2012 Lexus CT200h remote control

85
1-3. Opening, closing and locking the doors
1
Before driving
CT200h_OM_OM76067E_(EE)
Operation signals
Doors: The emergency flashers flash to indicate that the doors have been
locked/unlocked. (Locked: Once; Unlocked: Twice)
Windows:A buzzer sounds to indicate that the windows are opening.
Door lock buzzer
If an attempt to lock the doors is made when a door is not fully closed, a
buzzer sounds continuously for 10 seconds. Fully close the door to stop the
buzzer, and lock the vehicle once more.
Security feature
If a door is not opened within approximately 30 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.
Alarm (if equipped)
Using the wireless remote control to lock the doors will set the alarm sys-
tem.
(P. 142)

86
1-3. Opening, closing and locking the doors
CT200h_OM_OM76067E_(EE)
Conditions affecting operation
The smart entry & start system, push-button start system, wireless remote
control and immobilizer system use weak radio waves. In the following sit-
uations, the communication between the electronic key and the vehicle may
be affected, preventing the smart entry & start system, push-button start sys-
tem, wireless remote control and immobilizer system from operating prop-
erly.
(Ways of coping: P. 630)
When the electronic key battery is depleted
Near a TV tower, electric power plant, gas station, radio station, large
display, airport or other facility that generates strong radio waves or elec-
trical noise
When carrying a portable radio, cellular phone, cordless phone or other
wireless communication devices
When the electronic key is in contact with, or is covered by the follow-
ing metallic objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs
When other wireless key (that emit radio waves) is being used nearby
When carrying the electronic key together with the following devices
that emit radio waves
• Another vehicle’s electronic key or a wireless key that emits radio
waves
• Personal computers or personal digital assistants (PDAs)
• Digital audio players
• Portable game systems
If window tint with a metallic content or metallic objects are attached to
the rear window

87
1-3. Opening, closing and locking the doors
1
Before driving
CT200h_OM_OM76067E_(EE)
If the wireless remote control does not operate properly
Locking and unlocking the doors: Use the mechanical key. (P. 630)
Electronic key battery depletion
The standard battery life is 1 to 2 years. (The card key battery life is
about a year and a half.)
If the battery becomes low, an alarm will sound in the cabin when the
hybrid system stops. (P. 590)
As the electronic key always receives radio waves, the battery will
become depleted even if the electronic key is not used. The following
symptoms indicate that the electronic key battery may be depleted.
Replace the battery when necessary. (P. 527)
• The smart entry & start system or the wireless remote control does not
operate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.
To avoid serious deterioration, do not leave the electronic key within 1 m
(3 ft.) of the following electrical appliances that produce a magnetic
field:
•TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
• Induction cookers
• Table lamps
When the electronic key battery is fully depleted
P. 5 2 7
Customization
Settings (e.g. door unlocking function) can be changed.
(Customizable features P. 667)

88
1-3. Opening, closing and locking the doors
CT200h_OM_OM76067E_(EE)
CAUTION
When closing the windows using wireless remote control
Observe the following precautions. Failing to do so may result in death or
serious injury.
Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.
To prevent inadvertent power windows operation, never let a small child
have and use the wireless remote control.
Jam protection function
Never try jamming any part of your body to activate the jam protection
function intentionally.
The jam protection function may not work if something gets caught just
before the window fully closes.

89
1
1-3. Opening, closing and locking the doors
Before driving
CT200h_OM_OM76067E_(EE)
Side doors
The vehicle can be locked and unlocked using the entry function,
wireless remote control or door lock switch.
Entry function (if equipped)
P. 62
Wireless remote control
P. 84
Door lock switch
Locks all the doors
Unlocks all the doors
Inside lock buttons
Locks the door
Unlocks the door
The front doors can be
opened by pulling the inside
handle even if the lock but-
tons are in the lock position.

93
1
1-3. Opening, closing and locking the doors
Before driving
CT200h_OM_OM76067E_(EE)
Back door
When closing the back door
Lower the back door using the
back door handle, and make
sure to push the back door
down from the outside to close
it.
The back door can be locked/unlocked and opened by the following
procedures.
Locking and unlocking the back door
Entry function (if equipped)
P. 62
Wireless remote control
P. 84
Door lock switch
P. 89
Opening the back door from outside the vehicle
Raise the back door while
pushing up the back door
opener switch.

103
1-4. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
CT200h_OM_OM76067E_(EE)
Linking driving position memory with door unlock operation
(driver’s seat only)
Record your driving position to button 1, 2 or 3 before performing
the following:
Carry only the key (including the card key) to which you want to
link the driving position. If 2 or more keys are in the vehicle, the
driving position cannot be linked properly.
Close the driver’s door and turn the “POWER” switch to
OFF mode.
Press the desired button (1, 2 or
3) to recall the position. Then,
while keep pressing the button,
press the driver’s door lock
switches (either lock or unlock)
until the signal beeps.
The driving position is recalled
when the driver’s door is
unlocked using the entry func-
tion or wireless remote control
and the driver’s door is opened.
To prevent unintended triggering of the alarm, open and close a
door once after a driving position has been recorded. (If a door is
not opened within 30 seconds after door lock switch is pressed, the
doors will be locked again and the alarm will automatically be set.)
In case that the alarm is triggered, immediately stop the alarm.
(P. 143)
STEP1
STEP2

126
1-5. Opening and closing the windows and moon roof
CT200h_OM_OM76067E_(EE)
Door lock linked window operation
The power windows can be opened and closed using the mechanical
key.
*
(P. 630)
The power windows can be opened and closed using the wireless remote
control.
* (P. 8 4)
*:These settings must be customized at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional.
Customization
Setting (e.g. linked door lock operation) can be changed.
(Customizable features
P. 667)
CAUTION
Closing the windows
Observe the following precautions.
Failing to do so may result in death or serious injury.
Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.
Do not allow children to operate the power windows.
Closing a power window on someone can cause serious injury, and in
some instances, even death.
Jam protection function
Never use any part of your body to intentionally activate the jam protec-
tion function.
The jam protection function may not work if something gets caught just
before the window fully closes.
