2012 Acura TL Trunk pass through

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations .62 ............................
Instrument Panel .63
..........
Instrument Panel Indicators . 64
.............................................
Gauges .76
..................................
Fuel Gauge .76
...................
Temperature Gauge . 77
.............
Multi-Inf ormation Display . 78
Controls Near the Steering .........................................
Wheel .136
Windshield Wipers and .....................................
Washers .137
.......
Turn Signals and Headlights . 139
Automatic Lighting Off ...................................
Feature .141
.........
Daytime Running Lights . 142
.....................................
Fog Lights .143
......
Instrument Panel Brightness . 143
...............
Hazard Warning Button . 145
...............
Rear Window Def ogger . 145
......
Steering Wheel Adjustments . 146
.............................
Keys and Locks .147
......................
Immobilizer System .149
..............................
Ignition Switch .151
....................................
Door Locks .152
............
Childproof Door Locks . 153
..............................................
Trunk .154
......
Emergency Trunk Opener . 156.....................
Remote Transmitter .157
...............................................
Seats .161
......
Trunk Pass-through Cover . 166
...........................................
Mirrors .167
Driving Position Memory ........................................
System .170
................
Keyless Access System . 173
...........
Keyless Access Remote . 179
........
Engine Start/Stop Button . 183
..................................
Seat Heaters .202
.....
Seat Heaters and Ventilations . 204
............................
Power Windows .206
.......................................
Moonroof .210
...............................
Parking Brake .212
.........
Interior Convenience Items . 213
.....................
Beverage Holders .214
........
Accessory Power Sockets . 215
..................................
Glove Box .216
.............
Console Compartment . 216
............................
Vanity Mirror .217
...................................
Sun Visor .217
...........................
Center Pocket .218
....................
Sunglasses Holder .218
..................................
Coat Hook .219
...............................
Interior Lights .220
Instruments and Controls
Inst rument s and Cont rols
61
11/01/14 18:04:29 31TK4630_066
2012 TL

Youshouldhavereceivedakey
number tag with your key. You will
need this key number if you ever
have to get a lost key replaced. Use
only an Acura-approved key blank.Donotdropthekeysorsetheavy
objects on them. Protect the key f rom direct
sunlight, high temperature, and
high humidity.
Keep the keys away f rom liquids.
If they get wet, dry them
immediately with a sof t cloth.
These keys contain electronic
circuits that are activated by the
immobilizer system. They will not
work to start the engine if the
circuits are damaged.
The valet key does not contain a
battery. Do not try to take it apart.
The valet key works only in the
ignition and the driver’s door lock.
You can keep the trunk pass-through
cover and the glove box locked when
you leave your vehicle and the valet
key at a parking f acility. The master key fits all the locks on
your vehicle.
CONT INUED
On models without keyless access
system
Keys and Locks
Inst rument s and Cont rols
147
VALET
KEY
(GRAY)
KEY
NUMBER
TAG MASTER KEY
WITH REMOTE
TRANSMITTER
11/01/14 18:18:53 31TK4630_152
2012 TL

If your vehicle’s battery goes dead or
is disconnected, you can open the
trunk f rom the rear seat by pulling
the trunk release tab through the
trunk pass-through.
To close the trunk, use the inner
handle to lower the lid, then press
down on the back edge. Pull down the rear seat armrest, then
press on the button to f ully release
the cover. Reach in and locate the
trunk release tab, and pull it out.
Keep the trunk lid closed at all times
while driving to avoid damaging it,
and to prevent exhaust gas from
getting into the interior. See
,page .57
CONT INUED
On all models
Trunk
Carbon
Monoxide Hazard
Inst rument s and Cont rols
155
INNER
HANDLE BUTTON
COVERTRUNK RELEASE TAB
11/01/14 18:20:23 31TK4630_160
2012 TL

To protect items in the trunk, you
can disable the trunk release button
on the driver’s door by turning off
the trunk main switch in the glove
box, locking the glove box, and
locking the trunk pass-through cover
with the master key or the
built-in key.If you need to give the key to
someone else, give them the
valet key.
As a saf ety f eature, your vehicle has
a release lever on the trunk latch so
the trunk can be opened f rom the
inside.
To open the trunk, push the release
lever in the direction indicated by
the arrow.
Parents should decide if their
children should be shown how to use
this f eature. For more inf ormation
about child saf ety, see page .
To use the valet f unction, remove
thebuilt-inkeyfromtheremoteby
pressing the button, then give that
remote to someone else as a valet
key(seepage ).
Your vehicle is equipped with the
emergency f uel lid release in the
trunk. Refer to page for how to
access it.
40
201
599
On models without keyless accesssystem
On models with keyless access system
Trunk
Emergency T runk Opener
Emergency Fuel L id Release
156
TRUNK RELEASE LEVER
TRUNK MAIN SWITCH
Vehicle with keyless access system is
shown.
11/01/14 18:20:34 31TK4630_161
Inst rument s and Cont rols
OFF
2012 TL

