2012 HONDA CROSSTOUR instrument panel

Maintaining your vehicle according to the Maintenance Minder shown in
the instrument panel helps to keep your driving trouble-f ree while it
preserves your investment. When your vehicle needs maintenance, keep in
mind that your dealer’s staff is specially trained in servicing the many
systems unique to your vehicle. Your dealer is dedicated to your satisf action
and will be pleased to answer any questions and concerns. Several warranties protect your new vehicle. Read the warranty booklet
thoroughly so you understand the coverages and are aware of your rights
and responsibilities. One of the best ways to enhance the enjoyment of your new vehicle is to
read this manual. In it, you will learn how to operate its driving controls and
convenience items. Af terwards, keep this owner’s manual in your vehicle so
youcanrefertoitatanytime.As you read this manual, you will
f ind inf ormation that is preceded by
a
symbol. This
inf ormation is intended to help you
avoid damage to your vehicle, other
property, or the environment.
Congratulations! Your selection of a
2012 Crosstourwas a wise investment.
It will give you years of driving pleasure.
Introduction
i
TM

Index
Bo ok Ta ble of Contents
Chapter Ta ble of Contents
Navigation Key
Your Vehicle at a Glance

2012 Crosstour

A convenient ref erence to the
sections in this manual.
A quick ref erence to the main
controls in your vehicle.
Explains the purpose of each
instrument panel indicator and gauge,
and how to use the controls on the
dashboard and steering column.ID numbers, dimensions, capacities,
and technical information.
How to order manuals and other
technical literature.
A summary of the inf ormation you
need when you pull up to the f uel
pump. A summary of the warranties
covering your new vehicle, and how
to contact us for any reason. Refer to
your warranty manual f or detailed
inf ormation.
Important inf ormation about the
proper use and care of your vehicle’s
seat belts, an overview of the
supplemental restraint system, and
valuable inf ormation on how to
protect children with child restraints.
How to operate the climate control
system, the audio system, and other
convenience f eatures. What gasoline to use, how to break-
in your new vehicle, and how to load
luggage and other cargo.
The proper way to start the engine,
shif t the transmission, and park; plus
what you need to know if you’re
planning to tow a trailer.
The Maintenance Minder shows
you when you need to take your
vehicle to the dealer for maintenance
service. There is also a list of things
to check and instructions on how to
check them.
This section covers several problems
motorists sometimes experience,
and details how to handle them.
Contents
Your Vehicle at a Glance
Driver and Passenger Saf ety
Instruments and Controls
Features T echnical Inf ormation
Warranty and Customer
Relations
(U.S. and Canada only)
Authorized Manuals
(U.S. only)
Index
Service Inf ormation Summary
Bef ore Driving
Driving
Maintenance
T aking Care of the Unexpected
Overview of Contents
2
TM


2012 Crosstour

Î
ÎÎ
Î
If equipped
:
Your Vehicle at a Glance
3
MIRROR CONTROLS INSTRUMENT PANEL
INDICATORS (P.55)
GAUGES (P.63)
DRIVER’S FRONT
AIRBAG
AUXILIARY INPUT JACK
ACCESSORY POWER SOCKETS
(P.9,
23) HOMELINK BUTTONS
MOONROOF SWITCH
POWER WINDOW
SWITCHES
HOOD RELEASE
HANDLE CLOCK
COMPASS
PASSENGER’S
FRONT AIRBAG
(P.
9,23 )
DRIVING POSITION
MEMORY SYSTEM
BUTTONS
POWER DOOR LOCK
MASTER SWITCH
(Unlocking Fuel Fill
Door) (P. 80)
USB ADAPTER CABLEMIRROR CONTROL
AUTO BUTTON
AUTOMATIC
TRANSMISSION AUDIO SYSTEM
CLIMATE CONTROL
SYSTEM
(P.101)
(P.105)
(P.106)
(P .287)
Without navigation system is shown. (P.114,
115) (
P.236)
(P.161, 171,211,222)
(P.
302 )
(P.
134 ) (P.
242 )
(P.238)
(P.104)
(P.249)
(P.110)
(P.126)


2012 Crosstour

Î Î
Î
Î
Î
Î ÎÎ
Î
Only on vehicles equipped with navigation system. Ref er to the navigation system manual. If equipped
To use the horn, press the center pad of the steering wheel.
3: 1:
2:
Your Vehicle at a Glance
4
HAZARD WARNING
BUTTON
INTERFACE DIAL
HORN
REMOTE AUDIO
CONTROLS
NAVIGATION SYSTEM
VOICE CONTROL
BUTTONS CRUISE CONTROL
BUTTONS
REAR WINDOW DEFOGGER/
HEATED MIRROR BUTTON
SEAT HEATER SWITCHES
(P.70,
73)
VEHICLE STABILITY
ASSIST (VSA) SYSTEM
OFF SWITCH CENTER DISPLAY
SELECTOR KNOB (P.
74)
REAR WINDOW
DEFOGGER/
HEATED MIRROR
BUTTON
INSTRUMENT PANEL BRIGHTNESS
(P.73)
PASSENGER AIRBAG OFF INDICATOR
(P.30)
WINDSHIELD
WIPERS/WASHERS
(P. 68)
STEERING WHEEL
ADJUSTMENTS
(P.76)
BLUETOOTH
HANDSFREELINK
VOICE CONTROL
BUTTONS (P.246)
HEADLIGHTS/
TURN SIGNALS/
FOG LIGHTS
(P.234)
(P.312)
(P.253) (P.100)(P.135)(P.75/
106)(P.
177 )
(P.75/
106)
3
1
3 23
2


