2011 TOYOTA LAND CRUISER warning light

5
When trouble arises
523
5-2. Steps to take in an emergency
L/C200_U (OM60F74U)
If a warning message is displayed
Messages and warningsThe warning lights and warning buzzers operate as follows depend-
ing on the content of the message. If a message indicates the need
for inspection by a dealer, have th e vehicle inspected immediately by
your Toyota dealer.
The multi-information display shows warnings of system malfunc-
tions, incorrectly performed op erations, or shows messages that
indicate a need for maintenance. When a message is shown, perform
the correction procedure appropriate to the message.
Master warning light
The master warning light
comes on or flashes when a
message is being shown on
the multi-information display.
Multi-information display
If any of the warning messages is shown again after its correction
procedure has been performed, contact your Toyota dealer.

524 5-2. Steps to take in an emergency
L/C200_U (OM60F74U)
*: A buzzer sounds first time a message is shown on the multi-information dis-play.
System
warning lightWarning buzzer
*Warning
Comes on Sounds Indicates an important situation,
such as when a system related to
driving is malfunctioning or that
danger may result if the correction
procedure is not performed.
 Comes
on or
flashes Sounds Indicates an important situation,
such as when the system shown
on the multi-information display
may be malfunctioning.
Comes on Does not
sound Indicates a condition, such as
malfunction of electrical compo-
nents, their condition, or indicates
the need for maintenance.
Flashes Does not
sound Indicates a situation, such as
when an operation has been per-
formed incorrectly, or indicates
how to perform an operation cor-
rectly.

5
When trouble arises
525
5-2. Steps to take in an emergency
L/C200_U (OM60F74U)
■
System warning lights
The master warning light does not come on or flash in the following cases.
Instead, a separate system warning light will come on or flash along with the
message shown on the multi-information display.
● Malfunction of the brake system
The brake system warning light (red indicator) comes on. ( P. 512)
● Malfunction of the ABS
The ABS warning light comes on. ( P. 514)
● Malfunction of the charging system
The charging system warning light comes on. ( P. 513)
■ Resetting the tire pressure warning data
After adjusting the tire inflation pressure, be sure to initialize the data.
(P. 456)
If the message remains on, the system may have malfunctioned. Have the
vehicle inspected by your Toyota dealer as soon as possible.
NOTICE
■ Engine oil maintenance message
The warning message is based on the projected driving range after engine
oil maintenance message is reset.
The system does not monitor the purity of the engine oil.

598
L/C200_U (OM60F74U)
Alphabetical index
Alphabetical index
A/CAir conditioning filter ..............470
Automatic air conditioning
system ................................256
ABS ...........................................209
Active traction control ............. 209
Air conditioning filter............... 470
Air conditioning system
Air conditioning filter ..............470
Automatic air conditioning system ................................256
Airbags
Airbag operating conditions...109
Airbag precautions for your child .................................... 113
Airbag warning light............... 513
Curtain shield airbag operating conditions............109
Curtain shield airbag precautions .........................113
Front passenger occupant
classification system ...........121
General airbag precautions ...113
Locations of airbags ..............105
Modification and disposal of airbags ................................116
Proper driving posture ...103, 113
Roll sensing of curtain shield
airbags off switch ................119
Side airbag operating
conditions............................ 109
Side airbag precautions ........ 113
SRS airbags .......................... 105
Alarm ........................................... 99
Antenna.....................................280
Anti-lock brake system............209
Armrest .....................................403
Ashtrays.................................... 396
Audio input ............................... 316
Audio system Antenna .................................280 Audio input ............................ 316
AUX port ............................... 316
CD player/changer ................ 284
iPod ....................................... 299
MP3/WMA disc ..................... 292
Optimal use ........................... 314
Portable audio device ........... 316
Radio..................................... 275
Steering wheel audio
switch.................................. 317
USB memory......................... 306
Automatic air conditioning
system .................................... 256
Automatic light control system .................................... 176
Automatic transmission Automatic transmission ......... 158
If the shift lever cannot be shifted from P ..................... 542
S mode.................................. 160
AUX port ................................... 316
Back door
Back door ................................ 46
Wireless remote control key.... 39
Back-up lights
Replacing light bulbs ............. 489
Wattage................................. 567
Battery
Checking ............................... 451
If the vehicle has discharged battery ................................ 548
Preparing and checking before winter ....................... 229
Bluetooth
® audio ..................... 321
Bluetooth® phone .................... 341
Bottle holder............................. 387
Brake Fluid ...................................... 448
Parking brake ........................ 164
A
B

