2012 HONDA CIVIC service indicator

248
uuMaintenance Minder™uTo Use Maintenance MinderTM
Maintenance
The system message indicator ( ) comes on along with the Maintenance Minder message.
■Maintenance Minder Messages on the Multi-Information
Display
Maintenance MessageOil Life DisplayExplanationInformation
SERVICE DUE SOON15 %The remaining engine oil life is 15 to
6 percent. Once you switch the
display by pressing the
(display/information) button, this
message will go off.The engine oil is approaching the end
of its service life, and the maintenance
items should be inspected and serviced
soon.
SERVICE DUE NOW5 %The remaining engine oil life is 5 to 1
percent. Press the button to
switch to another display.The engine oil has almost reached the
end of its service life, and the
maintenance items should be inspected
and serviced as soon as possible.
SERVICE PAST DUENegative DistanceThe remaining engine oil life has
passed its service life, and a negative
distance appears after driving over
10 miles (U.S. models) or 10 km
(Canadian models). Press the
button to switch to another display.The engine oil life has passed.
The maintenance items must be
inspected and serviced immediately.
2345
15
Engine oil
Air filters
2345
2345
5
Engine oil
Air filters
2345
23452345
-30

249
uuMaintenance Minder™uTo Use Maintenance MinderTM
Continued
Maintenance
■Maintenance Service Items1Maintenance Service Items •
Independent of the Maintenance Minder
information, replace the brake fluid every 3 years.
• Inspect idle speed every 160,000 miles (256,000
km).
• Adjust the valves during services A, B, 1, 2, or 3 if
they are noisy.
2345
Maintenance Minder
Message
System Message
Indicator
Sub Items
Main
Item
*1: If a message

285
uuChecking and Maintaining TiresuWear Indicators
Maintenance
Wear IndicatorsThe groove where the wear indicator is
located is 1/16 inch (1.6 mm) shallower than
elsewhere on the tire. If the tread has worn so
that the indicator is exposed, replace the tire.
Worn out tires have poor traction on wet
roads.
Tire Service Life
The life of your tires is dependent on man y factors, including driving habits, road
conditions, vehicle loading, inflation pressure, maintenance history, speed, and
environmental conditions (even when the tires are not in use).
In addition to regular inspections and inflation pressure maintenance, it is
recommended that you have annual inspections performed once the tires reach five
years old. All tires, including the spare, should be removed from service after 10
years from the date of manufacture, regardless of their condition or state of wear.
1Checking Tires
High speed driving
We recommend that you do not drive faster than the
posted speed limits and conditions allow. If you drive
at sustained high speeds (over 118 mph or 190
km/h), adjust the cold tire pressures as shown below
to avoid excessive heat build up and sudden tire
failure.
*1: Optional for U.S. models (summer tires)
Tire SizeP215/45R17 87V
215/45ZR17 91W *1
Pressure 35 psi (240 kPa, 2.4 kgf/cm 2
)
2.4  engine modelsExample of a Wear
Indicator mark

338
INDEX
Bulb Replacement..................................... 268
Brake Light, Taillight, Back-Up Light, Rear Turn Signal Light and Rear Side Marker
Lights..................................................... 275
Fog Lights ................................................ 272
Front Turn Signal/Parking/Side Marker Lights..................................................... 273
Headlights ............................................... 268
High-Mount Brake Light .......................... 277
Rear License Plate Light............................ 276
Bulb Specifications ............................ 324, 326
C
Carbon Monoxide Gas ................................ 62
Carrying Cargo .................................. 203, 205
CD Player ........................................... 151, 161
Certification Label .................................... 328
Changing Bulbs ......................................... 268
Charging System Indicator ................. 67, 313
Child Safety ................................................. 50
Childproof Door Locks ............................. 104
Emergency Trunk Opener ........................ 111
Child Seat .................................................... 50
Booster Seats ............................................. 61
Child Seat for Infants ................................. 52
Child Seat for Small Children ..................... 53
Installing a Child Seat with a Lap/
Shoulder Seat Belt.................................... 57
Larger Children .......................................... 60
Rear-facing Child Seat ............................... 52 Selecting a Child Seat ................................ 54
Using a Tether ........................................... 59
Childproof Door Locks ............................. 104
Cleaning the Exterior ............................... 294
Cleaning the Interior ................................ 292
Clock ............................................................ 98
Clutch Fluid ............................................... 266
Coat Hook ................................................. 138
Compact Spare Tire .................. 299, 325, 327
Console Compartment ............................. 135
Controls ....................................................... 97
Coolant (Engine) ...................................... 261
Adding to the Radiator ......... ............... .... 262
Adding to the Reserve Tank..................... 261
High Temperature Indicator ....................... 69
Low Temperature Indicator........................ 74
Overheating ............................................ 311
Creeping (Automatic Transmission) ........ 214
Cruise Control ........................................... 220
Indicator.................................................... 75
Cup Holders .............................................. 136
Customer Service Information ................. 336
Customized Features .................................. 86
D
Daytime Running Lights .......................... 120
Dead Battery ............................................. 307
Defrosting the Windshield and
Windows ................................................. 142
Devices that Emit Radio Waves ............... 329Dimming
Headlights .............................................. 118
Rearview Mirror ...................................... 125
Dipstick (Engine Oil) ................................ 255
Directional Signals (Turn Signal) ............. 118
Display/Information Button ...................... 82
Door Mirrors ............................................. 125
Doors .......................................................... 99
Auto Door Locking.................................. 105
Auto Door Unlocking .............................. 105
Door Open Indicator ........................... 27, 70
Keys.......................................................... 99
Locking/Unlocking the Doors
from the Inside...................................... 103
Locking/Unlocking the Doors from the Outside................................... 101
Lockout Prevention System ..................... 102
DOT Tire Quality Grading ........................ 283
Driving ...................................................... 201
Automatic Transmission .......................... 214
Braking ................................................... 229
Cruise Control ........................................ 220
Shifting Gear ...... ............................ 215, 217
Starting the Engine ................................. 211
Dust and Pollen Filter .............................. 291
E
Eco Assist System .......................................... 7
ECON Button ............................................ 123
Elapsed Time .............................................. 84

