03 Your driving environment
Starting the engine
03

109
NOTE
•After a cold start, idle speed may be
noticeably higher than normal for a
short period. This is done to help bring
components in the emission control
system to their normal operating tem-
perature as quickly as possible, which
enables them to control emissions and
help reduce the vehicle's impact on the
environment
3.
•Keylock: Your vehicle is equipped with
a keylock system. When the engine is
switched off, the gear selector must be
in the Park position before the key can
be removed
4 from the ignition slot.
CAUTION
•When starting in cold weather, the auto-
matic transmission may shift up at
slightly higher engine speeds than nor-
mal until the automatic transmission
fluid reaches normal operating tem-
perature.
•Do not race a cold engine immediately
after starting. Oil flow may not reach
some lubrication points fast enough to
prevent engine damage.
•The engine should be idling when you
move the gear selector. Never acceler-
ate until after you feel the transmission
engage. Accelerating immediately after
selecting a gear will cause harsh
engagement and premature transmis-
sion wear.
•Selecting P or N when idling at a stand-
still for prolonged periods of time will
help prevent overheating of the auto-
matic transmission fluid.
Switching off the engine
With the engine running, press the START/
STOP ENGINE button.
If the gear selector is not in the P position or if
the vehicle is moving, press the button twice or
press and hold it in until the engine switches
off.
Jump starting
G021347
Connecting the jumper cables
Follow these instructions to jump start your
vehicle's dead battery or to jump start another
vehicle's dead battery using your vehicle. If the
12-volt auxiliary battery to be used is in another
vehicle, check that the vehicles are not touch-
3If the gear selector is in the D or R positions and the car is not moving, engine speed (rpm) will be lower and it will take longer for the engine to reach normal operating temperature.4Does not apply to vehicles with the optional keyless drive.

06 During your trip
Driving recommendations
06
240
Before a long distance tripIt is always worthwhile to have your vehicle
checked by a trained and qualified Volvo serv-
ice technician before driving long distances.
Your retailer will also be able to supply you with
bulbs, fuses, spark plugs and wiper blades for
your use in the event that problems occur.
As a minimum, the following items should be
checked before any long trip:
•Check that engine runs smoothly and that
fuel consumption is normal.
•Check for fuel, oil, and fluid leakage
•Have the transmission oil level checked.
•Check condition of drive belts.
•Check state of the battery's charge.
•Examine tires carefully (the spare tire as
well), and replace those that are worn.
Check tire pressures.
•The brakes, front wheel alignment, and
steering gear should be checked by a
trained and qualified Volvo service techni-
cian only.
•Check all lights, including high beams.
•Reflective warning triangles are legally
required in some states/provinces.
•Have a word with a trained and qualified
Volvo service technician if you intend to
drive in countries where it may be difficult
to obtain the correct fuel.
•Consider your destination. If you will be
driving through an area where snow or ice
are likely to occur, consider snow tires.
Cold weather precautionsIf you wish to check your vehicle before the
approach of cold weather, the following advice
is worth noting:
•Make sure that the engine coolant contains
50 percent antifreeze. Any other mixture
will reduce freeze protection. This gives
protection against freezing down to
–31 °F (–35 °C). The use of "recycled" anti-
freeze is not approved by Volvo. Different
types of antifreeze must not be mixed.
•Volvo recommends using only genuine
Volvo antifreeze in your vehicle's radiator.
•Try to keep the fuel tank well filled – this
helps prevent the formation of condensa-
tion in the tank. In addition, in extremely
cold weather conditions it is worthwhile to
add fuel line de-icer before refueling.
•The viscosity of the engine oil is important.
Oil with low viscosity (thinner oil) improves
cold-weather starting as well as decreas-
ing fuel consumption while the engine is
warming up. For winter use, 5W-30 oil, par-
ticularly the synthetic type, is recom-
mended. Be sure to use good quality oil but
do not use cold-weather oil for hard driving
or in warm weather, see page 325 for more
information on engine oil.
NOTE
Synthetic oil is not used when the oil is
changed at the normal maintenance inter-
vals except at owner request and at addi-
tional charge.
•The load placed on the battery is greater
during the winter since the windshield wip-
ers, lighting, etc. are used more often.
Moreover, the capacity of the battery
decreases as the temperature drops. In
very cold weather, a poorly charged bat-
tery can freeze and be damaged. It is there-
fore advisable to check the state of charge
more frequently and spray an anti-rust oil
on the battery posts.
•Volvo recommends the use of snow tires
on all four wheels for winter driving, see
page 270.
•To prevent the washer fluid reservoir from
freezing, add washer solvents containing
antifreeze. This is important since dirt is
often splashed on the windshield during
winter driving, requiring the frequent use of
the washers and wipers. Volvo Washer
Solvent should be diluted as follows: Down
to 14 °F (–10 °C): 1 part washer solvent and
4 parts water Down to 5 °F (–15 °C): 1 part
washer solvent and 3 parts water Down to
0 °F (–18 °C): 1 part washer solvent and

