PRACTICAL INFORMATION

Engine compartment fusebox

The fusebox is located in the engine
compartment near the battery (left-hand
side).

All work on the fuses in the fuse-
box located on the battery must
be carried out by a CITROËN
dealer or a qualifi ed workshop.
Access to the fuses


)
Unclip the cover.

)
Change the fuse (see corresponding
paragraph).

)
When you have fi nished, close the
cover carefully to ensure correct
sealing of the fusebox.

11
PRACTICAL INFORMATION

Fuse table


Fuse N°



Rating


Functions



F1



20 A

Engine control unit supply, cooling fan unit control
relay, multifunction engine control main relay,
injection pump (Diesel).


F2



15 A

Horn.


F3



10 A

Front/rear wash-wipe.


F4



20 A

Daytime running lamps.


F5



15 A

Diesel heater (Diesel), particle fi lter additive pump
(Diesel), air fl ow sensor (Diesel), fuel pump (1.1i
and 1.4i), blow-by heater and electrovalves (VTi).


F6



10 A

ABS/ESP control unit, secondary brake lamp
switch.


F7



10 A

Electric power steering, automatic gearbox.


F8



25 A

Starter motor control.


F9



10 A

Switching and protection unit (Diesel).


F10



30 A

Fuel heater (Diesel), blow-by heater (1.1i, 1.4i and
Diesel), fuel pump (VTi), injectors and ignition coils
(petrol), electronic thermostat and canister purge
electrovalve (1.1i and 1.4i).


F11



40 A

Heater blower.

11
PRACTICAL INFORMATION

Table of maxi-fuses


Fuse N°



Rating


Functions



MF1 *



60 A

Fan assembly.


MF2 *



30 A

ABS/ESP pump.


MF3 *



30 A

ABS/ESP electrovalves.


MF4 *



60 A

Built-in Systems Interface (BSI) supply.


MF5 *



60 A

Built-in Systems Interface (BSI) supply.


MF6 *



-

Not used.


MF7 *



80 A

Dashboard fusebox.


MF8 *



-

Not used.

*
The maxi-fuses provide additional protection for the electrical systems. All work on the maxi-fuses must be carried out by a
CITROËN dealer or a qualifi ed workshop.

11
PRACTICAL INFORMATION

*
To avoid any risk of jamming of the
pedals:

-
ensure that the mat is positioned and
secured correctly,

-
never fi t one mat on top of another.

ACCESSORIES

They are all adapted to your vehicle and
benefi t from CITROËN's recommenda-
tion and warranty.

"Comfort"

sun blinds, door defl ectors, isotherm
module, smoking kit, fragrance cartridg-
es, front centre armrest, moveable mirror,
reading lamp...
"Style":

leather steering wheel, gear lever knobs,
front spoiler, rear diffuser, bumper trims,
front foglamp trims, parking brake lever
trims, aluminium footrest, alloy wheels,
wheel trims, chrome tailgate fi nisher,
chrome tailpipe fi nisher, chrome mirror
shells, chrome door handles... A wide range of accessories and genu-
ine parts is available from the CITROËN
dealer network.
These accessories and parts have been
tested and approved for reliability and
safety.


Conversion kits
You can obtain an "Enterprise" kit to
convert a trade vehicle to a private car
and vice-versa.

"Transport solutions":

child seats and booster cushions, boot
tray, boot carpet, boot net, boot contain-
ers, transverse roof bars, bicycle carrier,
ski carrier, roof boxes, towbars, towbar
wiring harnesses...
"Safety":

anti-theft alarm, wheel security bolts,
stolen vehicle tracking system, breath-
alyser, fi rst aid kit, warning triangle, high
visibility vest, dog guard, snow chains,
non-slip covers, foglamps kit, parking
sensors, bumper protection strips (trans-
lucent, gloss black, chrome fi nish)...

"Protection" :

mats * , mudfl aps, seat covers, door sill
protectors... If a towbar and wiring are fi tted
outside the CITROËN dealer
network, this must be done
making use of the vehicle's
electrical pre-equipment and
following the manufacturer's
recommendations.