Make sure all items in the trunk and
those extending through the pass-
through are secured.Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving.Theinsidemirrorcanautomatically
darken to reduce glare. To turn on
this feature, press the button on the
bottom of the mirror. The AUTO
indicator comes on as a reminder.
When it is on, the mirror darkens
when it senses the headlights of a
vehicle behind you, then returns to
normal visibility when the lights are
gone. Press the button again to turn
of f this f eature.
For security, this cover can be
locked and unlocked only with the
master key(the built-in key on
models with keyless access system).
To lock the cover, insert the key, and
turn it clockwise.
Never drive with this cover open and
the trunk lid open.
See
on
page . 57
CONT INUED
Mirrors
Carbon Monoxide Hazard
Seats, Mirrors
Inst rument s and Cont rols
167
AUTO BUTTON SENSOR
INDICATOR
There is also a sensor on the back of
the mirror. Items hung on the mirror
may block this sensor and af f ect its
perf ormance.
11/01/14 18:22:41 31TK4630_172
2012 TL

The f ollowing keys come with your
vehicle. Refer to page for how to
separate the keys.
This key is used to lock/unlock the
doors, glove box, and trunk pass-
through cover.This remote is used to lock/unlock
the doors and unlock the trunk.
When you carry the remote, you can
lock/unlock the doors, unlock the
trunk, and start the engine.
Anyone can lock/unlock a door or
open the trunk if the remote is
within the operating range of the
door or the trunk. You can lock/unlock the doors
within about a 32 inch (about 80 cm)
radius f rom the outside door handle.
You can open the trunk within about
a 32 inch (about 80 cm) radius f rom
thetrunkreleaseswitch.
201
Keys
K eyless A ccess System
Built -in K ey
K eyless A ccess Remot e
174
BUILT-IN KEYS
OPERATING
RANGE
KEYLESS ACCESS
REMOTES
KEY NUMBER TAG
11/01/14 18:24:06 31TK4630_179
Inst rument s and Cont rols
2012 TL

The trunk and glove box cannot be
opened when you turn the trunk
main switch of f and lock the glove
box and trunk pass-through cover
with the built-in key. Then, the trunk
cannot be opened by using the
remote or the exterior trunk release
switch.
Remove the built-in key from the
remote by pressing the button, then
give that remote to someone else as
a valet key.
To avoid damaging the remote and
the built-in key, never pull on the
built-in key unless you are pressing
the release button.
The keyless access system uses an
electric f ield to identif y the remote.
If you use medical equipment such
as a cardiac pacemaker, ask your
doctor if the electric f ield used by
the remote will af f ect it.
Thebuilt-inkeycanbeusedtolock/
unlock the doors and the trunk when
the remote battery becomes weak
and the power door lock/unlock
operation is disabled.
To remove the built-in key, pull it out
while pressing the release button. To
reinstall the built-in key, push the
key into the remote until it clicks. Valet Function
Built-in key and Remote
K eyless A ccess System
Inst rument s and Cont rols
201
RELEASE BUTTON BUILT-IN KEY
11/01/14 18:29:12 31TK4630_206
2012 TL

With the system set, you can still
open the trunk with the remote
transmitter/keyless access remote
without triggering the alarm. The
alarm will sound if the trunk is
opened with the trunk release button
on the driver’s door, the trunk
release handle behind the trunk
pass-through cover, or the
emergency trunk opener.The security system does not set if
any door, the trunk, or hood is not
f ully closed. Bef ore you leave the
vehicle, make sure the doors, trunk
and hood are securely closed.
To see if the system sets af ter you
exit the vehicle, press the LOCK
button on the remote transmitter/
keyless access remote within f ive
seconds. If the system is set, the
horn will beep once.
Do not attempt to alter this system
or add other devices to it.
Security System
396
11/01/14 19:02:27 31TK4630_401
Features
2012 TL
