2011 TOYOTA MATRIX CD player

1
2
3
4
5
6
7
3
2-4. Using other driving
systems
Cruise control

...................... 141
Driving assist systems ........ 145
2-5. Driving information Cargo and luggage ............. 150
Vehicle load limits ............... 153
Winter driving tips ............... 154
Trailer towing (1.8 L 4-cylinder
[2ZR-FE] engine) .............. 158
Trailer towing (2.4 L 4-cylinder
[2AZ-FE] engine) .............. 159
Dinghy towing (automatic transmission) .................... 167
Dinghy towing (manual transmission) .................... 168
3-1.
Using the air conditioning
system a

nd defogger
Air conditioning system ....... 172
Rear window and outside rear view
mirror defoggers ............... 179
3-2. Using the audio system Audio system types ............. 180
Using the radio .................... 183
Using the CD player ............ 190
Playing MP3 and WMA discs.................................. 197
Operating an iPod ............... 206 Operating a USB
memory ............................ 213
Optimal use of the audio system .............................. 221
Using the AUX port............. 225
Using the steering wheel audio switches.................. 227
3-3. Using the Bluetooth
®
audio s

ystem
Bluetooth
® audio system .... 230
Using the Bluetooth®
audio system .................... 233
Operating a Bluetooth
®
enabled portable player.... 239
Setting up a Bluetooth
®
enabled portable player.... 241
Bluetooth
® audio system
setup ................................ 246
3-4. Using the ha
nds-free
phone system
(

for cellular phone)
Hands-free phone system (for cellular phone)
features ............................ 247
Using the hands-free phone system
(for cellular phone) ........... 252
Making a phone call ........... 262
Setting a cellular phone ...... 266
Security and system setup ................................ 271
Using the phone book ........ 275
3Interior features

82 1-7. Safety information
CAUTION
■SRS airbag precautions
●If breathing becomes difficult after the SRS airbag has deployed, open a
door or window to allow fresh air in, or leave the vehicle if it is safe to do
so. Wash off any residue as soon as possible to prevent skin irritation.
●If the areas where the SRS airbags are stored, such as the steering wheel
pad and front and rear pillar garnishes, are damaged or cracked, have
them replaced by your Toyota dealer.
■Modification and disposal of SRS airbag system components
Do not dispose of your vehicle or perform any of the following modifications
without consulting your Toyota dealer.
The SRS airbags may malfunction or deploy (inflate) accidentally, causing
death or serious injury.
●Installation, removal, disassembly and repair of the SRS airbags.
●Repairs, modifications, removal or replacement of the steering wheel,
instrument panel, dashboard, seats or seat upholstery, front, side and rear
pillars or roof side rail.
●Repairs or modifications of the front fender, front bumper, or side of the
occupant compartment.
●Installation of snow plows, winches, etc. to the front grille (bull bars, kan-
garoo bar etc.).
●Modifications to the vehicle's suspension system.
●Installation of electronic devices such as mobile two-way radios or CD
players.
●Modifications to your vehicle for a person with a physical disability.

170
3-1. Using the air conditioning system and defogger
Air conditioning system .... 172
Rear window and outside rear view
mirror defoggers ............ 179
3-2. Using the audio system Audio system types .......... 180
Using the radio ................. 183
Using the CD player ......... 190
Playing MP3 and WMA discs............................... 197
Operating an iPod ............ 206
Operating a USB memory .......................... 213
Optimal use of the audio system ........................... 221
Using the AUX port .......... 225
Using the steering wheel audio switches ............... 227 3-3. Using the Bluetooth®
audio system
Bluetooth
® audio
system ........................... 230
Using the Bluetooth
®
audio system.................. 233
Operating a Bluetooth
®
enabled portable
player ............................. 239
Setting up a Bluetooth
®
enabled portable
player ............................. 241
Bluetooth
® audio system
setup .............................. 246
Interior features3

180
3-2. Using the audio system
Audio system types
Type A: CD player and AM/FM radio (with CD changer controller)
Type B: CD player and AM/FM radio (with CD changer controller)

181 3-2. Using the audio system
3
Interior featuresLanguage settings (type B only)
The language used for all voice guidance, voice recognition and mes-
sages may be changed.
Press .
Press (MORE).
Press (LANG).
Press that corresponds to the desired language.
For vehicles sold in the U.S.A.
“ENG” (English) or “ESP” (Spanish)
For vehicles sold in Canada
“ENG” (English) or “FRAN” (French)
■Using cellular phones
Interference may be heard through the audio system's speakers if a cellular
phone is being used inside or close to the vehicle while the audio system is
operating.
TitlePage
Using the radioP. 183
Using the CD playerP. 190
Playing MP3 and WMA discsP. 197
Operating an iPodP. 206
Operating a USB memoryP. 213
Optimal use of the audio systemP. 221
Using the AUX portP. 225
Using the steering wheel audio switchesP. 227
STEP1
STEP2
STEP3
STEP4

182 3-2. Using the audio system
CAUTION
■For vehicles sold in U.S.A. and Canada
●Part 15 of the FCC Rules
FCC Warning:
Any unauthorized changes or modifications to this equipment will void the
user’s authority to operate this device.
●Laser products
• Do not take this unit apart or attempt to make any changes yourself.
This is an intricate unit that uses a laser pickup to retrieve information
from the surface of compact discs. The laser is carefully shielded so
that its rays remain inside the cabinet. Therefore, never try to disas-
semble the player or alter any of its parts since you may be exposed to
laser rays and dangerous voltages.
• This product utilizes a laser.
Use of controls or adjustments or performance of procedures other
than those specified herein may result in hazardous radiation expo-
sure.
NOTICE
■To prevent battery discharge
Do not leave the audio system on longer than necessary with the engine off.
■To avoid damaging the audio system
Take care not to spill drinks or other fluids over the audio system.

190
3-2. Using the audio system
Using the CD player
Ty p e A
Ty p e B
Vo lu m e
Random playback Selecting a trackRepeat play
Playback Power
CD eject
Displaying text
messages
Search playbackReverse
Fast-forward
Power Volume
Searching playbackCD eject
Selecting a
track/
fast-forwarding
and rewindingDisplaying text
messages Selector buttons
Playback
Playback/pauseSelecting a track

194 3-2. Using the audio system
■Display
Up to 12 characters can be displayed at a time.
If there are 13 characters or more, pressing and holding for 1 second
or more will display the remaining characters.
A maximum of 24 characters can be displayed.
If is pressed for 1 second or more again or has not been pressed for
6 seconds or more, the display will return to the first 12 characters.
Depending on the contents recorded, the characters may not be displayed
properly or may not be displayed at all.
■Error messages
“CD CHECK”: This indicates a problem either in the CD or inside the player.
The CD may be dirty, damaged or inserted up-side down.
“WAIT” or “PLEASE WAIT”: Operation has stopped due to a high tempera-
ture inside the player. Wait for a while and then
press or . Contact your Toyota
dealer if the CD still cannot be played back.
■Discs that can be used
Discs with the marks shown below can be used.
Playback may not be possible depending on the recording format or disc
features, or due to scratches, dirt or deterioration.
CDs with copy-protect features may not be used.
■CD player protection feature
To protect the internal components, playback is automatically stopped when
a problem is detected while the CD player is being used.
■If CDs are left inside the CD player or in the ejected position for
extended periods
CDs may be damaged and may not play properly.
■Lens cleaners
Do not use lens cleaners. Doing so may damage the CD player.
