05 Infotainment
AUX/USB sockets
05

223 Connecting external devices
Sockets for auxiliary devices in the storage com-
partment between the front seats
An auxiliary device, such as an iPodŸ or MP3
player can be connected to the audio system
via one of the sockets in the center console
storage compartment. A device connected to
the USB socket can be operated using the
vehicle's infotainment system controls.
An iPod
Ÿ or an MP3 player with rechargeable
batteries will also be charged if the device is
connected to the USB socket (if the vehicle's
ignition is on or if the engine is running).
To connect a device:1.
Press MEDIA several times to come to the
desired source (
iPod, USB or AUX).
Release the button and wait for several
seconds or press OK/MENU.
> For example, if a USB device has been
selected, the text
Connect USB will be
displayed.
2. Connect the device to one of the sockets
in the center console storage compartment
(see the illustration).
The text
Reading USB will be displayed while
the system reads the device's folders. This may
take a short time, depending on the folder
structure and the number of files.
When this information has been loaded, track
information will be displayed and a track can
be selected.
Tracks can be selected in two ways:
•Turn TUNE and press OK/MENU
•Use the right or left arrow keys
(
/ ) on the center console control
panel or on the steering wheel keypad
NOTE
•The system supports a number of
iPodŸ models produced in 2005 or later.
•In order to help avoid damage to the
USB socket, it will be switched off if
there is a short circuit or if the con-
nected device uses too much current
(which can happen if the device does
not comply with the USB standard). The
USB socket will reactivate the next time
the ignition is switched on if the problem
no longer exists. If the problem persists,
contact a trained and authorized Volvo
service technician.
MEDIA menu selections can be made from the
center console or the steering wheel keypad.
See page 241 for more information about the
infotainment menu system.
Navigating and playing tracks1
Turn TUNE to access the device's playlist and
to navigate in this list. Press OK/MENU to
either select a sub-folder or confirm a choice
and begin playback. Press EXIT to cancel and
exit the playlist or to go back in the folder struc-
ture.
1USB and iPodŸ only

05 Infotainment
AUX/USB sockets
05
224
The / buttons on the center console or
steering wheel keypad can also be used to
change tracks/files.
The following symbols are used in the display:
•- audio files
•- video files
•- folders
When a file has been played, the player will
continue to play the rest of the files (of the same
type) in the current folder. When all of the files
in the folder have been played, the player will
automatically go to the next folder
1 (unlessRepeat folder is activated) and play the files
in it.
The system automatically detects and changes
settings if a device containing only audio or
only video files is connected to the USB socket
and will play these files. However, the system
will not change settings if the device contains
both audio and video files and will continue to
play the current type of file.
Fast forward/reverse1
Press and hold the / buttons to fast
forward/reverse. This is done at one speed for
audio files but several speeds can be chosenfor video files. Press the
/ buttons sev-
eral times to increase the speed. Release the
button to return to normal viewing speed.
Scan1
This function plays the first ten seconds of
each track/audio file. To start scanning:
1.
Press OK/MENU.
2.
Turn TUNE to
Scan.
> The first ten seconds of each track/
audio file will be played.
3.
Stop scanning by pressing EXIT. The cur-
rent track/audio file will continue playing.
Random1
This function plays the tracks in random order
(shuffle). The random tracks/sound files can be
scrolled through in the normal way. To listen to
tracks in random order:
1.
Press OK/MENU,
2.
Turn TUNE to
Random
3.
Press OK/MENU to activate/deactivate
the random play function.
Press the
/ buttons on the center con-
sole or steering wheel keypad to change
tracks/audio files.
Repeat2
This function makes it possible to play files in
a folder repeatedly. When the last file has been
played, the first file will begin again. To acti-
vate:
1.
Press OK/MENU.
2.
Turn TUNE to
Repeat folder.
3.
Press OK/MENU to activate/deactivate
the function.
External sound sources
USB flash drive
To simplify the use of a USB flash drive, it is
advisable to only store music files on the drive.
It will take considerably longer for the system
to index the files on the drive if it contains any-
thing other than compatible music files.
1USB and iPodŸ only2USB only

