2012 HONDA CIVIC indicators

204
uuBefore DrivinguDriving Preparation
Driving
•Be sure items placed on the floor behind the front seats cannot roll under the seats.
uThey can interfere with the driver's ability to operate the pedals, the operation
of the seats, or the operation of the sensors under the seats.
• Everyone in the vehicle must fasten their seat belt.
2 Fastening a Seat Belt P. 31
• Make sure that the indicators in the instrument panel come on when you start the
vehicle, and go off soon after.
uAlways have a dealer check the vehicle if a problem is indicated.
2 Indicators P. 66

239
Maintenance
This chapter discusses basic maintenance.
Before Performing Maintenance Inspection and Maintenance ............ 240
Safety When Performing Maintenance..... 241
Parts and Fluids Used in Maintenance Service ........................................... 242
Maintenance Minder™ .................... 243
Maintenance Under the Hood Maintenance Items Under the Hood ..... 251
Opening the Hood ........................... 253
Recommended Engine Oil ...... .......... 254
Oil Check ......................................... 255
Adding Engine Oil ............................ 257
Changing the Engine Oil and Oil Filter ..... 258
Engine Coolant ................................ 261
Transmission Fluid ............................ 263
Brake/Clutch Fluid ............................ 266
Refilling Window Washer Fluid......... 267
Replacing Light Bulbs ....................... 268
Checking and Maintaining Wiper
Blades .......................................... 278
Checking and Maintaining Tires Checking Tires ................................. 280
Tire and Loading Information Label ...... 281
Tire Labeling .................................... 281
DOT Tire Quality Grading (U.S. Vehicles)....... 283
Wear Indicators................................ 285 Tire Service Life ................................ 285
Tire and Wheel Replacement ........... 286
Tire Rotation .................................... 287
Winter Tires ..................................... 288
Battery ............................................... 289
Remote Transmitter Care *
Replacing the Battery ....................... 290
Heating and Cooling *
System
Maintenance ................................... 291
Cleaning
Interior Care .................................... 292
Exterior Care.................................... 294
* Not available on all models

280
Maintenance
Checking and Maintaining Tires
Checking Tires
To safely operate your vehicle, your tires must be of the proper type and size, in
good condition with adequate tread, and properly inflated. ■Inflation guidelines
Properly inflated tires provide the best combination of handling, tread life, and comfort.
Refer to the driver’s doorjamb label or specification’s page for the specified pressure.
Underinflated tires wear unevenly, adversely affect handling and fuel economy, and
are more likely to fail from overheating.
Overinflated tires make your vehicle ride harshly, are more prone to road hazards, and wear unevenly.
Every day before you drive, look at each of the tires. If one looks lower than the
others, check the pressure with a tire gauge.
At least once a month or before long trips, use a gauge to measure the pressure in
all tires, including the spare. Even tires in good condition can lose 1 to 2 psi (10 to
20 kPa, 0.1 to 0.2 kgf/cm 2
) per month.
■ Inspection guidelines
Every time you check inflation, also examine the tires and valve stems.Look for:• Bumps or bulges on the side or in the tread. Replace the tire if you find any cuts,
splits, or cracks in the side of the tire. Replace it if you see fabric or cord.
• Remove any foreign objects and inspect for air leaks.
• Uneven tread wear. Have a dealer check the wheel alignment.
• Excessive tread wear.
2 Wear Indicators P. 285
• Cracks or other damage around valve stem.
1Checking Tires
Measure the air pressure when tires are cold. This
means the vehicle has been parked for at least three
hours, or driven less than 1 mile (1.6 km). If
necessary, add or release air until the specified
pressure is reached.
If checked when hot, tire pressure can be as much as
4–6 psi (30–40 kPa, 0.3–0.4 kgf/cm 2
) higher than if
checked when cold.
Have a dealer check the tires if you feel a consistent
vibration while driving. New tires and any that have
been removed and reinstalled should be properly balanced.
3WARNING
Using tires that are excessively worn or
improperly inflated can cause a crash in
which you can be seriously hurt or killed.
Follow all instruction s in this owner’s
manual regarding tire inflation and
maintenance.

