Horn With Remote Start
When this feature is selected, a short horn sound will
occur when the RKE transmitter REMOTE START button
is pressed. To make your selection, press and release the
SELECT button until a check-mark appears next to the
feature showing the system has been activated or the
check-mark is removed showing the system has been
deactivated.
Flash Lamps With Lock
When this feature is selected, the front and rear turn
signals will flash when the doors are locked or unlocked
with the RKE transmitter. This feature may be selected
with or without the sound horn on lock feature selected.
To make your selection, press and release the SELECT
button until a check-mark appears next to the feature
showing the system has been activated or the check-mark
is removed showing the system has been deactivated.
Headlamp Off Delay
When this feature is selected, the driver can choose to
have the headlights remain on for 0, 30, 60, or 90 seconds
when exiting the vehicle. To make your selection, scroll
up or down until the preferred setting is highlighted,
then press and release the SELECT button until a check-
mark appears next to the setting, showing that the setting
has been selected.
Headlamps With Wipers (Available with Automatic
Headlamps Only)
When this feature is selected, and the headlight switch is
in the AUTO position, the headlights will turn on ap-
proximately 10 seconds after the wipers are turned on.
The headlights will also turn off when the wipers are
turned off if they were turned on by this feature. To make
your selection, press and release the SELECT button until
a check-mark appears next to the feature showing the
system has been activated or the check-mark is removed
showing the system has been deactivated.
320 UNDERSTANDING YOUR INSTRUMENT PANEL

WARNING! (Continued)
•Guard against carbon monoxide with proper
maintenance. Have the exhaust system inspected
every time the vehicle is raised. Have any abnor-
mal conditions repaired promptly. Until repaired,
drive with all side windows fully open.
•Keep the liftgate/trunk closed when driving your
vehicle to prevent carbon monoxide and other
poisonous exhaust gases from entering the vehicle.
ADDING FUEL
Fuel Filler Cap (Gas Cap)
The gas cap is located behind the locking fuel filler door,
on the driver’s side of the vehicle. If the gas cap is lost or
damaged, be sure the replacement cap is for use with this
vehicle.1. Press the fuel filler door release switch (located under
the headlamp switch).
2. Open the fuel filler door, and remove the fuel filler
cap.Fuel Filler Door Release Switch
440 STARTING AND OPERATING

▫Brake System....................... 494
▫Front/Rear Axle Fluid................. 496
▫Transfer Case....................... 497
▫Automatic Transmission............... 498
▫Appearance Care And Protection From
Corrosion.......................... 499
Fuses.............................. 504
▫Totally Integrated Power Module......... 504
Vehicle Storage....................... 510
Replacement Bulbs.................... 511
Bulb Replacement..................... 512
▫High Intensity Discharge Headlamps (HID) –
If Equipped........................ 512▫Halogen Headlamps – If Equipped........ 512
▫Front Turn Signal.................... 513
▫Front Fog Lamps.................... 513
▫Rear Tail, Stop, Turn Signal, And Backup
Lamps............................ 514
▫Rear Liftgate Mounted Tail Lamp......... 515
▫Center High-Mounted Stop Lamp
(CHMSL).......................... 516
▫Rear License Lamp................... 517
Fluid Capacities...................... 517
Fluids, Lubricants, And Genuine Parts....... 518
▫Engine............................ 518
▫Chassis........................... 519
470 MAINTAINING YOUR VEHICLE

Cavity Cartridge
FuseMini
FuseDescription
J10 30 Amp
PinkHeadlamp Wash
Relay Contact
J11 30 Amp
PinkDrive Train Control
Module
J12 30 Amp
PinkRear Defroster
J13 60 Amp
YellowMain Ignition Off
Draw (IOD)
J14 20 Amp
BlueTrailer Tow
Lamps/Park Lamps
J15 40 Amp
GreenFront Cabin Fan/
Blower
J17 40 Amp
GreenStarter Motor Sole-
noidCavity Cartridge
FuseMini
FuseDescription
J18 20 Amp
BluePowertrain Control
Module/Powertrain
Control Module
Transmission Range
J19 60 Amp
YellowRadiator Fan Motor
HI/Radiator Fan
Motor Low
J20 30 Amp
PinkFront Wiper
J21 20 Amp
BlueFront/Rear Washer
Control
J22 25 Amp
NaturalSunroof Module
M1 15 Amp
BlueStop Lamps
506 MAINTAINING YOUR VEHICLE

•Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
ensure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
REPLACEMENT BULBS
Interior Lights Bulb Type
Glove Box Lamp......................... 194
Grab Handle Lamp................L002825W5W
Overhead Console Reading Lamps.........VT4976
Rear Cargo Lamp.......................214–2
Visor Vanity Lamp.....................V26377
Underpanel Courtesy Lamps................ 906
Instrument Cluster (General Illumination)....... 103
Telltale/Hazard Lamp...................... 74Exterior Lights Bulb Type
Backup Lamps.........................3157K
Front Park/Turn Lamp...................3757A
Front Fog Lamps........................9145
Front Side Marker...................... W5W
Headlamps (Low Beam) – High Intensity Discharge
(HID)................................ D1S
(Serviced at Authorized Dealer)
Headlamps (Low Beam)...................9006
Headlamps (High Beam)..................9005
Rear Turn/Stop/Tail Lamps...............3157K
NOTE:Numbers refer to commercial bulb types that
can be purchased from your authorized dealer.
If a bulb needs to be replaced, visit your authorized
dealer or refer to the applicable Service Manual.
7
MAINTAINING YOUR VEHICLE 511

BULB REPLACEMENT
High Intensity Discharge Headlamps (HID) – If
Equipped
The headlamps are a type of high voltage discharge tube.
High voltage can remain in the circuit even with the
headlamp switch off and the key removed.Because of
this, you should not attempt to service a headlamp bulb
yourself. If a headlamp bulb fails, take your vehicle to
an authorized dealer for service.
WARNING!
A transient high voltage occurs at the bulb sockets of
High Intensity Discharge (HID) headlamps when the
headlamp switch is turned ON. It may cause serious
electrical shock or electrocution if not serviced prop-
erly. See your authorized dealer for service.NOTE:On vehicles equipped with High Intensity Dis-
charge (HID) headlamps, when the headlamps are
turned on, there is a blue hue to the lamps. This dimin-
ishes and becomes more white after approximately
10 seconds, as the system charges.
Halogen Headlamps – If Equipped
1. Open the hood.
2. Turn the low or high beam bulb one–quarter turn
counterclockwise to remove from housing.
3. Disconnect the electrical connector and replace the
bulb.
