2011 TOYOTA AVALON key

5
When trouble arises
493
5-2. Steps to take in an emergency
AVALON_U (OM41428U)
If the electronic key does not operate properly (with smart key system)
Locking and unlocking the doors key linked functions
Using the mechanical key
(P. 24) in order to perform the
following operations:
Locks all doors
Unlocks the door
Turning the key rearward unlocks
the driver’s door. Turning the key
once again unlocks the other
doors.
If communication between the electronic key and vehicle is inter-
rupted (P. 30) or the electronic key cannot be used because the
battery is depleted, the smart key system and wireless remote con-
trol cannot be used. In such cases, the doors can be opened or the
engine can be started by following the procedure below.

494 5-2. Steps to take in an emergency
AVALON_U (OM41428U)
Changing “ENGINE START STOP” switch modes and starting the
engine
Put the shift lever in “P” and apply the brakes.
Touch the Toyota emblem side of
the electronic key to the
“ENGINE START STOP” switch.
An alarm will sound to indicate
that the start function cannot
detect the electronic key that is
touched to the “ENGINE START
STOP” switch if any of the doors
is opened and closed while the
key is touched to the switch.
To change the “ENGINE START STOP” switch modes: Within
5 seconds of the buzzer sounding, release the brake pedal
and press the “ENGINE START STOP” switch. Modes can be
changed each time the switch is pressed. (P. 149)
To start the engine: Press the “ENGINE START STOP” switch
within 5 seconds after the buzzer sounds, keeping the brake
pedal depressed.
If the “ENGINE START STOP” switch still cannot be operated, con-
tact your Toyota dealer.

5
When trouble arises
495 5-2. Steps to take in an emergency
AVALON_U (OM41428U)
■Stopping the engine
Shift the shift lever to “P” and press the “ENGINE START STOP” switch as
you normally do when stopping the engine.
■Replacing the key battery
As the above procedure is the temporary measure, it is recommended that
the electronic key battery be replaced immediately when the battery
depletes. (P. 428)

5
When trouble arises
497 5-2. Steps to take in an emergency
AVALON_U (OM41428U)
Start the engine of the second vehicle. Increase the engine
speed slightly and maintain at that level for approximately
five minutes to recharge the battery of your vehicle.
Vehicles with smart key system  Open and close any of
the doors with the “ENGINE START STOP” switch OFF.
Vehicles with smart key system: Maintain the engine speed
on the second vehicle and turn the “ENGINE START
STOP” switch to IGNITION ON mode, then start the vehi-
cle’s engine.
Vehicles without smart key system: Maintain the engine
speed on the second vehicle and turn the engine switch to
the “ON” position, then start the vehicle’s engine.
Once the vehicle’s engine has started, remove the jumper
cables in the exact reverse order in which they were con-
nected.
Once the engine starts, have the vehicle checked at your Toyota
dealer as soon as possible.

504
5-2. Steps to take in an emergency
AVALON_U (OM41428U)
If your vehicle has to be stopped in an emergency
Only in an emergency, such as if it becomes impossible to stop the
vehicle in the normal way, stop the vehicle using the following pro-
cedure:
Steadily step on the brake pedal with both feet and firmly
depress it.
Do not pump the brake pedal repeatedly as this will increase the
effort required to slow the vehicle.
Shift the shift lever to N.
If the shift lever is shifted to N
After slowing down, stop the vehicle in a safe place by the
road.
Stop the engine.
If the shift lever cannot be shifted to N
Keep depressing the brake pedal with both feet to reduce
vehicle speed as much as possible.
Vehicles without a smart key
system: Stop the engine by
turning the engine switch to
the “ACC” position.

5
When trouble arises
505 5-2. Steps to take in an emergency
AVALON_U (OM41428U)
CAUTION
■If the engine has to be turned off while driving
●Power assist for the brakes and steering wheel will be lost, making the
brake pedal harder to depress and the steering wheel heavier to turn.
Decelerate as much as possible before turning off the engine.
●Vehicles without a smart key system: Never attempt to remove the key, as
doing so will lock the steering wheel.
Vehicles with a smart key sys-
tem: To stop the engine, press
and hold the “ENGINE START
STOP” switch for 3 consecu-
tive seconds or more, or press
it briefly for 3 times or more in
succession.
Stop the vehicle in a safe place by the road.
Press and hold for 3 seconds or more
or press briefly for 3 times or more

532
AVALON_U (OM41428U)
6-2. Customization
Customizable features
ItemFunctionDefault settingCustomized
setting
Smart key
system
(P. 26)Smart key system ON OFF
Operation signal
(Emergency flashers)ON OFF
Operation signal
(Buzzer)ON OFF
Wireless
remote
control
(P. 38)Unlocking operationDriver’s door
unlocked in 1-
step, all doors
unlocked
in 2-stepAll doors
unlocked
in 1-step
Time elapsed before
automatic door lock
function is activated if
door is not opened after
being unlocked60 secondsOFF
30 seconds
120 seconds
Your vehicle includes a variety of electronic features that can be per-
sonalized to your preferences. Programming these preferences
requires specialized equipment and may be performed by your
Toyota dealer.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.

534 6-2. Customization
AVALON_U (OM41428U)
*: Vehicles sold outside Canada
ItemFunctionDefault settingCustomized
setting
Door lock
(
P. 43)Unlocking using a keyDriver’s door
unlocked in 1-
step, all doors
unlocked
in 2-stepAll doors
unlocked
in 1-step
Speed-detecting auto-
matic door lock functionOFF ON
Opening driver’s door
unlocks all doors OFF ON
Shift the shift lever to
“P” unlocks all doorsON OFF
Shift the shift lever to
position other than “P”
locks all doorsON OFF
Automatic
light control
system
(P. 173)Light sensor sensitivity Level 3 Levels 1 to 5
Time elapsed before
headlights automati-
cally turn off after doors
are closed60 seconds0 seconds
30 seconds
90 seconds
Daytime running light ON OFF
*