11
166
PRACTICAL INFORMATION

Depending on the legislation in
force in the country, it may be
compulsory to have a high vis-
ibility safety vest, warning trian-
gle and spare bulbs and fuses
available in the vehicle.
The fi tting of electrical equipment
or accessories which are not rec-
ommended by CITROËN may
result in a failure of your vehicle's
electronic system and excessive
electrical consumption.
Please note this precaution.
You are advised to contact a
CITROËN representative to be
shown the range of recommend-
ed equipment and accessories.

Installation of radio
communication transmitters
Before installing any after-
market radio communication
transmitter, you can contact a
CITROËN dealer for the speci-
fi cation of transmitters which
can be fi tted (frequency, maxi-
mum power, aerial position,
specifi c installation require-
ments), in line with the Vehicle
Electromagnetic Compatibility
Directive (2004/104/EC).


"Multimedia":

Bluetooth
® hands-free system, audio
equipment, portable satellite navigation
system, semi-integral portable navigation
system carrier, speed camera warning,
DVD player, auxiliary cable for connect-
ing a portable MP3 player, USB Box, Hi-
Fi module, speakers, Wi-Fi on board... By going to a CITROËN dealer, you
can also obtain cleaning and mainte-
nance products (interior and exterior) -
including ecological products in the
"TECHNATURE" range - products for
topping up (screenwash fl uid...), touch
up pens and paint aerosols for the exact
colour of your vehicle, recharges (car-
tridge for the temporary puncture repair
kit...), ...

237
VISUAL SEARCH
Instrument panels ................. 23-24
Warning lamps ...................... 25-34
Indicators .............................. 35-37
Adjustment buttons ............... 38-39


- trip distance recorder/clock

- lighting dimmer/black panel

INSTRUMENTS AND CONTROLS

Lighting controls ................... 77-80
Headlamp adjustment................ 80
Stop & Start ...................... 119-121
Speed limiter..................... 123-124
Cruise control ................... 125-126
Dashboard fuses .............. 151-153
Opening the bonnet ................. 130 Rear view mirror ........................ 63
Zenith windscreen blind ............... 6
Sun visor.................................... 87

Wiper controls....................... 81-83
Trip computer ....................... 40-42
Audio system .................... 213-234
Setting the date/time................ 227
MyWay .............................. 181-212
Setting the date/time................ 204
Emergency or assistance call .... 179
Ventilation/Heating................ 50-54
Manual air conditioning......... 52-54
Digital air conditioning .......... 55-56
Demisting - Defrosting
(rear screen) ........................ 57

Interior mood lighting ................. 85
Steering wheel adjustment ........ 63
Horn ......................................... 101 Scented air freshener ................ 58
Multifunction screens ............ 43-49
Hazard warning lamps ............. 101
Manual gearbox ........................110
Gear shift indicator ................... 111
Electronic gearbox ............. 112-115
Automatic gearbox............. 116-118
Parking brake ...........................110 Door mirrors ............................... 62
Electric windows ................... 68-69

