Fuses
07

* Option/accessory, for more information, see Introduction.281
Po
sFunctionA
Power front passenger's seat*20
Folding rear seat head
restraints*15
-
Audio system, Navigation sys-
tem display*10
Audio system15
Bluetooth hands-free system5
-
Power moonroof*
Courtesy lighting, climate sys-
tem sensor5
12-volt sockets15
Heated front passenger's
seat*15
Heated driver's seat*15
-
Po
sFunctionA
Heated rear passenger's seat
(right)*15
Heated rear passenger's seat
(left)*15
Park assist*, Volvo Navigation
System*, Park assist camera*5
All Wheel Drive* control mod-
ule5
Active chassis system*10
Positions-fuse box B
PosFunctionA
Tailgate wiper15
-
Front courtesy lighting,
power seat(s)*7.5
Instrument panel informa-
tion display5
Adaptive cruise control/
collision warning*10
PosFunctionA
Courtesy lighting, rain sen-
sor*7.5
Steering wheel module7.5
Rear cental locking and
fuel filler door10
Washers15
Windshield washer15
Tailgate unlock10
Tailgate lock10
Fuel pump20
Remote key receiver,
Alarm, Climate system5
Steering wheel lock15
Alarm, On-board diagnos-
tic system5
-
Airbag system, Occupant
weight system10

07 Maintenance and specifications
Vehicle care
07

285
CAUTION
•Avoid waxing or polishing plastic or rub-
ber components
•Polishing chromed strips can wear
away or damage the surface
•Polishes containing abrasive sub-
stances should not be used
Automatic car wash
•We do NOT recommend washing your car
in an automatic wash during the first few
months (because the paint will not have
hardened sufficiently).
•An automatic wash is a simple and quick
way to clean your car, but it is worth
remembering that it may not be as thor-
ough as when you yourself go over the car
with sponge and water. Keeping the under-
body clean is most important, especially in
the winter. Some automatic washers do
not have facilities for washing the under-
body.
CAUTION
•Before driving into an automatic car
wash, turn off the optional rain sensor to
avoid damaging the windshield wipers.
•Make sure that side view mirrors, auxil-
iary lamps, etc, are secure, and that any
antenna(s) are retracted or removed.
Otherwise there is risk of the machine
dislodging them.
•Chromed wheels: Clean chrome-
plated wheels using the same deter-
gents used for the body of the vehicle.
Aggressive wheel-cleaning agents can
permanently stain chrome-plated
wheels.
WARNING
•When the vehicle is driven immediately
after being washed, apply the brakes,
including the parking brake, several
times in order to remove any moisture
from the brake linings.
•Engine cleaning agents should not be
used when the engine is warm. This
constitutes a fire risk.
Exterior lightingCondensation may form temporarily on the
inside of the lenses of exterior lights such as
headlights, fog lights, or taillights. This is nor-mal and the lights are designed to withstand
moisture. Normally, condensation will dissi-
pate after the lights have been on for a short
time.
Polishing and waxing
•Normally, polishing is not required during
the first year after delivery, however, wax-
ing may be beneficial.
•Before applying polish or wax the vehicle
must be washed and dried. Tar spots can
be removed with kerosene or tar remover.
Difficult spots may require a fine rubbing
compound.
•After polishing use liquid or paste wax.
•Several commercially available products
contain both polish and wax.
•Waxing alone does not substitute for pol-
ishing a dull surface.
•A wide range of polymer-based waxes can
be purchased today. These waxes are easy
to use and produce a long-lasting, high-
gloss finish that protects the bodywork
against oxidation, road dirt and fading.
•Do not polish or wax your vehicle in direct
sunlight (the surface of the vehicle should
not be warmer than 113 °F (45 °C).

08 Specifications
Overview of information and warning symbols
08

* Option/accessory, for more information, see Introduction.301 Introduction
The symbols in the vehicle's various displays
are divided into three main categories:
•Warning symbols
•Indicator symbols
•Information symbols
The following tables list the most common
symbols, their meaning and the pages in this
manual that provide more detailed information.
Warning symbol
The red warning symbol lights up to
indicate a problem related to safety and/or
drivability. A message will also appear in the
main instruments panel's display.
Information symbol
The information symbol lights up and a
text message is displayed to provide the driver
with necessary information about one of the
vehicle's systems.
Symbols in the main instrument panel
Warning symbols
SymbolDescriptionPag
e
Low oil pressure76
A
Parking brake76
SRS airbags76
Seat belt reminder77
Generator not charg-
ing77
A
Fault in the brake
system77
Warning symbol77
ACanadian models
Indicator symbols
SymbolDescriptionPag
e
Fault in the Active
Bending Light
(ABL)*system75
A
Malfunction indicator
light75
A
Anti-lock brake sys-
tem (ABS)75
Rear fog light on75
Stability system
(DSTC), Hill Descent
Control,75
Tire pressure monitor-
ing sensor (TPMS)75
Low fuel level75
Information symbol,
see text in information
display75

08 Specifications
Overview of information and warning symbols
08
302* Option/accessory, for more information, see Introduction.
SymbolDescriptionPag
e
High beam indicator74
Left turn signal indica-
tor74
Right turn signal indi-
cator74
ACanadian models
Other information symbols
SymbolDescriptionPa
ge
Adaptive Cruise Con-
trol *164,
169
Adaptive Cruise Con-
trol *164,
169
Adaptive Cruise Con-
trol *, Distance Alert*164,
169,
171
Adaptive Cruise Con-
trol *, Distance Alert*164,
169,
171
SymbolDescriptionPa
ge
Adaptive Cruise Con-
trol *164,
169
Adaptive Cruise Con-
trol *, Distance Alert*164,
169,
171
Adaptive Cruise Con-
trol *, Distance Alert*164,
169,
171
Adaptive Cruise Con-
trol*164,
169
Radar sensor*166
Camera*177
SymbolDescriptionPa
ge
Collision Warning with
Auto-brake*,178
Driver Alert System*180
Active Bending Lights
(ABL)*89
Fuel filler door (arrow
indicates it is on right
side of vehicle)74
Rain sensor*94
Driver Alert System*181
Driver Alert System*,
Lane Departure Warn-
ing*183
Driver Alert System*,
Lane Departure Warn-
ing*183
