2011 VOLKSWAGEN CC Low beam

mation System. If your vehicle is not equipped with the Lights & Vi-
sion menu, the convenience turn signal feature can be deactivated
by an authorized Volkswagen dealer or authorized Volkswagen Ser-
vice Facility.
WARNING
Improper use of high beams can distract and blind others,
causing accidents and serious injuries.
The turn signal light works only when the ignition is switched on.
The emergency flasher works even when the ignition is switched off
⇒  In an emergency.
The indicator light flashes twice as fast if a turn signal bulb is
burned out.
High beams can only be switched on when the low beams are on.
Switching lights on and off

Fig. 86 Headlight switch next to the steering wheel. A: Vehicles with
fog lights. B: Vehicles without fog lights.

Symbol When the ignition is
switched off
When the ignition is
switched on
/ Fog lights and low beams
switched off.
Headlights off, daytime run-
ning lights (DRL) on.
!54/ Orientation lighting may be
switched on.
Automatic headlight control
active; DRL on.
 Low beams switched off.
The DRL may stay on. The
length of time they stay on
depends on the vehicle
battery charge.
Low beams switched on.
Fog lights switched off.
The DRL may stay on for
some time.
Headlights and fog lights
switched on.

Fog lights
The indicator light in the headlight switch or the instrument cluster
shows that the fog lights are switched on.
To switch on the fog lights : first turn the light switch to
position , then pull the light switch out to the first detent.
To switch off the fog lights, push the switch back in from the first
detent. To then turn off the headlights, turn the switch to position /.
Acoustic warning when lights are not switched off
In the following situation, a warning chime will sound if you take the
key out of the ignition and open the driver door. This is to remind you
that lights are still on.
Light switch in position  if the vehicle has no orientation lighting
⇒  Coming home and Leaving home feature (orientation lighting).

WARNING
Daytime running lights are not bright enough to let you see
ahead or be seen by others when it is dark.
Always switch on the low-beam headlights at dusk or when it
is dark and whenever the weather is bad or visibility is poor.
Never use the daytime running lights to see where you are
going. They are not bright enough and will not let you see far
enough ahead for safety, especially at dusk or when it is dark.
Always switch on the low-beam headlights at dusk or when it is
dark.
The taillights do not come on with the daytime running lights.
Unless the taillights are on, a vehicle cannot be seen by others
in bad weather, at dusk, or when it is dark.
Even if automatic headlight control (!54/) is switched on, the
low-beam headlights may still not come on by themselves in
fog or heavy rain. You have to switch on the low-beam head-
lights manually.
In cool or humid weather, the insides of the headlights, the rear
lights, and turn signals can temporarily fog up. This is normal and
does not affect the service life of the vehicle's lighting system.
Lights and vision features

If the light switch is in position !54/, a low-light sensor switches the
low beams as well as the instrument and switch lighting on and off
automatically.
Daytime running lights (DRL) parking feature
Some models are equipped with a daytime running lights (DRL) park-
ing feature that switches the daytime running lights off when the vehi-
cle is parked and the ignition is switched on.

Function Action
Switching the DRL off: – Switch the ignition on.
– Turn the light switch to the /
position.
– Set the parking brake.
Switching the DRL back on: – Release the parking brake.

Static cornering lights
Your vehicle may have fog lights under the front bumper, which on
some models are also static cornering lights. On some models the
static cornering lights may be integrated in the headlights. At speeds
below about 25 mph (40 km/h), the light on one side of the vehicle will
come on automatically when you turn a corner. If you turn to the right,
the right fog light comes on; turn left and the left fog light comes on.
The light dims and goes out when the steering wheel is straightened
out again.
When you move the selector lever to Reverse (R), the static cornering
lights on both sides of the vehicle may come on so that you can see
the area around the vehicle better when backing up.
The static cornering lights work only when the headlights are on. If
you are using automatic headlight control (headlight switch in the !54/
position ⇒ fig. 86), they work only when the headlights have been
automatically switched on. The static cornering lights do not come on
when the headlight switch is in the / position or when the fog lights
themselves have been switched on ⇒ Switching lights on and off.