10 Index
10
332
1, 2, 3 ...
12-volt sockets........................................ 188
A
ABS (anti-lock brake system).................. 115
Accessory installation warning.................. 14
Active chassis system.............................140
Active yaw control................................... 138
Adaptive brake lights............................... 114
Adaptive cruise control.................... 143, 145
Airbags
disconnecting the front passenger’s
side.................................................29, 30
front...................................................... 25
inflatable curtain................................... 35
side impact........................................... 33
Air conditioning........................................ 134
Air distribution.......................................... 130
Air distribution table................................. 136
Air vents................................................... 131
All Wheel Drive......................................... 113
Anti-freeze.......................................240, 292Anti-lock brake system............................ 114
warning light......................................... 76
Anti-lock Brake System (ABS)................. 115
Approach lighting................................56, 94
Audio system
AUX/USB sockets............................... 215
BluetoothŸ devices............................. 218
BluetoothŸ hands-free system........... 221
Bluetooth streaming audio................. 218
general functions................................ 199
getting started.................................... 194
HD digital radio................................... 204
introduction......................................... 192
media player....................................... 211
menus................................................. 233
overview.............................................. 192
radio functions.................................... 202
Sirius satellite radio............................206
sound settings.................................... 200
steering wheel keypad........................ 197
voice control....................................... 229
Auto-dim rearview mirror......................... 101
Automatic locking retractor....................... 40
Automatic transmission
Geartronic................................... 111, 112
general description.....................111, 112oil........................................................ 326
shiftlock override................................ 112
Axle weight.............................................. 267
B
Battery
changing............................................. 303
maintenance...............................302, 303
remote key, replacing........................... 59
specifications...................................... 327
warning symbols................................. 302
Blind Spot Information System
(BLIS)....................................... 182, 183, 184
Bluetooth cell phone connection............. 221
Booster cushions....................................... 47
Brake lights.............................................. 114
Brake system
checking fluid level............................. 292
emergency brake assistance.............. 115
fluid..................................................... 326
general information............................. 114
warning light......................................... 78

10 Index
10
334
E
ECC.................................................134, 135
Economical driving.................................. 238
Electric parking brake.............................. 116
Electronic Climate Control.......132, 134, 135
air distribution table............................ 136
Interior Air Quality System.................. 135
Emergency locking retractor...................... 40
Emergency starting.................................. 109
Emergency towing...........................253, 254
Emission inspection readiness................ 287
Engine
overheating........................................... 79
specifications...................................... 324
starting................................................ 108
switching off....................................... 109
Engine compartment overview................289
Engine Drag Control (EDC)......................138
Engine oil
checking............................................. 290
low pressure warning light.............. 77, 78
specifications...................................... 325
volumes.............................................. 325
Environment............................................... 13Eyelets for anchoring loads..................... 247
F
Federal Clean Air Act............................... 286
Fluid specifications.................................. 326
Fog lights
front/rear............................................... 92
Four C (active chassis system)................140
Front airbags.............................................. 25
disconnecting passenger’s side air-
bag.................................................. 29, 30
Front park assist.............................. 175, 177
Front seats...........................................83, 85
Fuel filler cap........................................... 245
Fuel filler door, opening........................... 244
Fuel level warning light.............................. 77
Fuel requirements............................ 242, 243
Fuel tank volume.....................................326
Fuses............................... 305, 306, 309, 312
G
Gasoline requirements............................. 243
Gas tank volume...................................... 326
Gauges...................................................... 75
Geartronic................................................ 112
Geartronic automatic transmission.. 111, 112
Generator warning light............................. 78
Glossary of tire terminology..................... 266
Grocery bag holder.................................. 248
Gross vehicle weight...............................267
H
Hazard warning flashers............................ 92
HD digital radio........................................ 204
Headlights
Active Bending Lights........................... 91
changing bulbs...........................295, 296
high/low beams.................................... 90
high beam flash.................................... 90
Headlight washers..................................... 97
Head restraints, rear seat.......................... 86
Heated oxygen sensors........................... 246
