03 Your driving environment
Instruments and controls
03
78
Reminder – doors not closedIf one of the doors, the hood or tailgate is not
closed properly, the information or warning
symbol comes on together with an explanatory
text message in the instrument panel. Stop the
vehicle in a safe place as soon as possible and
close the door, hood or tailgate.
If the vehicle is driven at a speed
lower than approximately 5 mph
(7 km/h), the information symbol comes on.
If the vehicle is driven at a speed
higher than approximately 5 mph
(7 km/h), the warning symbol comes on.
Trip odometers
Trip odometers and reset button
Odometer display
Button for toggling between T1 and T2,
and for resetting the odometer
The trip odometers are used to measure short
distances. A short press the button toggles
between the two trip odometers
T1 and T2. A
long press (more than 2 seconds) resets an
active trip odometer to zero. The distance is
shown in the display.
Clock
Clock and setting control
Display
Control for setting the clockTurn the control clockwise/counterclockwise
to set the time. The set time is shown in the
information display.
The clock may be temporarily replaced by a
symbol in conjunction with a message, see
page 126.

04 Comfort and driving pleasure
Climate system
04

* Option/accessory, for more information, see Introduction.131
•Level one: press the button three times for
the lowest output – one indicator light
comes on.
•Press the button a fourth time to switch off
the function – the indicator light will go out.
Heated front seats*Press the button once for the
highest heat level – three indi-
cator lights come on.
Press the button twice for a
lower heat level – two indica-
tor lights come on.
Press the button three times for the lowest heat
level – one indicator light comes on.
Press the button four times to switch off the
heat – no indicator lights come on.
The seat heating is normally switched off when
the engine is started. If the heating is on when
the ignition is switched off, the heating will also
switch off. Automatic start of the seat heating
can be activated/deactivated in the menu sys-
tem, under: Climate settings
Seat heating
off at start
Seat heating is switched off automatically after
a certain length of time. This function can be
activated/deactivated in the menu system,
under: Climate settings
Seat heating
timer
By default, seat heating is off when the engine
is started. If the heating is on, it will automati-
cally switch off when the engine is switched off.
Automatic start for seat heating can be set in
Climate settings
Seat heating off at
start
The seat heating switches off automatically
after several minutes. This function can be acti-
vated/deactivated in Climate settings
Seat
heating timer
Heated rear seats*
G021376
Heat control for the outboard seating positions
is done in the same way as for the front seats.
Blower controlTurn the control clockwise to
increase or counterclockwise
to decrease the blower
speed. Pressing the AUTO
switch will automatically reg-
ulate blower speed and over-
ride manual adjustment.
NOTE
If the blower is turned off completely, the air
conditioning is disengaged, which may
result in fogging on the windows.
Air distributionThe figure consists of three
buttons. When the buttons
are pressed, an indicator light
in front of the respective part
of the figure illuminates and
shows which manual air flow
has been selected. See also
the air distribution chart on page 134.

04 Comfort and driving pleasure
Audio system
04
136* Option/accessory, for more information, see Introduction.
Audio functions
Center console, controls for audio functions
Internal audio sources: AM, FM and CD
External audio source. For connection, see
page 135
Push button and knob controls for making
sound settings
Navigation button
Volume and on/off
Audio volume and automatic volume
control
The audio system compensates for disrupting
noises in the passenger compartment by
increasing the volume according to the speed
of the vehicle. The level of sound compensa-
tion can be set at low, medium or high. Selectthe level under Audio settings
Auto
volume control.
External audio source audio volumeExternal devices such as an MP3 player can be
connected to the AUX input, see page 135. The
volume of the external sound source AUX may
be different from the volume of the internal
sound sources such as the CD player or the
radio. If the external sound source's volume is
too high, the quality of the sound may be
impaired. To help prevent this, adjust the input
volume of the external audio source:
1. Set the audio system in AUX mode using
MODE and use (4) to navigate to
AUX
input volume.
2.
Turn the control (3) or press
/ the nav-
igation button.
NOTE
Sound quality may be affected if the MP3
player is being charged while the system is
in AUX mode. To help prevent this, avoid
charging the MP3 player in a 12-volt socket
while it is being played.
Sound settingsPress the control (3) repeatedly to toggle
among the sound settings. Adjustments are
made by turning the control (3).
•Bass – Bass level.
•Treble – Treble level.
•Fader – Balance between the front and
rear speakers.
•Balance – Balance between the right and
left speakers.
•Subwoofer* – Level for the bass speaker.
The subwoofer can be switched off by
turning control (3) counterclockwise to
Min. The location of the subwoofer is
shown in the illustration.
G019419
•Surround* – Surround settings.
Under
Surround, 3 channel stereo or Dolby
Surround Pro logic II can be activated by
selecting
3-ch or Dpl2 respectively. This ena-
bles the following options:

