Exterior

VISUAL SEARCH
10

EXTERIOR

Remote control 20-21
Changing the battery, reinitialisation 21
Key 21
Starting 43
Central locking / unlocking 20, 24
Locking / unlocking the load space 20, 24
Alarm 22-23
Fuel cut-off, Diesel priming 115-116 Wiper blade 136
Door mirrors 81
Side repeater 128
Front lamps, foglamps,
direction indicators 45-47
Headlamp beam height adjustment 47
Changing front bulbs 126-128
Headlamp wash 48, 110
Snow shield 125
Front doors 24
Sliding side door 25
Key 21
Opening the bonnet 106
Filler cap, fuel tank 114-115
Towing, lifting 137-138
Towbar 102-103
Rear parking sensors 85 Load space 20, 24
Doors, tailgate 24-26
Emergency control 26
Temporary puncture repair kit 119-120
Spare wheel, jack,
changing a wheel, tools 121-125
Infl ation, pressures 148 Rear lamps,
direction indicators 45-46, 129
3rd brake lamp 130
Changing rear bulbs 126, 129 Accessories 104-105
Roof bars 104
Number plate lamp 130 Van dimensions 140-143
Platform cab dimensions 144-145
Brakes, pads 84, 109, 111
Emergency braking 86
ABS, EBFD 86
ASR, ESP 87
Tyre, pressure 148
Rear suspension 78-80

150


Instruments and controls



Headlamp beam height adjustment 47
Starter, ignition 43
Wiper controls 48-49
Automatic wiping 48
Screenwash / headlamp wash 48
Trip computer Section 9

Cruise control 50-52
Fixed speed limiter 52
Speed limiter 53-55

Steering mounted controls:


- NaviDrive Section 9

- MyWay Section 9

- Audio system Section 9

Lighting controls 45-47
Automatic illumination of headlamps 47
Foglamps 46
Daytime running lamps 46


Opening the bonnet 106
Parking brake, handbrake 84

Electric windows,
electric mirrors 81-83
Instrument panels, screens,
speedometers 27-28
Warning lamps, indicator lamps 29-34
Indicators, gauge 35, 37-38
Setting the time in the instrument panel 28
Dashboard lighting dimmer 38
Gear effi ciency indicator 39

Steering wheel adjustment 43
Horn 86
Right-hand side
dashboard fuses 131-132

Technical data - Maintenance

VISUAL SEARCH
10

TECHNICAL DATA - MAINTENANCE

Identifi cation markings, serial number,
paint code, tyres 148
Engine fuses 131, 134
Windscreen / headlamp wash, levels 110
Bulbs, lighting,
changing bulbs 126-130
Opening the bonnet, stay 106 Warning lamps 29-34
Changing a wiper blade 136
Under the bonnet


- Diesel 107

- petrol 108
Fuel cut-off,
Diesel priming 115-116
Engine technical data 147
Van dimensions 140-143
Platform cab dimensions 144-145
Weights 146
Model code 154 Checks 111-112


- battery,

- gearbox,

- carbon/passenger compartment fi lter,

- oil fi lter,

- particle emission fi lter,

- parking brake,

- brake pads,

- brake drums, discs.
Emissions controls (EOBD) 36 Water bleeding, Diesel fi lter 112 Levels 109-110


- Diesel additive,

- dipstick,

- power steering fl uid,

- brake fl uid,

- coolant,

- screenwash and headlamp wash fl uid.
Towing, lifting 137-138
Towed loads 146