2012 Crosstour

µ
µ
µ
µ
Your vehicle is equipped with seat
belts in all seating positions.
Help protect you in almost every
type of crash, including:frontal impacts
side impacts
rear impacts
rollovers
Keep you connected to the vehicle
so you can take advantage of the
vehicle’s built-in saf ety f eatures.
When properly worn, seat belts: Help keep you f rom being thrown
against the inside of the vehicle
and against other occupants.
Keep you f rom being thrown out
of the vehicle.
Help keep you in a good position
should the airbags ever deploy. A
good position reduces the risk of
injury f rom an inf lating airbag and
allows you to get the best
advantage f rom the airbag.
Of course, seat belts cannot
completely protect you in every
crash.Butinmostcases,seatbelts
can reduce your risk of serious
injury.
Always wear your seat belt, and
make sure you wear it properly.
Your seat belt system also includes
an indicator on the instrument panel
and a beeper to remind you and your
passengers to f asten your seat belts.
Seat belts are the single most
effectivesafetydeviceforadultsand
larger children. (Inf ants and smaller
children must be properly restrained
in child seats.)
Not wearing a seat belt properly
increases the chance of serious
injury or death in a crash, even
though your vehicle has airbags.
In addition, most states and all
Canadian provinces and territories
require you to wear seat belts. Seat Belts
Your Vehicle’s Saf ety Features
What You Should Do:
Why Wear Seat Belt s
8
Not wearing a seat belt properly
increases the chance of serious
injury or death in a crash, even
though your vehicle has airbags.
Be sure you and your
passengers always wear seat
belts and wear them properly.

Driver and Passenger Saf ety

2012 Crosstour

µ
CONT INUED
Adjust the driver’s seat as far to the
rear as possible while allowing you to
maintain f ull control of the vehicle.
Have a front passenger adjust their
seat as far to the rear as possible.
The f ollowing pages provide
instructions on how to properly
protect the driver, adult passengers,
and teenage children who are large
enough and mature enough to drive
or ride in the f ront.
See pages f or important
guidelines on how to properly
protect inf ants, small children, and
larger children who ride in your
vehicle.
Locking the doors reduces the
chance of someone being thrown out
of the vehicle during a crash, and it
helps prevent passengers f rom
accidentally opening a door and
f alling out.
Locking the doors also helps prevent
an outsider f rom unexpectedly
opening a door when you come to a
stop.
Your vehicle has a programmable
auto door locking/unlocking f eature.
For more inf ormation, see page .
Your vehicle has a door and
tailgate open indicator on
the instrument panel to indicate
when a specif ic door or the tailgate is
not tightly closed. See page f or how to lock the
doors, and page f or how the door
and tailgate open indicator works.
After everyone has entered the
vehicle, be sure the doors and the
tailgate are closed and locked. 60
33 50
80
81
Protecting A dults and Teens
Introduction A djust the Front Seats
Close and L ock the Doors
1. 2.
11

Driver and Passenger Saf ety

2012 Crosstour

Your seat belt system includes lap/
shoulder belts in all seating positions.
The f ront seat belts are also
equipped with automatic seat belt
tensioners.If the indicator comes on or the
beeper sounds when the driver’s seat
belt is latched and there is no f ront
seat passenger and no items on the
front seat, something may be
interf ering with the monitoring
system. Look f or and remove:
Any items under the f ront
passenger’s seat.
Any object(s) hanging on the seat
or in the seat-back pocket.
Any object(s) touching the rear of
the seat-back.
If no obstructions are f ound, have
your vehicle checked by a dealer.
The seat belt system
includes an indicator on the
instrument panel and a beeper to
remind you and your passengers to
f asten your seat belts.
This system monitors the f ront seat
belts. If you turn the ignition switch
to the ON (II) position bef ore your
seat belt is f astened, the beeper will
sound and the indicator will f lash. If
your seat belt is not f astened bef ore
the beeper stops, the indicator will
stop f lashing but remain on. If a f ront passenger does not f asten
their seat belt, the indicator will
come on about 6 seconds af ter the
ignition switch is turned to the ON
(II) position.
If either the driver or a f ront
passenger does not f asten their seat
belt while driving, the beeper will
sound and the indicator will f lash
again at regular intervals.
When no one is sitting in the f ront
passenger’s seat, or a child or small
adult is riding there, the indicator
should not come on and the beeper
should not sound.
Additional Inf ormation About Your Seat Belts
Seat Belt System Components
18

Driver and Passenger Saf ety

2012 Crosstour

CONT INUED
During a frontal crash, your seat belt
restrains your lower body and torso,
and the f ront airbag helps protect
your head and chest.
Although both airbags normally
inf late within a split second of each
other, it is possible f or only one
airbag to deploy.
This can happen if the severity of a
collision is at the margin, or
threshold, that determines whether
or not the airbags will deploy. In
such cases, the seat belt will provide
suf f icient protection, and the
supplemental protection of f ered by
the airbag would be minimal.
If you ever have a moderate to
severe f rontal collision, sensors will
detect the vehicle’s rapid
deceleration.
If the rate of deceleration is high
enough, the control unit will inf late
the driver’s and f ront passenger’s
airbags, at the time and with the
f orce needed. Only the driver’s airbag can deploy if
there is no passenger in the f ront
seat, or if the advanced airbag
system has turned the passenger’s
airbag off (see page ).
An indicator on the instrument
panel that alerts you to a possible
problem with your airbag system
components or seat belt tensioners
(see pages and ).
Emergency backup power in case
your vehicle’s electrical system is
disconnected in a crash. An indicator on the dashboard that
alerts you that the passenger’s
f ront airbag has been turned of f
(see page ). An indicator on the instrument
panel that alerts you that the
passenger’s side airbag has been
turned of f (see page ).
25
29 55
30
30
Additional Inf ormation About Your Airbags
How Your Front A irbags Work
23

Driver and Passenger Saf ety

2012 Crosstour
