2012 Citroen C4 RHD key

252
1
2
2
3
1
3
4
06USING THE TELEPHONE

Press PHONE
twice.

Select " Dial
" then confi rm.
Select " Directory of contacts
" then
confi rm.

Dial the telephone number using the
virtual keypad selecting each number
in turn.
Confi rm " OK
" to make the call.

Press TEL
or twice on PHONE
.
CALLING A NEW NUMBER

CALLING A CONTACT

Select the desired contact and confi rm.
If access was via the PHONE
button,
select " Call
" and confi rm.

Select the number and confi rm to start
the call.








MAKING A CALL

Use of the telephone is not recommended while driving. We
recommended that you park safely or make use of the steering
mounted controls.

255
1
2a
2b
2c
2d
06USING THE TELEPHONE

OPTIONS DURING A CALL *


During a call, press the MODE
button
several times to select display of the
telephone screen, then press " OK
" to
open the contextual menu.

Select " Private mode
" and confi rm to
take the call on the handset.
Or select " Hands-free mode
" and
confi rm to take the call via the vehicle's
speakers.

Select " Put call on hold
" and confi rm to
put the current call on hold.
Or select " Resume the call
" and
confi rm to resume the call on hold.
Select " DTMF ring tones
" to use the
numerical keypad, so as to navigate
through the menu of an interactive vocal
server.

Select " Hang up
" to end the call.

* Depending on the compatibility of the phone and your service plan.
it is possible to hold a 3-way conference call by making 2 calls
in succession. Select " Conference



mode call
" in the contextual
menu accessible using the TEL
button at the steering mounted
controls.

258
07
1a
1b
1c
1
2
RADIO

By alphabetical list
Press RADIO
or LIST
, select the station
of your choice and confi rm.

By automatic frequency search
Press
or
for the automatic search
for a lower or higher radio frequency.
Or turn the thumb wheel at the steering
mounted controls.

By manual frequency search
Press
or
to adjust the radio
frequency step by step.

Press the button on the numerical
keypad to recall a preset station.
Or press then turn the thumb wheel at
the steering mounted controls.








SELECTING A STATION


The external environment (hill, building, tunnel, underground car park...) may interfere with the reception, including in RDS station tracking mode. This
phenomenon is a normal result of the way in which radio waves are transmitted and does not in any way indicate a fault with the audio system.


PRESETTING A STATION


Press one of the buttons on the
numerical keypad for 2 seconds to
preset the current station.
An audible signal confi rms that the
station has been preset.
The quality of reception is represented
by the number of active waves in this
symbol.

292
05
7
8
Saisir code authentification
01
OK Del23456789 _
9
10
USING THE TELEPHONE

A virtual keypad is displayed on the
screen: enter a code with at least
4 digits and conform with OK
.

A message is displayed on the screen of the
telephone: enter the same code and confi rm.
A message appears in the screen to confi rm the result of the
connection.

Pairing can also be initiated from the telephone by searching for
detected Bluetooth devices.
Accept the connection to the telephone.

If pairing fails, try agin; the number of attempts is not limited.
The directory and the calls list can be accessed after the
synchronisation period (if the telephone is compatible).
Automatic connection must be confi gured in the telephone to allow
the connection each time the vehicle is started.

In some cases, the reference number of the telephone may appear
instead of the name of the telephone.

298
2e
2d
05USING THE TELEPHONE
From the contextual menu, select
" DTMF tones
" and confi rm to use
the digital keypad to navigate in the
interactive voice response menu.
From the contextual menu, select
" Switch
" and conform to return to a call
left on hold.

Interactive voice response

Consultation call

303
08 TRIP COMPUTER


Each press of the button, located at the end of the
wiper stalk, displays the different trip computer
information in succession, depending on the screen.


- the "vehicle " tab with:


●
the range, the current fuel consumption and
the distance remaining to the destination or the
Stop & Start time counter,

- the "1" tab (trip 1) with:


●
the average speed, the average consumption
and the distance travelled calculated over trip " 1
",

- the "2" tab (trip 2) with the same information for a
second trip.

Zero reset
When the required trip is displayed, press the control
for more than two seconds.

