2012 ACURA RL display

(f luid capacities and tire pressures) (main controls)
(seat belts, SRS, and child protection)
(indicators, gauges, multi-inf ormation display, dashboard, and steering column)
()
(fuel, vehicle break-in, and cargo loading)
(engine and transmission operation)
(minders, f luid checking, minor services, and vehicle storage)
(vehicle specif ications, tires, and emissions controls)
(warranty and contact inf ormation)
(how to order) (f lat tire, jump starting, overheating, and f uses)
climate control, audio, steering wheel, security, cruise control, HomeLink, and other convenience items
Contents
................................................................................................................................................ Index.I
.................................................. Service Inf ormation Summary. last page ............................................................................................... Your Vehicle at a Glance.4
............................................................ Driver and Passenger Saf ety.7
....... Instruments and Controls.59
.............. Features. 203
....................................................................... Bef ore Driving. 381
......................................................................................... Driving. 399
............................................... Maintenance. 443
............................................. T echnical Inf ormation. 523
....................... Warranty and Client Relations (U.S. and Canada only) . 539
.................................................................................. A uthorized Manuals (U.S. only). 543 ........................................ T aking Care of the Unexpected. 495INDEX
1
11/07/20 17:59:32 31SJA670_006
ProCarManuals.com

A convenient ref erence to the
sections in this manual.
A quick ref erence to the main
controls in your vehicle.What gasoline to use, how to break-
in your new vehicle, and how to load
luggage and other cargo.
The proper way to start the engine,
shif t the transmission, and park; plus
what you need to know if you’re
planning to tow a trailer.ID numbers, dimensions, capacities,
and technical information.
The Maintenance Minder shows
you when you need to take your
vehicle to the dealer for maintenance
service. There is also a list of things
to check and instructions on how to
check them.
This section covers several problems
motorists sometimes experience,
and details how to handle them. Important inf ormation about the
proper use and care of your vehicle’s
seat belts, an overview of the
supplemental restraint system, and
valuable inf ormation on how to
protect children with child restraints.A summary of the warranties
covering your new vehicle, and how
to contact us for any reason. Refer to
your warranty manual f or detailed
inf ormation.
How to order manuals and other
technical literature.
A summary of the inf ormation you
need when you pull up to the f uel
pump. Explains the purpose of each
instrument panel indicator and gauge,
the multi-information display, and
how to use the controls on the
dashboard and steering column.
How to operate the climate control
system, the audio system, and other
convenience f eatures.
Overview of Contents
Your Vehicle at a Glance
Driver and Passenger Saf ety
Instruments and ControlsBef ore Driving
Driving
MaintenanceT echnical Inf ormation Contents
T aking Care of the UnexpectedWarranty and Client Relations
(U.S. and Canada only)
Authorized Manuals
(U.S. only)
Index
Service Inf ormation Summary
Features
3
TM
11/07/20 17:59:50 31SJA670_008
ProCarManuals.com

µ The f ollowing pages provide
instructions on how to properly
protect the driver, adult
passengers, and teenage children
who are large enough and mature
enough to drive or ride in the f ront.
See pages f or important
guidelines on how to properly
protect inf ants, small children, and
larger children who ride in your
vehicle.
Af ter everyone has entered the
vehicle, be sure the doors are
closed and locked.Your vehicle has a door and trunk
open indicators on the multi-
inf ormation display to indicate when
a specif ic door or the trunk is not
tightly closed. You will see the
appropriate indicator(s) and the
message f or each condition.
When one or more doors are not
tightly closed, the ‘‘DOOR OPEN’’
indicator will come on.
Your vehicle has a programmable
auto door locking/unlocking f eature.
For more inf ormation, see page .You will also hear a beep when you
turn the ignition switch to the ON
(II) position, and each time you open
any door or the trunk with the key in
the ON (II) position. 38
123 55
CONT INUED
Introduction
Close and L ock the Doors 1.
Protecting A dults and Teens
Driver and Passenger Saf ety
13
This shows the front right and rear left
doors open.
11/07/20 18:01:06 31SJA670_018
ProCarManuals.com

