2012.5 Citroen C3 PICASSO RHD headlamp

11
Practical information
165
Changing main beam headlampbulbs
)Remove the protective plastic cover bypulling on the tab.)Disconnect the bulb connector. )Move the springs to release the bulb.)Remove the bulb and change it.
To r e f i t , c a r ry out these operations in reverseorder.
Changing sidelamp bulbs
)
Remove the protective plastic cover by
pulling on the tab. ) Pull the bulb-holder.)
Remove the bulb and replace it.
To r efit, carry out these operations in reverse order.

11
Practical information
177
Fuse N°RatingFunctions
F1230 A Windscreen wipers slow / fast speed.
F1
340 A Built-in systems inter face supply (ignition positive).
F14
30 A Valvetronic supply (petrol).
F1
510 A Right-hand main beam headlamp.
F1
610 A
Left-hand main beam headlamp.
F17 15 A
Left-hand dipped headlamp.
F18 15 A
Ri
ght-hand dipped headlamp.
F1
915 A Multifunction engine control supply (petrol engine), air cooling electrovalves (Diesel).
F20 10 A Multi
function engine control supply (petrol engine), Turbo
pressure regulation valve (Diesel), engine coolant level
detector (Diesel).
F2
15 A Fan assembly control supply, APC, ABS ESP relays.

11
Practical information
181








Energy economy mode

These functions are reactivated automatically
the next time the vehicle is driven. ) In order to resume the use of thesefunctions immediately, star t the engine and
let it run for a few minutes.
The time available to you will then be double
the period for which the engine is left running. However, this period will always be between five and thir ty minutes.
Switching to economy mode
Once this period has elapsed, a message appears on the multifunction screen indicating
that the vehicle has switched to economy mode and the active functions are put on standby.
A flat battery prevents the engine from starting (refer to the correspondingparagraph).
If the telephone is being used at thesame time on the eMyWay audionavigation system, it will be interrupted after 10 minutes. S
ystem which manages the period of use of certain functions to conserve a sufficient level
of charge in the battery.
After the engine has stopped, you can still use functions such as the audioequipment, windscreen wipers, dipped
beam headlamps, cour tesy lamps, etc. for a maximum combined period of thirty minutes.
This period may be greatly reduced if the
battery is not fully charged.

243
10CONFIGURATION
Press SETUP
to display the"Confi guration
" menu.
Select " Choose colour" and confi rm torselect the screen colour harmony and
the map presentation mode:
-
day mode,
- n
ight mode,
- automatic day
/night mode,according to whether the
headlamps are on.
Select " Adjust luminosity" and confi rm
to adjust the screen brightness.
Pr
ess " OK" to save the changes.
The settings
for day and night are independent.

Select " Display confi guration" andconfi rm.


DISPLAY CONFIGURATION

247
11
2
3
3
1
4
2
2
1
4
4
2
2
Night mode

Auto Day/Night

Ad
just luminosity


Set date and time


"SETUP" MENU
Displa
y configuration


Choose colour
Harmon
y
Cartography
Day mode

Voice synthesis


Guidance instructions volume

Select male voice / Select female voice
2

Select units
SCREEN MENU MAP
2
3
3
2

Lighting confi guration
Parkin
g assistance
En
gage rear wiper in REVERSE
Duration of guide-me home lighting
1
Define vehicle parameters *
2

Operation of wipers
3Directional headlamps
3Mood lighting
3Daytime running lamps
*
The parameters var
y according to the vehicle.
2

Alert log
1
Trip computer
2

Status of functions

.
275 Alphabetical index