240
ALPHABETICAL INDEX
G G.P.S. ......................................... 187
Gearbox, automatic ............ 116, 135
Gearbox, electronic .... 112, 119, 135
Gearbox,
manual ............. 110, 111, 119, 135
Gear efficiency indicator ............. 111
Gear lever .................................... 21
Gear lever, automatic gearbox ... 116
Gear lever, electronic
gearbox system ................ 112, 135
Gear lever, manual gearbox ....... 110
Glove box ..................................... 87
Guidance .................................... 187
H Halogen headlamps ................... 145
Hands-free kit ............. 201, 202, 223
Hazard warning lamps ............... 101
Head restraints, front .................... 60
Head restraints, rear .................... 61
Heated seats ................................ 60
Heating ................................... 52, 55
Height and reach adjustment,
steering wheel ............................ 63
Hill start assist ............................ 122
Hooks ........................................... 91
Horn ........................................... 101
I Indicators, direction .... 101, 146, 148
Inflating accessories
(using the kit) ............................ 140
Inflating tyres ........................ 21, 177
Inputs for audio
system ................ 88, 200, 220, 222
Installing speakers ..................... 164 E Electronic brake force distribution
(EBFD) ..................................... 102
Electronic engine
immobiliser ........................... 65, 67
Emergency boot release .............. 73
Emergency braking system ........ 102
Emergency call ................... 102, 180
Emergency warning lamps ......... 101
Energy economy mode .............. 160
Engine, Diesel .............. 75, 132, 172
Engine, petrol ............... 75, 131, 167
Engine compartment .......... 131, 132
Engine compartment fusebox .... 154
Engine oil level indicator ...... 37, 133
Engines ...................... 167, 170, 172
Environment .................... 21, 51, 57,
67, 118, 134
ESP/ASR .................................... 103
F Filling with fuel .........................74-76
Fitting a wheel ............................ 144
Fittings, boot ................................. 90
Fitting speakers .......................... 164
Flashing indicators ..................... 101
Foglamps, front .................... 78, 147
Foglamps, rear ..................... 78, 148
Fragrance cartridge ...................... 58
Front seats ................................... 59
Fuel ........................................ 21, 75
Fuel consumption ......................... 21
Fuel filler flap .......................... 74, 76
Fuel gauge ................. 15, 23, 24, 74
Fuel tank ................................ 74, 76
Fusebox, dashboard .................. 152
Fuses ......................................... 151I Instrument panel lighting .............. 39
Instrument panels ................... 23, 24
Instrument panel
screen .................................. 23, 24
Interior fittings ......................... 86, 87
Interior lamp ......................... 84, 150
Interior mood lighting .................... 85
ISOFIX child seats ..................98-99
ISOFIX mountings .................. 97, 99
J Jack ............................................ 141
JACK socket ......... 88, 200, 220, 222
K Keeping children
safe .....................92-100, 105, 107
Key in ignition warning ................. 65
Key with remote control ...........64-67
L Labels, identification ................... 177
Lamps, warning and
indicator .................................25-34
Level, brake fluid ........................ 133
Levels and checks ...............131-135
Lighting, guide-me home ........ 79, 80
Lighting, interior .............. 84, 85, 150
Lighting bulbs
(replacement) ....................145-150
Lighting control stalk .................... 77
Lighting dimmer ............................ 39
Loading ........................................ 21
Load reduction mode ................. 159
Localised assistance call .... 102, 180
Localised emergency call ..... 102, 180

242
ALPHABETICAL INDEX
S Stability control (ESP) ................ 103
Starting the vehicle ....... 65, 112, 116
Steering mounted controls,
audio ........................................ 215
Stopping the vehicle ..... 65, 112, 116
Stop & Start ............. 42, 57, 74, 119,
130, 134, 158
Storage ................................... 86, 87
Storage box .................................. 91
Storage drawer ............................. 89
Stowing rings ................................ 90
Sun visor ...................................... 87
Synchronising the remote
control ........................................ 66
System, navigation ..................... 187
Systems, ASR and ESP ............. 103
T Table of weights ......... 168, 171, 174
Tables of engines ....... 167, 170, 172
Tables of fuses ........................... 151
Tank, fuel ............................... 74, 76
Technical data ............ 167, 170, 172
Telephone .......................... 201, 202
Temperature adjustment .............. 55
Temperature control for heated
seats ........................................... 60
Temporary tyre repair kit ............ 136
Third brake lamp ........................ 149
Time ..................... 38, 204, 226, 227
TMC (Traffic info) ....................... 195
Tools .......................................... 141
Total distance recorder ................ 38
Towbar ....................................... 163
Towed loads ............... 168, 171, 174
Towing another vehicle .............. 162T Traction control (ASR) ................ 103
Traffic information
(TA) .................................. 196, 218
Traffic information
(TMC) ............................... 195, 196
Trip computer ....................40-42, 45
Trip distance recorder .................. 38
Tyre pressures ........................... 177
Tyres ............................................ 21
U Unlocking ..................................... 64
Unlocking from the inside ............. 71
Update risk areas ....................... 194
Updating the date ....... 204, 226, 227
Updating
the time .............. 38, 204, 226, 227
USB Box ............................... 88, 220
USB player ........................... 88, 220
V Ventilation ...............................50-52
W Warning lamps ........................25-34
Wash-wipe, rear ........................... 82
Weights ...................... 168, 171, 174
Window controls ........................... 68
Wiper, rear ................................... 82
Wiper control stalk ...................81-83
Wipers .....................................81-83
Z Zenith windscreen .......................... 6