CONT INUED
Your seat belt system includes lap/
shoulder belts in all seating positions.
The f ront seat belts are also
equipped with automatic seat belt
tensioners and, on models with
collision mitigation braking system
(CMBS ), seat belt e-pretensioners.The seat belt system
includes an indicator on the
instrument panel and a beeper to
remind you and your passengers to
f asten your seat belts.
This system monitors the f ront seat
belts. If you turn the ignition switch
to the ON (II) position bef ore your
seat belt is f astened, the beeper will
sound and the indicator will f lash. If
your seat belt is not f astened bef ore
the beeper stops, the indicator will
stop f lashing but remain on.
If a f ront passenger does not f asten
their seat belt, the indicator will
come on about 6 seconds af ter the
ignition switch is turned to the ON
(II) position.You will also see a ‘‘FASTEN SEAT
BELT’’ or ‘‘FASTEN PASSENGER
SEAT BELT’’ message on the multi-
inf ormation display (see page ).
When no one is sitting in the f ront
passenger’s seat, or a child or small
adult is riding there, the indicator
should not come on and the beeper
should not sound. If either the driver or a f ront
passenger does not f asten their seat
belt while driving, the beeper will
sound and the indicator will f lash
again at regular intervals.
62 Seat Belt System Components
Additional Inf ormation About Your Seat Belts
Driver and Passenger Saf ety
21
TM
TM
11/07/20 18:02:05 31SJA670_026
ProCarManuals.com

If the impact is on the passenger’s
side, the passenger’s side curtain
airbag will inflate even if there are no
occupants on that side of the vehicle.
To get the best protection f rom the
side curtain airbags, occupants
should wear their seat belts and sit
upright and well back in their seats.The SRS indicator alerts you to a
potential problem with your airbag
system components.
When you turn the ignition switch to
the ON (II) position, this indicator
comes on brief ly then goes of f . This
tells you the system is working
properly.
If the indicator comes on at any
other time, or does not come on at all,
you should have the system checked
by your dealer. For example:
If the SRS indicator does not come
on after you turn the ignition
switch to the ON (II) position.
If the indicator stays on after the
engine starts.
If the indicator comes on or
f lashes on and of f while you drive.You will also see a ‘‘CHECK
AIRBAG SYSTEM’’ message on the
multi-inf ormation display (see page
).
If you see any of these indications,
the airbag system components may
not work properly when you need
them.63
Additional Inf ormation About Your Airbags
How the SRS Indicator
Works
34
Ignoring the SRS indicator can
result in serious injury or death
if the airbag systems or
tensioners do not work properly.
Have your vehicle checked by a
dealer as soon as possible if
the SRS indicator alerts you to
a possible problem.
11/07/20 18:03:48 31SJA670_039
ProCarManuals.com

CONT INUED
This indicator alerts you that the
passenger’s side airbag has been
automatically shut off. It does
mean there is a problem with your
side airbags.
When you turn the ignition switch to
the ON (II) position, the indicator
should come on brief ly and then go
out (see page ). If it does not
come on, stays on, or comes on while
driving without a passenger in the
f ront seat, you will also see a
‘‘PASSENGER SIDE AIRBAG OFF’’
message on the multi-inf ormation
display. Have the system checked
(see page ).This indicator alerts you that the
passenger’s f ront airbag has been
shut of f because weight sensors
detect about 65 lbs (29 kg) or less
(the weight of an inf ant or small
child) on the f ront passenger’s seat.
It does there is a problem
with the airbag.If an adult or teenage passenger is
riding in f ront, move the seat as f ar
to the rear as possible, and have the
passenger sit upright and wear the
seat belt properly. Be aware that objects placed on the
frontseatcancausetheindicatorto
come on.
If no weight is detected on the f ront
seat, the airbag will be automatically
shut of f . However, the indicator will
not come on.
The passenger airbag of f indicator
maycomeonandoff repeatedlyif
the total weight on the seat is near
the airbag cutof f threshold.
6363
Additional Inf ormation About Your Airbags
How the Side
Airbag Of f
Indicator WorksHow the Passenger Airbag Of f
Indicator Works
not
not mean
Driver and Passenger Saf ety
35
U.S. Canada
U.S.
PASSENGER AIRBAG OFF INDICATORCanada
11/07/20 18:03:58 31SJA670_040
ProCarManuals.com

