Page 476 of 564

476 5-2. Steps to take in an emergency
AVALON_U (OM41428U)
■If the tire pressure warning light continues to comes on after blink-
ing for 1 minute frequently
Vehicles with smart key system
If the tire pressure warning light comes on after blinking for 1 minute when
the “ENGINE START STOP” switch is turned to IGNITION ON mode, have it
checked by your Toyota dealer.
Vehicles without smart key system
If the tire pressure warning light comes on after blinking for 1 minute when
the engine switch is turned to the “ON” position, have it checked by your
Toyota dealer.
■
When the tire pressure warning light comes on
Check the tire inflation pressure and adjust to the appropriate level.
Pushing the tire pressure warning reset switch does not turn off the tire
pressure warning light.
■The tire pressure warning light may turn on due to natural causes
The tire pressure warning light may turn on due to natural causes such
as natural air leaks or tire inflation pressure changes caused by temper-
ature. In this case, adjusting the tire inflation pressure will turn off the
light (after a few minutes).
■When a tire is replaced with a spare tire
The spare tire is also equipped with the tire pressure warning valve and
transmitter. The tire pressure warning light will turn on if the tire inflation
pressure of the spare tire is low. If a tire goes flat, even though the flat
tire is replaced with the spare tire, the tire pressure warning light does
not turn off. Replace the spare tire with the repaired tire and adjust the
proper tire inflation pressure. The tire pressure warning light will turn off
after a few minutes.
Page 486 of 564

486 5-2. Steps to take in an emergency
AVALON_U (OM41428U)
CAUTION
■Using the tire jack
Improper use of the tire jack may lead to death or injuries due to the
vehicle suddenly falling off the jack.
●Do not use the tire jack for any purpose other than replacing tires or
installing and removing tire chains.
●Only use the tire jack that comes with this vehicle for replacing a flat
tire.
Do not use it on other vehicles, and do not use other tire jacks for
replacing tires on this vehicle.
●Always check that the tire jack is securely set to the jack point.
●Do not raise the vehicle while someone is in it.
●When raising the vehicle, do not put an object on or under the jack.
●Do not raise the vehicle to a height greater than that required to
replace the tire.
●Use a jack stand if it is necessary to get under the vehicle.
●Do not put any part of your body under the vehicle supported by a jack.
●Do not start or run the engine while your vehicle is supported by the
jack.
Take particular care when lowering the vehicle to ensure that no one
working on or near the vehicle may be injured.
Page 490 of 564

