bluetooth
*” screen.
Select “Details” on the “Registered devices” screen.
Select the device to be edited.
*: Bluetooth is a registered trademark of Bluetooth SIG. Inc.
4
5
6
7
1
2
3
4

6065-4. Using the hands-free phone system (for cellular phone)
GS350/250_EE (OM30C36E)Select “Connect portable
player from”.
Select the desired connec-
tion method, and select
“OK”.
“Vehicle”: Select to connect the
audio system to the portable
player.
“Portable player”: Select to con-
nect the portable player to the
audio system.
Depending on the portable
player, the “Vehicle” or “Porta-
ble player” connection method
may be best. As such, refer to
the manual that comes with the
portable player.
5
6

6075-4. Using the hands-free phone system (for cellular phone)
5
Interior features
GS350/250_EE (OM30C36E)
Editing the “Device name”
If you change a device name, the name registered in your cellular phone is
not changed.
About “Device address”
The address peculiar to the system. It cannot be changed. If you have regis-
tered two Bluetooth
® phones with the same device name and you cannot dis-
tinguish one from the other, refer to this address.
“My telephone no.”:
The phone number of the Bluetooth
® phone is displayed on the screen.
Depending on the type of phone, the phone number may not be displayed.
“Profiles”:
The compatibility profile of the Bluetooth
® device is displayed on the screen.
“Connect portable player from”:
There are 2 portable player connection settings available; “Vehicle” and
“Portable Player”.
When you delete a Bluetooth® phone
The phonebook data will be deleted at the same time.

6095-4. Using the hands-free phone system (for cellular phone)
5
Interior features
GS350/250_EE (OM30C36E)If multiple portable players are registered, follow the procedure
below to select the portable player to be used. You can only use one
portable player at a time.
Display the “Bluetooth
*” screen. (P. 601)
Select “Connect portable player” on the “Bluetooth
*” screen.
Choose the portable player
to be used.
The Bluetooth® mark is dis-
played when you connect the
portable player.
If a completion message is dis-
played, connection is complete.
*: Bluetooth is a registered trademark of Bluetooth SIG. Inc.
When another Bluetooth® device is connected during registering or selecting
a portable player
When another Bluetooth® device is connected, a confirmation message will
be displayed. If you want to disconnect it, select “Yes”.
The currently connected portable player’s screen button will have a Blue-
tooth® mark displayed on it. If the currently connected portable player’s
screen button is selected, the portable player can be disconnected. Select
“Yes” to disconnect.
Selecting a portable player
1
2
3
