Starting-switching off the engine
)Inser t the electronic key in the reader. )Press the brake pedal for vehicles with automatic gearbox or electronic gearbox
system, or fully declutch for vehicles witha manual gearbox.
Starting using
the electronic key
Startin
g with the "Keyless
Entry and Starting" system

If one of the star ting conditions is not met, a reminder message appears in the instrument panel screen. In some circumstances, it is necessary to turnthe steering wheel slightly while pressingthe "START/STOP" button to assistunlocking of the steering; a messagewarns you when this is needed.
With a manual gearbox, put the gear lever in neutral.With the electronic gearboxsystem
, put the gear lever in N.
With an automatic gearbox
, put the gear lever in Por N
.


For Diesel vehicles, in very cold weather the engine willnot star t until the preheater warning lamp has gone off.
If this warning lamp comes on after
pressing "STA R T/STOP", you shouldhold the brake pedal down until thewarning lamp goes off.
)
With the electronic key inside the vehicle(it is not necessary to put it in the reader),
press the brake pedal for vehicles with
automatic
gearbox or electronic gearbox system, or fully declutch for vehicles with
a manual gearbox.
) Press the "START/STOP" button.
The engine starts.
)Press the " START/STOP
" button.
The engine star ts.

The "Keyless Entry and Star ting" devicemust be in the defined zone.
For safety reasons, do not leave thiszone with the vehicle running.

Emergency starting with
the Keyless Entry and Startingsystem
When the electronic key is in the defined zone and your vehicle does not star t after pressingthe "STA R T/STOP" button: )Inser t the electronic key in the reader. )Press the brake pedal on vehicles withautomatic gearbox or electronic gearbox
system, or fully declutch with a manualgearbox.)Press the "STA R T/STOP" button.The engine starts. In the event o
f an emergency only, the enginecan be switched of without conditions. To dothis, press and hold the "START/STOP" button
for about 3 seconds.
In this case the steering column locks as soon
as the vehicle stops.
I
f the electronic key is no longer in the defined
zone when driving or when you (later) request switching off the engine, a message appears in
the instrument panel.

Emergency switch- off
Electronic key not recognised by
the "Keyless Entry and Starting"
system
)Press and hold the "STA R T/STOP"
button for about 3 seconds if you want to
force switchin
g off the engine (note that restarting will not be possible without
the key).

97
Driving

It is recommended that you do not apply the parking brake in very coldconditions (ice) and during towing (breakdown, caravan...). For this, with the ignition on, deactivate the automatic functions and release theparking brake manually:)Manual gearbox:
engage first gear or reverse. )Electronic gearbox system
: select position Aor R.)
Automatic gearbox: select position Por R.

The electric parking brake combines2 operating modes:

-
Automatic Application/Release Application is automatic when the engine stops, release is automatic on use of the accelerator (this mode is activated by
default), -Manual Application/Release Manual application of the parking brake is done by pulling control lever A. Manual release is done by pulling
thenreleasing the control lever, while pressing
the brake pedal.
When the driver's door is opened, there is an
audible si
gnal and a message is displayed if the
brake is not applied.
Programming the automatic
mode
Depending on the country of sale of the vehicle,
the automatic application when the engine is switched off and the automatic release when
you press the accelerator can be deactivated.
You can contact a CITROËN dealer or a qualified workshop to have it activated.
In this case, pro
gramming is done via
the configuration menu.








Electric parking brake
If deactivated, the parking brake must
be applied and released manually.
If this warning lamp comes on in the instrument panel, the automatic modeis deactivated.
Never leave the vehicle withoutchecking that the parking brake is on.
This warning lamp comes onfixed.
Label on door panel

With the ignition on or the engine running, torelease the parking brake, press the brakepedal, pullthen release control lever A.
The full release of the parking brake isconfirmed by:


Manual release



- the braking warning lamp and
the Pwarning lamp in the control lever A going off,

- display of the message "Handbrake off".
I
f you pull the control lever A
without pressing
the brake pedal, the parking brake will not
be released and a message appears in the
instrument panel.
I
f necessary, you can make a maximum application
of the parking brake. It is obtained
by means of a long pull
on control lever A
,
until you see the message "Parking brake
applied fully" and an audible signal is heard.
Maximum application is essential:

- in the case of a vehicle towing a caravan
or a trailer, if the automatic functions are activated but you are applying the parking
brake manually,

- when the slope
you are parked on may
vary (e.g. on a ferry, on a lorry, duringtowing).


Maximum application


In the case of towing, a loaded vehicle or parking on a gradient, make amaximum application of the parking brake then turn the front wheels towardsthe pavement and engage a gear when you park.
After a maximum application, therelease time will be longer.



Before leaving the vehicle, check thatparking brake warning lamps in the instrument panel and the control lever Aare on fixed, not flashing.
With the vehicle stationary, to apply the parkingbrake whether the engine is running or off, pullcontrol lever A.
Manual application
The application of the parking brake is confirmed by:


- illumination of the brakin
g warning
lamp and of the P warning lamp in
the control lever A,
- display of the message "Handbrake on".
When the driver
’s door is opened with the engine running, there is an audible signal and amessage is displayed if the parking brake has not been applied, unless the selector lever is
in position P (Park) in the case of an automatic
gearbox.

