2012 Citroen C3 PICASSO belt

7
95
CHILD SAFETY
INSTALLING CHILD SEATS ATTACHED USING THE SEAT BELT
In accordance with European regulations, this table indicates the options for installing child seats secured using a seat belt
and universally approved (a)
in accordance with the weight of the child and the seat in the vehicle.

a
Universal child seat: child seat that can be installed in all vehicles using a seat belt.

b
Group 0: from birth to 10 kg. Shells seats and baby carriers cannot be installed in the front passenger seat.

c
Consult the legislation in force in your country before installing your child on this seat.

U:
Seat suitable for the installation of a child seat secured using a seat belt and universally approved, "rearwards-facing"
and/or "forwards-facing".

X:
Seat position not suitable for installation of a child seat for the weight class indicated.
CITROËN recommends that children travel in the rear seats, with the rear seats in the fully back position.

Weight of the child and indicative age




Seat



Under 13 kg


(groups 0 ( b )
and 0+)
Up to approx 1 year

From 9 to 18 kg


(group 1)
1 to 3 years approx

From 15 to 25 kg


(group 2)
3 to 6 years approx

From 22 to 36 kg


(group 3)
6 to 10 years approx
Front passenger
seat ( c )

U



U



U



U


Outer rear seats

U



U



U



U


Centre rear seat

X



X



X



X

7
CHILD SAFETY




ADVICE ON CHILD SEATS


Installing a booster seat
The chest part of the seat belt must
be positioned on the child's shoulder
without touching the neck.
Ensure that the lap part of the seat
belt passes correctly over the child's
thighs.
CITROËN recommends the use of
a booster seat which has a back, fi t-
ted with a seat belt guide at shoulder
level. As a safety precaution, do not leave:


- a child or children alone and un-
supervised in a vehicle,

- a child or an animal in a vehicle
which is exposed to the sun, with
the windows closed,

- the keys within reach of children
inside the vehicle.
To prevent accidental opening of the
doors and rear windows, use the
"Child lock".
Take care not to open the rear win-
dows by more than one third.
To protect young children from the
rays of the sun, fi t side blinds on the
rear windows.
The incorrect installation of a child
seat in a vehicle compromises the
child's protection in the event of an
accident.
Remember to fasten the seat belts or
the child seat harnesses keeping the
slack relative to the child's body to a
minimum, even for short journeys.
When installing a child seat using the
seat belt, ensure that the seat belt is
tightened correctly on the child seat
and that it secures the child seat fi rm-
ly on the seat of your vehicle. If your
passenger seat is adjustable, move it
forwards if necessary.
For optimum installation of the "for-
wards-facing" child seat, ensure that
the back of the child seat is in contact
with the back of the vehicle's seat
and that the head restraint does not
cause any discomfort.
If the head restraint has to be re-
moved, ensure that it is stored or
attached securely to prevent it from
being thrown around the vehicle in
the event of sharp braking. Children under the age of 10 must
not travel in the "forwards-facing"
position on the front passenger seat,
unless the rear seats are already oc-
cupied by other children, cannot be
used or are absent.
Deactivate the passenger airbag
when a "rearwards-facing" child seat
is installed on the front seat.
Otherwise, the child would risk being
seriously injured or killed if the airbag
were to infl ate.

7
97
CHILD SAFETY
"ISOFIX" MOUNTINGS
Your vehicle is approved to the new
ISOFIX regulations
.
The seats represented below, are fi tted
with regulation ISOFIX mountings. There are 3 rings for each seat:


- 2 rings A
, located between the back-
rest and the seat cushion, identifi ed
by a label,
- a ring B
, located in the roof, with the
TOP TETHER
logo, for fi xing the top
tether belt.

7
CHILD SAFETY
This ISOFIX mounting system provides
reliable, safe and fast fi tting of the child
seat in your vehicle.

ISOFIX child seats
are fi tted with two
latches which are secured easily on
these rings A
.
Some also have a top tether belt
which
can be attached to ring B
.
To attach this belt, raise the head re-
straint of the seat, then pass the buckle
between the rods. Then fi x the buckle
on ring B
, then tension the top tether
belt.
If a child is not installed in a vehicle cor-
rectly, the child's protection in the event
of a collision will be compromised.
To know which ISOFIX child seats can
be installed in your vehicle, see the ta-
ble of seating positions for ISOFIX child
seats.
The rear seats must be in the fully back
position to install ISOFIX seats.
This child seat can also be used on seats which are not fi tted with ISOFIX
mountings. In this case, it must be attached to the vehicle seat using the
three point seat belt.

Follow the instructions for fi tting the child seat given in the seat manu-
facturer's installation guide. APPROVED FOR YOUR VEHICLE



RÖMER
Duo Plus ISOFIX

(size category B1
)


Group 1: from 9 to 18 kg



Installed only in the forwards-facing position.
Fitted with an upper strap to be secured on the up-
per ring B
, referred to as the TOP TETHER.
Three seat body angles: sitting, reclining, lying.


)
Adjust the front seat of the vehicle so that the
child's feet do not touch the back of the seat.

