2012 Lexus CT200h Reverse

212
2-1. Driving procedures
CT200h_OM_OM76067E_(EE)
In addition, if an attempt is made to change the shift position by moving the
shift lever in any of the following situations, the buzzer will sound and the
shifting operation will be disabled or the shift position will automatically
change to N. When this happens, select an appropriate shift position.
Situations where the shifting operation will be disabled:
• When an attempt is made to change the shift position from P to another
position by moving the shift lever without depressing the brake pedal.
• When an attempt is made to change the shift position from P or N to B
by moving the shift lever.
Situations where the shift position will automatically change to N:
• When the P position switch is pressed while the vehicle is running.
*1
• When an attempt is made to select the R position by moving the shift
lever when the vehicle is moving forward.
*2
• When an attempt is made to select the D position by moving the shift
lever when the vehicle is moving in reverse.
*3
• When an attempt is made to change the shift position from R to B by
moving the shift lever.
*1: Shift position may be changed to P when driving at extremely low
speeds.
*2: Shift position may be changed to R when driving at low speeds.
*3: Shift position may be changed to D when driving at low speeds.
Reverse warning buzzer
When shifting into R, a buzzer will sound to inform the driver that the shift
position is in R.

213
2-1. Driving procedures
2
When driving
CT200h_OM_OM76067E_(EE)
About engine braking
When shift position B is selected, releasing the accelerator pedal will apply
engine braking.
• When the vehicle is driven at high speeds, compared to ordinary gaso-
line-fueled vehicles, the engine braking deceleration is felt less than that
of other vehicles.
• The vehicle can be accelerated even when shift position B is selected.
If the vehicle is driven continuously in the B position, fuel efficiency will
become low. Usually, select the D position.
When driving with cruise control or dynamic radar cruise control activated
Even if switching the driving mode to sport mode with the intent of enabling
engine braking, engine braking will not activate because cruise control or
dynamic radar cruise control will not be canceled.
Automatically P position selection function
When the shift position is in a position other than P, pressing the “POWER”
switch with the vehicle stopped completely will cause the shift position to
change to P automatically, and then the “POWER” switch will turn off.
If the shift position cannot be shifted from P
There is a possibility that the 12-volt battery is discharged. Check the 12-
volt battery in this situation. (P. 633)
Sport mode automatic deactivation
Sport mode is automatically deactivated if the “POWER” switch is turned
off after driving in sport mode.
After recharging/reconnecting the 12-volt battery
P. 5 1 1
Customization
Settings (e.g. Reverse warning buzzer) can be changed.
(Customizable features P. 667)

282
2-4. Using other driving systems
CT200h_OM_OM76067E_(EE)
Rear view monitor system
: If equipped
Switching the screen
The rear view monitor system assists the driver by displaying an
image of the view behind the vehicle while reversing. The image is
displayed in reverse on the screen. This allows the image to appear in
the same manner as that of the rear view mirror.
The rear view image is dis-
played when the shift posi-
tion is in R and the
“POWER” switch is in ON
mode.
This reversed image is a sim-
ilar image to the one on the
inside rear view mirror.
If you shift the shift position
to any positions other than R,
To temporarily turn off the monitor
when it is on.
Push the “AUTO” button. The indica-
tor should turn orange.
The monitor will automatically turn on
again after the “POWER” switch is
turned OFF and ON.
To manually turn on the monitor when
it is turned off.
Push the “AUTO” button. The indica-
tor should turn green.

345
3-2. Using the audio system
3
Interior features
CT200h_OM_OM76067E_(EE)
Selecting, fast-forwarding and reversing tracks
Selecting a track
Press “” to move up or “” to move down using
until the desired track number appears on the displayed.
Fast-forwarding and reversing tracks
To fast-forward or reverse, press and hold “”or “” on
until you hear a beep.
Selecting a CD (type B)
To select the desired CD, press or .
Playing and pausing tracks (type B)
To play or pause a track, press .
Random playback
Current CD
Press .
Songs are played in random order.
To cancel, press again.
All CDs (type B)
Press and hold until you hear a beep.
Tracks on all loaded CDs are played in random order.
To cancel, press again.

352
3-2. Using the audio system
CT200h_OM_OM76067E_(EE)
Loading and ejecting MP3 and WMA discs
P. 343, 344
Selecting MP3 and WMA discs
P. 345
Selecting a folder
Selecting a folder one at a time
Press or to select the desired folder.
Returning to the first folder
Press and hold until you hear a beep.
Fast-forwarding and reversing files
To fast-forward or reverse, press and hold “”or “” on
until you hear a beep.
Selecting files
Turn or press “”or “” on to select the
desired file.

5
605
5-2. Steps to take in an emergency
When trouble arises
CT200h_OM_OM76067E_(EE)Lower the vehicle.
Firmly tighten each wheel nut
two or three times in the order
shown in the illustration.
Tightening torque:
103 N•m (10.5 kgf•m, 76 ft•lbf)
Stow the flat tire, tire jack and all tools.
Stowing the flat tire
Vehicles with a 16 or 17 inch
wheel: Before stowing the flat
tire, remove the center wheel
ornament by pushing from the
reverse side.
STEP3
STEP4
STEP5
STEP1

5
635
5-2. Steps to take in an emergency
When trouble arises
CT200h_OM_OM76067E_(EE)
Start the engine of the second vehicle. Increase the
engine speed slightly and maintain at that level for
approximately 5 minutes to recharge the battery of your
vehicle.
Open and close any of the doors of your vehicle with the
“POWER” switch off.
Maintain the engine speed of the second vehicle and start
the hybrid system of your vehicle by turning the
“POWER” switch to ON mode.
Make sure the “READY” indicator light comes on. If the
indicator light does not come on, contact any authorized
Lexus dealer or repairer, or another duly qualified and
equipped professional.
Once the hybrid system has started, remove the jumper
cables in the exact reverse order from which they were
connected.
To install the engine cover, conduct the removal proce-
dure in reverse. After installing, check that the fixed pins
are inserted securely.
Once the hybrid system starts, have the vehicle inspected at any
th i d L d l i th d l lifi dSTEP4
STEP5
STEP6
STEP7
STEP8
STEP9

685
6-2. Customization
6
Vehicle specifica-
CT200h_OM_OM76067E_(EE)
*1: If equipped
*2: Interior or exterior illumination can be set separately.
*3: Except when using the cruise control or dynamic radar cruise control.
*4: Refer to the “Navigation System Owner’s Manual”.
*5: This function cannot be customized unless power window operation
using the wireless remote control is enabled.
Seat belt
reminder
(
P. 575)
Vehicle speed
linked seat belt
reminder
buzzer
OnOff–––O
Reverse
buzzer
(
P. 212)
Signal
(buzzer) when
the shift posi-
tion is in R
IntermittentSingle–––O
Outside
rear view
mirrors
(
P. 1 1 8 )
Automatic
folding/
extending
operationLinked to
locking/
unlocking
of the doorsOff
–––O
Linked to
“POWER”
switch opera-
tion
ItemFunctionDefault
settingCustomized
setting
