09 Maintenance and servicing
Fluids 09
222
WARNING
Never remove the radiator cap while the
engine is warm. Wait until the vehicle cools.
If it is necessary to top off the coolant when
the engine is warm, unscrew the expansion
tank cap slowly so that the overpressure
dissipates.
Brake fluid
Brake fluid reservoir
The brake fluid should always be between the
MIN and MAX marks on the side of the reser-
voir. Check, without removing the cap, that
there is sufficient fluid in the reservoir.Fluid type: DOT 4+ boiling point >536 °F
(>280 °C), P/N 9437433
Replace: The fluid should be replaced accord-
ing to the intervals specified in the Warranty
and Service Records Information booklet.
When driving under extremely hard conditions
(mountain driving, etc), it may be necessary to
replace the fluid more often. Consult your
Volvo retailer. Always entrust brake fluid
changing to a trained and qualified Volvo serv-
ice technician.
WARNING
•If the fluid level is below the MIN mark
in the reservoir or if a brake-related
message is shown in the information
display: DO NOT DRIVE. Have the car
towed to a trained and qualified Volvo
service technician and have the brake
system inspected.
•Dot 4+ should never be mixed with any
other type of brake fluid.
Power steering fluid
The fluid level is checked at each service inter-
val.
Fluid type: Volvo power steering fluid or equiv-
alent.
Replace: No fluid change required.
WARNING
If a problem should occur in the power
steering system or if the vehicle has no elec-
trical current and must be towed, it is still
possible to steer the vehicle. However, keep
in mind that greater effort will be required to
turn the steering wheel.

09 Maintenance and servicing
Battery 09
224
Battery maintenance
Driving habits and conditions, climate, the
number of starts, etc., all affect the service life
and function of the battery. In order for your
battery to perform satisfactorily, keep the fol-
lowing in mind:
Check the fluid level in each cell in the battery
every 24 months or every 15,000
1 miles
(24,000 km), whichever is sooner.
•Use a screw driver to open the caps or
cover and a flashlight to inspect the level.
•If necessary, add distilled water. The level
should never be above the indicator.
•The fluid level should be checked if the
battery has been recharged.
•After inspection, be sure the cap over each
battery cell or the cover is securely in
place.
•Check that the battery cables are correctly
connected and properly tightened.
•Never disconnect the battery when the
engine is running, or when the key is in the
ignition. This could damage the vehicle's
electrical system.
•The battery should be disconnected from
the vehicle when a battery charger is used
directly on the battery.
•To help keep the battery in good condition,
the vehicle should be driven for at least 15
minutes a week or connected to a charger
with an automatic charging function.
•If the battery is fully discharged a number
of times, this may shorten its service life.
Keeping the battery fully charged helps
prolong its service life.
•The service life of a battery is affected by
factors such as driving conditions and cli-
mate. Extreme cold may also further
decrease the battery’s starting capacity.
•Because the battery’s starting capacity
decreases with time, it may be necessary
to recharge it if the vehicle is not driven for
an extended period of time or if the vehicle
is usually only driven short distances.
•
WARNING
PROPOSITION 65 WARNING!
Battery posts, terminals, and related acces-
sories contain lead and lead compounds,
chemicals known to the state of California
to cause cancer and reproductive harm.
Wash hands after handling.
Battery symbols
Wear protection goggles
See owner's manual for
details
Keep away from children
Corrosive
1More frequently in warm climates.

12 Index
12
286
Electronic Climate Control
air distribution table.............................. 94
Electronic Climate Control (ECC)............... 91
Emergency brake..................................... 156
Emergency locking retractor...................... 39
Emergency starting.................................. 162
Emergency towing................................... 159
Emission inspection readiness................ 215
Engine
specifications...................................... 275
starting................................................ 147
starting with keyless drive.................. 149
Engine compartment overview................218
Engine oil................................................. 219
changing............................................. 219
checking............................................. 219
specifications...................................... 274
volumes.............................................. 273
Environment............................................... 14
Equalizer, audio system........................... 247
Eyelets for anchoring loads..................... 118F
Federal Clean Air Act............................... 214
Flat tires
changing..................................... 192, 199
repairing with tire sealing system....... 194
Fluids and oils.......................................... 273
FM1/FM2 menu....................................... 248
Fog lights
front...................................................... 65
rear........................................................ 65
Front airbags.............................................. 24
disconnecting passenger’s side airbag 28
Front fog lights........................................... 65
Front seats................................................. 98
accessing the rear seat........................ 98
adjusting the head restraints.............. 104
manually operated................................ 98
power.................................................. 102
Fuel filler door
opening manually................................. 66
unlocking.............................................. 66
Fuel gauge................................................. 54
Fuel requirements.................................... 143
Fuel tank volume.....................................273Fuses, replacing......................................233
G
Gasoline requirements............................. 143
Geartronic................................................ 151
Glossary of tire terminology..................... 185
Glove compartment................................. 114
locking................................................ 133
Gross vehicle weight (GVW)............186, 271
H
Hand brake (parking brake)..................... 156
Hazard warning flashers............................ 75
HD digital radio........................................ 250
Headlights.................................................. 64
Active Bending Lights........................... 64
changing bulbs................................... 226
high and low beams............................. 67
high beam flash.................................... 67
Headlight washers..................................... 73
High beam flash......................................... 67