7
99
CHILD SAFETY
TABLE OF SEATING POSITIONS FOR ISOFIX CHILD SEATS
In accordance with European Regulations, this table indicates the options for installing ISOFIX child seats on seats in the
vehicle fi tted with ISOFIX mountings.
In the case of universal and semi-universal ISOFIX child seats, the ISOFIX size category, determined by a letter from A
to G
,
is indicated on the child seat next to the ISOFIX logo.

IUF:
seat suitable for the installation of an I
sofi x U
niversal seat, " F
orwards-facing" secured using the top belt.

IL-SU:
seat suitable for the installation of an I
sofi x S
emi- U
niversal seat either:


- "rearwards-facing" fi tted with a top belt or a stay,

- "forwards-facing" fi tted with a stay,

- a shell seat fi tted with an upper strap or a stay.
For advice on securing the top tether belt, refer to the "Isofi x mountings" section.

* The ISOFIX infant car seat (shell seat), secured on the lower rings of a vehicle ISOFIX seat, occupies two rear seats.



Weight of the child
/indicative age


Less than 10 kg
(group 0)


Up to approx.
6 months

Less than 10 kg


(group 0)
Less than 13 kg


(group 0+)


Up to approx. 1 year

From 9 to 18 kg (group 1)


From approx. 1 to 3 years


Type of ISOFIX child seat



Shell



"rearwards-facing"



"rearwards-facing"



"forwards-facing"




ISOFIX size category



F


G


C



D



E



C



D



A



B



B1




ISOFIX universal and
semi-universal child seats
which can be installed on the

outer

rear

seats



IL-SU

*


IL-SU



IL-SU



IUF


IL-SU

8
104
SAFETY

Height adjustment

Seat belt not fastened/unfastened
warning lamp









Fastening


)
Pull the strap, then insert the tongue
in the buckle.

)
Check that the seat belt is fastened
correctly by pulling the strap.


)
To lower the attachment point,
squeeze the control A
and slide it
downwards.

)
To raise the attachment point, slide
the control A
upwards.

When the ignition is switched
on, this warning lamp comes on,
either on the instrument panel or
on the seat belt and passenger's
front airbag warning lamp display, if the
driver and/or the front passenger has not
fastened their seat belt.
From approximately 12 mph (20 km/h)
this warning lamp fl ashes for two minutes
accompanied by an audible signal. Once
these two minutes have elapsed, this
warning lamp remains on until the driver
and/or the front passenger fastens their
seat belt.
Unfastening


)
Press the red button on the buckle.

)
Guide the seat belt as it rolls up.
SEAT BELTS


Front seat belts


The front seat belts are fi tted with a pre-
tensioning and force limiting system.
This system improves safety in the front
seats in the event of a front or side im-
pact. Depending on the severity of the
impact, the pretensioning system in-
stantly tightens the seat belts against
the body of the occupants.
The pretensioning seat belts are active
when the ignition is on.
The force limiter reduces the pressure
of the seat belt on the chest of the occu-
pant, so improving their protection.

8
105
SAFETY


1.
Front and/or rear seat belts not
fastened/unfastened warning lamp.

2.
Front left seat belt warning lamp.

3.
Front right seat belt warning lamp.

4.
Rear right seat belt warning lamp.

5.
Rear centre seat belt warning lamp.

6.
Rear left seat belt warning lamp.
Seat belt not fastened/unfastened
warning lamp display
Rear seat belts
The rear seats are each fi tted with a
three-point inertia reel seat belt with
force limiter (with the exception of the
rear centre seat).

Locking

When the rear side side belts are not being
used, you can lock them in place. To do so:


)
Raise the grip A
to its maximum
height.

Fastening


)
Pull the strap, then insert the tongue
in the buckle.

)
Check that the seat belt is fastened
correctly by pulling the strap.


Seat belt unfastened warning lamp
display
When the ignition is switched on, the corre-
sponding warning lamps 4
, 5
and 6
come
on in red for approximately 30 seconds, if
the seat belt is not fastened.
When the engine is running or the vehicle
is moving, the corresponding warning
lamp 4
, 5
or 6
comes on in red, accompa-
nied by an audible signal and a message
on the multifunction screen, if a rear pas-
senger has unfastened their seat belt.

Unfastening


)
Press the red button on the buckle.

)
Guide the seat belt as it rolls up.

The corresponding warning lamp 2
or 3

comes on in red on the seat belt and
passenger's front airbag warning lamp
display if the seat belt is not fastened or
is unfastened.

Seat belt unfastened warning lamp

This warning lamp comes on, either
on the instrument panel or on the
seat belt and passenger's front airbag
warning lamp display, when one or
more rear passengers unfasten their seat belt.
From approximately 12 mph (20 km/h),
this warning lamp fl ashes for two minutes
accompanied by an audible signal of in-
creasing volume. Once these two minutes
have elapsed, this warning lamp remains
on until the one or more rear passengers
fasten their seat belt.

8
SAFETY

2 nd row rear centre seat belt


Installation
Removal and storing


)
Press the red button on the buckle B
,
then on the buckle A
.

)
Guide the strap as it rolls up and
bring the tongue B
, then A
onto the
magnet of the attachment point on
the roof.




)

Pull the strap and insert the tongue A

in the left-hand buckle.

)
Insert the tongue B
in the right-hand
buckle.

)
Check the fastening of each buckle
by pulling the strap.
The seat belt for the rear centre seat of
the 2 nd row is incorporated at the rear
left of the roof.
