2012 HONDA ODYSSEY Anchor

61
uuChild SafetyuSafety of Infants and Small Children
Continued
Safe Driving
3.Raise the head restraint to its highest
position, then route the tether strap
between the head restraint legs, and secure
the tether strap hook onto the anchor.
4.Tighten the tether strap as instructed by the
child seat maker.
5.Make sure the child seat is firmly secured by
rocking it forward and back and side to
side; little movement should be felt.
6.Make sure any unused seat belt that a child
can reach is buckled, the lockable retractor
is activated, and the belt is fully retracted
and locked.
Anchor
Tether Strap Hook
Anchor
Tether
Strap
HookSecond row center seatSecond row outer position

uuChild SafetyuSafety of Infants and Small Children
64Safe Driving
A tether anchorage point is provided behind
each second and third row seating position. A
child seat that is installed with a seat belt and
comes with a tether can use the tether for
additional security.
1.Locate the appropriate tether anchorage
point.
2.Raise the head restraint to its highest
position, then route the tether strap
through the head restraint legs. Make sure
the strap is not twisted.
■
Adding Security with a Tether
1Adding Security with a Tether
Since a tether can provide additional security to the
lap/shoulder seat belt installation, we recommend
using a tether whenever one is available.
Second row seatThird row seatSecond row outer position

65
uuChild SafetyuSafety of Infants and Small Children
Safe Driving
3.Secure the tether strap hook onto the
anchor.
4.Tighten the tether strap as instructed by the
child seat manufacturer.
Second row center seatThird row seat

Continued
165
uuAdjusting the SeatsuRear Seats
Controls
Your vehicle’s multi-functional second row center seat is removable.
1.Store the center seat belt first. Insert a key
into the slot on the side of the anchor
buckle.
2.Retract the seat belt into the holder on the
ceiling.
2Seat Belt with Detachable Anchor P. 35
3.Pull up the adjustment strap, and fold down
the seat-back.
4.Pull the lock release strap under the seat
cushion, and lift the rear of the seat.
uTo lift the seat, hold the seat-back.
5.Pull the seat-back slightly, then pivot it
upward.
uThis unhooks the front of the seat from
the floor.
■
Removing the Second Row Center Seat
*
1Removing the Second Row Center Seat
Do not remove the seat while driving.
The multi-functional center seat can be used as the
beverage holder when folded down.
2Beverage Holders P. 174
To reinstall the seat, hook the front of the seat to the
floor first. Pushing the rear of the seat-back locks the
seat in place. Make sure the seat is latched before
driving.
Adjustment Strap
Lock Release
Strap* Not available on all models

uuAdjusting the SeatsuRear Seats
166Controls
1.Store the center seat belt first. Insert a key
into the slot on the side of the anchor
buckle.
2.Retract the seat belt into the holder on the
ceiling.
2Seat Belt with Detachable Anchor P. 35
3.Lower the head restraints to their lowest
position.
4.The right and left halves can be tucked
away separately. Pull either strap to release
the front leg lock of the third row seat.
5.Continue pulling the strap to tuck the seat
and strap away into the cargo area.
■
Tucking away the One-Motion Third row magic Seat
®
1Tucking away the One-Motion Third Row Magic Seat
Remove any items from the cargo area before you
tuck away the third row seat.
The instruction label is attached at the back of the
third row seat-back.
When you tuck away one side of the third row seats
and use the non-recessed part of the cargo area,
make sure to secure the cargo. Loose items can fly
forward and cause injury if you have to brake hard.
Straps

385
Continued
Maintenance
CleaningInterior CareUse a damp cloth with a mixture of mild detergent and warm water to remove dirt.
Use a clean cloth to remove detergent residue.
Use a soft brush with a mixture of mild soap and warm water to clean the seat belts.
Let the belts air dry. Wipe the openings of the seat belt anchors using a clean cloth.■
Cleaning Seat Belts
1Interior Care
Do not spill liquids inside the vehicle.
Electrical devices and systems may malfunction if
liquids are splashed on them.
Do not use silicone based sprays on electrical devices
such as audio devices and switches.
Doing so may cause the items to malfunction or a fire
inside the vehicle.
If a silicone based spray is inadvertently used on
electrical devices, consult a dealer.
Depending on their composition, chemicals and
liquid aromatics may cause discoloration, wrinkles,
and cracking to resin-based parts and textiles.
Do not use alkali solvents or organic solvents such as
benzene or gasoline.
After using chemicals, make sure to gently wipe them
off using a dry cloth.
Do not place used cloths on top of resin based parts
or textiles for long periods of time without washing.
Opening

