515 6-1. Specifications
6
Vehicle specifications
AVALON_U (OM41428U)
Light bulbs
A: D4S discharge bulbs
B: H11 halogen bulbs
C: HB3 halogen bulbs
D: Wedge base bulbs (amber)
E: Wedge base bulbs (clear)
F: Double end bulbs
Light BulbsBulb No.WTy p e
ExteriorHeadlights
Low beam (discharge bulbs)
Low beam (halogen bulbs)
High beamD4S
H11
HB335
55
60A
B
C
Fog lights H11 55 B
Auxiliary light W5W 5 E
Front turn signal/parking
lights3457A 28/8 D
Front side marker lights W5W 5 E
Rear turn signal lights 7440A 21 D
Stop lights 7440 21 E
Rear side marker lights W5W 5 E
Back-up lights 921 16 E
License plate lights W5W 5 E
InteriorInterior light W5W 5 E
Personal lights W5W 5 E
Vanity lights 7065 1.4 F
Glove box light 74 1.2 E
Door courtesy lights 168 5 E
Trunk light 2825 4.8 E
558 Alphabetical index
AVALON_U (OM41428U)
Hands-free system
(for cellular phone) ................296
Hazard lights
Switch.................................... 458
Head restraints ...........................62
Headlight aim ...........................441
Headlights
Discharge headlights
precautions .........................455
Switch.................................... 173
Wattage .................................515
Heaters
Seat heaters .......................... 351
Side mirror............................. 225
Hood .......................................... 391
Hooks
Cargo .................................... 358
Shopping bag ........................358
Horn...........................................163
I/M test....................................... 386
Ignition switch .................. 149, 153
Identification
Engine ...................................509
Vehicle .................................. 509
Illuminated entry system .........334
Indicator lights .........................167
Initialization
Items to initialize.................... 536
Inside rear view mirror ..............75
Instrument panel light
control .................................... 166
Interior lights
Interior lights.......................... 334
Switch.................................... 336
Wattage .................................515Jack
Positioning a floor jack .......... 392
Vehicle-equipped jack ........... 479
Jack handle .............................. 479
Keyless entry ............................. 38
Keys
Electronic key.......................... 24
Engine switch ................ 149, 153
If the electronic key does not
properly............................... 493
If you lose your keys ............. 492
Key number plate .................... 25
Keyless entry .......................... 38
Keys ........................................ 24
Mechanical key ....................... 24
Wireless remote control key.... 38
Licence plate lights
Replacing light bulbs ............. 443
Wattage................................. 515
Light bulbs
Replacing .............................. 443
Wattage................................. 515
Lights
Emergency flasher switch ..... 458
Fog light switch ..................... 176
Hazard light switch ................ 458
Headlights switch .................. 173
Interior lights list .................... 334
Outer foot light ...................... 334
Personal light switch ............. 336
Replacing light bulbs ............. 443
Turn signal lever ................... 161
Vanity lights........................... 346
Wattage................................. 515
Load capacity ........................... 205
Lock steering column...... 151, 154H
I
J
K
L