05 During your trip
Refueling
05

209
Opening/closing the fuel cap
G022915
Fuel vapor expands in hot weather. Open the
filler cap slowly.
After refueling, close the fuel filler cap by turn-
ing it clockwise until it clicks into place.
CAUTION
•Do not refuel with the engine running2.
Turn the ignition off or to position I. If the
ignition is on, an incorrect reading could
occur in the fuel gauge.
•Avoid overfilling the fuel tank. Do not
press the handle on the filler nozzle
more than one extra time. Too much fuel
in the tank in hot weather conditions can
cause the fuel to overflow. Overfilling
could also cause damage to the emis-
sion control systems.
Emission controls
Three-way catalytic converter
•Keep your engine properly tuned. Certain
engine malfunctions, particularly involving
the electrical, fuel or distributor ignition
systems, may cause unusually high three-
way catalytic converter temperatures. Do
not continue to operate your vehicle if you
detect engine misfire, noticeable loss of
power or other unusual operating condi-
tions, such as engine overheating or back-
firing. A properly tuned engine will helpavoid malfunctions that could damage the
three-way catalytic converter.
•Do not park your vehicle over combustible
materials, such as grass or leaves, which
can come into contact with the hot exhaust
system and cause such materials to ignite
under certain wind and weather condi-
tions.
•Excessive starter cranking (in excess of
one minute), or an intermittently firing or
flooded engine can cause three-way cata-
lytic converter or exhaust system over-
heating.
•Remember that tampering or unauthorized
modifications to the engine, the Engine
Control Module, or the vehicle may be ille-
gal and can cause three-way catalytic con-
verter or exhaust system overheating. This
includes: altering fuel injection settings or
components, altering emission system
components or location or removing com-
ponents, and/or repeated use of leaded
fuel.
NOTE
Unleaded fuel is required for vehicles with
three-way catalytic converters.
2If the fuel filler cap is not closed tightly or if the engine is running when the vehicle is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle's
performance will not be affected. Use only Volvo original or approved fuel filler caps.

09 Index
09
307
license plate lights.............................. 269
side marker lights...............................267
specifications...................................... 270
taillight................................................ 268
C
Camera, Park Assist................................ 189
Capacity weight....................................... 236
Cargo area
changing bulbs................................... 269
floor rails............................................. 213
hooks for securing loads............213, 214
steel grid............................................. 216
Cargo area cover..................................... 217
Cargo area net......................................... 217
Catalytic converter................................... 209
CD player/changer................................... 147
Cell phone, hands-free connection......... 149
Central locking system, introduction......... 54
Chains...................................................... 239
Check engine light..................................... 74
Child restraints
recalls and registration......................... 47Child restraint systems.............................. 38
booster cushions.................................. 44
convertible seats.................................. 42
infant seats........................................... 40
ISOFIX/LATCH anchors........................ 45
top tether anchors................................ 46
Child safety.......................................... 36, 37
booster cushions.................................. 44
child restraint systems.......................... 38
convertible seats.................................. 42
infant seats........................................... 40
Child safety locks...................................... 51
Climate system........................................ 132
air distribution............................. 129, 134
air vents.............................................. 129
Interior Air Quality System.................. 129
introduction......................................... 128
passenger compartment filter............ 128
refrigerant........................................... 128
Clock, setting............................................. 78
Cold weather driving................................ 204
Collision warning system......................... 174
Compass in rearview mirror..................... 101
Conserving electrical current................... 203
Convertible seats....................................... 42
Coolant............................................262, 299Cooling system, general information....... 203
Courtesy lighting.................................. 91, 92
Crash mode............................................... 35
Cruise control..................................160, 161
adaptive.............................................. 162
Curb weight............................................. 236
Current, conserving................................. 203
D
Defroster.................................................. 132
Detachable key blade..........................58, 61
Dimensions
XC70................................................... 294
Disconnecting the front passenger’s air-
bag....................................................... 26, 27
Dome lighting....................................... 91, 92
Door mirrors............................................... 99
Driver alert............................................... 180
Driver distraction warning.......................... 13
Driving economically................................ 202
Driving in cold weather............................ 204
Driving through water..............................203