599
Alphabetical index
L/C200_U (OM60F74U)
Brake assist ............................. 209
Break-in tips ............................ 145
Brightness control
Instrument light control ......... 167
Care Exterior ................................. 424
Interior .................................. 427
Seat belts ............................. 428
Card holder .............................. 389
Cargo capacity ........................ 221
Cargo net hooks ...................... 406
CD player/changer .................. 284
Center differential lock/unlock switch ................ 200
Chains ...................................... 231
Child-protectors ........................ 42
Child restraint system Booster seats, definition ....... 126
Booster seats, installation .... 130
Convertible seats, definition............................. 126
Convertible seats, installation .......................... 130
Front passenger occupant classification system .......... 120
Infant seats, definition .......... 126
Infant seats, installation ........ 130
Installing CRS with LATCH system ..... .............. 131
Installing CRS with seat belts............................ 133
Installing CRS with top
tether strap ......................... 138
Child safety Airbag precautions ............... 113
Battery precautions ...... 453, 475
Child-protectors ...................... 42
Child restraint system ........... 126
How your child should wear
the seat belt ......................... 75 Installing child restraints ........130
Moon roof precautions ............92
Power window lock switch.......86
Power window precautions .....89
Removed key battery
precautions .........................473
Seat belt extender precautions ...........................78
Seat belt precautions ..............76
Seat heater precautions ........402
Cigarette lighter .......................398
Cleaning Exterior ..................................424
Interior ...................................427
Seat belts ..............................428
Clock .........................................394
Condenser ................................447
Console box .............................384
Cool box....................................390
Cooling system Engine overheating ...............551
Cruise control...........................187
Cup holder ................................386
Crawl Control ...........................205
Curtain shield airbags .............105
Customizable features.............583
Daytime running light
system ....................................177
Defogger
Rear window .........................270
Dimension.................................558
Dinghy towing ..........................252
Display Crawl Control display ............205
Intuitive parking assist display.................................191
Trip information .....................173
Shift position and shift range...................................160
Warning messages ...............523
C
D

600 Alphabetical index
L/C200_U (OM60F74U)
Do-it-yourself maintenance..... 436
Door courtesy lights Door courtesy lights ..............341
Wattage .................................567
Door lock Back door ................................46
Side door ................................. 41
Wireless remote control key .... 39
Doors
Back door ................................46
Side door ................................. 41
Side mirrors .............................83
Driver’s seat belt reminder light ......................................... 515
Driving
Break-in tips .......................... 145
Correct posture ..................... 103
Off-road precautions ............. 216
Procedures............................ 144
Winter driving tips.................. 229
Driving position memory...........62
Electronic key If your electronic key
battery is discharged...473, 545
Emergency flashers Switch.................................... 502
Emergency, in case of If a warning message is displayed............................. 523
If the electronic key does not operate properly............ 545
If the engine will not start ......540
If the shift lever cannot be
shifted from P......................542
If the vehicle has discharged
battery ................................548
If the warning buzzer sounds ................................512
If the warning light turns on ...512
If you cannot operate back door opener ........................544 If you have a flat tire ............. 526
If you lose your keys ............. 543
If you think something is
wrong .................................. 508
If your vehicle becomes stuck ................................... 554
If your vehicle has to be stopped in an emergency ... 555
If your vehicle needs to be
towed .................................. 503
If your vehicle overheats ....... 551
Engine
Compartment ........................ 440
Engine switch ........................ 154
Hood ..................................... 439
How to start the engine ......... 154
Identification number............. 559
If the engine will not start ...... 540
Ignition switch ....................... 154
Overheating .......................... 551
Engine coolant Capacity ................................ 562
Checking ............................... 446
Preparing and checking before winter ....................... 229
Engine coolan t temperature
gauge ...................................... 166
Engine immobilizer system ...... 97
Engine oil
Capacity ................................ 561
Checking ............................... 442
Preparing and checking before winter ....................... 229
Engine oil maintenance
data ......................................... 444
Engine switch........................... 154
Event data recorder ................. 510
First-aid kit holder ................... 406
Floor mats ................................ 404
E
F

