2011 VOLVO C70 transmission fluid

06 Starting and driving
General information
06
142
water Down to –18 °F (–28 °C): 1 part
washer solvent and 1 part water.
•Use Volvo Teflon Lock Spray in the locks.
NOTE
Avoid using de-icing sprays as they can
cause damage to the locks.
Conserving electrical current
Keep the following in mind to help minimize
battery drain:
•When the engine is not running, avoid turn-
ing the ignition key to position II. Many
electrical systems (the audio system, the
optional navigation system, power win-
dows, etc) will function with the ignition key
in position I. This position reduces drain on
the battery.
•Please keep in mind that using systems,
accessories, etc that consume a great deal
of current when the engine is not running
could result in the battery being completely
drained. Driving or having the engine run-
ning for approximately 15 minutes will help
keep the battery charged.
•The optional 12 volt socket in the trunk
(certain models only) provides electricalcurrent even with the ignition switched off,
which drains the battery.
NOTE
•If the ignition is switched on, a warning
message will be displayed in the text
window in the instrument panel when
the battery charge is low.
•An energy conserving function
designed into the vehicle's electrical
system will switch off certain functions
or reduce the load on the battery by,
e.g., reducing the audio system's vol-
ume.
Before a long distance trip
It is always worthwhile to have your vehicle
checked at a trained and qualified Volvo serv-
ice technician before driving long distances.
Your trained and qualified Volvo service tech-
nician will also be able to supply you with
bulbs, fuses, spark plugs and wiper blades for
your use in the event that problems occur.
As a minimum, the following items should be
checked before any long trip:
•Check that engine runs smoothly and that
fuel consumption is normal.
•Check for fuel, oil, and fluid leakage
•Have the transmission oil level checked2.
•Check condition of drive belts.
•Check state of the battery's charge.
•Examine tires carefully (the spare tire as
well), and replace those that are worn.
Check tire pressures.
•The brakes, front wheel alignment, and
steering gear should be checked by your
Volvo retailer only.
•Check all lights, including high beams.
•Reflective warning triangles are legally
required in some states/provinces.
•Have a word with your Volvo retailer if you
intend to drive in countries where it may be
difficult to obtain the correct fuel.
•Consider your destination. If you will be
driving through an area where snow or ice
are likely to occur, consider snow tires.
2To prevent injury from contact with hot surfaces, do not inspect your vehicle's transmission fluid yourself. Have your vehicle's transmission fluid level inspected by a qualified Volvo service technician.

06 Starting and driving
Starting the vehicle
06

147 To start the engine
WARNING
Before starting, check that the seat, steering
wheel and mirrors are adjusted properly.
Make sure the brake pedal can be
depressed completely. Adjust the seat if
necessary.
1. Fasten the seat belt.
2. Apply the parking brake if not already set.
The gear selector should be locked in the
Park (P) position (Shiftlock). See also page
152.
NOTE
After a cold start, idle speed may be notice-
ably higher than normal for a short period.
This is done to help bring components in the
emission control system to their normal
operating temperature as quickly as possi-
ble, which enables them to control emis-
sions and help reduce the vehicle's impact
on the environment.
3. The vehicle is equipped with an autostart
feature. Without touching the throttle
pedal, turn the key to position III and
release it. The starter motor will then oper-ate automatically (for up to ten seconds)
until the engine starts. If the engine fails to
start, repeat this step.
4. To release the gear selector from the Park
(P) position, the engine must be running (or
the ignition key must be in position II) and
the brake pedal must be depressed.
5. Select the desired gear. The gear engages
after a very slight delay, which is especially
noticeable when selecting R.
NOTE
•Immobilizer: If two of the keys to your
vehicle are close together, e.g., on the
same key ring when you try to start the
vehicle, this could cause interference in
the immobilizer system and result in the
vehicle not starting. If this should occur,
remove one of the keys from the key
ring before trying to start the vehicle
again.
•Keylock: The automatic transmission
has a keylock system. When the engine
is switched off, the gear selector must
be in the Park (P) position before the key
can be removed from the ignition
switch
1.
•When starting in cold weather, an auto-
matic transmission may shift up at
slightly higher engine speeds than nor-
mal until the automatic transmission
fluid reaches normal operating tem-
perature.
•Do not race a cold engine immediately
after starting. Oil flow may not reach
some lubrication points fast enough to
prevent engine damage.
1The optional keyless drive start control does not need to be removed from the ignition switch.