05 Infotainment
AUX/USB sockets
05
225
NOTE
•The system supports removable media
that uses the USB 2.0 standard and the
FAT32 file system. It can index up to
1,000 folders and a maximum of 254
sub-folders/files for each folder. How-
ever, the highest folder level can sup-
port up to 1,000 sub-folders/files.
•When using a longer type of USB
device, connecting it with a USB
adapter cable will help reduce mechan-
ical wear on the USB socket and on the
device.
USB hubA USB hub can be connected to the USB
socket, making it possible to connect several
USB devices at the same time. To select one
of the devices, go to the menu USB menu
Select USB device
MP3 playerMany MP3 players have a file indexing system
that is not supported by the vehicle's audio
system. In order to use an MP3 player, the sys-
tem must be set to
USB Removable device/
Mass Storage Device.
iPodŸ
An iPodŸ receives current and its battery is
charged through the USB cable.The system will only play audio files from an
iPod
Ÿ.
NOTE
When an iPodŸ is used as a sound source,
the vehicle's audio system has a menu
structure similar to the one in the iPod
Ÿ. See
the iPod's manual for detailed information.
Compatible file formats via the USB
socket
The following audio and video files are suppor-
ted by the system when playing a device con-
nected to the USB socket.
Audio formatsmp3, wma, aac,
m4a
Video formatsdivx, avi, asf

05 Infotainment
BluetoothŸŸ media
05
226
Streaming audio
IntroductionThe vehicle's media player is equipped with
BluetoothŸ and can play streaming audio files
from a BluetoothŸ device such as a cell phone
or PDA. Navigation and control of the device
can be done through the vehicle's center con-
sole control panel or the steering wheel key-
pad. On certain external devices, it is also pos-
sible to change tracks from the device.
In order to listen streaming audio, the vehicle's
media player must first be put in
Bluetoothmode. To do so, Press MEDIA several times
until Bluetooth is displayed. Release the but-
ton and wait several seconds or press OK/
MENU.
Choices can be made in the
Bluetooth menus
from the center console control panel or the
steering wheel keypad. See page 241 for addi-
tional information about navigating the various
menus.
NOTE
Any Bluetooth media players used must
support Audio/Video Remote Control Pro-
file (AVRCP) and Advanced Audio Distribu-
tion Profile (A2DP). The player must use
AVRCP version 1.3 and A2DP 1.2. If older
versions of these standards are used, cer-
tain features (e.g., scan or random) may not
function.
Not all cell phones or media players are fully
compatible with the vehicle's Bluetooth sys-
tem. A list of compatible devices is available
at you Volvo retailer or at www.volvo-
cars.us.
The vehicle's media player can only play audio
files through the BluetoothŸ function.
Overview
Center console control panel
VOL: Volume control
MEDIA button
TUNE: Turn to navigate among menu alter-
natives and folders shown in the display.
OK/MENU: Press to confirm your selec-
tion or access the menus.
EXIT: Press to go back in the menu struc-
ture or cancel a function.
Left/right arrow keys: Short press: change
tracks. Long press: fast forward/reverse
within a track. The arrow keys on the steer-
ing wheel keypad can be used in the same
way.
MEDIA menu selections can be made from the
center console or the steering wheel keypad.

10 Index
10
350
1, 2, 3 ...
12-volt sockets........................................ 195
A
ABS (anti-lock brake system).................. 116
Accessory installation warning.................. 13
Active chassis system.............................146
Active yaw control................................... 144
Adaptive brake lights............................... 115
Adaptive cruise control.................... 149, 151
Airbags
disconnecting the front passenger’s
side.................................................26, 27
front...................................................... 22
inflatable curtain................................... 32
side impact........................................... 30
Air conditioning........................................ 139
Air distribution.......................................... 135
Air distribution table................................. 141
Air vents................................................... 136
All Wheel Drive......................................... 114
Anti-freeze.......................................248, 306Anti-lock brake system
warning light......................................... 76
Anti-lock Brake System (ABS)................. 116
Approach lighting................................58, 93
Audio system
AUX/USB sockets............................... 223
BluetoothŸ devices............................. 226
BluetoothŸ hands-free system........... 229
Bluetooth streaming audio................. 226
general functions................................ 207
getting started.................................... 202
HD digital radio................................... 212
introduction......................................... 200
media player....................................... 219
menus................................................. 241
overview.............................................. 200
radio functions.................................... 210
Sirius satellite radio............................214
sound settings.................................... 208
steering wheel keypad........................ 205
voice control....................................... 237
Auto-dim rearview mirror......................... 101
Automatic locking retractor....................... 38
Automatic transmission
Geartronic................................... 112, 113
general description.....................112, 113oil........................................................ 343
shiftlock override................................ 113
Axle weight.............................................. 280
B
Battery
changing..................................... 318, 319
maintenance....................................... 318
remote key, replacing........................... 61
specifications...................................... 344
warning symbols................................. 317
Black box................................................... 11
Blind Spot Information System
(BLIS)....................................... 189, 190, 191
Bluetooth cell phone connection............. 229
Booster cushion, integrated...................... 49
Booster cushions....................................... 45
Brake lights.............................................. 115
Brake system
ABS..................................................... 116
checking fluid level............................. 306
emergency brake assistance.............. 116
fluid..................................................... 343
general information............................. 115