uuChecking and Maintaining TiresuTire Labeling
282
Maintenance
The tire identification number (TIN) is a group of numbers and letters that look like
the example in the side column. TIN is located on the sidewall of the tire.
Cold Tire Pressure – The tire air pressure when the vehicle has been parked for at
least three hours or driven less than 1 mile (1.6 km).
Load Rating – Means the maximum load that a tire is rated to carry for a given
inflation pressure.
Maximum Inflation Pressure – The maximum tire air pressure that the tire can
hold.
Maximum Load Rating – Means the load rating for a tire at the maximum
permissible inflation pressure for that tire.
Recommended Inflation Pressure – The cold tire inflation pressure recommended
by the manufacturer.
Treadwear Indicators (TWI) – Means the projections within the principal grooves
designed to give a vi sual indication of the degrees of wear of the tread.
■Tire Identification Number (TIN)
■Glossary of Tire Terminology
1Tire Identification Number (TIN)
DOT B97R FW6X 2209
DOT: This indicates that the tire meets all
requirements of the U.S. Department of Transportation.
B97R: Manufacturer's identification mark.
FW6X: Tire type code.
22 09: Date of manufacture.
Year
Week

285
uuChecking and Maintaining TiresuWear Indicators
Maintenance
Wear IndicatorsThe groove where the wear indicator is
located is 1/16 inch (1.6 mm) shallower than
elsewhere on the tire. If the tread has worn so
that the indicator is exposed, replace the tire.
Worn out tires have poor traction on wet
roads.
Tire Service Life
The life of your tires is dependent on man y factors, including driving habits, road
conditions, vehicle loading, inflation pressure, maintenance history, speed, and
environmental conditions (even when the tires are not in use).
In addition to regular inspections and inflation pressure maintenance, it is
recommended that you have annual inspections performed once the tires reach five
years old. All tires, including the spare, should be removed from service after 10
years from the date of manufacture, regardless of their condition or state of wear.
1Checking Tires
High speed driving
We recommend that you do not drive faster than the
posted speed limits and conditions allow. If you drive
at sustained high speeds (over 118 mph or 190
km/h), adjust the cold tire pressures as shown below
to avoid excessive heat build up and sudden tire
failure.
*1: Optional for U.S. models (summer tires)
Tire SizeP215/45R17 87V
215/45ZR17 91W *1
Pressure 35 psi (240 kPa, 2.4 kgf/cm 2
)
2.4  engine modelsExample of a Wear
Indicator mark