06 Starting and driving
Starting the vehicle
06
148
WARNING
•Volvo's floor mats are specially manu-
factured for your car. They must be
firmly secured in the clips on the floor so
that they cannot slide and become trap-
ped under the pedals on the driver's
side.
•Always place the gear selector in Park
(P) and apply the parking brake before
leaving the vehicle. Never leave the
vehicle unattended with the engine run-
ning.
•Always open garage doors fully before
starting the engine inside a garage to
ensure adequate ventilation. The
exhaust gases contain carbon monox-
ide, which is invisible and odorless but
very poisonous.
CAUTION
Automatic transmission: The engine
should be idling when you move the gear
selector. Never accelerate until after you
feel the transmission engage! Accelerating
immediately after selecting a gear will cause
harsh engagement and premature trans-
mission wear. Selecting P or N when idling
at a standstill for prolonged periods of time
will help prevent overheating of the auto-
matic transmission fluid.

11 Specifications
Fuel, oils, and fluids
11

273 Specifications and capacities
CategorySpecificationCapacity
Fuel tankOctane rating: unleaded gasoline, minimum
octane requirement AKI 87, recommended rat-
ing AKI 91 or above.15.9 US gallons (60 liters)
Engine oil (with filter replacement)See page 274 for information on engine oil
specifications.6.1 US quarts (5.8 liters)
Automatic transmission oilJWS 33098.14 US quarts (7.7 liters)
CoolantVolvo original coolant/antifreeze (50/50 mix-
ture of water and anti-freeze)10.5 US quarts (10 liters) – models with automatic
transmission
Brake fluidDOT 4+ boiling point >536 °F (280 °C), P/N
94374330.63 US quarts (0.6 liters)
Power steering fluidWSS M2C204-A or equivalent1.3 US quarts (1.2 liters) – system and reservoir com-
bined
Washer fluid reservoirUse washer fluid solvent in cold weather con-
ditions.4.2 US qts (4 liters)
Air conditioning systemRefrigerant – R134a1.2 lbs. (530 grams)

11 Specifications
Fuel, oils, and fluids
11
274
NOTE
The transmission oil does not normally need
to be changed during the service life of the
vehicle. However, it may be necessary to
replace the oil if the vehicle is often driven
in areas of sustained temperature extremes
(hot or cold), when towing a trailer over long
distances, for prolonged driving in moun-
tainous areas, or if the vehicle is often driven
short distances in temperatures under 40 °F
(5 °C).
Oil specifications
Engine oil must meet the minimum ILSAC
specification GF-4, API SL, or ACEA A1/B1.
Lower quality oils may not offer the same fuel
economy, engine performance, or engine pro-
tection.
Volume: 6.1 US qts (5.8 liters).
Volume between the MIN and MAX marks on
the dipstick: approximately 1.4 US qts (1.3 lit-
ers).
Volvo recommends Castrol.
Depending on your driving habits, premium or
synthetic oils may provide superior fuel econ-
omy and engine protection. Consult your Volvo
retailer or a trained and qualified Volvo service
technician for recommendations on premium
or synthetic oils.
Oil additives must not be used.
NOTE
Synthetic oil is not used when the oil is
changed at the normal service intervals.
This oil is only used at customer request, at
additional charge. Please consult a trained
and qualified Volvo service technician.
Oil viscosityIncorrect viscosity oil can shorten engine life
under normal use. SAE 5W-30 will provide
good fuel economy and engine protection. See
the viscosity chart.
G023491
Viscosity chart
Extreme engine operationSynthetic oils meeting SAE 0W-30 or 0W-40
and complying with oil quality requirements are
recommended for driving in areas of sustained
temperature extremes (hot or cold), when tow-ing a trailer over long distances, and for pro-
longed driving in mountainous areas.
American Petroleum Institute (API)
symbol
G022917
The API Service Symbol "donut" is divided into
three parts:
•The upper section describes the oil's per-
formance level.
•The center identifies the oil's viscosity.
•The lower section indicates whether the oil
has demonstrated energy-conserving
properties in a standard test in comparison
to a reference oil.

