2012 INFINITI EX navigation

*1 Files created with a combination of 48 kHz sampling frequency and 64 kbps bit rate cannot be played.
*2 Protected WMA files (DRM) cannot be played.
*3 Available codes depend on what kind of media, versions and information are going to be displayed.
*4 When VBR files are played, the playback time may not be displayed correctly.
*5 Models with navigation system
Monitor, climate, audio, phone and voice recognition systems4-61

Compressed Video Files (models
with navigation system)
GUID-E2445A26-4CDB-4384-A0C2-18D86B23258C

JVH0132X
With navigation system
1. AM·FM·SAT band select button
2. DISC·AUX button
SAA2922
Without navigation system (Type A)
1. AUX/Satellite band select button
2. RADIO AM·FM band select button
3. DISC button
SAA2101A
Without navigation system (Type B)
1. RADIO AM·FM band select button
2. DISC/DISC·AUX button
For all operation precautions, see “Audio
operation precautions” earlier in this sec-
tion.
The satellite radio mode requires an active
XM Satellite Radio subscription. The satel-
lite radio is not available in Alaska, Hawaii
and Guam.
It may take some time to receive the
activation signal after subscribing the XM
Satellite Radio. After receiving the activa-
tion signal, an available channel list will be
automatically updated in the radio. For XM,
Monitor, climate, audio, phone and voice recognition systems4-67

4-68Monitor, climate, audio, phone and voice recognition systems
push the ignition switch from LOCK to ACC
to update the channel list.
Audio main operationGUID-E0255B26-FC35-4652-89E7-8756B7322814
radio (FM/AM/SAT) band select
(models with navigation system):
GUID-4D508F5D-FA8E-49D6-A9E2-6F8E76C17033
radio (FM/AM) band select (models
without navigation system):
GUID-4D508F5D-FA8E-49D6-A9E2-6F8E76C17033

4-70Monitor, climate, audio, phone and voice recognition systems
selected while the XM Satellite Radio is
being played, the menu list will be
displayed.
The following items are available.
.Preset List
Displays the preset channel list. If 1 of
the 6 preset stations listed is touched
and held, the current station will be
stored as the new preset.
. Customize Channel List
Selects specific channels to skip while
using the TUNE, SEEK/CATEGORY or
Menu-Categories feature.
. Favorite Artists & Songs
Stores the current artist or song that is
being played. Touch the “Alert”key to
be reminded when the stored artist or
song is playing on a station while
listening to XM.
. Categories
Selecting a category will go to the first
channel in that category as defined by
XM Radio.
. Direct Tune
Inputs the channel number by using a
keypad. Text (models without navigation system):GUID-4D508F5D-FA8E-49D6-A9E2-6F8E76C17033
orPLAY:GUID-4D508F5D-FA8E-49D6-A9E2-6F8E76C17033

—1 Track Repeat
— 1 Disc Random
— 1 Folder Random (for CD with
compressed audio files)
. Record to Music Box
®(for CD)
Select to choose specific songs on the
CD to record to the Music Box
®.
. Title Text Priority (for CD)
Set the priority to CDDB (Compact Disc
Data Base) to acquire track information
from the Gracenote Database, or set
the priority to CD-TEXT to acquire the
information from CDs.
. Automatic Recording (for CD)
When this item is turned to ON, the
Music Box
®hard drive/flash memory
automatically starts recording when a
CD is inserted.
. Recording Quality (for CD)
The larger number (132) will increase
the recorded sound quality while taking
up more space on the Music Box
®
leaving less room for more songs.
For the details of Music Box®, see “Music
Box®” later in this section. Text (models without navigation system):
GUID-4D508F5D-FA8E-49D6-A9E2-6F8E76C17033
Next/Previous Track and Fast
Forward/Rewind:
GUID-4D508F5D-FA8E-49D6-A9E2-6F8E76C17033
REPEAT (RPT), RANDOM (RDM):GUID-4D508F5D-FA8E-49D6-A9E2-6F8E76C17033
NOS2606
NOS2607
CD EJECT:GUID-4D508F5D-FA8E-49D6-A9E2-6F8E76C17033

4-76Monitor, climate, audio, phone and voice recognition systems
SAA2501
With navigation system
SAA2611
Without navigation system
Audio file operationGUID-435F6144-8A1A-4BF6-8750-BFB28E8300D9
orPLAY:GUID-4D508F5D-FA8E-49D6-A9E2-6F8E76C17033
Next/Previous File and Fast
Forward/Rewind:
GUID-4D508F5D-FA8E-49D6-A9E2-6F8E76C17033
REPEAT (RPT), RANDOM (RDM):GUID-4D508F5D-FA8E-49D6-A9E2-6F8E76C17033

Text (models without navigation system):GUID-4D508F5D-FA8E-49D6-A9E2-6F8E76C17033
SAA2502
Menu (models with navigation system):GUID-4D508F5D-FA8E-49D6-A9E2-6F8E76C17033
