2012 FORD SUPER DUTY service schedule

Ford Motor Company has recommended maintenance intervals for various
parts and component systems based upon engineering testing. Ford Motor
Company relies upon this testing to determine the most appropriate
mileage for replacement of oils and fluids to protect your vehicle at the
lowest overall cost to you and recommends against maintenance schedules
that deviate from the scheduled maintenance information.
Ford strongly recommends the use of genuine Ford replacement parts.
Parts other than Ford, Motorcraftor Ford-authorized remanufactured
parts that are used for maintenance replacement or for the service of
components affecting emission control must be equivalent to genuine
Ford Motor Company parts in performance and durability. It is the
owner’s responsibility to determine the equivalency of such parts. Please
consult yourWarranty Guidefor complete warranty information.
Non Ford-approved chemicals or additives are not required for factory
recommended maintenance. In fact, Ford Motor Company recommends
against the use of such additive products unless specifically
recommended by Ford for a particular application.
Oils, fluids and flushing
In many cases, fluid discoloration is a normal operating characteristic of the
chemical compound and may not necessarily demonstrate that a fluid
needs to be changed. Oils and fluids identified in this guide should be
changed at the specified interval or in conjunction with a repair. Flushing is
a viable way to change fluid for many vehicle sub-systems during scheduled
maintenance and should only be done using the same fluid required to
finish the maintenance procedure, or a Ford-approved flushing chemical.
Genuine Ford parts and service
When planning your maintenance services, consider your dealership for
all your vehicle’s needs.
There are a lot of reasons why your dealership is a great way to help
keep your vehicle running great.
Convenience
To make your service visit even more convenient, in many cases, you’ll find
extended evening hours and Saturday hours. How’s that for quality service?
Factory-trained technicians
Service technicians participate in extensive factory-sponsored training to
help them become the experts on the operation of your vehicle. Many
participate in Ford-sponsored training to become certified. Ask your dealer
about the training and certification their technicians have received.
Scheduled Maintenance Guide
69
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Genuine Ford and Motorcraftreplacement parts
Dealerships stock Ford and Motorcraftbranded replacement parts.
These parts meet or exceed Ford Motor Company’s specifications, and
we stand behind them. Maintenance parts installed at your dealership
carry a nationwide, 12 month/12,000 mile (20,000 km) parts and labor
limited warranty. Your dealer can give you details.
Value shopping for your vehicle’s maintenance needs
Your dealership recognizes the competitive landscape of maintenance and
light repair automotive services. With factory-trained technicians, and
one-stop service from routine maintenance like oil changes and tire
rotations to repairs like brake service, check out the value your dealers
can offer.
Owner checks and services
Certain basic maintenance checks and inspections should be performed
by the owner or a service technician at the intervals indicated. Service
information and supporting specifications are provided in theOwner’s
Guide.
Any adverse condition should be brought to the attention of your dealer
or qualified service technician as soon as possible for the proper service
advice. The owner maintenance service checks are generally not covered
by warranties so you may be charged for labor, parts or fluids used.
Maximum oil change interval
Normal schedule As indicated by the message center (do not
exceed one year or 10,000 miles [16,000 km])
Special operating
conditionsRefer toSpecial operating conditionslater in
this chapter
Maximum fuel filter change interval
Normal schedule 22,500 miles (36,000 km) or as indicated by the
message center (whichever comes first)
Special operating
conditionsRefer toSpecial operating conditionslater in
this chapter
Scheduled Maintenance Guide
70
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Normal Scheduled Maintenance
At every oil change
interval as indicated
by the message
centerChange engine oil and filter
Refill diesel exhaust fluid tank
Rotate tires, inspect tire wear and measure tread
depth; vehicles equipped with dual rear wheels
should only rotate the rear wheels if unusual
wear is observed
Perform multi-point inspection (recommended)
Inspect air filter restriction gauge, replace filter
as necessary
Inspect automatic transmission fluid level
Inspect brake pads, shoes, rotors, drums, brake
linings, hoses and parking brake
Inspect cabin air filter (if equipped)
Inspect engine cooling system strength and hoses
Inspect exhaust system and heat shields
Inspect front axle and U-joints; lubricate if
equipped with grease fittings (4WD vehicles)
Inspect half-shaft boots (if equipped)
Inspect steering linkage, ball joints, suspension,
tie-rod ends, driveshaft and U-joints; lubricate if
equipped with grease fittings
Inspect wheels and related components for
abnormal noise, wear, looseness or drag
Reset your Intelligent Oil Life Monitor™ after each engine oil and filter
change; refer to theInstrument Clusterchapter in yourOwner’s
Guide.