12 Index
12
284
1, 2, 3 ...
12-volt socket.......................................... 118
12-volt sockets.......................................... 63
A
A/C (air conditioning)................................. 88
ABS (anti-lock brake system).................. 154
Accessory installation warning.................. 15
Adaptive brake lights............................... 153
Airbags
front...................................................... 24
inflatable curtain................................... 33
side impact........................................... 31
Airbag system............................................ 24
Air conditioning.......................................... 88
Air distribution table................................... 94
Air vents..................................................... 90
Alarm system........................................... 134
turning off sensors.............................. 135
Anti-lock Brake System (ABS)................. 154
Approach lighting...................................... 81
Audio files................................................ 256Audio system
audio functions................................... 243
automatic sound control..................... 247
AUX port............................................. 243
compact disc care.............................. 257
Dolby Surround Pro Logic II............... 246
equalizer............................................. 247
HD digital radio................................... 250
menu settings..................................... 259
radio functions.................................... 248
selecting a sound source.................... 243
Sirius satellite radio............................252
sound settings.................................... 246
steering wheel keypad........................ 244
storing radio stations.......................... 248
subwoofer........................................... 246
USB/iPodŸ connector........................ 244
Auto-dim rearview mirror........................... 77
Autolock..................................................... 80
Automatic locking retractor....................... 39
Automatic sound control.........................247
Automatic transmission........................... 150
kickdown............................................ 151
oil........................................................ 273
shiftlock override................................ 152
Automatic transmission - Geartronic....... 151AUX port.................................................. 243
Axle weight......................................186, 271
B
Bass......................................................... 246
Battery
maintenance....................................... 224
remote key, replacing......................... 124
specifications...................................... 277
warning symbols................................. 224
Battery – replacing................................... 225
Black box................................................... 13
Blind Spot Information System (BLIS)..... 167
Bluetooth cell phone connection............. 260
Booster cushion
accessory............................................. 46
Brake fluid........................................ 222, 273
Brake lights........................................ 65, 153
Brake system
anti-lock brakes (ABS)........................ 154
emergency brake assistance.............. 154
fluid..................................................... 222
general information............................. 153

12 Index
12
290
speed ratings...................................... 180
storing................................................. 177
studded............................................... 189
tire pressure monitoring system......... 201
tire sealing system.............................. 194
tread wear indicator............................ 178
uniform tire quality grading................. 188
winter driving...................................... 189
Tire sealing system.................................. 194
Towing a trailer........................................ 163
trailer hitch.......................................... 165
Towing the vehicle................................... 159
Trailer hitch - detachable......................... 165
Trailer towing........................................... 163
Transmission
Geartronic........................................... 151
shiftlock override................................ 152
Tread wear indicator................................ 178
Treble....................................................... 246
Trip computer............................................ 69
Trips, long distance................................. 142
Trunk
loading................................................117
opening from the inside...................... 133
opening mechanically......................... 133Trunk divider (Power retractable hard
top)........................................................... 107
Turn signals............................................... 67
indicator lights...................................... 54
U
Uniform Tire Quality Grading...................188
V
Valet locking............................................ 126
Vehicle dimensions.................................. 270
Vehicle Event Data..................................... 13
Vehicle loading........................................ 186
Vehicle maintenance................................ 214
performed by the owner.....................215
Vehicle towing.........................................159
Vehicle weights........................................ 271
VIN (Vehicle Identification Number)......... 269
Volvo and the environment........................ 14
Volvo maintenance.................................. 214
Volvo On Call Roadside Assistance........ 282
W
Warning flashers, hazard........................... 75
Warning symbol......................................... 56
Warranties................................................ 214
Washer fluid..................................... 221, 273
Washer fluid reservoir......................218, 221
Water, driving through............................. 140
Weights.................................................... 271
Wheel nuts............................................... 191
Wheels.....................................................176
changing............................................. 199
storing................................................. 177
Whiplash Protection System (WHIPS)....... 34
Wind blocker (power retractable hard top)
(Power retractable hard top).................... 110
Windows
power.................................................... 76
Windshield washer fluid reservoir............218
Windshield wiper blades.......................... 223
Windshield wipers...................................... 73
rains sensor.......................................... 74
Winter tires............................................... 189