604 Alphabetical index
L/C200_U (OM60F74U)
Side airbags..............................105
Side marker lightsReplacing light bulbs ............. 489
Switch.................................... 176
Wattage .................................567
Side mirror
Adjusting and folding ............... 83
Mirror position memory ...........62
Smart key system
Entry function ..........................26
Starting the engine ................154
“SOS” button............................ 415
Spare tire
Inflation pressure...................464
Storage location .................... 526
Spark plug ................................563
Specifications...........................558
Speedometer ............................ 166
Steering Column lock release..............156
Fluid ......................................450
Steering wheel
Adjustment .............................. 79
Audio switches ......................317
Steering wheel position memory ................................. 62
Stop lights Replacing light bulbs ............. 489
Storage feature.........................382
Storage precautions ................221
Stuck If your vehicle becomes stuck ...................................554
Sun visors.................................392
Sunshade
Roof......................................... 91
Switch
ECT switch ............................ 159
Driving mode select switch....159
Emergency flasher switch ..... 502
Engine switch ........................154 Fog light switch ..................... 179
Hazard light switch ................ 502
Ignition switch ....................... 154
Light switches ....................... 176
Power door lock switch ........... 41
Power window switch .............. 86
Rear window wiper and
washer switch ..................... 185
Window lock switch ................. 86
Wipers and washer
switch.......................... 180, 185
Tachometer Tachometer ........................... 166
Tail lights Switch ................................... 176
Talk switch
*............................. 346
Telephone switch
*.................. 346
Theft deterrent system Alarm....................................... 99
Engine immobilizer system ..... 97
Tire inflation pressure ............. 464
Tie-down hooks ....................... 406
Tire information Glossary ................................ 576
Size ....................................... 573
Tire identification number...... 572
Uniform tire quality grading ... 574
Tires Chains ................................... 229
Checking ............................... 455
If you have a flat tire.............. 526
Inflation pressure .................. 464
Information ............................ 571
Pressure warning system...... 455
Replacing .............................. 526
Rotating tires ......................... 455
Size ....................................... 566
Snow tires ............................. 229
Spare tire .............................. 526
Tools ......................................... 526
T

605
Alphabetical index
L/C200_U (OM60F74U)
Total load capacity .................. 228
Towing
Dinghy towing ....................... 252
Emergency towing ................ 503
Trailer towing ........................ 234
TRAC ........................................ 209
Traction control ....................... 209
Trailer towing........................... 234
Trip information display ......... 172
Trip meter................................. 166
Turn signal lights Replacing light bulbs ............ 489
Switch ................................... 163
Wattage ................................ 567
Vanity lights Vanity lights .......................... 393
Wattage ................................ 567
Vanity mirrors .......................... 393
Vehicle identification number................................... 559
Vehicle stability control .......... 209
Voice command switch
* ....... 346
VSC ........................................... 209
Warning buzzers
Brake system........................ 512
Open door ........................... 514
Seat belt reminder ................ 515
Warning lights Anti-lock brake system ......... 514
Brake system........................ 512
Charging system .... .............. 513
Low fuel level........................ 516
Malfunction indicator lamp.... 513
Master warning ..................... 516
Open door ............................ 514
Pre-collision .......................... 514 Seat belt reminder .................515
SRS airbags ..........................513
Tire pressure .........................515
Unengaged “Park” .................515
Warning messages ..................523
Warning reflector holder .........406
Washer Checking ...............................454
Preparing and checking before winter .......................229
Switch............................180, 185
Washing and waxing ...............424
Weight
Cargo capacity ......................221
Load limits .............................228
Weight ...................................558
Wheels ......................................468
Window glasses ........................86
Window lock switch ...................86
Windows Power windows .......................86
Rear window defogger ..........270
Washer ..........................180, 185
Windshield wiper de-icer.........271
Windshield wipers ...................180
Wireless remote control key Replacing the battery ............473
Wireless remote control key ....39
WMA disc ..................................292
V
W
*: Refer to the “Navigation System Owner’s Manual”.