341
INDEX
Keys............................................................. 99
Lockout Prevention ................................. 102
Master Keys .............................................. 99
Number Tag............................................ 100
Rear Door Won’t Open ........................... 104
Remote Transmitter ................................ 101
Types and Functions.................................. 99
Valet Key ................................................ 100
Won’t Turn ............................................... 19
Kickdown (Automatic Transmission) ...... 214
L
Language (HFL) ........................................ 178
LATCH (Child Seats) ................................... 55
Lights ................................................ 118, 268
Automatic............................................... 119
Bulb Replacement ................................... 268
Daytime Running Lights .......................... 120
Fog Lights ............................................... 120
High-Beam Indicator ................................. 73
Interior.................................................... 134
Light Switches......................................... 118
Lights On Indicator.................................... 73
Turn Signals ............................................ 118
Load Limits ............................................... 205
Locking/Unlocking ..................................... 99
Auto Door Locking/Unlocking .... ............. 105
Childproof Door Locks ............................ 104
From Inside ............................................. 103
From Outside .......................................... 101 Keys .......................................................... 99
Using a Key ............................................. 102
Lockout Prevention System ...................... 102
Low Battery Charge .................................. 313
Low Fuel Indicator ...................................... 68
Low Oil Pressure Indicator ................. 66, 313
Lower Anchors ............................................ 55
Lubricant Specifications Chart ......... 324, 326
Luggage (Maximum Load Limit) ............. 205
M
Maintenance ............................................. 239
Battery .................................................... 289
Brake/Clutch Fluid ................................... 266
Cleaning.................................................. 292
Coolant ................................................... 261
Heating and Cooling System.................... 291
Maintenance Minder™............................ 243
Oil ........................................................... 255
Precautions.............................................. 240
Radiator .................................................. 262
Remote Transmitter ................................. 290
Replacing Light Bulbs............................... 268
Safety ...................................................... 241
Service Items ................................... 245, 249
Tires ........................................................ 280
Transmission Fluid ................................... 263
Under the Hood ...................................... 251
Malfunction Indicator Lamp .............. 67, 314
Manual Transmission ................................ 217 Map Lights
................................................ 134
Maximum Load Limit ............................... 205
Meters, Gauges ........................................... 78
Mirrors ...................................................... 125
Adjusting ................................................ 125
Door ....................................................... 125
Exterior ................................................... 125
Interior Rearview ..................................... 125
Modifications (and Accessories) .............. 238
Moonroof ................................................. 116
MP3 ........................................... 151, 161, 167
Multi-Information Display ......................... 82
N
Numbers (Identification) .......................... 328
O
Odometer ............................................. 80, 83
Oil (Engine) ............................................... 254
Adding .................................................... 257
Checking................................................. 255
Displaying Oil Life ............................ 243, 247
Low Oil Pressure Indicator ................. 66, 313
Recommended Engine Oil ....................... 254
Viscosity .................................................. 254
Opening/Closing Hood....................................................... 253
Moonroof ............................................... 116
Power Windows ...................................... 114
