2012 Citroen C4 RHD navigation

236
04

Service station
Garage
CITROËN
Motor racing circuit
Covered car park
Car park

Rest area
Hotel
Restaurant
Cafeteria
Bed and breakfast

Airport Bus station
Port

Industrial estate
Supermarket
Bank
Vending machine

Sports complex, sports centre,
sports ground
Swimming pool
Winter sports resort
Entertainment, show
Cinema Railway station

Hospital, Chemist, Vet
Police station
School
Town hall
Post offi ce
Museum, Culture, Theatre,
Historic monument
Tourist information, Tourist
attraction
Automatic speed camera *
Red light camera *
Risk area *

Theme parks


LIST OF PRINCIPAL POINTS OF INTEREST (POI)
NAVIGATION - GUIDANCE

This icon appears when several POIs are grouped
together in the same area. Zooming in on this icon
shows details of the POIs.

*
According to availability in the
country. University










The detailed procedure for updating POIs can be found at citroen.navigation.com.

237
1
2
3
04NAVIGATION - GUIDANCE

ALERT PARAMETERS
RISK AREAS

Press NAV
to display the " Navigation -
guidance
" menu.

Select:


- "Visual alert"

- "Audible alert"

- "Alert only in guidance"

- "Overspeed alarm only".
The choice of time of notifi cation defi nes
how long in advance that speed camera
warnings are given.
Select " OK
" to confi rm the screen.
Select " Guidance options
" and confi rm,
then select " Set parameters for risk
areas
" and confi rm.
These functions are only available if risk areas have been
downloaded and installed on the system.
The detailed procedure for updating risk areas can be found
at www.citroen.co.uk.

238
04
1
4
3
1
3
22
NAVIGATION - GUIDANCE

ADDING A STAGE


Press NAV
to display the
" Navigation - guidance
" menu.

Select " Journey leg and route
" then
confi rm.

Select " Close to
" a route passing
close to the stage or " Strict
" for a route
passing through the stage.
Confi rm " OK
" to start the guidance, and
give a general indication of the guidance
route.

Select " Add a stage
" then confi rm .
The address of the stage is entered as
a destination, by " Enter an address
",
a contact in " Directory
", or " Previous
destinations
".


ORGANISING STAGES


To organise stages, carry out operations
1 to 2 again, then select " Order/delete
journey legs
" and confi rm.

Select and confi rm to save the
modifi cations.
Select the stage that you want to move
in the order.

Select " Delete
" to delete the stage.

239
04
3
4
1
2
NAVIGATION - GUIDANCE






ROUTE OPTIONS


CALCULATION CRITERIA

Select " Guidance options
" and confi rm.

Select " OK
" and confi rm to save
the modifi cations.

Select " Defi ne calculation criteria
" and
confi rm.
This function allows modifi cation of:


- the guidance criteria: (" Fastest
route
", " Shortest route
",
" Distance/Time
"),

- the exclusion criteria: (" With tolls
"
or " With Ferry
"),

- traffi c avoidance: (" Traffi c info
").

Press NAV
to display the
" Navigation - guidance
" menu.
If traffi c avoidance (Traffi c info) is selected, the system suggests
an alternative route if there is a delay on the guidance route.

240
04
35
1
2
4
NAVIGATION - GUIDANCE

Press NAV
to display the
" Navigation - guidance
" menu.


MAP MANAGEMENT


SELECTING THE POINTS OF INTEREST DISPLAYED ON THE MAP


Select " Map management
" and confi rm.
Select from the various categories the
ones that you want to display on the
screen.

Select " Map details
" and confi rm.
Select " By default
" to have only " Oil stations, garages
" and
" Accident-prone area
" appear on the map (if installed in the
system).

Select " OK
" then confi rm and
select " OK
" again then confi rm to save
the modifi cations.

241
04
3
1
2
4
NAVIGATION - GUIDANCE

Select " Map management
" and confi rm.
Select:


- " Vehicle direction
" to have the map
follow the direction of travel,

- " North direction
" to keep the map
always North up,

- " Perspective view
" to display a
perspective view.


Select " Map orientation
" and confi rm.
The colour of the map, different from the day and night mode, is
confi gured in the " SETUP
" menu.

MAP ORIENTATION

Press NAV
to display the
" Navigation - guidance
" menu.

Street names are visible on the map from the 100 m scale.

242
04
1
2
36
4
5
NAVIGATION - GUIDANCE

Press NAV
to display the
" Navigation - guidance
" menu.







ADJUSTING THE GUIDANCE SPEECH SYNTHESIS


Select " Guidance options
" and confi rm.
ADJUSTING THE VOLUME/DEACTIVATION

Select " Set speech synthesis
" and
confi rm.
Select the volume graph and confi rm.

Select " Deactivate
" to deactivate voice messages.

Select " OK
" and press the dial to
confi rm.

Adjust the volume to the desired level
and confi rm.
The volume of messages can be adjusted during the transmission
of the message using the volume adjustment control.
The volume setting of guidance messages is also accessible via the
" SETUP
"/" Voice synthesis
" menu.

243
04
3
1
2
NAVIGATION - GUIDANCE


MALE VOICE/FEMALE VOICE

Press SETUP
to display the
confi guration menu.

Select " Select male voice
" or " Select
female voice
" then confi rm " Ye s
" to
activate a male or female voice. The
system restarts.

Select " Voice synthesis
" and confi rm.