99Driving

Before leaving the vehicle, check that parking brake warning lamps in the instrument panel and in the control lever Aare on fixed (not flashing).
Never leave a child alone inside thevehicle with the ignition on, as they could release the parking brake.



Automatic application,
engine off



- illumination of the braking warning
lamp and of the Pwarning lamp in
the control lever A ,

- display of the message "Handbrake on". With the vehicle stationar
y, the parking brake is automatically applied when the engine is
switched off. The application of the parking brake is confirmed by:
Automatic release
The electric parking brake releasesautomatically and progressively
when you press the accelerator:)Manual gearbox
: fully depress
the clutch pedal, engage 1stor reverse gear; press the accelerator
pedal and let up the clutch pedal until the brake releases.)Electronic gearbox system: select position A, M or R
then press the
accelerator pedal.
)Automatic gearbox: select
position D , M or Rthen press
the accelerator pedal.
Full release of the parkin
g brake is confirmed by:


- the brakin
g warning lamp and
the P warning lamp in the control
lever Agoing off,

- display of the message
"Handbrake off".
When stationary, with the engine running, do not press the accelerator pedal unnecessarily,
as you may release the parking brake.



Before leaving the vehicle, check that parking brake warning lamps in the instrument panel and the control lever Aare on fixed, not flashing.


Immobilising the vehicle,
engine running

With the engine running and the vehicle stationary, in order to immobilise the vehicleit is essential to manuallyapply the parking brake by pullingcontrol lever A.
The application of the parking brake isconfirmed by:
- illumination o
f the braking warninglamp and of the P
warning lamp in
the control lever A,
- display of the message"Handbrake on".
When the driver’s door is opened, a loud beep
is heard and a messa
ge is displayed if the
parking brake has not been applied, unless the gear lever is in position P(Park) in the case of
an automatic gearbox.

Emergency braking
In the event of a failure of the main servicebrake or in an exceptional situation (e.g. driver
taken ill, under instruction, etc) a continuouspull on the control lever A
will stop the vehicle.
The Dynamic Stability Control system provides stability during emergency braking.
If the emer
gency braking malfunctions, themessage "Parking brake control faulty" will be
displayed.
)Take the vehicle blocks and the release
device, located under the boot carpet.
)On sloping ground, secure the vehicle by placing chocks in front or behind the front
wheels, on the falling side of the slope.
The emergency braking must only be used in exceptional circumstances.
I
f a failure of the DSC system is
signalled by the illumination of this
warning lamp, then braking stability is
not guaranteed.
In this event, stability must be assured by the
driver by repeating alternate "pull-release"actions on the control lever A.








Emergency release

In the event of the electric parking brake
malfunctioning or the battery running flat, an emergency manual device can release the
parkin
g brake. ) Immobilise the vehicle:


- by engaging first gear (manual gearbox),

- with the engine running, position P(automatic gearbox) or Mor R
(electronicgearbox system).)
Switch off the engine then switch the
ignition on. If it is impossible to immobilise
the vehicle, do not operate the control and
contact a CITROËN dealer or a qualified
workshop urgently.

105
Driving





Hill start assist
System which keeps your vehicle immobilised
temporarily (approximately 2 seconds) whenstarting on a gradient, the time it takes to move your foot from the brake pedal to the
accelerator pedal.
This s
ystem only operates when:


- the vehicle is completely stationary, with your foot on the brake pedal,

- in par ticular conditions on a slope,

- with the driver’s door closed.
The hill star t assist system cannot be
deactivated.
On an ascendin
g slope, with the vehicle
stationary, the vehicle is held for amomentarily when you release the brake
pedal:- provided you are in first gear or neutral on
a manual
gearbox,
- provided you are in position A
or M
on an electronic gear control gearbox,
- provided you are in position D
or M
on an
automatic gearbox.
Operation
On a descending slope, with the vehicle
stationary and reverse gear engaged, thevehicle is held momentarily when you
release the brake pedal.

Do not exit the vehicle while it is beingheld in the hill star t assist phase.
If you need to exit the vehicle with the engine running, apply the parking brake manually then ensure that the parking brake warning lamp (and the warninglamp P
in the lever of the electricparking brake) are on fixed(not flashing).


Operating fault

If a fault in the system occurs, these warning
lamps come on. Contact a CITROËN dealer or a qualified workshop to have the systemchecked.

Only engage reverse gear when thevehicle is stationary with the engine at idle.
As a safety precaution and to facilitatestarting of the engine, always select neutral.









6-speed manual
gearbox
) Move the lever fully to the right to engage 5th or 6th gear.



Engaging 5th or 6th gear
Engaging reverse gear
)Raise the trigger under the knob and move
the gear lever to the left then forwards.