uuCleaninguInterior Care
386Maintenance
The front and second row passenger’s floor
mats hook over the floor anchors, which keep
the mats from sliding forward. To remove a
mat for cleaning, turn the anchor knobs to the
unlock position. When reinstalling the mat
after cleaning, turn the knobs to the lock
position.
Do not put additional floor mats on top of
the anchored mats.
Vacuum dirt and dust from the leather frequently. Pay close attention to the pleats
and seams. Clean the leather with a soft cloth dampened with a 90% water and
10% neutral soap solution. Then buff it with a clean, dry cloth. Remove any dust or
dirt on leather surfaces immediately.
■
Floor Mats
1Floor Mats
If you use any floor mats that were not originally
provided with your vehicle, make sure they are
designed for your specific vehicle, fit correctly, and
are securely anchored by the floor anchors.
Position the rear seat floor mat properly. If they are
not properly positioned, the floor mat can interfere
with the front seat functions.
To Unlock
Front
(Driver Side)
Rear
To Unlock■
Maintaining Genuine Leather
*
* Not available on all models

437
Index
Instrument Panel........................................ 71
Brightness Control .................................. 147
Integrated Sunshades.............................. 182
Interior Lights........................................... 169
Interior Rearview Mirror......................... 152JJack (Wheel Nut Wrench)........................ 394
Jump Starting........................................... 401KKey Number Tag...................................... 111
Keyless Lockout Prevention..................... 113
Keys........................................................... 110
Lockout Prevention ................................. 113
Master Keys ............................................ 110
Number Tag............................................ 111
Rear Door Won’t Open ........................... 115
Remote Transmitter ................................ 112
Types and Functions................................ 110
Valet Key ................................................ 111
Won’t Turn ............................................... 21
Kickdown (Automatic Transmission)...... 300LLanguage (HFL)........................................ 260
LATCH (Child Seats)................................... 59
Lights................................................ 142, 355
Automatic............................................... 143Bulb Replacement .................................... 355
Daytime Running Lights ........................... 144
Fog Lights ................................................ 144
High Beam Indicator .................................. 79
Interior .................................................... 169
Light Switches ......................................... 142
Lights On Indicator .................................... 79
Turn Signals ............................................. 142
Load Limits................................................ 289
Locking/Unlocking.................................... 110
Auto Door Locking/Unlocking .................. 116
Childproof Door Locks ............................. 115
From Inside .............................................. 114
From Outside ........................................... 112
Keys ........................................................ 110
Using a Key ............................................. 113
Lockout Prevention System...................... 113
Low Battery Charge.................................. 406
Low Fuel Indicator...................................... 75
Low Oil Pressure Indicator................. 72, 406
Lower Anchors............................................ 59
Luggage (Maximum Load Limit)............. 289
MMaintenance............................................. 331
Battery .................................................... 379
Brake Fluid .............................................. 353
Cleaning .................................................. 385
Climate Control System ........................... 384
Coolant ................................................... 350Heating and Cooling System ................... 384
Maintenance Minder™ ........................... 335
Oil ........................................................... 346
Power Steering Fluid................................ 354
Precautions ............................................. 332
Radiator .................................................. 351
Remote Control
and Wireless Headphone ....................... 382
Remote Transmitter ................................. 380
Replacing Light Bulbs .............................. 355
Safety...................................................... 333
Service Items ................................... 337, 341
Tires ........................................................ 370
Transmission Fluid ................................... 352
Under the Hood ...................................... 343
Malfunction Indicator Lamp.............. 73, 407
Map Lights................................................ 170
Maximum Load Limit............................... 289
Meters, Gauges........................................... 86
Mirrors...................................................... 152
Adjusting ................................................ 152
Door ....................................................... 153
Exterior ................................................... 153
Interior Rearview ..................................... 152
Modifications (and Accessories).............. 329
Moonroof................................................. 140
MP3........................................... 200, 212, 226
Multi-Information Display......................... 98