340
INDEX
HFL Status Display.................................... 178
Making a Call .......................................... 195
Options During a Call .............................. 200
Phone Setup ............................................ 183
Receiving a Call ....................................... 199
Speed Dial ............................................... 192
To Clear the System ................................. 190
To Create a Security PIN........................... 188
Hazard Warning Button ............................... 2
Head Restraints ......................................... 129
Headlights ................................................. 118
Aiming .................................................... 268
Automatic Operation ............................... 119
Dimming ......................................... 118, 120
Operating ................................................ 118
Heaters (Seat) ............................................ 139
Heating and Cooling System .................... 140
Cooling ................................................... 142
Defrosting the Windshield and
Windows ............................................... 142
Dust and Pollen Filter ............................... 291
Heating ................................................... 141
HFL (HandsFreeLink ®
)............................... 177
High-Beam Indicator .................................. 73
I
Identification Numbers ............................ 328
Engine and Transmission.......................... 328
Vehicle Identification ............................... 328
Ignition Switch .......................................... 117 Illumination Control
................................. 122
Knob ....................................................... 122
Immobilizer System .................................. 112
Indicator.................................................... 74
Indicators .................................................... 66
ABS (Anti-lock Brake System)..................... 69
Charging System ............................... 67, 313
CRUISE CONTROL ............................. 75, 221
CRUISE MAIN .................................... 75, 220
Daytime Running Lights............................. 71
Door Open .......................................... 27, 70
ECON Mode ...................................... 75, 123
EPS (Electric Power Steering
System) ........................................... 71, 315
Fog Light ................................................... 73
High Temperature ..................................... 69
High-Beam ................................................ 73
Immobilizer System ................................... 74
i-VTEC ................................................. 75, 79
Lights On .................................................. 73
Low Fuel ................................................... 68
Low Oil Pressure ................................ 66, 313
Low Temperature ...................................... 74
Low Tire Pressure .............................. 72, 225
Low Tire Pressure/TPMS ............. 72, 225, 226
Maintenance Minder ......................... 75, 243
Malfunction Indicator Lamp............... 67, 314
Parking Brake and Brake System ........ 66, 315
REV ..................................................... 75, 79
Seat Belt Reminder .............................. 29, 68
Security System Alarm ............................... 74 Shift Position............................................. 67
Side Airbag Off ................................... 48, 73
Supplemental Restraint System ........... 46, 69
System Message ....................................... 72
TPMS ................................................ 71, 227
Transmission ............................................. 68
Trunk Open .............................................. 71
Turn Signal ............................................... 73 VSA
®
(Vehicle Stability Assist)
System ............................................ 70, 223
VSA ®
OFF .......................................... 70, 224
Washer Level ............................................ 75
Information .............................................. 323
Information Display ................................... 80
Instant Fuel Economy .......................... 78, 85
Instrument Panel ........................................ 65
Brightness Control .................................. 122
Interior Lights ........................................... 134
Interior Rearview Mirror ......................... 125
i-VTEC and REV Indicators ......................... 79
J
Jack (Wheel Nut Wrench) ........................ 302
Jump Starting ........................................... 307
K
Key Number Tag ...................................... 100
Keyless Lockout Prevention ..................... 102

342
INDEX
Trunk....................................................... 109
Outside Temperature Display .................... 85
Overheating .............................................. 311
P
Panic Mode ............................................... 113
Parking ...................................................... 233
Parking Brake ............................................ 229
Parking Brake and Brake System Indicator ............................................ 66, 315
Passenger Airbag Off Indicator ................. 47
Passing Indicators ..................................... 118
Power Windows ........................................ 114
Precautions While Driving ........................ 213
Rain ......................................................... 213
Pregnant Women ....................................... 33
Puncture (Tire) .......................................... 299
R
Radiator ..................................................... 262
Radio (AM/FM) .................................. 149, 158
Radio Data System (RDS) .................. 150, 160
Range .................................................... 81, 84
RDS (Radio Data System) .................. 150, 160
Readiness Codes (Emissions Testing) ....... 331
Rear Defogger/Heated Door Mirror
Button ...................................................... 123
Rear Seats (Folding Down) ....................... 132
Rearview Mirror ........................................ 125 Refueling
.................................................. 234
Fuel Gauge................................................ 78
Gasoline .................................. 234, 324, 326
Low Fuel Indicator ..................................... 68
Regulations ............................... 226, 283, 329
Remote Transmitter ................................. 101
Replacement
Battery .................................................... 290
Bulbs ....................................................... 268
Fuses ............................................... 318, 319
Tires ........................................................ 286
Wiper Blade Rubber ................................ 278
Reporting Safety Defects ......................... 330
Resetting a Trip Meter ......................... 80, 83
S
Safe Driving ................................................ 23
Safety Check ............................................... 27
Safety Labels ............................................... 63
Safety Message ........................................... 22
Seat Belts .................................................... 28
Adjusting the Shoulder Anchor.................. 32
Automatic Seat Belt Tensioners ................. 30
Checking................................................... 34
Fastening .................................................. 31
Installing a Child Seat with a Lap/
Shoulder Seat Belt ................................... 57
Pregnant Women ...................................... 33
Reminder .................................................. 29
Warning Indicator ............................... 29, 68 Seat Heaters
............................................. 139
Seats .......................................................... 126
Adjusting ................................................ 126
Front Seats.............................................. 126
Rear Seats ............................................... 132
Seat Heaters ........................................... 139
Security System ........................................ 112
Immobilizer System Indicator..................... 74
Security System Alarm Indicator ................ 74
SEL/RESET Knob .................................... 80, 82
Select Lever ................................ 15, 215, 217
Operation ................................. 15, 216, 217
Releasing ................................................ 310
Won’t Move ........................................... 310
Selecting a Child Seat ................................ 54
Selector Knob (Audio) ..................... 147, 155
Setting the Clock ........................................ 98
Shift Lever .................................. 15, 215, 217
Shift Position Indicator ...................... 67, 216
Shifting (Transmission) .................... 215, 217
Shoulder Anchor ........................................ 32
Side Airbags ............................................... 42
Cutoff System ........................................... 44
Off Indicator ............................................. 44
Side Curtain Airbags .................................. 45
Snow Tires ................................................ 288
Spare Tire ................................. 299, 325, 327
Spark Plugs ....................................... 324, 326
Specifications ........................................... 324
Specified Fuel ........................... 234, 324, 326
Speedometer .............................................. 78