Do not exceed one year or 10,000 miles (16,000 km) between
service intervals
Scheduled Maintenance Guide
74
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

SPECIAL OPERATING CONDITIONS
If you operate your vehicleprimarilyin one of the conditions listed
below, you will need to have some items serviced more frequently. If you
onlyoccasionallyoperate your vehicle under any of these conditions,
you don’t need to perform the additional maintenance. For specific
recommendations, see your dealership service advisor or technician.
Frequent/extended idling (over 10 minutes per hour of normal
driving) or frequent low speed operation if vehicle is used for
stationary operation
As required Change engine oil and filter as indicated by
message center and perform services listed in the
scheduled maintenance chart
Every 15,000 miles
(24,000 km), 6 months,
600 engine hours or as
indicated by message
centerReplace engine- and frame-mounted fuel filters
Every 15,000 miles
(24,000 km) or 600
engine hoursInspect concentration (freeze-point protection)
and additive strength (corrosion inhibitor); add
engine coolant additive, if required
Every 60,000 miles
(96,000 km) or 2,400
engine hoursFlush and refill engine coolant; do not add
engine coolant additive
Perform the services noted in the preceding table at the specified
time/mileage (km) period either within 3,000 miles (4,800 km) of the
OIL CHANGE REQUIRED message appearing in the message center or
when the time/mileage (km) reading indicates service is due.
Example #1:The OIL CHANGE REQUIRED message comes on at
19,751 miles (31,786 km); perform the 22,500 mile (36,000 km) fuel
filter replacement.
Example #2:The OIL CHANGE REQUIRED message hasnotcome on
but the odometer reads 22,500 miles (36,000 km); perform the fuel filter
replacement. (i.e., Intelligent Oil Life Monitor™ was reset at 15,000 miles
[24,000 km].)
Note:Vehicles operating under these severe service conditions need to
have their maintenance requirements adjusted. This needs to be
considered when determining vehicle service intervals.
Scheduled Maintenance Guide
80
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Note:When adding coolant additive, do not exceed the specified
maximum of 48 fl. oz. (1.4L). Operating the engine with excessive
coolant additive may cause overheating which could lead to severe
permanent engine damage.
Note:After initial coolant flush and fill at 60,000 miles (96,000 km) or
2,400 engine hours, flush and fill every 45,000 miles (72,000 km) or
1,800 engine hours thereafter.
Frequent low speed operation, consistent heavy traffic less than
25 mph (40 km/h) and/or long rush hour traffic
As required Change engine oil and filter as indicated by
message center and perform services listed in the
scheduled maintenance chart
Every 15,000 miles
(24,000 km), 6 months,
600 engine hours or as
indicated by message
centerReplace engine- and frame-mounted fuel filters
Every 15,000 miles
(24,000 km) or 600
engine hoursInspect concentration (freeze-point protection)
and additive strength (corrosion inhibitor); add
engine coolant additive, if required
Every 60,000 miles
(96,000 km)Change transfer case fluid (4WD vehicles)
Every 60,000 miles
(96,000 km) or 2,400
engine hoursFlush and refill engine coolant; do not add
engine coolant additive
Perform the services noted in the preceding table at the specified
time/mileage (km) period either within 3,000 miles (4,800 km) of the
OIL CHANGE REQUIRED message appearing in the message center or
when the time/mileage (km) reading indicates service is due.
Example #1:The OIL CHANGE REQUIRED message comes on at
19,751 miles (31,786 km); perform the 22,500 mile (36,000 km) fuel
filter replacement.
Example #2:The OIL CHANGE REQUIRED message hasnotcome on
but the odometer reads 22,500 miles (36,000 km); perform the fuel filter
replacement. (i.e., Intelligent Oil Life Monitor™ was reset at 15,000 miles
[24,000 km].)
Scheduled Maintenance Guide
81
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Note:When adding coolant additive, do not exceed the specified
maximum of 48 fl. oz. (1.4L). Operating the engine with excessive
coolant additive may cause overheating which could lead to severe
permanent engine damage.
Note:After initial coolant flush and fill at 60,000 miles (96,000 km) or
2,400 engine hours, flush and fill every 45,000 miles (72,000 km) or
1,800 engine hours thereafter.
