2012 INFINITI G37 CD player

Black plate (235,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SAA1533
Models with navigation system
1. Radio band select button
2. DISC·AUX button SAA2922
Models without navigation system
1. AUX/Satellite band select button
2. Radio band select button
3. DISC button
FM-AM-SAT RADIO WITH COMPACT
DISC (CD) PLAYER GUID-5CFED4B1-9F3C-4769-A868-FC87F9315191
For all operation precautions, see “ Audio
operation precautions ” (P.4-41).
The satellite radio mode requires an active
XM Satellite Radio subscription. The satel-
lite radio is not available in Alaska, Hawaii
and Guam.
It may take some time to receive the
activation signal after subscribing the XM Satellite Radio. After receiving the activa-
tion signal, an available channel list will be
automatically updated in the radio. For XM,
push the ignition switch from LOCK to ACC
to update the channel list.
Audio main operation GUID-40188482-C854-4E49-BD1F-ACF1B41DBA2D
Head unit: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The auto loudness circuit enhances the low
and high frequency ranges automatically in
both radio reception and CD playback.
ON·OFF/Volume control: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Push the ignition switch to the ACC or ON
position, and then push the ON·OFF button
while the system is off to turn on the last
audio source, which was playing immedi-
ately before the system was turned off.
While the system is on, pushing the
ON·OFF button turns the system off.
Turn the VOL control knob to adjust the
volume.
Adjusting tone quality and speaker bal-
ance: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To adjust Bass, Treble, Balance and Fade,
push the Audio control knob. When the
display shows the setting you want to
change (Bass, Treble, Balance and Fade),
rotate the Audio control knob to set the
Monitor, climate, audio, phone and voice recognition systems
4-57

Black plate (238,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-60 Monitor, climate, audio, phone and voice recognition systems4. The stations indicator will then come on
and the sound will resume. Memorizing
is now complete.
5. Other buttons can be set in the same
manner.
If the battery cable is disconnected, or if
the fuse opens, the radio memory will be
erased. In that case, reset the desired
stations/channels.
List (AM and FM radio) (models with
navigation system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the “ List ” key on the display is
selected while the FM or AM radio is being
played, the preset station list will be
displayed.
If 1 of the 6 preset stations listed is
touched and held, the current station will
be stored as the new preset.
Menu (XM Satellite Radio) (models with
navigation system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the “ Menu ” key on the display is
selected while the XM Satellite Radio is
being played, the menu list will be
displayed.
The following items are available.
. Preset List
Displays the preset channel list. If 1 of the 6 preset stations listed is touched
and held, the current station will be
stored as the new preset.
. Customize Channel List
Selects specific channels to skip while
using the TUNE, SEEK/CATEGORY or
Menu-Categories feature.
. Favorite Artists & Songs
Stores the current artist or song that is
being played. Touch the “ Alert ” key to
be reminded when the stored artist or
song is playing on a station while
listening to XM.
. Categories
Selecting a category will go to the first
channel in that category as defined by
XM Radio.
. Direct Tune
Inputs the channel number by using a
keypad.
Text (models without navigation system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the “ Text ” key is selected with the
INFINITI controller on the display and then
the ENTER button is pushed while the
satellite radio is being played, the text
information listed below will be displayed
on the screen. . CH Name
. Category
. Name
. Title
. Other
Compact Disc (CD) player operation GUID-92C6C7F8-3A3B-42D9-B8DF-915DA610B375
Push the ignition switch to the ACC or ON
position and insert the Compact Disc (CD)
into the slot with the label side facing up.
The CD will be guided automatically into
the slot and start playing.
After loading the CD, the number of tracks
on the CD and the play time will appear on
the display.
If the radio is already operating, it will
automatically turn off and the CD will play.
If the system has been turned off while the
CD was playing, pushing the ON·OFF
button will start the CD.
Do not use 3.1 in (8 cm) discs.
or PLAY: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the DISC·AUX or DISC (CD play)
button is pushed with the system off and
the CD loaded, the system will turn on and
the CD will start to play.

Black plate (240,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-62 Monitor, climate, audio, phone and voice recognition systemsREPEAT (RPT), RANDOM (RDM) (Type
A): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the RPT button is pushed while the
CD is played, the play pattern can be
changed as follows:
(CD) NOS2606
(CD with compressed audio files) NOS2607
REPEAT (RPT) (Type B): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the SCAN·RPT button is pushed while
the CD is played, the play pattern can be
changed as follows:
(CD) NOS2079
(CD with MP3 or WMA)
NOS2080CD EJECT: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the CD EJECT button is pushed with
the CD loaded, the CD will be ejected.
When this button is pushed while the CD is
being played, the CD will be ejected.
If the CD comes out and is not removed, it
will be pulled back into the slot to protect
it.
DVD (Digital Versatile Disc) PLAYER
OPERATION (models with naviga-
tion system) GUID-8205EDF5-3DB4-4E4E-8CDD-3F75914B7BB8
Precautions GUID-8812ACDC-FD40-4CAA-9CB9-437BDD03B225
Start the engine when using the DVD
entertainment system.
Movies will not be shown on the front
display while the vehicle is in any drive
position to reduce driver distraction. Audio
is available when a movie is played. To
view movies in the front display, stop the
vehicle in a safe location, move the
selector lever to the P (Park) position
(Automatic Transmission models) or apply
the parking brake (Manual Transmission
models). WARNING . The driver must not attempt to operate
the DVD system or wear the headphones
while the vehicle is in motion so that full
attention may be given to vehicle opera-
tion.
. Do not attempt to modify the system to
display a movie on the front screen while
the vehicle is being driven. Doing so may
distract the driver and may cause a
collision and serious personal injury or
death.
CAUTION . Only operate the DVD while the vehicle
engine is running. Operating the DVD for
extended periods of time with the
engine OFF can discharge the vehicle
battery.
. Do not allow the system to get wet.
Excessive moisture such as spilled
liquids may cause the system to mal-
function.
. While playing VIDEO-CD media, this DVD

