7907-2. Steps to take in an emergency
GS350/250_EE (OM30C36E)Turn the tire jack portion “A”
by hand until the notch of the
jack is in contact with the jack
point.
The jack point guides are located
under the rocker panel. They indi-
cate the jack point positions.
Raise the vehicle until the tire
is slightly raised off the
ground.
Remove all the wheel nuts and
the tire.
When resting the tire on the
ground, place the tire so that the
wheel design faces up to avoid
scratching the wheel surface.
Vehicles with a full-size spare
tire: Remove the wheel orna-
ment by pushing from the
reverse side.
3
4
5
6

7937-2. Steps to take in an emergency
7
When trouble arises
GS350/250_EE (OM30C36E)Firmly tighten each wheel nut
two or three times in the order
shown in the illustration.
Tightening torque:
103 N•m (10.5 kgf•m, 76 ft•lbf)
Vehicles with a full-size spare
tire: Reinstall the wheel orna-
ment.
Stow the flat tire, tire jack and all tools.
4
5
6

7947-2. Steps to take in an emergency
GS350/250_EE (OM30C36E)
The compact spare tire
The compact spare tire is identified by the label “TEMPORARY USE
ONLY” on the tire sidewall.
Use the compact spare tire temporarily, and only in an emergency.
Make sure to check the tire inflation pressure of the compact spare tire.
(P. 850)
When using the compact spare tire
As the compact spare tire is not equipped with a tire pressure warning valve
and transmitter, low inflation pressure of the spare tire will not be indicated
by the tire pressure warning system. Also, if you replace the compact spare
tire after the tire pressure warning light comes on, the light remains on.
When the compact spare tire is equipped
The vehicle becomes lower when driving with the compact spare tire com-
pared to when driving with standard tires.
If you have a flat rear tire on a road covered with snow or ice (vehicles with
front and rear tires of the same size and compact spare tire only)
Install the compact spare tire on one of the front wheels of the vehicle. Per-
form the following steps and fit tire chains to the rear tires:
Replace a front tire with the compact spare tire.
Replace the flat rear tire with the tire removed from the front of the vehicle.
Fit tire chains to the rear tires.
1
2
3

8127-2. Steps to take in an emergency
GS350/250_EE (OM30C36E)
In the following cases, the tire cannot be repaired with the emergency tire
puncture repair kit. Contact any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional.
When the tire is damaged due to driving without sufficient air pressure
When the tire lost air pressure due to a crack or damage in the tire sidewall
When the tire is visibly separated from the wheel
When the cut or damage to the tread is 4 mm (0.16 in.) long or more
When the wheel is damaged
When two or more tires have been punctured
When there is more than one hole or cut in the damaged tire
Emergency tire puncture repair kit
The sealant has a limited lifespan. The expiry date is marked on the bottle.
The sealant should be replaced before the expiry date. Contact any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional for replacement.
The sealant stored in the emergency tire puncture repair kit can be used only
once to temporarily repair a single tire. If the sealant in the bottle and other
parts of the kit have been used and need to be purchased, contact any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional.
The sealant can be used when the outside temperature is from -30 C (-22
F) to 60 C (140 F).
The kit is exclusively designed for size and type of tires originally installed
on your vehicle. Do not use it for tires that a different size than the original
ones, or for any other purposes.
If the sealant gets on your clothes, it may stain.
If the sealant adheres to a wheel or the surface of the vehicle body, the stain
may not be removable if it is not cleaned at once. Immediately wipe away
the sealant with a wet cloth.
During operation of the kit, a loud operation noise is produced. This does
not indicate a malfunction.

8508-1. Specifications
GS350/250_EE (OM30C36E)
Type A
*: 5 passengers and full loaded
Type B
Tires and wheels
Tire size225/50R17 94W
Tire inflation
pressure
(Recommended
cold tire inflation
pressure)
Vehicle speed
Front wheel
kPa (kgf/cm2
or bar, psi)
Rear wheel
kPa (kgf/cm2
or bar, psi)
More than 210 km/
h
(132 mph)270 (2.7, 39)*
250 (2.5, 36)
290 (2.9, 42)*
250 (2.5, 36)
From 160 km/h
(100
mph) to 210 km/h
(132 mph)
230 (2.3, 33)
240 (2.4, 35)*
230 (2.3, 33)
160 km/h
(100 mph)
or less
230 (2.3, 33)
Wheel size17  7 1/2J
Wheel nut torque103 N•m (10.5 kgf•m, 76 ft•lbf)
Tire size235/45R18 94Y
Tire inflation
pressure
(Recommended
cold tire inflation
pressure)
Vehicle speed
Front wheel
kPa (kgf/cm2
or bar, psi)
Rear wheel
kPa (kgf/cm2
or bar, psi)
More than 210 km/
h
(132 mph)
230 (2.3, 33)
250 (2.5, 36)*
230 (2.3, 33)
From 160 km/h
(100
mph) to 210 km/h
(132 mph)
230 (2.3, 33)
160 km/h (100
mph)
or less

851
8 8-1. Specifications
Vehicle specifications
GS350/250_EE (OM30C36E)
*: 5 passengers and full loaded
Wheel size18  8J
Wheel nut torque103 N•m (10.5 kgf•m, 76 ft•lbf)

8528-1. Specifications
GS350/250_EE (OM30C36E)
Type C
*: 5 passengers and full loaded
Compact spare tire
When towing a trailer
Add 20.0 kPa (0.2 kgf/cm
2 or bar, 3 psi) to the recommended tire inflation
pressure and drive at speeds below 100 km/h (62 mph).
Tire size235/40R19 96Y XL, 265/35R19 94Y
Tire inflation
pressure
(Recommended
cold tire inflation
pressure)
Vehicle speed
Front wheel
kPa (kgf/cm2
or bar, psi)
Rear wheel
kPa (kgf/cm2
or bar, psi)
More than 210 km/
h
(132 mph)250 (2.5, 36)*
240 (2.4, 35)
250 (2.5, 36)
From 160 km/h
(100
mph) to 210 km/h
(132 mph)
240 (2.4, 35)
160 km/h (100
mph)
or less
Wheel size19  8J (235/40R19), 19  9J (265/35R19)
Wheel nut torque103 N•m (10.5 kgf•m, 76 ft•lbf)
Tire sizeT155/70D17 110M, T145/70D18 107M
Tire inflation pressure
(Recommended cold
tire
inflation pressure)
420 kPa (4.2 kgf/cm2 or bar, 60 psi)
Wheel size17  4T (T155/70D17), 18  4T (T145/70D18)
Wheel nut torque103 N•m (10.5 kgf•m, 76 ft•lbf)