Sustained high-speed driving at Gross Vehicle Weight Rating
(maximum loaded weight for vehicle operation)
As required Change engine oil and filter as indicated by
message center and perform services listed in the
scheduled maintenance chart
Every 15,000 miles
(24,000 km), 6 months,
600 engine hours or as
indicated by message
centerReplace engine- and frame-mounted fuel filters
Every 15,000 miles
(24,000 km) or 600
engine hoursInspect concentration (freeze-point protection)
and additive strength (corrosion inhibitor); add
engine coolant additive, if required
Every 30,000 miles
(48,000 km)Replace wheel bearing grease and grease seals if
non-sealed bearings are used (2WD vehicles)
Every 50,000 miles
(80,000 km)Change rear axle fluid (if equipped with a Dana
rear axle; some F-350s, all F-450/550s)
Change transfer case fluid (4WD vehicles)
Every 60,000 miles
(96,000 km) or 2,400
engine hoursFlush and refill engine coolant; do not add
engine coolant additive
Perform the services noted in the preceding table at the specified
time/mileage (km) period either within 3,000 miles (4,800 km) of the
OIL CHANGE REQUIRED message appearing in the message center or
when the time/mileage (km) reading indicates service is due.
Example #1:The OIL CHANGE REQUIRED message comes on at
19,751 miles (31,786 km); perform the 22,500 mile (36,000 km) fuel
filter replacement.
Example #2:The OIL CHANGE REQUIRED message hasnotcome on
but the odometer reads 22,500 miles (36,000 km); perform the fuel filter
replacement. (i.e., Intelligent Oil Life Monitor™ was reset at 15,000 miles
[24,000 km].)
Scheduled Maintenance Guide
82
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Note:When adding coolant additive, do not exceed the specified
maximum of 48 fl. oz. (1.4L). Operating the engine with excessive
coolant additive may cause overheating which could lead to severe
permanent engine damage.
Note:After initial coolant flush and fill at 60,000 miles (96,000 km) or
2,400 engine hours, flush and fill every 45,000 miles (72,000 km) or
1,800 engine hours thereafter.
Operating in sustained ambient temperatures below -10°F
(-23°C) or above 100°F (38°C)
As required Change engine oil and filter as indicated by
message center and perform services listed in
the scheduled maintenance chart
Every 15,000 miles
(24,000 km),
6 months, 600 engine
hours or as indicated
by message centerReplace engine- and frame-mounted fuel filters
Every 30,000 miles
(48,000 km)Replace wheel bearing grease/grease seals if
non-sealed bearings are used (2WD vehicles)
Every 60,000 miles
(96,000 km)Change transfer case fluid (4WD vehicles)
Perform the services noted in the preceding table at the specified
time/mileage (km) period either within 3,000 miles (4,800 km) of the
OIL CHANGE REQUIRED message appearing in the message center or
when the time/mileage (km) reading indicates service is due.
Example #1:The OIL CHANGE REQUIRED message comes on at
19,751 miles (31,786 km); perform the 22,500 mile (36,000 km) fuel
filter replacement.
Example #2:The OIL CHANGE REQUIRED message hasnotcome on
but the odometer reads 22,500 miles (36,000 km); perform the fuel filter
replacement. (i.e., Intelligent Oil Life Monitor™ was reset at 15,000 miles
[24,000 km].)
Scheduled Maintenance Guide
83
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Towing a trailer or using a camper or car-top carrier
As required Change engine oil and filter as indicated by
message center and perform services listed in
the scheduled maintenance chart
Every 15,000 miles
(24,000 km) or 600
engine hoursInspect concentration (freeze-point
protection) and additive strength (corrosion
inhibitor); add engine coolant additive, if
required
Every 15,000 miles
(24,000 km),
6 months, 600 engine
hours or as indicated
by message centerReplace engine- and frame-mounted fuel filters
Every 30,000 miles
(48,000 km)Replace wheel bearing grease/grease seals if
non-sealed bearings are used (2WD vehicles)
Every 60,000 miles
(96,000 km)Change transfer case fluid (4WD vehicles)
Every 60,000 miles
(96,000 km) or 2,400
engine hoursFlush and refill engine coolant; do not add
engine coolant additive
Perform the services noted in the preceding table at the specified
time/mileage (km) period either within 3,000 miles (4,800 km) of the
OIL CHANGE REQUIRED message appearing in the message center or
when the time/mileage (km) reading indicates service is due.
Example #1:The OIL CHANGE REQUIRED message comes on at
19,751 miles (31,786 km); perform the 22,500 mile (36,000 km) fuel
filter replacement.
Example #2:The OIL CHANGE REQUIRED message hasnotcome on
but the odometer reads 22,500 miles (36,000 km); perform the fuel filter
replacement. (i.e., Intelligent Oil Life Monitor™ was reset at 15,000 miles
[24,000 km].)
Note:When adding coolant additive, do not exceed the specified
maximum of 48 fl. oz. (1.4L). Operating the engine with excessive
coolant additive may cause overheating which could lead to severe
permanent engine damage.
Note:After initial coolant flush and fill at 60,000 miles (96,000 km) or
2,400 engine hours, flush and fill every 45,000 miles (72,000 km) or
1,800 engine hours thereafter.
Scheduled Maintenance Guide
84
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)
