Black plate (103,1)Cadillac CTS/CTS-V Owner Manual (Include Mex) - 2012
Vehicle Care 10-103
Compact Spare Tire
{WARNING
Driving with more than one
compact spare tire at a time could
result in loss of braking and
handling. This could lead to a
crash and you or others could be
injured. Use only one compact
spare tire at a time.
If your vehicle is equipped with a
compact spare tire it was fully
inflated when the vehicle was new, it
can lose air after a time. Check the
inflation pressure regularly. It should
be 420 kPa (60 psi). After installing the compact spare
on the vehicle, stop as soon as
possible and make sure the spare
tire is correctly inflated. The
compact spare is made to perform
well at speeds up to 105 km/h
(65 mph) for distances up to
5 000 km (3,000 mi), so you can
finish your trip and have the full-size
tire repaired or replaced at your
convenience. Of course, it is best to
replace the spare with a full-size tire
as soon as possible. The spare tire
will last longer and be in good
shape in case it is needed again.
Notice:
When the compact spare
is installed, do not take the
vehicle through an automatic
car wash with guide rails. The
compact spare can get caught on
the rails which can damage the
tire, wheel, and other parts of the
vehicle.
Do not use the compact spare on
other vehicles.
And do not mix the compact spare
tire or wheel with other wheels or
tires. They will not fit. Keep the
spare tire and its wheel together.
Notice: Tire chains will not fit the
compact spare. Using them can
damage the vehicle and can
damage the chains too. Do not
use tire chains on the compact
spare.

Black plate (7,1)Cadillac CTS/CTS-V Owner Manual (Include Mex) - 2012
Service and Maintenance 11-7
Footnotes—Maintenance
Schedule Additional Required
Services —Normal
a) Vehicles with different size front
and rear tires do not have tire
rotation. See Tire Rotation on
page 10‑77.
b) Or every two years, whichever
comes first. More frequent
replacement may be needed if the
vehicle is driven in areas with heavy
traffic, areas with poor air quality, or
areas with high dust levels.
Replacement may also be needed if
there is a reduction in air flow,
excessive window fogging, or odors,
c) Check all fuel and vapor lines
and hoses for proper hook‐up,
routing, and condition. Check that
the purge valve, if the vehicle has
one, works properly. Replace as
needed. d)
Or every four years, whichever
comes first.
e) Do not directly power wash the
transfer case output seals. High
pressure water can overcome the
seals and contaminate the transfer
case fluid. Contaminated fluid will
decrease the life of the transfer
case and should be replaced.
f) Or every five years, whichever
comes first. See Cooling System on
page 10‑18.
g) Or every 10 years, whichever
comes first. Inspect for fraying,
excessive cracking, or damage;
replace, if needed.
h) Inspect for fraying, excessive
cracking, or damage; replace,
if needed.

Black plate (9,1)Cadillac CTS/CTS-V Owner Manual (Include Mex) - 2012
Service and Maintenance 11-9
Footnotes—Maintenance
Schedule Additional Required
Services —Severe
a) Vehicles with different size front
and rear tires do not have tire
rotation. See Tire Rotation on
page 10‑77.
b) Or every two years, whichever
comes first. More frequent
replacement may be needed if the
vehicle is driven in areas with heavy
traffic, areas with poor air quality, or
areas with high dust levels.
Replacement may also be needed if
there is a reduction in air flow,
excessive window fogging, or odors,
c) Check all fuel and vapor lines
and hoses for proper hook‐up,
routing, and condition. Check that
the purge valve, if the vehicle has
one, works properly. Replace as
needed. d)
Or every four years, whichever
comes first.
e) Do not directly power wash the
transfer case output seals. High
pressure water can overcome the
seals and contaminate the transfer
case fluid. Contaminated fluid will
decrease the life of the transfer
case and should be replaced.
f) Or every five years, whichever
comes first. See Cooling System on
page 10‑18.
g) Or every 10 years, whichever
comes first. Inspect for fraying,
excessive cracking, or damage;
replace, if needed.
h) Inspect for fraying, excessive
cracking, or damage; replace,
if needed.Special Application
Services
.Vehicles with manual
transmissions: Every two years
drain, flush, and fill clutch
hydraulic system.
.Severe Commercial Use
Vehicles Only: Lubricate chassis
components every 5 000 km/
3,000 mi.
.Have underbody flushing service
performed once a year.

