2011 VOLKSWAGEN CC heating

WARNING
Certain medical conditions, such as paralysis and diabetes, and
certain medications can increase the risk of serious burns
when the seat heating feature is switched on.
Vehicle occupants who have a low level of perceived pain or
a lowered awareness of pain can receive serious burns to the
back, buttocks, and legs that take a long time to heal or may
never heal completely.
Never use the seat heating feature if you or your passengers
are at risk of being burned because of a medical condition.
Take regular breaks and get out of the vehicle, particularly on
long trips. Consult your doctor for advice regarding your spe-
cific condition.
Never let exposed skin remain in contact with the seat uphol-
stery when the seat heating is being used.
WARNING
A wet seat can cause the seat heating to malfunction and in-
crease the risk of serious burns.
Always make sure the seats are dry before using the seat
heating.
Never sit on the seat with wet clothes.
Never put damp or wet things including clothes on the seat.
Never spill liquids on the seats.
NOTICE
To help prevent damage to electrical and other parts in the
seat, do not kneel on the front seats or apply concentrated pres-
sure to a small area of the seat or backrest.
Liquids, sharp objects and things that do not let the heat in the
seat escape into the air, including, for example, a child restraint,
a blanket, or seat covers on the seat can damage seat heating.
If you smell an odor, immediately shut off seat heating and
have it checked by an authorized Volkswagen dealer or author-
ized Volkswagen Service Facility.

Never install leather upholstery on a vehicle with seat heating
that originally had cloth upholstery. The seat heating elements
for seats with cloth seats will overheat if the cloth upholstery is
replaced with leather upholstery.
Switch off seat heating when it is not needed to help reduce un-
necessary fuel consumption.
Ventilated seats

Fig. 56 On front seat: Switch for seat ventilation.

Push the button (1) again to turn seat ventilation off. The indicator
light in the front seat (3) goes out.
Seat heating must be switched on again if needed each time the igni-
tion is switched on.
Setting the ventilation level
Move the fan switch (2) all the way down toward the – symbol to
set the ventilation level to low.
Move the fan switch (2) to the middle position to set the ventilation
level to medium.
Move the fan switch (2) all the way up toward the + symbol to set
the ventilation level to high.
If the indicator light in the front seat (3) flashes, there is a malfunction
in the system. Have the system inspected by your authorized
Volkswagen dealer or authorized Volkswagen Service Facility.
You may hear the sound of the seat ventilation when the feature
is switched on. The sound is part of normal operation and not a cause
for concern.
Memory seats

Fig. 57 On the outer side of the driver and front passenger seats:
Memory buttons.

Wiper performance in different situations:
During automatic
wipe/wash:
While the washer system is working, the
Climatronic switches to recirculation for
about 30 seconds to help prevent the
washer fluid odor from entering the vehi-
cle interior.
During intermittent
wiping:
Speed-dependent interval control: The
higher the vehicle speed, the faster the
wipers move.

Heated washer nozzles
The heating thaws frozen washer nozzles, but not the fluid supply
hoses. When the ignition is switched on, the heat applied to the
washer nozzles is automatically regulated depending on the outside
air temperature.
Headlight washer system
The headlight washer system cleans the headlight glass.
If the ignition and the headlights (high or low beams) are switched on,
the headlights are cleaned the first time and every fifth time the front
windshield washers are activated. This happens only when the low or
high beams are on when the windshield wiper lever is pulled towards
the steering wheel. However, the headlights must still be washed by
hand periodically (for instance, during refueling) in order to get rid of
hard-to-remove dirt (like insect splatter).
To help make sure that the headlight cleaning system works during
winter weather, always keep the headlight washer nozzles free of
snow and remove any ice with a deicer spray before driving. Use a
deicer spray to remove any ice.
If there is something on the windshield, the wiper will try to wipe it
away. If it continues to block the wiper, the wiper will stop moving.
Remove the obstacle and switch the wiper on again.

