Black plate (232,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-54 Monitor, climate, audio, phone and voice recognition systems. Bluetooth ®
is a trademark owned by
Bluetooth SIG, Inc. and licensed to
Clarion Co., Ltd.
Music Box ®
(if so equipped) GUID-01A6EAF1-99CE-435D-AB80-3B7790059F71
Recording: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Note that data that is lost and not
stored to the hard drive/flash memory
due to system damage, improper op-
eration or malfunction is not under
warranty.
. Vehicle owners are not permitted to
record music without permission of the
owner of the copyright except for
personal use.
. Check if the music is appropriately
recorded to the hard drive/flash mem-
ory after recording when the compact
disc cannot be rerecorded.
. Some music cannot be recorded de-
pending on the disc condition due to
high-speed recording.
. Jumping sounds may be recorded when
a compact disc is recorded while
driving on rough roads and excessive
vibration occurs.
. A mark indicating jumping sounds is
displayed if jumping sounds are re- corded.
. No sounds may be recorded if jumping
sounds occurs or the disc is in poor
condition.
. Tracks that include Serial Copy Manage-
ment System (SCMS) are not recorded.
. If a compact disc is scratched or dirty, it
may not be recorded, jumping sounds
may occur or it may take a long time to
record.
Automatic title download: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. The title information that is automati-
cally downloaded may differ from the
actual title.
. When newly released compact discs are
recorded, their title information may
not be downloaded.
. The title information in the hard drive/
flash memory can be updated. (See
“ Playing recorded songs ” (P.4-80).

Black plate (236,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-58 Monitor, climate, audio, phone and voice recognition systemsdesired setting. For the other setting
methods, see “ How to use SETTING button ”
(P.4-14).
This vehicle has some sound effect func-
tions as follows:
. Speed Sensitive Vol.
. Precision Phased Audio (if so equipped)
. Driver ’ s Audio Stage (if so equipped)
For more details, see “ How to use SETTING
button ” (P.4-14).
Switching the display (Type A): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Models with navigation system
Pushing the DISC·AUX button will switch
the displays as follows:
iPod ®
/USB ? CD/DVD ? Music Box ®
?
Bluetooth ®
Audio ? iPod ®
/USB
. Models without navigation system
Pushing the DISC button will switch the
display as follows:
CD ? Music Box ®
? CD
Pushing the AUX button will switch the
display as follows:
USB/iPod ? XM1 ? XM2 ? XM3 ? USB/
iPod FM-AM-SAT radio operation GUID-F30EED1A-8A3C-4DC2-9E53-63B256076C22
When the radio band select button is
pushed while the ignition switch is in the
ACC or ON position, the radio will come on
at the channel last played.
The last channel played will also come on
when the ON·OFF button is pushed to ON.
The satellite radio is not available in
Alaska, Hawaii and Guam.
If another audio source is playing when the
radio or satellite band select button is
turned to ON, the audio source will
automatically be turned off and the last
radio channel played will come on.
When the stereo broadcast signal is weak,
the radio will automatically change from
stereo to monaural reception.
or radio (FM/AM/SAT) band
select (Type A): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Pushing the RADIO AM·FM or FM·AM radio
band select button will change the band as
follows:
. Models with navigation system
AM ? FM1 ? FM2 ? XM1 ? XM2 ? XM3
? AM . Models without navigation system
AM ? FM1 ? FM2 ? AM
radio (SAT) band select (Type A): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Push the satellite band select button to
select the satellite radio mode XM1, XM2
or XM3.
radio (FM/AM/SAT) band select
(Type B): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Pushing the radio band select button will
change the band as follows:
AM ? FM ? XM ? AM
When the radio band select button is
pushed while the ignition switch is in the
ACC or ON position, the radio will come on
at the station last played.
TUNE (Tuning): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. For AM and FM radio
Turn the radio TUNE knob for manual
tuning.
. For XM Satellite Radio
Turn the radio TUNE knob to seek
channels from all of the categories
when any category is not selected.

