Unscrew and remove the engine oil
fill cap on top of the valve cover.
Pour in the oil slowly and caref ully so
you do not spill. Clean up any spills
immediately. Spilled oil could
damage components in the engine
compartment. Install the engine oil
f ill cap, and tighten it securely. Wait
a f ew minutes, and recheck the oil
level (see page ). Do not f ill
above the upper mark; you could
damage the engine.Oil is a major contributor to your
engine’s perf ormance and longevity.
Always use a premium-grade
detergent oil displaying the API
Certif ication Seal. This seal indicates
the oil is energy conserving, and that
it meets the American Petroleum
Institute’s latest requirements. It is
highly recommended that you use
Acura Motor Oil in your vehicle f or
optimum engine protection.
Make sure the API Certif ication Seal
says ‘‘For Gasoline Engines.’’
The oil viscosity or weight is
provided on the container’s label.
Acura Motor Oil is the pref erred
0W-20 lubricant f or your vehicle.
0W-20 oil is f ormulated f or year-
round protection of your vehicle to
improve cold weather starting and
f uel economy.
474
CONT INUED
Recommended Engine Oil 2WD models:
A dding Engine Oil
Maint enance
543
ENGINE OIL FILL CAP
Ambient Temperature
API CERTIFICATION SEAL
11/01/14 19:28:57 31TK4630_548
2012 TL

You may use a synthetic motor oil if
it meets the same requirements
given f or a conventional motor oil: it
displays the API Certif ication Seal
and it is the proper weight. You must
f ollow the oil and f ilter change
intervals shown on the multi-
inf ormation display.
Your vehicle does not require any oil
additives. Additives may adversely
af f ect the engine or transmission
perf ormance and durability.Always change the oil and f ilter
according to the maintenance
messages shown on the multi-
inf ormation display. The oil and f ilter
collect contaminants that can
damage your engine if they are not
removed regularly.
Changing the oil and filter requires
special tools and access from
underneath the vehicle. The vehicle
should be raised on a service station-
type hydraulic lift for this service.
Unless you have the knowledge and
proper equipment, you should have
this maintenance done by a skilled
technician.
Acura Motor Oil is the pref erred
5W-20 lubricant f or your vehicle. 5W-
20 oil is f ormulated f or year-round
protection of your vehicle to improve
cold weather starting and f uel
economy.
Synthetic Oil
Engine Oil A dditivesChanging the Engine
Oil and Filter
SH-AWD models:
A dding Engine Oil, Changing the Engine Oil and Filter
544
Ambient Temperature
11/01/14 19:29:07 31TK4630_549
Maint enance
2012 TL

Check the f luid level in the
windshield washer reservoir at least
monthly during normal use.If the washer f luid is low, a ‘‘LOW
WASHER FLUID’’ message appears
on the multi-information display.
Fill the reservoir with a good-quality
windshield washer f luid. This
increases the cleaning capability and
prevents f reezing in cold weather.
When you ref ill the reservoir, clean
the edges of the windshield wiper
blades with windshield washer f luid
on a clean cloth. This will help to
condition the blade edges.
To check washer f luid level, cover
the reservoir cap center hole with
your f inger while lif ting the cap and
the attached measuring tube. The
washer f luid level in the tube will
indicate the washer f luid level in the
reservoir.
On U.S. models On Canadian models
Windshield Washers
548
TUBE
Do not use engine antif reeze or a
vinegar/water solution in the
windshield washer reservoir. Antif reeze
can damage your vehicle’s paint, while
a vinegar/water solution can damage
the windshield washer pump. Use only
commercially-available windshield
washer f luid.
11/01/14 19:29:55 31TK4630_553
Maint enance
2012 TL

The f luid level should be between
theMINandMAXmarksontheside
of the reservoir. If the level is at or
below the MIN mark, your brake
system needs attention. Have the
brake system inspected f or leaks or
worn brake pads.
You need to remove the lef t engine
compartment cover to check the
f luid level (see page ).
Check the f luid level in the
reservoirs monthly. There are up to
two reservoirs, depending on the
model. They are:
Brake f luid reservoir (all models)
Clutch f luid reservoir
(manual transmission models
only)
To access the reservoirs, remove the
lef t engine compartment cover (see
page ).
You will also see a ‘‘LOW BRAKE
FLUID’’ message on the multi-
inf ormation display. Always use Honda Heavy Duty
Brake Fluid DOT 3. If it is not
available, you should use only DOT 3
or DOT 4 f luid, f rom a sealed
container, as a temporary
replacement.
Brake f luid marked DOT 5 is not
compatible with your vehicle’s
braking system and can cause
extensive damage. Using any non-Honda brake f luid can
cause corrosion and decrease the lif e
of the system. Have the brake
system f lushed and ref illed with
Honda Heavy Duty Brake Fluid
DOT 3 as soon as possible.
Independent of the Maintenance
Minder inf ormation, replace the
brake f luid every 3 years. 542
542
Brake and Clutch Fluid
Brake Fluid
Maint enance
553
MAX
MIN
11/01/14 19:30:47 31TK4630_558
2012 TL

