1603-3. Adjusting the seats
GS350/250_EE (OM30C36E)
CAUTION
Operating the front passenger’s seat from the driver’s seat (if equipped)
Do not operate the front passenger’s seat when a passenger is seated in it. In
addition, do not let anyone sit down in the front passenger’s seat while the
seat is being operated. The front passenger may catch their legs between the
instrument panel and seat, resulting in injury.
When adjusting the seat positions or the calf support (if equipped)
Make sure to leave enough space around the feet so they do not get stuck.
When using the calf support (if equipped)
Do not operate the calf support when the vehicle is moving.
Failure to do so may cause death or serious injury in the event of sudden
braking or a collision.
Do not sit on the calf support of the passenger seat.
Doing so may cause seat belts to be worn improperly, which may lead to
serious injury or death in the event of sudden braking or a collision.
Do not step on the calf support.
Doing so could damage the calf support, or could cause you to seriously
injure yourself by falling over.
Stow the calf support when you get in or out of the vehicle or when the
calf support is not in use to avoid stumbling over it.
Do not allow anyone to put their hands or feet under the passenger seat
when stowing the calf support.

161
3 3-3. Adjusting the seats
Operation of each component
GS350/250_EE (OM30C36E)
NOTICE
Operating the front passenger’s seat from the driver’s seat (if equipped)
Before operating the front passenger’s seat, make sure that there is no lug-
gage or any other objects on the seat or in the footwell that could prevent its
operation.
Such items may result in excess force being applied, causing damage to the
seat and/or the luggage.
To prevent a calf support malfunction (if equipped)
Do not place any objects in the front passenger footwell that could prevent
the operation of the calf support.
Do not place heavy luggage on the calf support.
Do not place anything under the calf support when in use.
There is a possibility that something may get caught and cause damages
when stowing the calf support.

1633-3. Adjusting the seats
3
Operation of each component
GS350/250_EE (OM30C36E)Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Press button “1”, “2” or “3” to
recall the desired position.
Vehicles with front passenger’s
seat calf support:
The memorized position will only
be recalled if the calf support is in
a position higher than the memo-
rized position. It will not move in
an upward direction.
When you want to stop the position recall operation part-way through
Perform any of the following operations:
Press the “SET” button.
Press button “1”, “2” or “3”.
Adjust the seat using the switches (only cancels seat position recall).
The adjusted positions that can be memorized
Vehicles without seatback side support adjustment switch
The adjusted positions other than the position adjusted by lumber support
switch can be memorized.
Vehicles with seatback side support adjustment switch
All adjusted positions can be memorized.
Automatic calf support adjustment
While the memorized position is being recalled, if it appears that the front
edge of the cushion will make contact with the area surrounding the instru-
ment panel, the calf support will be automatically stowed.
Recalling the memorized position
1
2
3

1663-3. Adjusting the seats
GS350/250_EE (OM30C36E)The auto away/return function
enables easy access by activating
when the driver or front passen-
ger attempts to enter or exit the
vehicle.
Auto away function when exiting the vehicle (driver’s/front pas-
senger’s seat)
Driver’s seat
When all of the following actions have been performed, the
steering wheel will move up and back to the point farthest away
from the driver and the seat will move backward:
• The shift lever has been shifted to P.
• The engine switch has been turned off.
• The driver’s seat belt has been unfastened.
Front passenger’s seat (if equipped)
If the lumbar support, calf support (if equipped), etc. of the front
passenger’s seat has been adjusted, the seat will return to its orig-
inal state if the front passenger’s door is opened while the vehicle
is stopped to allow easy exit from the vehicle.
Auto return function when entering the vehicle (driver’s seat
only)
When either of the following actions has been performed, the
steering wheel will move toward the driver and seat will move
forward:
• The engine switch has been turned to ACCESSORY mode.
• The driver’s seat belt has been fastened.
Power easy access system

167
3 3-3. Adjusting the seats
Operation of each component
GS350/250_EE (OM30C36E)
When driving position memory is linked with door unlock operation
If the driver’s door is opened, the driver’s seat will move toward the memo-
rized position but stop slightly beforehand to allow easy access to the vehi-
cle.
Turning the engine switch to ACCESSORY or IGNITION ON mode, or fas-
tening the driver’s seat belt moves the seat fully into the memorized position.
Operating the driving position memory after turning the engine switch off
Driver’s seat:
Memorized seat positions can be activated up to 180 seconds after the
driver’s door is opened and another 60 seconds after it is closed again. Mem-
orized steering wheel position can be activated by pressing the engine switch.
Front passenger’s seat:
Memorized positions can be activated up to 180 seconds after the front pas-
senger’s door is opened by pressing button “1”, “2” or “3”.
Correct seat position
When the seat is in the most forward or most backward position, and the seat
is being moved in those directions, the system may not correctly recognize
the current position and the memorized position will not be correctly
recalled.
The auto away function for exiting the driver’s seat
If the seat is already close to the rearmost position, the auto away function
may not operate when the driver exits the vehicle.
Customization
The distance that the driver’s seat moves backward during the auto away
function can be changed. (Customizable features: P. 855)
CAUTION
Seat adjustment caution
Take care during seat adjustment so that the seat does not strike the rear
passenger or squeeze your body against the steering wheel.

1703-3. Adjusting the seats
GS350/250_EE (OM30C36E)
Adjusting the height of the head restraints
Adjusting the rear seat head restraint
Always raise the head restraint one level from the stowed position when
using. Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.
CAUTION
Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
Use the head restraints designed for each respective seat.
Adjust the head restraints to the correct position at all times.
After adjusting the head restraints, push down on them and make sure
they are locked in position.
Do not drive with the head restraints removed.

1703-4. Adjusting the steering wheel and mirrors
GS350/250_EE (OM30C36E)
Steering wheel
Operating the switch moves the steering wheel in the following
directions:
Up
Down
Toward the driver
Away from the driver
The steering wheel can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode
*.
*: If the driver’s seat belt is fastened, the steering wheel can be adjusted
regardless of engine switch mode.
Automatic adjustment of the steering position
A desired steering position can be entered to memory and recalled automati-
cally by the driving position memory system. (P. 162)
Power easy access system
The steering wheel and driver’s seat move in accordance with engine switch
mode and the driver’s seat belt condition. (P. 166)
Adjustment procedure
1
2
3
4
CAUTION
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an acci-
dent, resulting in death or serious injury.

1773-4. Adjusting the steering wheel and mirrors
3
Operation of each component
GS350/250_EE (OM30C36E)
Auto anti-glare function (if equipped)
When the anti-glare inside rear view mirror is set to automatic mode, the out-
side rear view mirrors will activate in conjunction with the anti-glare inside
rear view mirror to reduce reflected light. (P. 172)
Using automatic mode in cold weather
When automatic mode is used in cold weather, the door mirror could freeze
up and automatic stowing and return may not be possible. In this event,
remove any ice and snow from the door mirror, then either operate the mirror
using manual mode or move the mirror by hand.
CAUTION
Important points while driving
Observe the following precautions while driving.
Failure to do so may result in loss of control of the vehicle and cause an
accident, resulting in death or serious injury.
Do not adjust the mirrors while driving.
Do not drive with the mirrors folded.
Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.
When a mirror is moving
To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.
When the mirror defoggers are operating
Do not touch the rear view mirror surfaces, as they can become very hot
and burn you.
NOTICE
If the mirrors become iced up (vehicles with rain-clearing mirror)
In order to retain the rain-clearing properties of the mirror, do not attempt to
scrape the ice off. Instead, remove it by turning on the mirror defoggers or
by applying warm water.
