2011 VOLVO XC70 trip computer

Contents
* Option/accessory, for more information, see Introduction.5
03
03 Your driving environment
Instruments and controls.......................... 72
Ignition modes.......................................... 79
Seats......................................................... 81
Steering wheel.......................................... 87
Lighting..................................................... 88
Wipers and washers................................. 94
Power windows......................................... 97
Mirrors....................................................... 99
Compass*............................................... 101
Power moonroof* ................................... 102
HomeLink® Wireless Control System*. . . 104
Starting the engine.................................. 107
Transmission...........................................111
Brakes..................................................... 114
Parking brake.......................................... 116
Hill Descent Control (HDC)*....................119
04
04 Comfort and driving pleasure
Menus and messages............................. 124
Climate system....................................... 128
Audio system.......................................... 135
Bluetooth
® hands-free connection......... 149
Trip computer......................................... 155
Stability system....................................... 157
Active chassis system–Four C*............... 159
Cruise control.......................................... 160
Adaptive Cruise Control (ACC)*.............. 162
Distance Alert* ....................................... 171
Collision warning with Auto-brake*......... 174
Driver Alert System* ............................... 180
Park assist*............................................. 185
Rear Park Assist Camera (PAC)* ............ 189
Blind Spot Information System*.............. 192
Passenger compartment convenience. . . 196
05
05 During your trip
Driving recommendations....................... 202
Refueling................................................. 206
Loading................................................... 211
Cargo area ............................................. 216
Towing a trailer....................................... 220
Emergency towing.................................. 222

03 Your driving environment
Instruments and controls
03

* Option/accessory, for more information, see Introduction.73
FunctionPage
Menus and mes-
sages, turn signals,
high/low beams,
trip computer124, 91,
88, 155
Cruise control160
Horn, airbag87, 22
Main instrument
panel73
Audio system/Blue-
tooth hands-free
controls135, 149
Ignition slot79
START/STOP
ENGINE button79
Hazard warning
flashers90
Door handle–
FunctionPage
In-door control pan-
els (power win-
dows, mirrors,
power child safety
locks, central lock-
ing button)97, 99,
51, 65
Menu controls,
audio and climate
control systems124, 136,
130
Center console but-
tons124
Gear selector111
Controls for active
chassis (Four-C) -
certain models only159
Wipers and washers94, 95
Steering wheel
adjustment87
Parking brake116
Hood opening con-
trol259
FunctionPage
Power seat* adjust-
ment controls81
Lighting panel, but-
tons for opening
fuel filler door and
unlocking the tail-
gate88, 208,
66
Information displays
Information displays in the instrument panel
The information displays (1) show information
on some of the vehicle's functions, such as
cruise control, the trip computer and mes-
sages. The information is shown with text and
symbols.

122* Option/accessory, for more information, see Introduction.
Menus and messages........................................................................... 124
Climate system..................................................................................... 128
Audio system........................................................................................ 135
Bluetooth
® hands-free connection....................................................... 149
Trip computer........................................................................................ 155
Stability system..................................................................................... 157
Active chassis system–Four C*............................................................. 159
Cruise control........................................................................................ 160
Adaptive Cruise Control (ACC)*............................................................ 162
Distance Alert* ..................................................................................... 171
Collision warning with Auto-brake*.......................................................174
Driver Alert System* ............................................................................. 180
Park assist*........................................................................................... 185
Rear Park Assist Camera (PAC)* .......................................................... 189
Blind Spot Information System*............................................................ 192
Passenger compartment convenience................................................. 196

04 Comfort and driving pleasure
Menus and messages
04
126
Phone settings
Call options
Sounds and volume
Synchronize phone book
Main instrument panel
G022908
Information display and menu controls
READ – access to the list of messages and
message confirmation.
Thumbwheel – browse among menus and
options in the list of functions.
RESET – reset the active function. Used in
certain cases to select/activate a function,
see the explanation under each respective
function.The menus shown on the information displays
in the instrument panel are controlled with the
left lever. The menus shown depend on ignition
mode. Press READ to erase a message and
return to the menus.
Menu overviewDriving distance on current fuel reserve
Average
Instantaneous
Average speed
Current speed in mph (Canadian models
only)
DSTC
Messages
G028940
When a warning, information or indicator sym-
bol comes on, a corresponding message
appears on the information display. An error
message is stored in a memory list until the
fault is rectified.
Press READ to acknowledge and scroll among
the messages.
NOTE
If a warning message appears while you are
using the trip computer, the message must
be read and confirmed by pressing READ
before the previous activity can be
resumed.
MessageDescription
Stop safelyStop and switch off
the engine. Serious
risk of damage.
Contact an author-
ized Volvo work-
shop.
Stopping the
engineStop and switch off
the engine. Serious
risk of damage.
Contact an author-
ized Volvo work-
shop.

