359
4-1. Maintenance and care
4
Maintenance and care
ES350_U
■Aluminum wheels
●Remove any dirt immediately by using a neutral detergent. Do not use hard
brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners.
Use the same mild detergent and wax as used on the paint.
●Do not use detergent on the wheels when they are hot, for example after driving
for long distance in the hot weather.
●Wash detergent from the wheels immediately after use.
■Bumpers and side moldings
Do not scrub with abrasive cleaners.
CAUTION
■When cleaning the windshield
●When the upper part of the windshield where the raindrop sensor is located is
touched by hand
●When a wet rag or similar is held close to the raindrop sensor
●If something bumps against the windshield
●If you directly touch the raindrop sensor body or if something bumps into the
raindrop sensor
■Caution about the exhaust pipe
Exhaust gasses cause the exhaust pipe to become quite hot.
When washing the vehicle, be careful not to touch the pipe until it has cooled suffi-
ciently, as touching a hot exhaust pipe can cause burns.
Set the wiper switch to off.
If the wiper switch is in “AUTO”, the wipers
may operate unexpectedly in the following
situations, and may result in hands being
caught or other serious injuries and cause
damage to the wiper blades.
Off
416
4-3. Do-it-yourself maintenance
ES350_U
15ECU-IG NO. 110 A
Moon roof, seat heaters, power win-
dows, clock, automatic windshield
wiper, electric cooling fans, driving
position memory system, seat position
memory system
16ECU-IG NO. 27. 5 A
Anti-lock brake system, vehicle stabil-
ity control system, traction control sys-
tem, brake assist system, cruise
control system, stop lights, shift lock
control system
17A/C NO. 210 AAir conditioning system, rear window
defogger
18WA S H10 AWindshield washer
19S-HTR20 ASeat heaters, air conditioning system
20GAUGE NO. 110 AEmergency flashers, back-up lights,
rear sunshade, charging system
21WIP25 AWindshield wipers
22H-LP LVL7. 5 AHeadlight leveling system
23IGN10 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, SRS airbag system, steering lock
system
24GAUGE NO. 27. 5 AMeters
25ECU-ACC7. 5 AClock, main body ECU
26CIG20 ACigarette lighter
27PWR OUTLET20 APo w e r o u t l e t
28RADIO NO. 27. 5 AAudio system
29MIR HTR15 AOutside rear view mirror defoggers
FuseAmpereCircuit
456
5-2. Steps to take in an emergency
ES350_U*: Refer to the separate “Scheduled maintenance” or “Owner’s Manual
Supplement” for the maintenance interval applicable to your vehicle.
Wa r n i n g m e s s a g eDetailsCorrection procedure
(Flashing and then con-
tinuously on)
(Flashing)
(If equipped)
Indicates that the radar
cruise control system is
unable to judge vehicle-
to-vehicle distance
because the windshield
wipers are set at high
speed operation mode. A buzzer also sounds.
Turn them off or set them
to either the intermittent
or the slow mode.
(Flashing)
(If equipped)
Indicates that your vehi-
cle is nearing the vehicle
ahead (in radar cruise
mode). A buzzer also sounds.
Slow the vehicle by apply-
ing the brakes.
Indicates one or more
stop lights are burned
out.Have the defective bulbs
replaced by your Lexus
dealer.
549
Alphabetical index
ES350_U
Warning messagesDynamic radar
cruise control .......................450, 452
Engine oil level .................................... 452
Engine oil maintenance.................. 452
Engine oil pressure........................... 449
Hood ....................................................... 452
Intuitive parking assist
sensor ......................................450, 452
Moon roof............................................. 452
Open door ........................................... 452
Parking brake ...................................... 452
Pre-collision system .............450, 452
Smart access system with
push-button start............................ 458
Steering lock ........................................ 450
Trunk ........................................................ 452
Washer fluid......................................... 452 Washer
Checking .............................................. 389
Preparing and checking before winter ..................................... 196
Switch........................................................ 156
Washing and waxing .......................... 358
Weight Cargo capacity .....................................192
Load limits .............................................. 195
Weight.................................................... 486
Wheels ......................................................403
Window glasses ...................................... 70
Window lock switch ............................... 70
Windows Power windows ..................................... 70
Rear window defogger.....................213
Washer .................................................... 156
Windshield wipers
Position..................................................... 199
Windshield wipers ............................. 156
Wireless remote control key Replacing the battery.......................407
Wireless remote control key ..........40
WMA disc* .............................................. 231
*: For vehicles with a navigation system, refer to the “Navigation System Owner’s Manual”.