Black plate (12,1)Cadillac CTS/CTS-V Owner Manual (Include Mex) - 2012
i-12 INDEX
Shift Lock Control FunctionCheck, Automatic
Transmission . . . . . . . . . . . . . . . . 10-31
Shifting Into Park . . . . . . . . . . . . . . . . . . . . . . 9-23
Out of Park . . . . . . . . . . . . . . . . . . . 9-24
Side Blind Zone Alert . . . . . . . . . . 9-45
Signals, Turn and
Lane-Change . . . . . . . . . . . . . . . . . 6-5
Spare Tire Compact . . . . . . . . . . . . . . . . . . . 10-103
Specifications and Capacities . . . . . . . . . . . . . . . . . . . . 12-2
Speed Limiter, Engine . . . . . . . . . 5-14
Speedometer . . . . . . . . . . . . . . . . . . 5-13
StabiliTrak OFF Light . . . . . . . . . . . . . . . . . . . . . 5-23
System . . . . . . . . . . . . . . . . . . . . . . . 9-39
Start Vehicle, Remote . . . . . . . . . 2-12
Starter Switch Check . . . . . . . . . 10-30
Starting the Engine . . . . . . . 1-4, 9-20 Steering . . . . . . . . . . . . . . . . . . . . . . . . 9-4
Fluid, Power . . . . . . . . . . . . . . . . 10-24
Heated Wheel . . . . . . . . . . . . . . . . . 5-4
Wheel Adjustment . . . . . . . . . . . . . 5-2
Wheel Controls . . . . . . . . . . . . . . . . 5-3
Storage Areas Cargo Cover . . . . . . . . . . . . . . . . . . . 4-2
Cargo Management System . . . 4-3
Center Console . . . . . . . . . . . . . . . . 4-2
Convenience Net . . . . . . . . . . . . . . 4-6
Glove Box . . . . . . . . . . . . . . . . . . . . . 4-1
Instrument Panel . . . . . . . . . . . . . . 4-1
Roof Rack System . . . . . . . . . . . . . 4-6
Storing the Tire Sealant and
Compressor Kit . . . . . .10-93, 10-94
Stuck Vehicle . . . . . . . . . . . . . . . . . . 9-11
Sun Visors . . . . . . . . . . . . . . . . . . . . . 2-32
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . 2-32
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . iv
System Infotainment . . . . . . . . . . . . . . . . . . . 7-1
Roof Rack . . . . . . . . . . . . . . . . . . . . . 4-6T
Tachometer . . . . . . . . . . . . . . . . . . . . 5-13
Text Telephone (TTY) Users . . . 13-6
Theft-DeterrentSystems . . . . . . . . . . . . . . . 2-25, 2-26
Immobilizer . . . . . . . . . . . . . . . . . . . 2-25
Thigh Support Adjustment . . . . . . 3-6
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Tires
Buying New Tires . . . . . . . . . . . 10-79
Chains . . . . . . . . . . . . . . . . . . . . . . 10-83
Changing . . . . . . . . . . . . . . . . . . . 10-95
Compact Spare . . . . . . . . . . . . 10-103
Designations . . . . . . . . . . . . . . . 10-67
Different Size . . . . . . . . . . . . . . . 10-80
If a Tire Goes Flat . . . . . . . . . . 10-84
Inflation Monitor System . . . . 10-73
Inspection . . . . . . . . . . . . . . . . . . 10-76
Low Profile . . . . . . . . . . . . . . . . . 10-64
Messages . . . . . . . . . . . . . . . . . . . . 5-43
Pressure . . . . . . . . . . . . . . . . . . . . 10-72
Pressure Light . . . . . . . . . . . . . . . . 5-25
Pressure Monitor System . . . 10-72
Rotation . . . . . . . . . . . . . . . . . . . . 10-77
Sealant andCompressor Kit . . . . . . . . . . . 10-86

Black plate (14,1)Cadillac CTS/CTS-V Owner Manual (Include Mex) - 2012
i-14 INDEX
Vehicle CareStoring the Tire
Sealant and
Compressor Kit . . . . 10-93, 10-94
Tire Pressure . . . . . . . . . . . . . . . 10-70
Vehicle Identification Service Parts Identification
Label . . . . . . . . . . . . . . . . . . . . . . . . 12-1
Ventilation, Air . . . . . . . . . . . . . . . . . . 8-6
Visors . . . . . . . . . . . . . . . . . . . . . . . . . 2-32W
Warning Brake System Light . . . . . . . . . . . 5-22
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . 5-10
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . iv Cautions and Danger . . . . . . . . . . . .iv
Hazard Flashers . . . . . . . . . . . . . . . 6-5
Washer Fluid . . . . . . . . . . . . . . . . . 10-25
Washer Fluid Messages . . . . . . . 5-45
Washer, Headlamps . . . . . . . . . . . . 5-7 Wheels
Alignment and Tire
Balance . . . . . . . . . . . . . . . . . . . 10-82
Different Size . . . . . . . . . . . . . . . 10-80
Replacement . . . . . . . . . . . . . . . 10-82
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 10-78
Where to Put the Restraint . . . . 3-41
Windows . . . . . . . . . . . . . . . . . . . . . . 2-29 Power . . . . . . . . . . . . . . . . . . . . . . . . 2-30
Windshield
Wiper/Washer . . . . . . . . . . . . . . . . . 5-4
Winter Driving . . . . . . . . . . . . . . . . . . . . . . . . . 9-9
Winter Tires . . . . . . . . . . . . . . . . . . 10-64
Wiper Blade Replacement . . . . 10-32
Wipers Rear Washer . . . . . . . . . . . . . . . . . . 5-6