WARNING
Improper use of the folding outside mirrors can cause personal
injury.
Always make sure that nobody is in the way when folding the
mirrors in or out.
Make sure that you do not get your finger caught between the
mirror and the mirror base when moving the mirrors.
WARNING
Incorrectly estimating distances with the right outside mirror
can cause collisions and serious injury.
The right outside mirror has a convex (curved) surface. This
widens your field of vision. But vehicles or other objects seen
in a convex mirror will look smaller and farther away than they
really are.
If you use the right outside mirror to judge distances from
vehicles behind you when changing lanes, you could estimate
incorrectly and cause a crash and serious injuries.
Whenever possible, use the inside mirror to more accurately
judge distance and size of vehicles or other objects seen in the
convex mirror.
Always make sure you have a clear view to the rear of the ve-
hicle.
NOTICE
Always fold in the outside mirrors when taking the vehicle
through an automatic car wash.
Never fold power mirrors in manually because doing so could
damage the electrical drive.
To reduce fuel consumption, use outside mirror heating only
when needed.
When first switched on, outside mirror heating works with maxi-
mum heat for about 2 minutes.

Secure luggage in the luggage compartment using suitable straps
and the tie downs ⇒ Tie-downs. Also see ⇒  Luggage compartment.
Adjust the headlight range, if necessary ⇒  Lights.
Check the pressure in all 4 tires when the tires are still cold. Never
reduce air pressure in warm tires to match cold tire inflation pressure.
Heed the information on the tire pressure label ⇒  Tires and wheels.
Pay especially close attention to your vehicle's Tire Pressure Moni-
toring System when driving with a heavy load ⇒ Tire Pressure Moni-
toring System (TPMS).
NOTICE
Wires in the rear windows such as for heating or for an antenna
can be damaged by objects that rub against them.
Please review the information on loading a trailer⇒ Trailer towing
and a roof rack ⇒  Roof rack.
Driving with an open luggage compartment lid

WARNING
Transporting heavy objects causes the handling characteristics
of the vehicle to change and increases braking distances.
Heavy loads which are not properly stowed or secured in the
vehicle can lead to a loss of vehicle control and cause serious
personal injury.
Transporting heavy items causes the handling characteris-
tics of the vehicle to change by shifting the vehicle's center of
gravity.
Always distribute luggage evenly and as low as possible
within the vehicle. The vehicle capacity weight figures apply
when the load is distributed evenly in the vehicle (passengers
and luggage).
Always stow luggage and heavy items in the luggage com-
partment as far forward of the rear axle as possible and secure
them with appropriate straps to the tie-downs provided.
Never exceed the vehicle's Gross Vehicle Weight Rating or
Gross Axle Weight Ratings, which are printed on the Safety
Compliance Certification Label located on the door jamb of the
driver door. Exceeding the permissible weight can cause the
vehicle to skid and behave differently.
Always adapt your speed and driving style to accommodate
your payload and its weight distribution within your vehicle.
Be especially cautious and gentle when stepping on the ac-
celerator pedal and avoid sudden braking and other maneu-
vers.
Brake earlier than you would if you were not driving a loaded
vehicle.
NOTICE
The defroster heating wires or antenna in the rear window can
be damaged by objects that rub against them.
The ventilation slots between the rear window and the shelf be-
hind the rear seat backrest must not be blocked so that stale air can
escape from the vehicle.

WARNING
Objects in the driver footwell can prevent the pedals from mov-
ing freely. This can cause loss of vehicle control and increase
the risk of serious personal injuries.
Always make sure that nothing can interfere with the pedals.
Always fasten floor mats securely to the floor.
Never put floor mats or other floor coverings on top of al-
ready installed floor mats.
Always make sure that nothing can fall into the driver
footwell while the vehicle is moving.
WARNING
Some kinds of cigarette lighters can be lit unintentionally, or
crushed causing a fire that can result in serious burns and ve-
hicle damage.
Always make sure that there are no lighters in the seat tracks
or near other moving parts before adjusting the seats.
Before closing a storage compartment, always make sure
that no cigarette lighter can be activated, crushed, or otherwise
damaged.
Never leave a cigarette lighter in a storage compartment, on
the instrument panel, or in other places in the vehicle. Heat
buildup in the passenger and luggage compartment of a parked
vehicle can result in temperatures in the vehicle that are much
higher than the outside temperatures, particularly in summer.
High temperatures could cause the cigarette lighter to catch
fire.
NOTICE
The defroster heating wires or antenna in the rear window can
be damaged by hard or sharp things on the shelf below the rear
window.
Do not keep any food, medicine, or other items sensitive to
heat or cold in the vehicle. They can be damaged or made unus-
able by heat or cold.