This f ilter removes the dust and
pollenthatisbroughtinfromthe
outside through the climate control
system.
Have your dealer replace the filter
when this service is indicated by a
maintenance message on the multi-
inf ormation display. It should be
replaced every 15,000 miles (24,000
km) if you drive primarily in urban
areas that have high concentrations
of soot in the air, or if the f low f rom
theclimatecontrolsystembecomes
less than usual.Check the condition of the wiper
blades at least every 6 months.
Replace them if you f ind signs of
cracking in the rubber, areas that are
getting hard, or if they leave streaks
and unwiped areas when used.
To replace a wiper blade:
Raise each wiper arm of f the
windshield, lif ting the driver’s side
first, then the passenger’s side.
1.
Dust and Pollen Filter
Wiper Blades
Exterior Care
Dust and Pollen Filter, Exterior Care, Wiper Blades
566
Do not open the hood when the wiper
arms are raised, or you will damage the
hood and wiper arms.
Chemical solvents and strong cleaners
can damage the paint, metal, and
plastic on your vehicle.
11/01/14 19:33:12 31TK4630_571
Maint enance
2012 TL

CONT INUED
Replace your tires with radial tires of
the same size, load range, speed
rating, and maximum cold tire
pressure rating (as shown on the
tire’s sidewall).
Mixing radial and bias-ply tires on
your vehicle can reduce braking
ability, traction, and steering
accuracy. Using tires of a dif f erent
size or construction can cause the
ABS and vehicle stability assist
system (VSA) to work inconsistently.
The ABS and VSA system work by
comparing the speed of each wheel.
When replacing tires, use the same
size originally supplied with the
vehicle. Tire size and construction
can af f ect wheel speed and may
cause the system to activate.
To help increase tire lif e and
distribute wear more evenly, rotate
the tires according to the
maintenance messages displayed on
the multi-information display. Move
the tires to the positions shown in
the illustration each time they are
rotated. If you purchase directional
tires, rotate only front-to-back.
When the tires are rotated, make
sure the air pressures are checked.
In addition to proper inf lation,
correct wheel alignment helps to
decrease tire wear. If you f ind a tire
is worn unevenly, have your dealer
check the wheel alignment.
Have your dealer check the tires if
you f eel a consistent vibration while
driving. A tire should always be
rebalanced if it is removed f rom the
wheel. When you have new tires
installed, make sure they are
balanced. This increases riding
comf ort and tire lif e. For best results,
have the installer perform a dynamic
balance.
Tires
Replacing T ires and Wheels
Tire Rotation
T ire Maintenance
Maint enance
573
Front Front
(For Non-directional
Tires and Wheels) (For Directional
Tires and Wheels)
Improper wheel weights can damage
your vehicle’s aluminum wheels. Use
only Acura wheel weights f or balancing.
11/01/14 19:34:34 31TK4630_578
2012 TL

µ
If you need to connect the battery to
a charger, disconnect both cables to
prevent damaging your vehicle’s
electrical system. Always disconnect
the negative ( ) cable first, and
reconnect it last.
Check the terminals f or corrosion (a
white or yellowish powder) af ter
removing all engine compartment
covers (see page ). To remove
corrosion, cover the terminals with a
solution of baking soda and water. It
will bubble up and turn brown. When
this stops, wash it of f with plain
water. Dry off the battery with a
cloth or paper towel. Coat the
terminals with grease to help prevent
f urther corrosion.
If additional battery maintenance is
needed, see your Acura dealer or a
qualif ied technician.
Battery posts,
terminals, and related accessories
contain lead and lead compounds.
The sensor on the negative terminal
monitors your vehicle’s battery
condition.
If there is a problem with the sensor,
you will see a ‘‘CHECK BATTERY
SENSOR’’ message on the multi-
inf ormation display. Have the vehicle
checked by your dealer.
To see the battery label, remove the
lef t side engine compartment cover
(see page ).
542 542
CONT INUED
Checking the Battery
WARNING:
Wash your hands af ter handling.
Maint enance
577
The battery gives off explosive
hydrogen gas during normal
operation.
A spark or flame can cause the
battery to explode with enough
force to kill or seriously hurt you.
Wear protective clothing and a
face shield, or have a skilled
technician do the battery
maintenance.
11/01/14 19:35:18 31TK4630_582
2012 TL

Block the rear wheels.
If the vehicle is to be stored f or a
longer period, it should be
supported on jackstands so the
tires are of f the ground.
Leave one window open slightly (if
the vehicle is being stored
indoors).
Disconnect the battery.
Support the f ront wiper blade
arms with a f olded towel or rag so
they do not touch the windshield.
To minimize sticking, apply a
silicone spray lubricant to all door
and trunk seals. Also, apply a
vehiclebodywaxtothepainted
surfaces that mate with the door
and trunk seals.
If you need to park your vehicle f or
an extended period (more than 1
month), there are several things you
should do to prepare it f or storage.
Proper preparation helps prevent
deterioration and makes it easier to
get your vehicle back on the road. If
possible, store your vehicle indoors.
Leave the parking brake off. Put
the transmission in reverse
(manual) or Park (automatic). Cleantheinterior.Makesurethe
carpeting, floor mats, etc., are
completely dry. Wash and dry the exterior
completely. Fill the f uel tank.
If your vehicle’s battery is
disconnected or goes dead, the audio
system may disable itself . The next
timeyouturnontheradio,youwill
see ‘‘ENTER CODE’’ in the
frequency display. Use the preset
buttons to enter the code (see
).
If your vehicle’s battery is
disconnected, or goes dead, the time
setting may be lost. To reset the time,
see page .
The navigation system will also
disableitself.Thenexttimeyouset
to the ON mode, the system will
require you to enter a PIN bef ore it
can be used. Ref er to the navigation
system manual. 391On models without navigation system
On models with navigation system
Checking the Battery, Vehicle Storage
Vehicle Storage
578
11/01/14 19:35:33 31TK4630_583
Maint enancepage 390
2012 TL