04 Comfort and driving pleasure
Trip computer
04

155 Introduction
G022909
Information display and controls
READ–press to acknowledge/confirm/
erase a message)
Thumb wheel (used to scroll among the trip
computer menus)
RESET–resets certain functions
To scroll through trip computer information,
move the thumb wheel up or down. Continue
turning to return to the starting point.
Functions
NOTE
If a warning message appears while you are
using the trip computer, this message must
be acknowledged in order to return to the
trip computer function. Acknowledge a
message by pressing READ.
To change the unit of measure specified for
distance and speed, contact an authorized
Volvo workshop.
Average speedThe system calculates the average speed from
the last resetting. Reset using RESET.
Current speed in mph (Canadian models
only)
This function provides the driver with an instan-
taneous conversion of the car's current speed
from km/h to mph.
Current speed in km/h (U.S. models only)This function provides the driver with an instan-
taneous conversion of the car's current speed
from mph to km/h.
Current fuel consumption
(Instantaneous)
Current fuel consumption is calculated every
second. The information on the display isupdated every few seconds. When the vehicle
is stationary, "
----" appears on the display.
Average fuel consumptionThe average fuel consumption since the last
reset. Reset using RESET.
Driving distance on current fuel reserveThis function shows the approximate distance
that can be driven on the fuel remaining in the
tank. The calculation is based on average fuel
consumption during the last 20 miles (30 km)
of driving and the amount of fuel remaining in
the tank when the reading was taken. When the
message
---- miles to empty tank appears in
the display, refuel as soon as possible.
NOTE
The actual distance that can be driven on
the usable fuel remaining in the tank may be
influenced by a change in driving style.
See also page 202 for information on driving
economically.
Resetting1.
Select --- mph average speed or --.-
mpg average.
2.
Press and hold RESET for approx. 1 sec-
ond to reset the selected function. If
RESET is kept depressed for at 3 three

04 Comfort and driving pleasure
Trip computer
04
156
seconds, Average speed and Average fuel
consumption are reset simultaneously.

04 Comfort and driving pleasure
Driver Alert System*
04

* Option/accessory, for more information, see Introduction.181 Operating DAC
Certain settings can be made from the menu
system controlled from the center instrument
panel.
The current system status can be checked on
the trip computer’s display by using the but-
tons on the left steering wheel lever.
Thumb wheel. Turn this wheel until Driver
Alert is displayed. The second line shows
the alternatives Off, Unavailable, or [-----
], i.e., the number of bars.
READ button. Confirms and erases a mes-
sage in the display.
Activating DACIn the center instrument panel, go to Car
settings and select Driver Alert on.
The function is activated when the
vehicle exceeds a speed of 40 mph
(65 km/h). The display will show level
markings of 1–5 bars, where a low
number of bars indicates erratic driving. A high
number of bars indicates stable driving.
If the vehicle is being driven erratically, the
driver will be alerted by an audible signal and
the message Driver Alert, Time for a break is
displayed. The warning will be repeated after a
short time if the driving pattern remains the
same.
WARNING
•An alert should be taken seriously since
it is sometimes difficult for a driver to
realize that he/she is fatigued.
•In the event of a warning or if the driver
feels fatigued, stop as soon as possible
in a safe place and rest.
Symbols and messages in the display
SymbolMessageDescription
-Driver alert offThe function is not switched on.
-Driver alert
UnavailableThe vehicle’s speed is below 37 mph (60 km/h) or the road lacks clear marking lines.

04 Comfort and driving pleasure
Driver Alert System*
04

* Option/accessory, for more information, see Introduction.183 Lane Departure Warning (LDW)–
introduction
This function is designed to help reduce the
risk of accidents in situations where the vehicle
leaves its lane and there is a risk of driving off
the road or into the opposite lane. LDW con-
sists of a camera that monitors the lane’s side
marker lines. The driver is alerted by an audible
signal if the vehicle crosses a side marker line
or the road’s center dividing line.
Operation and function
LDW can be switched on or off by pressing the
button on the center console. A light in the but-
ton illuminates when the function is on.
The trip computer display shows
Lane Depart
Warn Unavailable when the function is in
standby mode.
When LDW is in standby mode, the function is
activated automatically after the camera has
monitored the road’s side marker lines and the
vehicle’s speed exceeds 40 mph (65 km/h).
Lane Depart Warn Available will be dis-
played.
If the camera can no longer monitor the road’s
side marker lines, or if the vehicle’s speed fallsbelow 37 mph (60 km/h), LDW will return to
standby mode and
Lane Depart Warn
Unavailable will be displayed.
If the vehicle unexpectedly crosses the lane’s
left or right side marker lines, the driver will be
alerted by an audible signal.
No warning signal will be given in the follow-
ing situations:
•The turn signal is being used
•The driver’s foot is on the brake pedal1
•The throttle pedal is pressed quickly
•If the steering wheel is moved quickly
•In sharp turns that cause the vehicle’s
body to sway.
See page 177 for information on the camera’s
limitations.
WARNING
The driver will only be warned once for each
time the wheels cross a marker line. No
alarm will be given if a marker line is
between the wheels.
1A warning will be given even when Increased sensitivity has been selected.