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach.
........................... Control Locations . 60
............................ Instrument Panel . 61.......... Instrument Panel Indicators . 62
............................................. Gauges . 70
................... Temperature Gauge . 70
.................................. Fuel Gauge . 70
............. Multi-Inf ormation Display . 71
Controls Near the Steering
......................................... Wheel . 136
Windshield Wipers and
..................................... Washers . 137
....... Turn Signals and Headlights . 140
................................. Fog Lights . 142
......... Daytime Running Lights . 142
Automatic Lighting Off
................................... Feature . 143
Adaptive Front Lighting System
.......................................... (AFS) . 144
............... Hazard Warning Button . 146
...... Instrument Panel Brightness . 146
............... Rear Window Def ogger . 147
...... Steering Wheel Adjustments . 148
............................. Keys and Locks . 150
...................... Immobilizer System . 150
.............................. Ignition Switch . 152
.................................... Door Locks . 153
.............................................. Trunk . 154
...... Emergency Trunk Opener . 155................ Childproof Door Locks . 155
............................................... Seats . 156
........................................... Mirrors . 161
Driving Position Memory
........................................ System . 164
................ Keyless Access System . 167
....................... Front Seat Heaters . 182
Front Seat Heaters and Seat
................................. Ventilation . 183
Rear Seat Heaters
................... (Canadian models) . 185
............................ Power Windows . 186
....................................... Moonroof . 189
............................... Parking Brake . 191
......... Interior Convenience Items . 192
.................................. Glove Box . 193
..................... Beverage Holders . 194
............. Console Compartment . 195
.................................. Sun Visors . 196
............................ Vanity Mirror . 196
........ Accessory Power Sockets . 197
.................. Front Door Pockets . 198
.............. Power Rear Sunshade . 198
.............. Integrated Sunshades . 199
............................... Interior Lights . 200
Instruments and Controls
Inst rument s and Cont rols
59
11/07/20 18:07:19 31SJA670_064
ProCarManuals.com

ÎÎ
ÎÎ
Î
The U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text.
Instrument Panel
Inst rument s and Cont rols
61
SEAT BELT REMINDER
INDICATOR
LOW FUEL INDICATOR(P.21, 62) (P.68)
SUPPLEMENTAL RESTRAINT SYSTEM
(SRS) INDICATOR (P.65)
(P.66)(P.66)ADAPTIVE CRUISE CONTROL (ACC)
INDICATOR(P.65) /
CRUISE MAIN INDICATOR
(P.66, 319)
: If equipped(P.63, 510)
IMMOBILIZER SYSTEM INDICATOR
(P.64)PARKING BRAKE AND
BRAKE SYSTEM INDICATORELECTRONICALLY
CONTROLLED POWER
STEERINGSYSTEM
(ECPS) INDICATORSIDE AIRBAG OFF
INDICATOR(P.35, 63) ANTI-LOCK BRAKE SYSTEM
(ABS) INDICATOR(P.64, 416)(P.65, 435) VEHICLE STABILITY ASSIST (VSA)
SYSTEM INDICATOR
VSA OFF INDICATORHIGH BEAM INDICATOR
ADAPTIVE FRONT LIGHTING SYSTEM
(AFS) INDICATOR (P.69, 144) COLLISION MITIGATION BRAKING
SYSTEM (CMBS) INDICATOR
LOW TIRE PRESSURE/TPMS INDICATOR (P.67, 429) (P.69) (P.68)
SH-AWD INDICATOR KEYLESS ACCESS SYSTEM INDICATOR
(P.68)
MESSAGE INDICATOR
SECURITY SYSTEM
INDICATOR
MULTI-INFORMATION
DISPLAY
MALFUNCTION INDICATOR
LAMP(P.65)(P.64) CHARGING SYSTEM INDICATOR
(P.62, 508)
LIGHTS ON INDICATOR
FOG LIGHT INDICATOR
(P.69)
(P.71)
(P.62, 509)
(P.62, 508) LOW OIL PRESSURE INDICATOR
(P.34, 63) (P.65, 435)
11/07/20 18:07:37 31SJA670_066
ProCarManuals.com