Range:
displays the distance which can travelled with the remaining fuel
detected in the tank, basd on the average consumption over the last few
miles (kilometres).
This displayed value may vary signifi cantly following a change in the
vehicle speed or the relief of the route.
When the range falls below 20 miles (30 km), dashes are displayed.
After fi lling with at least 10 litres of fuel, the range is recalculated and is
displayed when it exceeds 60 miles (100 km).
If, whilst driving, dashes are displayed continuously in place of the digits,
contact a CITROËN dealer.
A FEW DEFINITIONS


Current fuel consumption:
only calculated and displayed above 20 mph (30 km/h).


Average fuel consumption:
this is the average fuel consumption since
the last trip computer zero reset.

Distance travelled:
calculated since the last trip computer zero reset.

Distance remaining to the destination:
calculated with reference to
the fi nal destination, entered by the user. If guidance is activated, the
navigation system calculates it as a current value.

Average speed:
this is the average speed calculated since the last trip
computer zero reset (ignition on).







Stop & Start time counter
(minutes/seconds or hours/minutes)
If your vehicle is fi tted with Stop & Start, a time counter calculates the
time spent in STOP mode during a journey.
It resets to zero every time the ignition is switched on with the key.

316
ALPHABETICAL INDEX
E EBA (Emergency braking
assistance) ...............................132
Eco-driving ..................................26
Economical driving ......................26
Economy mode ..........................203
Electric window controls ...............90
Electronic brake force distribution
(EBFD) .....................................132
Electronic
engine immobiliser ...............81, 83
Electronic stability control
(ESC) .......................................133
Emergency boot release ..............89
Emergency braking system ........132
Emergency call ...................134, 224
Emergency warning lamps .........130
eMyWay ...............................56, 225
Energy economy mode ..............203
Engine, Diesel ......94, 175, 177, 217
Engine, petrol ............... 94, 176, 211
Engine compartment ..........176, 177
Engine compartment fusebox ....197
Engine
oil level indicator ...........44, 47, 178
Engines ...................... 211, 215, 217
Environment ...........................26, 83
Equipment settings .....51, 53, 56, 57
ESC/ASR ...................................133
ESP ............................................133
F Filling with fuel .........................93-95
Fitting a wheel ............................189
Fitting roof bars ..........................204
Fittings, boot ............................... 118
Fitting speakers ..........................208
Flashing indicators 99, 130, 192, 194
Foglamps, rear .....................98, 195F Front foglamps .....98, 104, 191, 194
Front seats .............................71, 72
Fuel ........................................26, 94
Fuel consumption .........................26
Fuel fi ller fl ap ..........................93, 95
Fuel gauge ...................................93
Fuel tank ................................93, 95
Fusebox, dashboard ..................197
Fuses .........................................197
G G.P.S. .........................................234
Gearbox, automatic ............154, 181
Gearbox, electronic ....151, 158, 181
Gearbox,
manual .............149, 150, 158, 181
Gear effi ciency indicator .............150
Gear lever ....................................26
Gear lever, automatic gearbox ...154
Gear lever, electronic gearbox
system ......................................151
Gear lever, manual gearbox .......149
Glove box ................................... 111
Grab handles .............................. 110
Guidance ............................232, 239
H Halogen headlamps ...................191
Hands-free kit .....................248, 291
Hazard warning lamps ...............130
Headlamp adjustment ................102
Headlamps,
directional .................102, 103, 191
Headlamp wash .........................106
Head restraints, front ....................73
Head restraints, rear ....................75
Heated seats ................................73
Heating ...................................26, 65H Height and reach adjustment,
steering wheel ............................78
Hill start assist ............................157
Hooks ......................................... 119
I Ignition ..........................................81
Indicator lamps, status .................41
Indicators, direction ............130, 192
Infl ating accessories
(using the kit) ............................182
Infl ating tyres ................................26
Inputs for audio
system ...................... 112, 265, 289
Installing speakers .....................208
Instrument panel lighting ..............49
Instrument
panels ................. 28-31, 47, 50, 57
Instrument
panel screen ................. 28-31, 150
Intelligent Traction Control .........133
Interior fi ttings ......................110, 111
Interior mood lighting ..................109
ISOFIX child seats ..............126-128
ISOFIX mountings ......................126
J Jack ............................................187
JACK socket ............... 112, 265, 289
K Keeping children
safe ..........121, 124, 127, 128, 138
Key in ignition warning .................81
Key with remote control .....79-81, 83
L
Labels, identifi cation ...................221
Lamps, warning
and indicator ...................33, 40, 43