10 Index
10
353
high/low beams.................................... 89
high beam flash.................................... 89
Headlight washers..................................... 96
Head restraints, rear seat.......................... 85
Heated oxygen sensors........................... 254
Heated rear seats.................................... 138
High beams................................................ 89
indicator light........................................ 77
Hill Descent Control................................. 121
Hoisting the vehicle.................................301
Home safe lighting..................................... 93
Hood, opening/closing............................303
Horn........................................................... 88
I
Ignition modes........................................... 81
Immobilizer................................................ 57
Important information.................................. 8
Indicator lights.........................75, 76, 77, 78
Infant seats................................................ 41
Inflatable Curtain........................................ 32
Inflation pressure..................................... 273Inflation pressure tables..................275, 276
Information and warning symbols, table
of.............................................................. 345
Information lights.....................75, 76, 77, 78
Information symbol.................................... 77
Infotainment system................................ 200
AUX/USB sockets............................... 223
Bluetooth
Ÿ devices............................. 226
Bluetooth® hands-free system........... 229
general functions................................ 207
getting started.................................... 202
media player....................................... 219
menus................................................. 241
radio functions.................................... 210
sound settings.................................... 208
voice control....................................... 237
Inspection readiness................................ 301
Instrument lighting..................................... 89
Instrument overview............................74, 75
Instrument panel...................................... 126
Integrated two-stage booster cushion...... 49
Interior Air Quality System....................... 135
Interior lighting..................................... 92, 93
iPodŸ connector (audio system)............. 223
ISOFIX/LATCH anchors............................. 46
J
Jack
attaching.............................................291
location of........................................... 291
Jump starting........................................... 110
K
Key blade.......................................56, 60, 63
Keyless drive
general description............................... 63
starting the vehicle.............................109
L
Labels
list of................................................... 337
location of........................................... 336
Laminated panoramic roof...................... 103
LATCH anchors......................................... 46
Leather care............................................. 330
Lighting panel............................................ 89
Load anchoring eyelets...........................257

10 Index
10
354
Loading the vehicle.......................... 255, 280
roof loads............................................ 258
Locking...................................................... 66
tailgate.................................................. 67
Locking the vehicle.................................... 58
Locks, child safety..................................... 52
Low beams................................................ 89
Low fuel level warning light........................ 77
Low oil pressure warning light................... 78
M
Main instrument panel............................. 126
Maintenance............................................ 300
hoisting the vehicle............................. 301
performed by the owner.....................301
Malfunction indicator light......................... 76
Media player (infotainment system)......... 219
Menu........................................................ 128
Messages in the instrument panel........... 126
Mirrors
defroster............................................. 101
power door......................................... 100
rearview, auto-dim function................ 101retractable........................................... 100
vanity.................................................. 195
Motor oil
checking............................................. 304
specifications...................................... 342
volumes.............................................. 343
MY CAR................................................... 128
N
Net in cargo area..................................... 260
O
Occupant safety........................................ 16
Occupant weight sensor...................... 26, 27
Octane recommendations.......................251
Odometer, trip........................................... 80
Oil
checking............................................. 304
specifications...................................... 342
volumes.............................................. 343
On Call Roadside Assistance.................. 348
Overhead courtesy lighting.................. 92, 93Overheating, engine................................... 79
Oxygen sensors, heated.......................... 254
P
Paint, touching up.................................... 331
Park assist.......................................181, 183
Park Assist Camera................................. 185
Parking brake
electric, applying/releasing................. 118
warning light......................................... 78
Parking lights............................................. 91
Personal Car Communicator, unique func-
tions........................................................... 59
Polishing.................................................. 329
Power front seat
memory function................................... 83
with keyless drive................................. 84
Power mirrors.......................................... 100
defroster............................................. 101
Power steering
fluid..................................................... 307
speed-dependent............................... 146
Power steering fluid................................. 343