Black plate (241,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]player does not guarantee complete
functionality of all VIDEO-CD formats.
Display settings GUID-720BCAE9-AA46-4971-99AF-5389717886E1
To adjust the front display mode, push the
SETTING button while the DVD is being
played, select the “ Others ” key and then
select the “ Display ” key.
To adjust the display ON/OFF, brightness,
tint, color and contrast, select the “ Display
Adjustment ” key and then select each key.
Then you can adjust each item using the
INFINITI controller. After changes have
been made push the BACK button to save
the setting. SAA2497
Playing a DVD GUID-EEE03BD8-3059-4917-ACAC-2BF65D28CBB9
DISC·AUX button: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Park the vehicle in a safe location for the
front seat occupants to operate the DVD
drive while watching the images.
Push the DISC·AUX button on the instru-
ment panel and turn the display to the DVD
mode.
When a DVD is loaded, it will be replayed
automatically.
The operation screen will be turned on
when the DISC·AUX button located on the
instrument panel is pushed while a DVD is
being played, and it will turn off auto- matically after a period of time. To turn it
on again, push the DISC·AUX button again.
DVD operation keys: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the DVD is playing without the
operation screen being shown, you may
use the touch screen to select items from
the displayed video. You may also use the
INFINITI controller to select an item from
the displayed video. When the operation
screen is being shown, use the INFINITI
controller or touch screen to select an item
from the displayed menus.
PAUSE:
Select the “
” key to pause the DVD. To
resume playing the DVD, use the “ PLAY ”
key.
PLAY:
Select the “
” key to start playing the
DVD, for example, after pausing the DVD.
STOP:
Select the “
” key to stop playing the
DVD.
Monitor, climate, audio, phone and voice recognition systems
4-63

Black plate (253,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]see “ Bluetooth ®
Hands-Free Phone System
(models with navigation system) ” (P.4-90).
SAA2974
Automatic transmission models
SAA2426
Manual transmission models iPod ®
PLAYER OPERATION (if so
equipped) GUID-90F666E1-0F3B-4A21-AC5D-3DCDEFBD204E
Connecting iPod ® GUID-F75E089D-4DAB-4B27-BB33-FF3E7F0793C7
Open the console lid and connect the
iPod ®
cable to the USB connector. If
compatible, the battery of the iPod ®
is
charged while the connection to the
vehicle.
Depending on the version of the iPod ®
, the
display on the iPod ®
shows an INFINITI or
Accessory Attached screen when the con-
nection is completed. When the iPod ®
is
connected to the vehicle, the iPod ®
music
library can only be operated by the vehicle
audio controls.
* iPod ®
is a trademark of Apple Inc.,
registered in the U.S. and other countries.
Compatibility GUID-62CF64CA-AF90-4D76-AA98-3269E0716164
The following models are available:
Models with navigation system: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Fifth generation iPod ®
(version 1.2.3 or
later)
. iPod Classic ®
(version 1.1.1 or later)
. First generation iPod touch ®
(version
2.0.0 or later)
Monitor, climate, audio, phone and voice recognition systems
4-75

Black plate (256,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-78 Monitor, climate, audio, phone and voice recognition systems SAA2513
Models with navigation system
SAA2612
Models without navigation system Recording CDs GUID-03E2C3C7-C335-41B9-B085-629B07E0AE20
1. Operate the audio system to play a CD.
For the details of playing CDs, see
“ Compact Disc (CD) player operation ”
(P.4-60).
2. Select the “ Start REC ” or “ REC ” key.
NOTE:
. The system starts playing and record-
ing the 1st track on the CD when the
“ Start REC ” or “ REC ” key is selected.
. The recording process can be stopped
at any time. All tracks that were played
before the CD was stopped are stored.
. Individual tracks can be deleted from
the hard drive/flash memory after the
CD is recorded.
. The order of the tracks may not be
changed while recording. SAA2514
Models with navigation system
SAA2613
Models without navigation system

Black plate (263,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]Gracenote and CDDB are registered trade-
marks of Gracenote. The Gracenote logo
and logotype, and the “ Powered by Grace-
note ” logo are trademarks of Gracenote.
SAA2990
AUXILIARY INPUT JACKS (if so
equipped) GUID-0280CC1A-0892-4C7E-8144-201453B60254
The auxiliary input jacks are located in the
center console. NTSC compatible devices
such as video games, camcorders and
portable video players can be connected
to the auxiliary jacks. Compatible audio
devices, such as some MP3 players, can
also be connected to the system through
the auxiliary jacks.
The auxiliary jacks are color coded for
identification purposes.
. Yellow - video input . White - left channel audio input
. Red - right channel audio input
Before connecting a device to a jack, turn
off the power of the portable device.
With a compatible device connected to the
jacks, push the AUX button to switch to the
AUX mode. The output from the device will
be played through the monitor and audio
system.
Monitor, climate, audio, phone and voice recognition systems
4-85

Black plate (311,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]Audio Commands: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Command Action
Music Box Turns on the Music Box hard drive audio system.
CD Starts to play a CD.
FM Turns to the FM band, selecting the station last played.
AM Turns to the AM band, selecting the station last played.
XM Turns to the XM Satellite Radio band, selecting the channel last played.
USB Turns on the USB memory.
Bluetooth Audio Turns on the Bluetooth ®
audio player.
AUX Turns on the AUX.
Monitor, climate, audio, phone and voice recognition systems
4-133