Black plate (248,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-70 Monitor, climate, audio, phone and voice recognition systemsInput the number to be searched and
select the “ OK ” key.
The specified folder/file will be played.
. Display
To adjust the image quality of the
screen, select the preferred adjustment
items.
. DRC
DRC (Dynamic Range Compression)
automatically adjusts the soundtrack
volume level to maintain a more even
sound to the speakers.
. Audio
Select the preferred language for audio.
. Subtitle
Select the preferred language for sub-
title.
. Display Mode
Select the “ Normal ” , “ Wide ” , “ Cinema ”
or “ Full ” mode. Bluetooth ®
STREAMING AUDIO
(models with navigation system) GUID-384085FE-4107-49E0-ABDF-8432D24FAAB8
Your INFINITI is equipped with Bluetooth ®
Streaming Audio. If you have a compatible
Bluetooth ®
device with streaming audio
(A2DP profile), you can set up the wireless
connection between your Bluetooth ®
de-
vice and the in-vehicle audio system. This
connection allows you to listen to the
audio from the Bluetooth ®
device using
your vehicle speakers. It also may allow
basic control of the device for playing and
skipping audio files using the AVRCP
Bluetooth ®
profile. All Bluetooth ®
Devices
do not have the same level of controls for
AVRCP. Please consult the manual for your
Bluetooth ®
Device for more details.
Once your Bluetooth ®
device is connected
to the in-vehicle audio system, it will
automatically reconnect whenever the de-
vice is present in the vehicle and you select
Bluetooth ®
Audio from your audio system.
You do not need to manually reconnect for
each usage.
Wireless LAN (Wi-Fi) and the Bluetooth ®
functions share the same frequency band
(2.4 GHz). Using the Bluetooth ®
and the
wireless LAN functions at the same time
may slow down or disconnect the commu- nication and cause undesired noise. It is
recommended that you turn off the wire-
less LAN (Wi-Fi) when using the Bluetooth ®
functions.
Regulatory information GUID-6C3C217B-4E76-422B-A1AB-9113DCE019A0
FCC Regulatory information: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. CAUTION: To maintain compliance with
FCC ’ s RF exposure guidelines, use only
the supplied antenna. Unauthorized
antenna, modification, or attachments
could damage the transmitter and may
violate FCC regulations.
. Operation is subject to the following
two conditions:
1) This device may not cause inter-
ference and
2) This device must accept any inter-
ference, including interference that
may cause undesired operation of
the device
IC Regulatory information: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Operation is subject to the following
two conditions:
1) This device may not cause inter-
ference, and
2) This device must accept any inter-
ference, including interference that

Black plate (249,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]may cause undesired operation of
the device.
. This Class B digital apparatus meets all
requirements of the Canadian Interfer-
ence-Causing Equipment Regulations.
Bluetooth trademark: Bluetooth ®
is a trademark
owned by Bluetooth SIG, Inc.
and licensed to Clarion Co., Ltd.
SAA2505
Connecting procedure GUID-67E97C0D-664E-47C1-84FC-BE1054289D2F
1. Push the SETTING button and select the
“ Bluetooth ” key. SAA2506
2. Select the “ Connect Bluetooth ” key.
Monitor, climate, audio, phone and voice recognition systems
4-71

Black plate (250,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-72 Monitor, climate, audio, phone and voice recognition systems SAA2507
3. A confirmation screen will be dis-
played. Select “ No ” .
Note: Selecting “ Yes ” will only connect
the hands free phone portion of a
Bluetooth ®
device. SAA3005
4. Choose a PIN code to use with the
compatible Bluetooth ®
audio device
using the number input screen. The
PIN code will need to be entered into
the Bluetooth ®
audio device after step
5. Select the “ OK ” key. SAA3006
5. The standby message screen will ap-
pear. Operate the compatible Blue-
tooth ®
audio device. For the
connecting procedure of the audio
device, see the Bluetooth ®
audio in-
structions.
When the connecting is completed, the
screen will return to the Bluetooth ®
setup display.

