Visibility
Certain windscreen wiper functions(intermittent operation, ...) can beconfigured via the colour screen"Equipment" menu.

Manual controls


Windscreen wipers
B.
intermittent operation or rain sensor sensitivity adjustment ring.
Windscreen wash
Pull the wiper stalk towards you. Thewindscreen wash then the wipers operate for aset time. The headlamp wash is also activated if the
dipped beam headlamps are on.


Headlamp wash

Press the end of the lighting stalk to activate
the headlamp wash, when the dipped beam
headlamps are on. sin
gle wipe.
park.
intermittent
(the speed can be set
manually).
or
automat
ic rain sensitive wipers(the speed can be set manually).
slow.
f
ast.
A
.wiping speed selection stalk:
Y
ou can increase or decrease:
- the wiping frequency when the intermittent
mode is active,- the sensitivity of the rain sensor when theautomatic mode is active.


- "+": high sensitivity.

- "-": low sensitivity.


To reduce the consumption of screenwash fluid, the headlampwashers only operate with the firstoperation of the screenwash.

180
Practical information








Changing a bulb
For bulbs that have alignment lugs (H1, H7...) ensure that they arefitted correctly for the best lightingperformance.

The headlamps have polycarbonate lenses with a protective coating:)do not clean them using a dry or abrasive cloth, nor with a detergent or solvent product,)use a sponge and soapy water, )when using a high pressurewasher on persistent marks,do not keep the lance directedtowards the lamps or their edges for too long, so as not to damage their protectivecoating and seals.
)Do not touch the bulb directly withyour fingers, use lint-free cloths. Changing a bulb should only be doneafter the headlamp has been switched off for a few minutes (risk of seriousburns). It is imperative to use only anti-ultraviolet (UV) type bulbs in order notto damage the headlamp. Always replace a failed bulb with a new bulb with the same type andspecification.
Risk of electrocution
Replacement of the xenon bulbs (D1S-35W) must be carried out bya CITROËN dealer or a qualified workshop.


Front lamps
1.Direction indicators(W Y21W-21W).2.Main beam headlamps (H1- 55W).3.Dipped beam headlamps (H11- 55W) or
Xenon bulb (D1S-35W).4.Sidelamps (W5W-5W).5.Daytime running lamps(P13W-13W).6. Daytime running lamps / sidelamps (light emitting doides-LEDs).7.Front foglamps (H11- 55W).

182
Practical information
) Remove the protective plastic cover.)
Turn the bulb holder to the left and pull it out. )
Remove the bulb and its base by pressing on the lug at the bottom. )
Change the bulb.
For reassembly, carry out these operations in reverse order.
Changing main beam headlamp bulbs (2)
)
Turn the bulb holder a quar ter turn to the
left and pull it out. ) Pull out the bulb and replace it.
To reassemble, carry out these operations in reverse order.
Changing the daytime running lamps / sidelamps (light-emittingdiodes - LEDs) (6)
For the replacement of this type of LED lamp,contact a CITROËN dealer or a qualified
workshop.
Changing dipped headlamp
bulbs (3)
For the replacement of these bulbs, contact aCITROËN dealer or a qualified workshop.

To replace these bulbs contact a CITROËN
dealer or a qualified workshop.

Changing front foglamp
bulbs (7) / daytime running lamp bulbs (5)

187
7
Practical information

Dashboard fuses

The fusebox is located in the lower dashboard(left-hand side).


Access to the fuses
)Open the cover and remove it completely
by pulling it towards you.
Fuse N°RatingFunctions
1*30 A Cabin fan.
2 15 A
Brake lam
ps, third brake lamp.
310 A
Rear foglamps.
430 A Windscreen wiper, screenwash.
620 A
Central locking, electric door mirrors.
7 15 A
Audio equipment, telematics, USB unit, Bluetooth s
ystem.
87. 5 A
Remote control key, air conditioning control unit, instrument
panel, electric windows, rain and sunshine sensors, alarm,
switch panel, steering mounted controls.
915 A
Instrument panel and interior lighting.
1015 A
Hazard warning lamps
1115 A Rear wiper.
12 7.5
A Instrument panel, multifunction screen, parking sensors, heated seats, heated rear screen, electric blind, automatic headlampadjustment.
1
315 A
Cigarette lighter, accessory socket.
1520 A
Electric blind.
1
610 A Door mirrors, audio equipment.

189
7
Practical information

Engine compartment fuses


Access to the fuses
)Unclip the cover and remove it completely.
Fuse N°RatingFunctions
115 A
Front foglamps.
410 A
Horn.
57.5
A Alternator.
620 A Headlamp wash.
7 10 A
Air conditionin
g.
920 A
Alarm.
1015 A
Demisting, wipers.
11- Not used.
12-
Not used. The fusebox is placed in the en
gine compartment (left-hand side).

190
Practical information
Fuse N°RatingFunctions
1
310 A
Daytime running lamps.
14 10 A
Left-hand main beam headlamp.
1510 A Right-hand main beam headlamp.
1
620 A Left-hand dipped beam headlamp (xenon).
1
720 A Right-hand dipped beam headlamp (xenon).
1810 A Left-hand dipped beam headlamp (halogen), manual and
automatic headlamp adjustment.
1
910 A
Right-hand dipped beam headlamp (halogen).
3130 A
Audio amplifier.


The maxi-fuses provide additional protection for the electrical systems. All work on the maxi-fuses must be carried out by a CITROËN dealer or a qualified workshop.


Carefully close the cover after replacinga fuse so as to ensure the correctsealing of the fusebox.

195
7
Practical information

Removing a front or rear
wiper blade
) Raise the corresponding wiper arm.)
Remove the wiper blade, sliding it towards
the outside.










Changing a wiper
blade

Fitting a front or rear wiper
blade
) At the front, check the size of the wiper blade as the shorter blade is fitted on the
right-hand side of the vehicle.) Put the corresponding new wiper blade in
place and fix it. )
Fold down the wiper arm carefully.


Automatic power cut-off to accessories

After the engine has stopped, when the ignition switch is in the "ACC" position(or the vehicle in "ACC" mode)
you can still use functions such as the audio equipment, windscreen wipers, dipped beamheadlamps, cour tesy lamps, etc. for about
t
hirty minutes.
Cutting off
Once the thir ty minutes have expired, thepower supply to the accessories will be automatically cut off.
Restoring power
The power supply will be restored the next time
the ignition is switched on.

The period before cut-off can beextended up to about sixty minutes or deactivated, via the colour screen"Equipment" menu.

206
Checks
fluids and the replacement of cer taincomponents.














Petrol engines
1.
Screenwash and headlamp wash fluidreservoir.2.
Coolant header tank.3.
Brake fluid reservoir.4.
Battery. 5.
Fusebox.
6.Air filter.
7. Engine oil dipstick. 8.Engine oil filler cap.
1.6 litre 115
2.0 litre 150