343
INDEX
SRS Airbags (Airbags)................................ 38
Starting the Engine .................................. 211
Does Not Start ........................................ 306
Engine Switch Buzzer .............................. 117
Jump Starting ......................................... 307
Steering Wheel ........................................ 124
Adjusting ................................................ 124
Stopping ................................................... 233
Summer Tires ............................................ 288
Supplemental Restraint System (SRS) ....... 38
Switches (Around the Steering Wheel) ............................. 2, 3, 117
System Message Indicator ......................... 72
T
Tachometer ................................................ 78
Temperature
High Temperature Indicator ....... ............... 69
Low Temperature Indicator ....................... 74
Outside Temperature Display .................... 85
Temperature Sensor .................................. 85
Time (Setting) ............................................. 98
Tire Pressure Monitoring System
(TPMS) ..................................................... 225
Indicator ............................. 71, 72, 316, 317
Tires .......................................................... 280
Air Pressure............................. 281, 325, 327 Checking and Maintaining ...................... 280
Inspection ............................................... 280
Labeling .................................................. 281 Puncture (Flat Tire)................................... 299
Regulations ............................................. 283
Rotation .................................................. 287
Spare Tire ................................ 299, 325, 327
Summer .................................................. 288
Tire Chains .............................................. 288
Wear Indicators ....................................... 285
Winter ..................................................... 288
Tools .......................................................... 298
Towing a Trailer ....................................... 207
Equipment and Accessories ..................... 208
Load Limits .............................................. 207
Towing Your Vehicle ................................ 210
Emergency .............................................. 321
TPMS (Tire Pressure Monitoring
System) .................................................... 225
Indicator .............................. 71, 72, 316, 317
Transmission ..................................... 215, 217
Automatic ............................................... 215
Fluid ................................................ 263, 264
Manual.................................................... 217
Number ................................................... 328
Shift Position Indicator ....................... 67, 216
Trip Meter ............................................. 80, 83
Troubleshooting ....................................... 297
Blown Fuse ...................................... 318, 319
Brake Pedal Vibrates .................................. 19
Buzzer Sounds When Opening Door .......... 20
Emergency Towing .................................. 321
Engine Won’t Start .................................. 306
Noise When Braking .................................. 20 Overheating ............................................ 311
Premium Gasoline ........................... 234, 326
Puncture/Flat Tire .................................... 299
Rear Door Won’t Open...................... 19, 104
Select Lever Won’t Move ......................... 310
Warning Indicators .................................... 66
Trunk ......................................................... 109
Lid........................................................... 109
Light Bulb........................................ 324, 326
Turn Signals .............................................. 118
Indicators (Instrument Panel) ..................... 73
U
Unlocking the Doors ................................ 101
Unlocking the Front Doors from the Inside ......................................... 11
USB Adapter Cable ........................... 144, 145
USB Flash Drives ....................................... 176
VValet Key ................................................... 100
Vanity Mirrors ............................................... 5
Vehicle Identification Number ................ 328
Vehicle Stability Assist (VSA ®
).................. 223
Off Button............................................... 224
Off Indicator.............................................. 70
System Indicator ........................................ 70
Viscosity (Oil) ............................ 254, 325, 327
VSA ®
(Vehicle Stability Assist) .................. 223