Black plate (251,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SAA2510
Audio main operation GUID-14B0AB43-2E50-4AF4-9B57-A348F7513796
Push the ignition switch to the ACC or ON
position. Then, push the DISC·AUX button
repeatedly to switch to the Bluetooth ®
audio mode. If the system has been turned
off while the Bluetooth ®
audio device was
playing, pushing the ON·OFF/VOL control
knob will start the Bluetooth ®
audio
device.
The ability to pause, change tracks, fast
forward, rewind, randomize and repeat
music may be different between devices.
Some or all of these functions may not be
supported on each device. DISC·AUX button: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the DISC·AUX button is pushed with
the system off and the Bluetooth ®
audio
device connected, the system will turn on.
If another audio source is playing and the
Bluetooth ®
audio device is connected,
push the DISC·AUX button repeatedly until
the display changes to the Bluetooth ®
audio mode.
Next/Previous Track and Fast
Forward/Rewind: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the or button is pushed for
more than 1.5 seconds while a Bluetooth ®
audio file is being played, the Bluetooth ®
audio device will play while forwarding or
rewinding. When the button is released,
the Bluetooth ®
audio device will return to
normal play speed.
When the
or button is pushed for
less than 1.5 seconds while a Bluetooth ®
audio file is being played, the next track or
the beginning of the current track on the
Bluetooth ®
audio device will be played.
The INFINITI controller can also be used to
select tracks when the Bluetooth ®
audio
play mode screen is shown on the display.
( “ Bluetooth audio ” will be indicated on the header of the screen.)
REPEAT (RPT), RANDOM (RDM): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To change the play mode, push the
button repeatedly and the mode changes
as follows.
Normal ? Shuffle All Tracks ? Shuffle
Group ? Repeat 1 Track ? Repeat All
Tracks ? Repeat Group ? Normal
Operation keys: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To operate a Bluetooth ®
audio device,
select a key displayed on the operation
screen using the INFINITI controller.
Play
Select the “
” key to start playing when
pausing. Select this key again to pause the
audio play.
Pause
Select the “
” key to pause the Blue-
tooth ®
audio device. Select this key again
to resume playing.
Play Mode: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The play mode setting display will appear
when the “ Menu ” key is selected.
Choose the preferred play mode from the
Monitor, climate, audio, phone and voice recognition systems
4-73

Black plate (252,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-74 Monitor, climate, audio, phone and voice recognition systemsfollowing items.
. Shuffle
Choose “ Shuffle OFF ” , “ Shuffle All
Tracks ” and “ Shuffle Group ” .
. Repeat
Choose from “ Repeat OFF ” , “ Repeat 1
Track ” , “ Repeat All Tracks ” and “ Repeat
Group ” . SAA2511
Bluetooth ®
settings GUID-E740A90F-DA65-4B4B-9DB5-140E8E82A0BF
To set up the Bluetooth ®
device system to
the preferred settings, push the SETTING
button and select the “ Bluetooth ” key.
Bluetooth: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
If this setting is turned off, the connection
between the Bluetooth ®
devices and the
in-vehicle Bluetooth ®
module will be can-
celed.
Connect Bluetooth: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Connects to the Bluetooth ®
device. See
“ Connecting procedure ” (P.4-71). Up to 5
devices can be registered. Connected Devices: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Registered devices are shown on the list.
Select a Bluetooth ®
device from the list,
the following options will be available.
. Select
Select “ Select ” to connect the selected
device to the vehicle. If there is a
different device currently connected,
the selected device will replace the
current device.
. Edit
Rename the selected Bluetooth ®
device
using the keypad displayed on the
screen. (See “ How to use touch screen
(models with navigation system) ” (P.4-
5).)
. Delete
Delete the selected Bluetooth ®
device.
Edit Bluetooth Info: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Change the name broadcasted by this
system over Bluetooth ®
. Change the PIN
code that is entered when connecting a
hands free device to this system.
Replace Connected Phone: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Replace the Bluetooth ®
connection with a
connected Bluetooth ®
cellular phone. For
details about Hands-Free Phone System,

Black plate (253,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]see “ Bluetooth ®
Hands-Free Phone System
(models with navigation system) ” (P.4-90).
SAA2974
Automatic transmission models
SAA2426
Manual transmission models iPod ®
PLAYER OPERATION (if so
equipped) GUID-90F666E1-0F3B-4A21-AC5D-3DCDEFBD204E
Connecting iPod ® GUID-F75E089D-4DAB-4B27-BB33-FF3E7F0793C7
Open the console lid and connect the
iPod ®
cable to the USB connector. If
compatible, the battery of the iPod ®
is
charged while the connection to the
vehicle.
Depending on the version of the iPod ®
, the
display on the iPod ®
shows an INFINITI or
Accessory Attached screen when the con-
nection is completed. When the iPod ®
is
connected to the vehicle, the iPod ®
music
library can only be operated by the vehicle
audio controls.
* iPod ®
is a trademark of Apple Inc.,
registered in the U.S. and other countries.
Compatibility GUID-62CF64CA-AF90-4D76-AA98-3269E0716164
The following models are available:
Models with navigation system: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Fifth generation iPod ®
(version 1.2.3 or
later)
. iPod Classic ®
(version 1.1.1 or later)
. First generation iPod touch ®
(version
2.0.0 or later)
Monitor, climate, audio, phone and voice recognition systems
4-75