12 Index
12
287
High beams................................................ 67
Hoisting the vehicle.................................215
Home safe lighting............................... 67, 81
Hood, opening......................................... 217
I
Ignition switch.......................................... 146
Immobilizer.............................................. 147
Immobilizer (start inhibitor)...................... 122
Important information................................ 10
Indicator and warning symbols............ 54, 56
Inflatable Curtain........................................ 33
Inflation pressure..................................... 179
Inflation pressure, checking..................... 179
Inflation pressure table
Canadian models................................ 182
US models.......................................... 181
Information and warning symbols, table
of.............................................................. 280
Information display..............................54, 61
messages in.......................................... 61
Information symbol.................................... 56Inspection, preparing for......................... 215
Inspection readiness................................ 215
Instrument overview.................................. 52
Instrument panel.................................. 52, 54
Instrument panel lighting........................... 65
Interior lighting......................................... 111
iPodŸ connector (audio system)............. 244
ISOFIX/LATCH anchors............................. 47
J
Jack
location of........................................... 192
Jump starting........................................... 162
K
Key (ignition switch) positions................. 146
Key blade.........................................124, 129
Keyless drive
location of antennas (pacemaker warn-
ing)...................................................... 130
locking and unlocking the vehicle...... 128power seat memory............................ 129
starting the engine.............................. 149
Keylock.................................................... 147
Kickdown.................................................151
L
Label information..................................... 268
LATCH (ISOFIX) anchors........................... 47
Lighting panel............................................ 64
Load anchoring eyelets...........................118
Locking
from the inside.................................... 132
glove compartment............................. 133
Locking the vehicle.................................. 128
Long distance trips.................................. 142
Long loads, ski hatch............................... 119
Lug nuts (wheel nuts)............................... 191

12 Index
12
289
Roll-over protection system (ROPS).......... 36
S
Safety, occupant........................................ 18
Safety defects, reporting
Canada................................................. 19
USA....................................................... 18
Seat belt
reminder................................................ 22
Seat belts................................................... 20
Automatic locking retractor/Emergency
locking retractor.................................... 39
buckling................................................ 20
guides...................................................21
maintenance......................................... 22
pretensioners........................................ 20
unbuckling............................................ 20
use during pregnancy........................... 21
Seats, front................................................ 98
Shiftlock
override............................................... 152
Side door mirrors....................................... 78
Side impact airbags................................... 31
Side impact protection (SIPS) airbags....... 31Sirius satellite radio.................................. 252
Ski hatch.................................................. 119
Snow chains............................................ 189
Snow tires................................................ 189
Sound control, automatic........................247
Sound settings, audio system................. 246
Spare tire.........................................190, 192
Stability system....................................... 157
Dynamic Stability Traction Control
(DSTC)................................................ 157
Starting the engine..................................147
with keyless drive...............................149
Start inhibitor (immobilizer)..............122, 147
STC, stability system............................... 157
Steering wheel
adjusting............................................... 75
keypad................................................ 244
Storage compartments............................ 113
Studded tires........................................... 189
Subwoofer............................................... 246
Supplemental restraint system.................. 23
Symbols, overview................................... 280
T
Tachometer................................................ 54
Temporary spare tire.......................190, 192
Three-way catalytic converter................. 279
Tire inflation............................................. 179
Tire inflation pressure
Canadian models................................ 182
US models.......................................... 181
Tire Pressure Monitoring System (TPMS) 201
Tires.........................................................176
age...................................................... 176
changing..................................... 192, 199
changing from summer to winter........ 177
designations....................................... 183
glossary of terms................................ 185
improving economy............................ 176
inflation............................................... 179
inflation pressure, checking................ 179
inflation pressure table, Canadian mod-
els....................................................... 182
inflation pressure table, US models.... 181
load ratings......................................... 180
rotation............................................... 177
snow...................................................189
spare................................................... 190
spare tire (location)............................. 192