Automatic headlight control (!54/)
Automatic headlight control is a convenience feature only and cannot
always recognize all lighting and driving situations.
If the light switch is in the !54/ position, both vehicle lighting and in-
strument and switch lighting are automatically switched on and off in
the following situations ⇒ :

Automatic activation: Automatic deactivation:
If the low-light sensor registers
darkness, for example when driv-
ing through a tunnel.
If sufficient brightness is regis-
tered.
If the rain sensor recognizes rain
and switches the windshield wip-
ers on.
If the windshield wipers have not
moved for several minutes.

Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System works only with the low beams
switched on and only at speeds above about 6 mph (10 km/h). The
swivel-mounted lamps automatically improve road illumination during
cornering.
On vehicles equipped with the Adaptive Front Lighting System, the
feature is switched on and off via the Assistants menu in the instru-
ment cluster display ⇒ Volkswagen Information System.

WARNING
Crashes and other accidents can happen when you cannot see
the road ahead and when you cannot be seen by other motor-
ists.
Never use daytime running lights (DRL) to see where you are
going. DRL are not bright enough to light up the roadway and
be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark.
Always switch on the low-beam headlights at dusk or when it is
dark.
The taillights do not come on when the daytime running
lights are switched on. A vehicle without taillights on cannot be
seen by others in bad weather, at dusk, or when it is dark.
If automatic headlight control (!54/) is switched on, the low-
beam headlights still may not be switched on in fog or heavy
rain. You have to switch on the low-beam headlights yourself.
In cool or humid weather, the insides of the headlights, the rear
lights, and turn signals can temporarily fog up. This is normal and
does not affect the service life of the vehicle's lighting system.
“Coming home” and “Leaving home” feature (orientation
lighting)

Dynamic headlight range adjustment
In some vehicles with HID (Xenon) headlights, the headlight range is
automatically adjusted to the vehicle loading condition once the low
beams are switched on ⇒ .
WARNING
Headlights that are aimed too high because of the way the ve-
hicle is loaded can blind and distract other drivers. This can
lead to a crash and serious personal injuries.
Always make sure the headlights are adjusted to loading
conditions so that they do not blind others.
WARNING
If dynamic headlight range adjustment does not work properly
or at all, the headlights could blind and distract other drivers.
This can lead to a crash and serious personal injuries.
Have headlight range adjustment checked immediately by an
authorized Volkswagen dealer or an authorized Volkswagen
Service Facility.
Interior and reading lights

Wiper performance in different situations:
During automatic
wipe/wash:
While the washer system is working, the
Climatronic switches to recirculation for
about 30 seconds to help prevent the
washer fluid odor from entering the vehi-
cle interior.
During intermittent
wiping:
Speed-dependent interval control: The
higher the vehicle speed, the faster the
wipers move.

Heated washer nozzles
The heating thaws frozen washer nozzles, but not the fluid supply
hoses. When the ignition is switched on, the heat applied to the
washer nozzles is automatically regulated depending on the outside
air temperature.
Headlight washer system
The headlight washer system cleans the headlight glass.
If the ignition and the headlights (high or low beams) are switched on,
the headlights are cleaned the first time and every fifth time the front
windshield washers are activated. This happens only when the low or
high beams are on when the windshield wiper lever is pulled towards
the steering wheel. However, the headlights must still be washed by
hand periodically (for instance, during refueling) in order to get rid of
hard-to-remove dirt (like insect splatter).
To help make sure that the headlight cleaning system works during
winter weather, always keep the headlight washer nozzles free of
snow and remove any ice with a deicer spray before driving. Use a
deicer spray to remove any ice.
If there is something on the windshield, the wiper will try to wipe it
away. If it continues to block the wiper, the wiper will stop moving.
Remove the obstacle and switch the wiper on again.