490 5-2. Steps to take in an emergency
AVALON_U (OM41428U)
Emergency start function (vehicles with smart key system)
When the engine does not start, the following steps can be used as
an interim measure to start the engine if the “ENGINE START STOP”
switch is functioning normally.
Set the parking brake.
Shift the shift lever to “P”.
Set the “ENGINE START STOP” switch to the ACC mode.
Push and hold the “ENGINE START STOP” switch about 15
seconds while depressing the brake pedal firmly.
Even if the engine can be started using the above steps, the system
may be malfunctioning. Have the vehicle checked by your Toyota
dealer.
■The starter motor does not turn over, the interior lights and
headlights do not turn on, or the horn does not sound
One of the following may be the cause of the problem.
●One or both of the battery terminals may be disconnected.
●The battery may be discharged. (P. 496)
●There may be a malfunction in the steering lock system (vehi-
cles with smart key system).
Contact your Toyota dealer if the problem cannot be repaired, or if
repair procedures are unknown.
Page 497 of 564
5
When trouble arises
497 5-2. Steps to take in an emergency
AVALON_U (OM41428U)
Start the engine of the second vehicle. Increase the engine
speed slightly and maintain at that level for approximately
five minutes to recharge the battery of your vehicle.
Vehicles with smart key system Open and close any of
the doors with the “ENGINE START STOP” switch OFF.
Vehicles with smart key system: Maintain the engine speed
on the second vehicle and turn the “ENGINE START
STOP” switch to IGNITION ON mode, then start the vehi-
cle’s engine.
Vehicles without smart key system: Maintain the engine
speed on the second vehicle and turn the engine switch to
the “ON” position, then start the vehicle’s engine.
Once the vehicle’s engine has started, remove the jumper
cables in the exact reverse order in which they were con-
nected.
Once the engine starts, have the vehicle checked at your Toyota
dealer as soon as possible.
Page 500 of 564
500
5-2. Steps to take in an emergency
AVALON_U (OM41428U)
If your vehicle overheats
If your engine overheats:
Stop the vehicle in a safe place and turn off the air condi-
tioning system.
Check to see if steam is coming out from under the hood.
If you see steam:
Stop the engine. Carefully lift the hood after the steam
subsides and then restart the engine.
If you do not see steam:
Leave the engine running and carefully lift the hood.
Check to see if the cooling fan is operating.
If the fan is operating:
Wait until the engine coolant temperature gauge begins
to fall and then stop the engine.
If the fan is not operating:
Stop the engine immediately and call your local Toyota
dealer.
After the engine has cooled
down sufficiently, check the
coolant level and inspect the
radiator core (radiator) for any
leaks.
If the engine compartment
cover needs to be removed.
(P. 395)
Page 501 of 564
5
When trouble arises
501 5-2. Steps to take in an emergency
AVALON_U (OM41428U)
■Overheating
In the following situations, your vehicle may be overheating.
●The engine coolant temperature gauge enters the red zone or a loss of
power is experienced.
●Steam is coming from under the hood.
Add coolant if required.
Water can be used in an emer-
gency measure if coolant is
unavailable. (P. 512)
Have the vehicle checked at your nearest Toyota dealer as soon as
possible.
Page 512 of 564
512 6-1. Specifications
AVALON_U (OM41428U)
Cooling system
Ignition system
Electrical system
Capacity8.8 qt. (8.3 L, 7.3 lmp.qt.)
Coolant typeUse either of the following:
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-
silicate, non-amine, non-nitrite, and non-borate
coolant with long-life hybrid organic acid technol-
ogy
Do not use plain water alone.
Spark plug
Make DENSO
FK20HR11
Gap 0.043 in. (1.1 mm)
NOTICE
■Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine.
Battery
Open voltage at
68 F (20 C):
12.6 12.8 V Fully charged
12.2 12.4 V Half charged
11 . 8 12.0 V Discharged
(Voltage is checked 20 minutes after the engine
and all lights are turned off.)
Charging rates 5A max.
Page 557 of 564

557 Alphabetical index
AVALON_U (OM41428U)
Emergency, in case of
If a warning light turns on ..... 467
If the electronic key does not
operate properly ................. 493
If the engine will not start...... 489
If the shift lever cannot be
shifted from P ..................... 491
If the battery is discharged .. 496
If the warning buzzer
sounds ............................... 467
If the warning light
turns on .............................. 467
If you have a flat tire ............ 479
If you lose your keys............. 492
If you think something is
wrong ................................. 463
If your vehicle becomes
stuck................................... 503
If your vehicle has to be stopped
in an emergency ................ 504
If your vehicle needs to be
towed ................................. 459
If your vehicle overheats ...... 500
Engine
Compartment........................ 394
Engine switch ............... 149, 153
Hood ..................................... 391
How to start the
engine ........................ 149, 153
Identification number ............ 509
If the engine will not start...... 489
Ignition switch ............... 149, 153
Overheating .......................... 500
Engine compartment cover .... 395
Engine coolant
Capacity ............................... 512
Checking .............................. 400
Preparing and checking
before winter ...................... 207
Engine coolant temperature
gauge ..................................... 164
Engine immobilizer system ...... 91Engine oil
Capacity ................................510
Checking ...............................396
Preparing and checking
before winter .......................207
Event data recorder .................465
Floor mats.................................356
Fluid
Brake .....................................402
Washer ..................................408
Fog lights
Switch....................................176
Wattage .................................515
Foot light...................................334
Front passenger occupant
classification system ............114
Front passenger’s seat belt
reminder light.........................470
Front seats
Adjustment ..............................54
Driving position memory..........58
Front turn signal lights
Wattage .................................515
Fuel
Capacity ................................510
Fuel gauge ............................164
Fuel pump shut off system ....464
Gas station information .........564
Information ............................516
Refueling .................................87
Fuel door.....................................87
Fuel filler door ............................87
Fuel pump shut off system .....464
Fuses.........................................432
Garage door opener.................360
Gas station information...........564
Gauges ......................................164
Glove box..................................338
F
G
